MINN KOTA RIPTIDE MAXXUM User manual

RIPTIDE® MAXXUM®
BOW-MOUNT TROLLING MOTOR
USER MANUAL
BowGuard 360° ®
Latch & Door

WARRANTY ON MINN KOTA SALTWATER TROLLING MOTORS
Johnson Outdoors Marine Electronics, Inc. (“JOME”) extends the following limited warranty to the original retail purchaser only. Warranty coverage is not
transferable.
MINN KOTA LIMITED TWO-YEAR WARRANTY ON THE ENTIRE PRODUCT
JOME warrants to the original retail purchaser only that the purchaser’s new Minn Kota saltwater trolling motor will be materially free from defects in materials
and workmanship appearing within two (2) years after the date of purchase. JOME will (at its option) either repair or replace, free of charge, any parts found by
JOME to be defective during the term of this warranty. Such repair, or replacement shall be the sole and exclusive liability of JOME and the sole and exclusive
remedy of the purchaser for breach of this warranty.
MINN KOTA LIMITED LIFETIME WARRANTY ON COMPOSITE SHAFT
JOME warrants to the original retail purchaser only that the composite shaft of the purchaser’s Minn Kota trolling motor will be materially free from defects in
materials and workmanship appearing within the original purchaser’s lifetime. JOME will provide a new composite shaft, free of charge, to replace any composite
shaft found by JOME to be defective during the term of this warranty. Providing a new composite shaft shall be the sole and exclusive liability of JOME and the
sole and exclusive remedy of the purchaser for breach of this warranty; and purchaser shall be responsible for installing, or for the cost of labor to
install, any new composite shaft provided by JOME.
EXCLUSIONS & LIMITATIONS
This limited warranty does not apply to products that have been used commercially or for rental purposes. This limited warranty does not cover normal wear
and tear, blemishes that do not affect the operation of the product, or damage caused by accidents, abuse, alteration, modification, shipping damages, acts
of God, negligence of the user or misuse, improper or insufficient care or maintenance. DAMAGE CAUSED BY THE USE OF OTHER REPLACEMENT
PARTS NOT MEETING THE DESIGN SPECIFICATIONS OF THE ORIGINAL PARTS WILL NOT BE COVERED BY THIS LIMITED WARRANTY.
The cost of normal maintenance or replacement parts which are not in breach of the limited warranty are the responsibility of the purchaser. Prior to using
products, the purchaser shall determine the suitability of the products for the intended use and assumes all related risk and liability. Any assistance JOME
provides to or procures for the purchaser outside the terms, limitations or exclusions of this limited warranty will not constitute a waiver of the terms, limitations
or exclusions, nor will such assistance extend or revive the warranty. JOME will not reimburse the purchaser for any expenses incurred by the purchaser
in repairing, correcting or replacing any defective products or parts, except those incurred with JOME’s prior written permission. JOME’S AGGREGATE
LIABILITY WITH RESPECT TO COVERED PRODUCTS IS LIMITED TO AN AMOUNT EQUAL TO THE PURCHASER’S ORIGINAL PURCHASE
PRICE PAID FOR SUCH PRODUCT.
MINN KOTA SERVICE INFORMATION
To obtain warranty service in the U.S., the product believed to be defective, and proof of original purchase (including the date of purchase), must be presented
to a Minn Kota Authorized Service Center or to Minn Kota’s factory service center in Mankato, MN. Any charges incurred for service calls, transportation or
shipping/freight to/from the Minn Kota Authorized Service Center or factory, labor to haul out, remove, re-install or re-rig products removed for warranty service,
or any other similar items are the sole and exclusive responsibility of the purchaser. Products purchased outside of the U.S. must be returned prepaid with
proof of purchase (including the date of purchase and serial number) to any Authorized Minn Kota Service Center in the country of purchase. Warranty service
can be arranged by contacting a Minn Kota Authorized Service Center or by contacting the factory at 1-800-227-6433 or email [e-mail].
Products repaired or replaced will be warranted for the remainder of the original warranty period [or for 90 days from the date of repair
or replacement, whichever is longer]. For any product that is returned for warranty service that JOME finds to be not covered by or not
in breach of this limited warranty, there will be a billing for services rendered at the prevailing posted labor rate and for a minimum of at
least one hour.
NOTE: Do not return your Minn Kota product to your retailer. Your retailer is not authorized to repair or replace products.
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THESE LIMITED WARRANTIES. IN NO EVENT SHALL ANY IMPLIED
WARRANTIES INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR PARTICULAR PURPOSE, EXTEND
BEYOND THE DURATION OF THE RELEVANT EXPRESS LIMITED WARRANTY. IN NO EVENT SHALL JOME BE LIABLE FOR PUNITIVE,
INDIRECT, INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES. Without limiting the foregoing, JOME assumes no responsibility for
loss of use of product, loss of time, inconvenience or other damage.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above
limitations and/or exclusions may not apply to you. This warranty gives you specific legal rights and you may also have other legal rights which vary from state
to state.
FEATURES
Specifications subject to change without notice.
This diagram is for reference only and may differ from your actual motor.
BowGuard 360° ®
Breakaway Protection
(On Applicable Models)
Battery Meter
Lifetime Warranty
Flexible Composite Shaft
Propeller
Cool Quiet
Power Motor
Depth Collar Knob
Tilt/Extend Tiller Controls: On/Off, Speed,
Forward/Reverse and Direction
Steering Tension Knob

