Minka Group minkaAire CONCEPT IV Guide

INSTRUCTION MANUAL WARRANTY CERTIFICATE
CONCEPT IV 54”
BY

©2020 Minka Lighting Inc. Manual design and all elements of manual design are protected by United States Federal and/or State Law including
Patents, Trademark, and/or Copyright Laws.

The Minka-Aire® warranty is for one (1) year from the date of purchase from an authorized Minka-Aire® dealer.
This warranty is only valid to the original purchaser or user against all defects in material and workmanship (light bulbs
excluded) for one (1) full year. Additionally, Minka-Aire® warrants the motor only for the lifetime of the Minka Aire ceiling
fan (excluding wall controls and electrical components), to the original purchaser or user.
* The warranty is voided with the use of any non- Minka-Aire®electrical devices, E.g., wall controls or electrical dimmer switches, etc…
* The warranty is void once the original purchaser or user ceases to own the fan or the fan is moved from its original point of installation.
* The warranty is void with the use of any hanger bracket (non-Minka Aire or non-fan specific) other than the hanger bracket supplied & installed
with this specific fan.

Date Purchased Store Purchased Model Number Serial Number
F465L
Warranty Service Information
To obtain warranty service during the warranty period, the purchaser should return the fan with the sales receipt to the original place of
purchase. The authorized Minka-Aire® dealer, at its sole discretion, will either repair or replace the fan after verifying the legitimacy of the warranty
claim. Replacement is subject to availability of the same model. If the model is unavailable it will be replaced by one of equal value. This is a limited
warranty; the original purchaser or user is responsible for the cost of removal and reinstallation of repaired or replacement product.
To obtain the name of the Minka-Aire® authorized dealer nearest you call the Minka-Aire® customer care department at 1-800-307-3267,
or contact Minka-Aire® through www.minkagroup.net and select FAQ to answer any questions or if you require additional assistance submit the
question form found there.

SAFETY RULES....................................................................................
PACKAGE CONTENTS.....................................................................
INSTALLING THE FAN.....................................................................
HANGING THE FAN.........................................................................
ELECTRICAL CONNECTIONS.......................................................
FINISHING THE INSTALLATION................................................
BLADE INSTALLATION...................................................................
INSTALLING THE MOUNTING PLATE.....................................
CONTENTS
INSTALLING THE LED LIGHT KIT......................................................
INSTALLING THE GLASS SHADE ..................................................
OPERATING THE REMOTE CONTROL..........................................
ENJOY YOUR SMART CEILING FAN...............................................
CARE OF YOUR FAN..............................................................................
TROUBLESHOOTING............................................................................
SPECIFICATIONS.....................................................................................
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1151 W. Bradford Court, Corona, CA 92882 For Customer Assistance Call: 1-800-307-3267

SAFETY RULES
1
1. Before you begin installing the fan, shut power off at the circuit breaker of the fuse box.
2. Be cautious! Read all instructions and safety information before installing your new fan. Review accompanying assembly diagrams.
3. Make sure that all electrical connections comply with local codes, ordinances, or National Electrical Codes. Hire a qualified electrician or consult a
do-it-yourself wiring handbook if you are unfamiliar with installing electrical wiring.
4. Make sure the installation site you choose allows the fan blades to rotate without any obstructions. Allow a minimum clearance of 7 feet from the
floor and 18 inches from the tip of the blades to the wall.
5. If you are mounting the fan to a ceiling fan outlet box, use a U.L. Listed metal octagonal outlet box marked "Acceptable for Fan Support". Secure the
box directly to the building structure. The outlet box and its support must be able to support the moving weight of the fan (at least 50 pounds) Do
not use a plastic box.
6. CAUTION:
CAUTION:
To reduce the risk of injury use only the screws provided with the outlet box in conjunction with the lock washers provided with the fan.
7. If you are mounting the fan to a joist, make sure it is able to support the moving weight of the fan (at least 50 pounds).
8. After you install the fan, make sure that all mounting components are secured to prevent the fan from falling.
9. Do not insert anything into the fan blades while the fan is operating.
10. Turn the fan off and wait for the blades to stop completely before performing any maintenance or cleaning.
SUITABLE FOR USE IN
WET LOCATIONS

WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR OTHER PERSONAL INJURY, MOUNT FAN ONLY TO A U.L. LISTED OUTLET BOX OR SUPPORTING SYSTEM MARKED
ACCEPTABLE FOR FAN SUPPORT AND USE MOUNTING SCREWS PROVIDED WITH THE OUTLET BOX IN CONJUCTION WITH THE LOCK WASHERS PROVIDED WITH THE
FAN. MOST OUTLET BOXES COMMONLY USED FOR FAN SUPPORT OF LIGHTING FIXTURES ARE NOT ACCEPTABLE FOR FAN SUPPORT AND NEED TO BE REPLACED.
CONSULT A QUALIFIED ELECTRICIAN IF IN DOUBT.
TO REDUCE THE RISK OF PERSONAL INJURY, DO NOT BEND THE BLADE HOLDERS WHILE INSTALLING, BALANCING THE BLADES OR CLEANING THE FAN. DO NOT
INSERT FOREIGN OBJECTS BETWEEN ROTATING FAN BLADES.
TO REDUCE THE RISK OF FIRE OR ELECTRONIC SHOCK, THIS FAN CAN ONLY USE AL158-RM351F170001 SOLID-STATE SPEED CONTROL WITH
RC1000 REMOTE CONTROL ONLY
NOTE
NOTE
: The important safeguards and instructions appearing in this manual are not meant to cover all possible conditions and situations that may
occur. It must be understood that common sense, caution and care are factors which can not be built into this product. These factors must be
supplied by the person (s) installing, caring for and operating the unit.
NOTE:
NOTE:
READ AND SAVE ALL INSTRUCTIONS!

2
PACKAGE CONTENTS
Unpack your fan and check the contents. You should have the following items:
B
C
1. Fan blades (3)
2. Hanger bracket
3. Canopy
4. Canopy cover
5. Downrod rubber cover
6. Standard downrod assembly
7. Coupling cover
8. Fan motor/housing assembly
9. Mounting plate
10. 30W LED light kit
1 1. Glass shade
12.Receiver
13. Remote control with holder and 2
mounting screws
14. 1.5V AAA battery (2)
15. Balancing kit
A. Mounting hardware:
#8 x 3/4" Machine screws (2)
#10 x 1.5" Wood screws (2)
Starwashers (2)
Lock washers (2)
Wire nuts (3)
Washers (2)
B. Blade removal tool
C. Extension cords 18" x 1set & 24"
x 2sets
A
7
8
9
2
3
14
5
6
10
12
11
13
14
15
1
2
34
5
6

3
Tools Required: Phillips screw driver; slotted screw driver; step-ladder; wire cutters; electrical tape.
INSTALLING THE FAN
MOUNTING OPTIONS
If there isn't an existing mounting box, then read the following instructions. Disconnect the
power by removing fuses or turning off circuit breakers.
Secure the outlet box directly to the building structure. Use appropriate fasteners and building
materials. The outlet box and its support must be able to fully support the moving weight of
the fan (at least 50 lbs.). Use a UL Listed metal outlet box. Do not use a plastic outlet box.
Figure 1, 2 and 3 are examples of different ways to mount the outlet box.
NOTE:
NOTE:
You may need a longer downrod to maintain proper blade clearance when installing on a
steep, sloped ceiling. Longer downrods are available from your Minka-Aire® dealer.
To hang your fan where there is an existing fixture but no ceiling joist, you may need to install
a hanger bar as shown in Fig. 4 (available at your Minka-Aire® dealer).
FIG. 1
FIG. 3
FIG. 2
FIG. 4
CROSS BRACE
CEILING
JOIST
CEILING
jOIST
CEILING
JOIST
OUTLET BOX
PARALLEL WOOD BRACE
(MIN. 2" THICK)
OUTLET
BOX
OUTLET BOX
CEILING JOIST OR
CROSS BRACE
ANGLED CEILING
MAXIMUM 20 ANGLE PROVIDE
STRONG
SUPPORT
RECESSED
OUTLET BOX
HANGER
OPENING
must be
FACING
UPSIDE
HANGER BAR
(OPTIONAL)
HANGER
BRACKET

