MinimumRC P-51 Mustang User manual

P-51 Mustang
Assembly Instructions
Important Instructions
1.The model is supplied with UFO and 502 glue. UFO is for bonding foam parts, and 502 for
bonding wood, carbon fiber and metal parts. 502 glue will cause serious corrosion to foam parts.
2.Please wait for the glue to dry and solidify in each installation step before the next installation.
3.Please avoid using flame to heat the heat shrinkable tube on the model. Electric iron shall be
used for heating.
4.Please use razor blade to remove the parts from the plate. Do not tear the parts by force.

1. Fuselage wooden frame parts.
2. Assemble the fuselage wooden frame.
3. Continue assembling the wooden frame and install the motor.

4. Overlap and install two servo wooden spacers. (Bottom view of the parts)
5. Install the servo as shown. (Top view of the parts)
6. Install the servo as shown. (Bottom view of the parts)

7. Connect the receiver to the servos, secure the receiver with Velcro, power it on, and
bind it to the transmitter to ensure that the servo arms return to their neutral positions.
Test if the servos are functioning correctly and install the servos and arms as shown in
the diagram. Note: This step is crucial; make sure the servos are powered, the arms are
centered, and follow the diagram precisely. Adjustments cannot be made after the
model is assembled.
8. Remove the fuselage from the foam board.

9. Use a sharp tool (screwdriver) to score through the marked lines on the bottom of the fuselage.
10. Magnets and its supporting structures.
11. Install the magnet.

12. Install the assembled magnet-supporting structure onto the wooden frame at the
corresponding location.
13. Use glue to secure the wooden frame and attach the fuselage to one sides of the
wooden frame, with the side marked with lines facing inward.
14. PS foam parts.

15. Press the fuselage inward along the score lines and use glue to install the bulkhead.
16. Use glue to secure the cockpit foam board.
17. Use glue to secure the front fuselage top plate and nose filler plate.

18. Use glue to secure the fuselage bottom plate, do not apply glue to the red-lined
section.
19.
20. Combine the fuselage.

21. Remove the propeller and apply the fuselage stickers.
22. The front bottom plate of the fuselage can be opened forward as a battery
compartment cover.
23. Install magnets at the circular hole position of the battery compartment cover.

24. Seal the mounting holes with sticker.
25. Install the tailwheel in the corresponding slot on the bottom of the aircraft.
26. Apply stickers to the aircraft tailwheel.

27. Cut off the excess parts of the canopy cover vacuum-formed part as shown in the
diagram.
28. Trim to the finished size.
29. Install the canopy onto the fuselage at the corresponding location.

30. Apply stickers to the canopy.
31. Install the propeller and spinner, using a small amount of glue to secure the spinner.
32. Use a sharp tool (screwdriver) to score through the marked lines on the bottom of
the horizontal stabilizer, allowing the elevator to move freely along the lines on both
sides.

33. Use a sharp tool (screwdriver) to score through the marked lines on the bottom of
the vertical stabilizer, allowing the rudder to move freely along the lines on both sides.
34. Install the vertical stabilizer reinforcement.
35. Attach the vertical stabilizer to the horizontal stabilizer.

36. Attach the horizontal stabilizer to the corresponding location on the fuselage,
ensuring that the horizontal stabilizer is parallel to the wing spar.
37. Use stickers to conceal the vertical stabilizer reinforcement.
38.

39. Use a sharp tool (screwdriver) to score along the wing's marked line, allowing the
wing to fold downward along the center longitudinal line to form the airfoil.
40. Use a sharp tool (screwdriver) to score along the aileron's marked line, allowing the
aileron to move up and down along the line.
41. Paste carbon fiber rods at the bottom of the wing to increase wing strength.

42. Install the wings.
43. The landing gear on both sides is designed to be mirror symmetric. Synchronize the
mirror symmetric assembly of both landing gears to avoid confusion.
44. Assemble both landing gears.

45. Install the landing gear at the corresponding position on the wing.
46. Install the landing gear cover plate reinforcement and bend the landing gear wire to
be parallel.
47. Observe from the front; the landing gear wire should be vertical to the ground.

48. Install the landing gear rigid reinforcement structure at the corresponding location.
49. Axle sleeves, hubs, and tires.
50. Assemble the axle sleeve and hub, securing with glue.

51. Assemble the hub and tire, securing with glue.
52. Apply stickers to the hub.
53. Install the wheels and bend the landing gear wire at the tail end to prevent the
wheels from falling off. Alternatively, slide heat shrink tubing over the wire end, heat -
shrink it, and apply a small amount of glue to prevent the wheels from falling off.

54. Install the landing gear cover plate.
55. Install the aileron control horns.
56. Install the horizontal stabilizer control horns.