MOUNT INSTALLATION
TOOLS AND RESOURCES REQUIRED:
• (2) 1/2” Wrenches
• Standard or Needle Nose Pliers
• A second person to help with the installation
INSTALLATION OF MOTOR TO MOUNT
1. With mount closed as shown below, use two 1/2” wrenches to remove one of the two nylock nuts and washers from the
upper pin and remove pin from mount.
NOTE: The two bushings in the upper arm may come out. If so, keep them for re-assembly.
2. Using a pair of pliers, remove the spring clip on freshwater models (or the E-clip on saltwater models) from the lower pin and
remove lower pin from mount.
Upper Arm
Lower Aluminum Bracket/Arm
Upper Pin with
Nut and Washer
Bow Guard
Lower Pin
Lower Pin
Upper Pin with
Nut and Washer
Bushing
Spring Clip
Lower Aluminum Bracket/Arm
Upper Pin with
Nut and Washer
Bow Guard
Lower Pin
Upper Arm

MOUNT INSTALLATION
3. Open upper arm, rotate and lay over out of the way for lower arm assembly.
4. Align the lower arm and the lower bow guard ears and insert lower pin.
5. Re-install spring clip into lower pin for freshwater models or (E-clip for saltwater motors).
6. Route rope underneath lower pin and through eyelet in bowguard.
7. Rotate upper arm back over to bowguard.
8. Align the upper arm holes with upper bow guard ears and install upper pin.
NOTE: The two bushings in the upper arm may come out. Re-assemble them into the upper arm making sure the “keys” of
the inserts are aligned with the “key” punchouts in upper arm.
9. Re-install washer and locknut and tighten.
10. Route rope through pull grip handle and small washer.
Secure by tying a figure eight knot.
Rope Eyelet
Spring Clip
(freshwater models only)
Lower Pin
E-Ring Clip
(saltwater models only)
Bushing
Upper Pin with
Nut & Washer
Figure 8 Knot
Washer
Pull Grip