4
WARNING:
WARNING:
All of the parts, hardware and components such as the
hanger bracket and hanger ball have been provided for your safety and the
proper installation of your new ceiling fan. The use of other parts,
hardware or components not supplied by Minka Aire®with the fan will
void the Minka Aire®Warranty.
REMEMBER
REMEMBER
to turn off the power. Follow the steps below to hang your
fan properly:
Step 1. Secure the hanger bracket to the ceiling outlet box using the screws
provided with your outlet box in conjunction with the lock-washers
provided with the fan. (Fig. 5)
Step 2. Loosen the two set screws and remove the hitch pin and lock pin
from the coupling located on the top of the motor assembly. (Fig. 6)
Step 3. Remove the hanger ball from the downrod assembly by loosening
the set screw and removing the cross pin. (Fig. 7)
Step 4. Carefully feed fan wires up through the downrod. (Fig. 8) Thread
downrod into the coupling until the holes are lined up and secure with
the lock pin and hitch pin previously removed, tighten set screws. (Fig. 9)
NOTE:
NOTE:
This fan comes with a 6” downrod. In addition you have been
provided with a wire harness which you can attached to the fans wiring
should you need to use a longer downrod. Please refer the owner's
manual included with the extension cord packge.
Step 5.Slip coupling cover, canopy cover and canopy onto downrod.
Carefully reinstall the hanger ball onto the downrod being sure that it's
properly positioned over the cross pin and the wires are not twisted,
tighten set screw. Place downrod rubber cover onto the hanger ball (Fig. 9)
Step 6. Lift the motor assembly and place the hanger ball into the
hanger bracket. rotate the motor assembly as needed until the check
groove from the hanger ball rests firmly over the registration tab from
the hanger bracket. Motor assembly should not rotate if this is done
correctly. (Fig. 10)
HANGING THE FAN

DOWNROD
Fig. 7 Fig. 8Fig. 6 Fig. 10
REGISTRATION
SLOT
CROSS PIN
HANGER
BALL
DOWNROD
HITCH
PIN LOCK
PIN
SET SCREWS
SET SCREW
Fig. 9
DOWNROD
CANOPY
CANOPY COVER
SET SCREWS
HITCH PIN
LOCK PIN
COUPLING COVER
OUTLET BOX
HANGER BRACKET
Fig. 5
SUPPLY
WIRES
DOWNROD
RUBBER COVER

5
ELECTRICAL CONNECTIONS
ON
12345
ON
12345
ON
12345
ON
12345
FREQUENCY
Fig. 11
WARNING
WARNING:
To avoid possible electrical shock be sure electricity is turned off at the
main fuse or breaker box before wiring.
NOTE:
NOTE:
The Aire Control®System is equipped with a learning frequency function which
has 1024 code combinations to prevent potential interference from other remote units.
The frequency on your Receiver and Transmitter units have been preset at the factory.
(Fig. 11) No frequency change is necessary, should you desire to install another fan
within the same home or area with a seperate frequency code please see the "frequency
interference" troubleshooting section of this instruction manual to learn how to change
the frequency.

Step 1. Insert Receiver into Hanger Bracket with the flat side of the Receiver facing the ceiling. (Fig. 12)
Step 2. Motor to Receiver Electrical Connections: Be sure to snap together the 2-PIN, 4-PIN connectors and sansor wire connector from the receiver
and fan. (Fig. 13)
Step 3. Receiver to House Supply Wires Electrical Connections: Connect the WHITE wire (Neutral) from the outlet box to the WHITE wire marked "AC
in N" from the receiver. Connect the BLACK wire (Hot) from the outlet box to the BLACK wire marked "AC in L" from the receiver. Secure all wire
connections with the plastic wire nuts provided. (Fig. 13)
Step 4. If your outlet box has a GROUND wire (Green or Bare Copper) connect this wire to the Hanger Ball and Hanger Bracket Ground wires. If your
outlet box does not have a Ground Wire, then connect the Hanger Ball and Hanger Bracket Ground Wires together. Secure wire connection with the
plastic wire nut provided. (Fig. 13)
After all splices are made, check to make sure there are no loose strands. As an additional precaution we suggest to secure the plastic wire
connectors to the wires with electrical tape.
NOTE:
NOTE:
Fan must be installed from a maximum distance of 40 feet from the transmitting unit for proper signal transmission between the
transmitting unit and the fan's receiving unit.