MOUNT INSTALLATION
INSTALLATION OF THE BOW-MOUNT
We recommend that you have another person help with this procedure.
1. For installation, DO NOT REMOVE THE SHAFT/MOTOR FROM THE BOWGUARD. The Bowguard spring is
under tension and must always remain secured. Latch and Door models can be removed from the mount if needed.
2. Place the mount, with the motor in the fully stowed (flat) position, on the deck of the
boat:
• The motor should be mounted as close to the centerline of the boat as possible
when it is deployed (see illustration).
• Make sure bow area under the chosen location is clear and unobstructed for
drilling.
• Make sure the motor rest is positioned far enough beyond the edge of the
boat. The motor, as it is lowered into the water or raised into the boat, must not
encounter any obstructions
3. Once in position, determine which bolt pattern to use (see below), mark at least 4
of the holes (2 on each side) in the bow plate and drill through with a 9/32” drill bit.
Either pattern may be used when installing the motor.
- Pattern 1: Minn Kota 3” bolt pattern standard motors.
- Pattern 2: Alternate 4” bolt pattern commonly used.
4. Install hold down strap between the motor and deck of boat between second and third set of mounting holes.
5. Mount the plate to the bow through the drilled holes using the provided (1/4-20 x 3-1/2”) bolts, nuts and washers.
NOTE: If possible, secure all sets of mounting bolts, nuts and washers.
6. Install the bow mount stabilizer (if included). See next section for installation instructions.
Hold Down Strap 1
2

MOUNT INSTALLATION
INSTALLING THE BOWMOUNT STABILIZER KIT
Tools Needed:
• Hand Saw
• 3/8” Nut Driver
• File or Sandpaper
1. Place the motor in the stowed position.
2. Measure from the screw hole in the upper arm to the boat deck or gunwale. Add
3/4” to the total to get the correct support shaft length (image 1).
3. Trim the bottom of the support shaft with a hand saw to the correct length. Round
the cut edge with a file or sandpaper. Attach the rubber bumper.
4. Secure the support shaft to the bowmount with the 1/4” hex head screw with a
lock washer on top and one on bottom of the bowmount arm (image 2).
5. Verify that the motor locks into the stowed position when retracted. The stabilizer should support the bowmount to prevent
bouncing yet not interfere with the locking system (image 3). Adjust the stabilizer length as needed.
INSTALLATION OF THE HOLD DOWN STRAP
(Not included on all models)
1. Before mounting the trolling motor place the Hold Down Strap under the bowmount
between the mounting holes near the back of the motor rest with the hook and loop
side of the strap facing down (image 4).
2. Secure the bowmount with the mounting bolts to capture the strap.
3. To stow the motor, pull the strap through the rectangular ring until snug. Press the hook
pad of the strap, into the loop pad and secure (image 5). This should be used whenever
the motor is stowed.
Image 1
Image 2
Image 3
Image 4
Image 5

BOAT RIGGING & PRODUCT INSTALLATION
For safety and compliance reasons, we recommend that you follow American Boat and Yacht Council (ABYC) standards when
rigging your boat. Altering boat wiring should be completed by a qualified marine technician. The following specifications are for
general guidelines only:
CAUTION: These guidelines apply to general rigging to support your Minn Kota motor. Powering multiple motors or additional
electrical devices from the same power circuit may impact the recommended conductor gauge and circuit breaker size. If you are
using wire longer than that provided with your unit, follow the conductor gauge and circuit breaker sizing table below. If your wire
extension length is more than 25 feet, we recommend that you contact a qualified marine technician.
An over-current protection device (circuit breaker or fuse) must be used. Coast Guard requirements dictate that
each ungrounded current-carrying conductor must be protected by a manually reset, trip-free circuit breaker or fuse. The type
(voltage and current rating) of the fuse or circuit breaker must be sized accordingly to the trolling motor used. The table below gives
recommended guidelines for circuit breaker sizing.
Reference:
United States Code of Federal Regulations: 33 CFR 183 – Boats and Associated Equipment
ABYC E-11: AC and DC Electrical Systems on Boats
CONDUCTOR GAUGE AND CIRCUIT BREAKER SIZING TABLE
Motor Thrust /
Model Max Amp Draw Circuit Breaker Wire Extension Length *
5 feet 10 feet 15 feet 20 feet 25 feet
30 lb. 30 50 Amp @ 12 VDC 10 AWG 10 AWG 8 AWG 6 AWG 4 AWG
40 lb., 45 lb. 42 10 AWG 8 AWG 6 AWG 4 AWG 4 AWG
50 lb., 55 lb. 50 60 Amp @ 12 VDC 8 AWG 6 AWG 4 AWG 4 AWG 2 AWG
70 lb. 42 50 Amp @ 24 VDC 10 AWG 10 AWG 8 AWG 8 AWG 6 AWG
80 lb. 56 60 Amp @ 24 VDC 8 AWG 8 AWG 8 AWG 6 AWG 6 AWG
101 lb. 46 50 Amp @ 36 VDC 8 AWG 8 AWG 8 AWG 8 AWG 8 AWG
Engine Mount 101 50 60 Amp @ 36 VDC 8 AWG 6 AWG 4 AWG 4 AWG 2 AWG
112 lb. 52 60 Amp @ 36 VDC 8 AWG 8 AWG 8 AWG 8 AWG 8 AWG
Engine Mount 160 116 (2) x 60 Amp @ 24 VDC 2 AWG 2 AWG 2 AWG 2 AWG 2 AWG
E-Drive 40 50 Amp @ 48 VDC 10 AWG 10 AWG 10 AWG 10 AWG 10 AWG
This conductor and circuit breaker sizing table is only valid for the following assumptions:
1. No more than 3 conductors are bundled together inside of a sheath or conduit outside of engine spaces.
2. Each conductor has 105° C temp rated insulation.
3. No more than 5% voltage drop allowed at full motor power based on published product power requirements.
*Wire Extension Length refers to the distance from the batteries to the trolling motor leads.
PUSH-TO-TEST BATTERY METER
This motor is equipped with a “push-to-test” battery meter. The LED light provides an accurate
display of the remaining charge in the battery. It is only accurate when the motor is off.
The meter reads as:
• One light indicates recharge.
• Two lights indicate low charge.
• Three lights indicate good charge.
• Four lights indicate full charge.
Testwith
Motor Off
BATTERY WIRING & INSTALLATION

SELECTING THE CORRECT BATTERIES
The motor will operate with any lead acid, deep cycle marine 12 volt battery/batteries. For best results, use a deep cycle, marine
battery with at least a 105 ampere hour rating. Maintain battery at full charge. Proper care will ensure having battery power
when you need it, and will significantly improve the battery life. Failure to recharge lead-acid batteries (within 12-24 hours) is the
leading cause of premature battery failure. Use a multi-stage charger to avoid overcharging. We offer a wide selection of chargers
to fit your charging needs. If you are using a crank battery to start a gasoline outboard, we recommend that you use a separate
deep cycle marine battery/batteries for your Minn Kota trolling motor.
Advice Regarding Batteries:
• Never connect the (+) and the (–) terminals of the same battery together. Take care that no metal object can fall onto the
battery and short the terminals. This would immediately lead to a short and extreme fire danger.
• It is highly recommended that a circuit breaker or fuse be used with this trolling motor. Refer to “Conductor Gauge and Circuit
Breaker Sizing Table” in the previous section to find the appropriate circuit breaker or fuse for your motor. For motors requiring
a 60-amp breaker, the Minn Kota MKR-19 60-amp circuit breaker is recommended.
CONNECTING THE BATTERIES IN SERIES (IF REQUIRED FOR YOUR MOTOR)
24 VOLT SYSTEMS:
1. Make sure that the motor is switched off (speed selector on “0”).
2. Two 12 volt batteries are required.
3. The batteries must be wired in series, only as directed in wiring
diagram, to provide 24 volts.
a. Connect a connector cable to the positive ( + ) terminal of
battery 1 and to the negative ( – ) terminal of battery 2.
b. Connect positive ( + ) red motor lead to
positive ( + ) terminal on battery 2.
c. Connect negative ( – ) black motor lead to
negative ( – ) terminal of battery 1.
4. For safety reasons do not switch the motor on until the propeller is in the water. If installing a leadwire plug, observe proper
polarity and follow instructions in your boat owner’s manual. See wiring diagram on following pages.
CAUTION
• For safety reasons, disconnect the motor from the battery or batteries when the motor is not in use or while
the battery/batteries are being charged.
• Improper wiring of 24/36 volt systems could cause battery explosion!
• Keep leadwire wing nut connections tight and solid to battery terminals.
• Locate battery in a ventilated compartment.
To trolling motor negative
24 Volt Series Connection
Battery #1 (Low Side)
Neg - Neg -Pos + Pos +
Battery #2 (High Side)
+24 Volts to trolling motor
positive (or circuit breaker)
Two 12-volt batteries connected in series for 24 volts
CONNECTING THE BATTERIES
12 VOLT SYSTEMS:
1. Make sure that the motor is switched off (speed selector on “OFF” or “0”).
2. Connect positive ( + ) red lead to positive ( + ) battery terminal.
3. Connect negative ( – ) black lead to negative ( – ) battery terminal.
4. For safety reasons do not switch the motor on until the propeller is in the water.
CAUTION:
For safety reasons, disconnect the motor from the battery/batteries when the motor is not in use or while the
battery/batteries are being charged.
BATTERY WIRING & INSTALLATION