Fig. 12
RECEIVER
HANGER BRACKET
Fig. 13
GREEN OR BARE
COPPER (GROUND)
GREEN
(HANGER
BRACKET)
GREEN
(RECEIVER)
GREEN
(HANGER BALL)
OUTLET BOX
RECEIVER
WH
BLK WH
BLK
CONNECTORS

6
FINISHING THE INSTALLATION
Step 1. Remove 1 of the 2 screws from the bottom of the hanger bracket and loosen the other
one half a turn from the screw head.
Step 2. Slide the canopy up towards the hanger bracket and place the key hole on the canopy
over the screw on the hanger bracket, turn canopy until it locks in place at the narrow section of
the key holes. (Fig. 14)
Step 3. Align the circular hole on canopy with the remaining hole on the hanger bracket, secure
by tightening the two set screws.
NOTE:
NOTE:
Adjust the canopy screws as necessary until the canopy are snug.
Fig. 14
CANOPY
CANOPY COVER
OUTLET BOX
HANGER
BRACKET
HANGER
BALL

7
THE FOLLOWING OPERATION MUST BE ACCOMPLISHED BEFORE INSTALLING THE GLASS SHADE.
Step 1. Insert the blades into the motor housing blade slots, push blade until it stops. You should be
able to hear the inside safety pin drops into the blade hole to secure the blade in place. (Fig. 15)
CAUTION:
CAUTION:
Re-check each blade to make sure all blades are secured to the motor by holding the blade
from the tip and gently pulling it outwards. The blades should be snug to the motor housing
without any up, down or sideways play.
All blade sets are grouped by weight. Because plastic injection varies in density, the fan may wobble
even though the blades are weight matched.
BLADE REMOVAL
BLADE REMOVAL
In the event that the blades need to be removed, use the blade removal tool included with your fan.
Remove the rubber plug first, then remove the blades by pulling the safety pin via the opening
above the blade in the motor housing as shown and replace the rubber plug. (Fig. 16)
BLADE INSTALLATION
Fig 15
BLADE

Fig 16
BLADE
SAFETY PIN SAFETY PIN
RUBBER PLUG

MOUNTING
PLATE
MOUNTING
RING
SCREWS
8
Fig. 17
The fan motor assembly is shipped with motor support plate to prevent movement during
transportation. Remove the motor support plate from the mounting ring and discard.
Step 1. Remove 1 of 3 screws from the mounting ring and loosen the other 2 screws. (Do
not remove)
Step 2. Place the key holes from the mounting plate over the 2 screws previously loosened
from the mounting ring, turn mounting plate until it locks in place at the narrow section of
the key holes. Secure by tightening the 2 screws previously loosened and the one
previously removed. (Fig. 17)
INSTALLING THE MOUNTING PLATE
MOTOR
SUPPORT
PLATE

MOUNTING PLATE
CONNECTORS
SCREWS
LED
LIGHT KIT
Fig 18
INSTALLING THE LED LIGHT KIT
NOTE:
NOTE:
Before starting installation, make sure power is turned off at the circuit breaker.
CAUTION:
CAUTION:
The light source is designed for this specific application and can overheat if serviced by
untrained personnel. If any servicing is required, the product should be returned to an authorized
service facility for examination or repair.
Step 1. Remove 1 of the 3 screws from the mounting plate and keep it for future use. Loosen the
other 2 screws. (Do not remove)
Step 2. While holding the LED light kit under the fan motor assembly, make the 2-pin wire
connections: (Fig. 18)
- White to white - Blue to blue
Step 3. Place the key holes from the LED light kit over the 2 screws previously loosened from the
mounting plate, turn light kit until it locks in place at the narrow section of the key holes. Secure by
tightening the 2 screws previously loosened and the one previously removed. (Fig. 18)
9

GLASS
SHADE
10
Raise glass shade up against bottom of light kit and secure it to the fan by turning the glass
shade assembly clockwise until snug. DO NOT OVERTIGHTEN. (Fig. 19)
CAUTION:
CAUTION:
Before starting installation, make sure power is turned off at the circuit breaker.
INSTALLING THE GLASS SHADE
Fig. 19