MOTOR WIRING DIAGRAM
VARIABLE SPEED CONTROL BOARD
NOTE: This is a universal, multi-voltage diagram. Double-check your motor's voltage for proper connections. Over-Current
Protection Devices not shown in this illustration.
12v
24v
36v
BLACK M-
RED M+
RED B+
MOTOR
SPEED
ADJUSTMENT
SWITCH
BATTERY GAUGE
RED
12V BATT 1
12V BATT 1 12V BATT 2
12V BATT 1 12V BATT 2 12V BATT 3
BLACK
BLACK B-

MOTOR WIRING GUIDE
FIVE-SPEED SWITCH
RED+
WHITE
YELLOW
BLACK-
RED B+ BLACK B-
Battery 1
MOTOR
BATTERY METER
RED
WHITE
YELLOW
BAT+
BAT-
BLACK
24v
12v
Battery 1 Battery 2
NOTE: This is a universal, multi-voltage diagram. Double-check your motor's voltage for proper connections. Over-Current
Protection Devices not shown in this illustration.

STOWING AND DEPLOYING THE MOTOR
WARNING:
When raising or lowering the motor, keep fingers clear of all hinge and pivot points and all moving parts.
MOUNT FEATURES
• The motor mount is designed to fold back and lock the motor flat on the deck when not in use and to
provide secure stowage for transport.
• The pull grip and rope releases the lock bar, which automatically engages when the unit is lowered or
raised into position. The pull grip and rope should be used to both lower and raise the unit.
• The motor rest positions the lower unit as it comes in contact with the nose of the mount and guides
it onto the motor rest.
• The yoke captures the motor shaft and keeps the lower unit centered on the motor rest.
• The hold-down strap must be used to place pressure on the motor shaft to hold the lower unit
tightly against the motor rest when stowed.
• The pull grip and rope can be stored by placing the pull grip into the rope stow slot on the control box of the motor.
TO DEPLOY THE MOTOR
Simply pull back and lift the motor off of the mount with the pull grip and rope. Lower the motor into the water using the pull grip
and rope. The motor will lock into the deployed position automatically.
TO STOW THE MOTOR
Pull back and lift the motor out of the water with the pull grip and rope. Lower the motor lower unit onto the motor rest using the
pull grip and rope. The motor will lock into the stowed position automatically. Wrap the hold-down strap over top of the motor
shaft to secure the motor.
Lower Unit
Motor Shaft
Motor Rest
Hold Down Strap
Pull Grip and Rope
USING AND ADJUSTING THE MOTOR

ADJUSTING THE DEPTH OF THE MOTOR
When setting the depth be sure the top of the motor is submerged at least 12” to
avoid churning or agitation of surface water. The propeller must be completely
submerged.
1. Firmly grasp the motor shaft and hold it steady.
2. Loosen steering tension knob.
3. Open the lever arm to loosen the Quick Release Depth Collar.
4. Vertically adjust the height of the motor to the desired position.
5. Bring the depth collar to the top of the steering tension knob, and close the
lever arm to lock the depth collar into position.
6. Tighten the steering tension knob to achieve the desired steering resistance.
NOTE: The tension of the quick release depth collar can be adjusted with a screw
driver to obtain the proper feel.
• Never operate your motor when it is out of the water.
• Over-tightening the clamp screws can damage the bracket.
ADJUSTING THE STEERING
• Adjust the steering tension knob to provide enough tension to allow the motor to turn freely, yet remain in any position without
being held
OR
• Tighten the knob to place the motor in a preset position to leave your hands free for fishing.
Quick Release
Depth Collar
Steering Tension
Vertical Stow Knob
12” Minimum
Depth
Lever Arm
ADJUSTING THE DEPTH OF THE MOTOR
When setting the depth be sure the top of the motor is submerged at least 12” to
avoid churning or agitation of surface water. The propeller must be completely
submerged.
1. Firmly grasp the motor shaft and hold it steady.
2. Loosen steering tension knob.
3. Open the lever arm to loosen the Quick Release Depth Collar.
4. Vertically adjust the height of the motor to the desired position.
5. Bring the depth collar to the top of the steering tension knob, and close the
lever arm to lock the depth collar into position.
6. Tighten the steering tension knob to achieve the desired steering resistance.
NOTE: The tension of the quick release depth collar can be adjusted with a screw
driver to obtain the proper feel.
CAUTION:
• Never operate your motor when it is out of the water.
• Over-tightening the clamp screws can damage the bracket.
ADJUSTING THE STEERING
•
Adjust the steering tension knob to provide enough tension to allow the motor to turn freely, yet remain in any position without
being held
OR
• Tighten the knob to place the motor in a preset position to leave your hands free for fishing.
Quick Release
Depth Collar
Steering Tension
Vertical Stow Knob
12” Minimum
Depth
Lever Arm
Depth Adjustment Knob
Outer Shaft
12” Minimum
Depth
LATCH & DOOR MODELS
1. Firmly grasp the outer shaft or control head and hold it steady.
2. Open the lever arm to loosen the Quick Release Depth Collar.
3. Loosen depth adjustment knob on the hinge cover until the shaft
slides freely.
4. Raise or lower the motor to the desired depth.
5. Turn the motor control head to the desired position.
6. Bring the depth collar to the top of the steering tension knob, and
close the lever arm to lock the depth collar into position
7. Tighten depth setting knob to secure the motor in place.
Depth Collar Knob
Hinged Cover Knob
12” Minimum
Depth
Outer Shaft
Bow-Guard 360° Models
Latch & Door Models
USING & ADJUSTING THE MOTOR

ADJUSTING THE TILT/EXTEND TILLER
Your trolling motor features 7 usable handle tilt positions: 45°, 30°, and 15° up and
down from the 0° (horizontal) position. To use the down positions, you must first press
the release button located on the left underside of the pivot handle.
Your trolling motor handle also features a unique stow
position, that is useful for limiting the amount of space
required for storage or travel.
Important: BEFORE attempting to put the
handle in the stowed position, the speed selector
must be in the OFF/STOW position . Failure to do
so will damage the internal mechanism.
First press the release button located on the left underside of the pivot handle,
then push the handle down until you feel the handle “lock in” to the stowed
position. This will be almost parallel to the motor shaft.
To extend the handle, pull the handle towards you to the desired position.
The handle will extend a full 6 inches. To retract, push the handle in until it
meets the face of the motor control head.
Handle Controls:
Off/On, Steering, and
Forward/Reverse
Release Button
CONTROLLING SPEED & STEERING WITH THE TILLER
This motor offers variable forward and reverse speeds. The speed control may be operated in either
direction, forward or reverse. Turn the tiller handle counterclockwise from (OFF) to increase reverse
speed and clockwise from (OFF) to increase forward speed. Speed decreases as you approach (OFF)
from either direction.
Forward
Reverse
USING & ADJUSTING THE MOTOR

Propeller
Drive Pin
Anode/Nut
Washer
PROPELLER REPLACEMENT
TOOLS AND RESOURCES REQUIRED:
• Box End Wrench
- 1/2” for motors with 70 lbs thrust or lower.
- 9/16” for motors with 80 lbs thrust or higher.
• Screwdriver (optional)
CAUTION:
Disconnect the motor from the battery before
beginning any prop work or maintenance.
NOTE: The propeller on your motor may differ from
the one pictured.
1. Disconnect motor from battery prior to changing the propeller.
2. Hold the propeller and loosen the anode/nut with a wrench.
3. Remove anode/nut and washer. If the drive pin is sheared/broken, you will need to hold the shaft steady with a screwdriver
blade pressed into the slot on the end of the shaft.
4. Turn the old prop to horizontal (as illustrated) and pull it straight off. If drive pin falls out, push it back in.
5. Align new propeller with drive pin.
6. Install prop washer and anode/nut.
7. Tighten anode/ nut 1/4 turn past snug. [25-35 inch lbs.] Be careful, over tightening can damage prop.
GENERAL MAINTENANCE
• After every use, the entire motor should be rinsed with freshwater, then wiped down with a cloth dampened with an aqueous
based silicone spray. Do not spray water into the ventilation openings in the head of the motor.
• The composite shaft requires periodic cleaning and lubrication for proper retraction and deployment. A coating of an aqueous
based silicone spray will improve operation.
• The propeller must be inspected and cleaned of weeds and fishing line after every use. Fishing line and weeds can get behind
the prop, damage the seals and allow water to enter the motor.
• Verify the prop nut is secure each time the motor is used.
• To prevent accidental damage during transportation or storage, disconnect the battery whenever the motor is off of the water.
For prolonged storage, lightly coat all metal parts with an aqueous based silicone spray.
• For maximum battery life, recharge the battery(s) as soon as possible after use. For maximum motor performance, restore
battery to full charge prior to use.
• Keep battery terminals clean with fine sandpaper or emery cloth (flooded lead acid only).
• The propeller is designed to provide optimum operation with very high efficiency. To maintain this top performance, the
leading edge of the blades must be kept smooth. If they are rough or nicked from use, restore to smooth by sanding with fine
sandpaper.
SERVICE & MAINTENANCE

1. Motor fails to run or lacks power:
• Check battery connections for proper polarity.
• Make sure terminals are clean and corrosion free. Use fine sandpaper or emery cloth to clean terminals.
• Check battery water level. Add water if needed.
2. Motor loses power after a short running time:
• Check battery charge. If low, restore to full charge.
3. Motor is difficult to steer:
• Loosen the steering tension knob on the bracket
• Lubricate the composite shaft.
4. You experience prop vibration during normal operation:
• Remove and rotate the prop 180°. See removal instructions in the Propeller Replacement section.
5. Experiencing interference with your fishfinder:
TROUBLESHOOTING & REPAIR

1. Motor fails to run or lacks power:
• Check battery connections for proper polarity.
• Make sure terminals are clean and corrosion free. Use fine sandpaper or emery cloth to clean terminals.
• Check battery water level. Add water if needed.
2. Motor loses power after a short running time:
• Check battery charge. If low, restore to full charge.
3. Motor is difficult to steer:
• Loosen the steering tension knob on the bracket
• Lubricate the composite shaft.
4. You experience prop vibration during normal operation:
• Remove and rotate the prop 180°. See removal instructions in the Propeller Replacement section.
5. Experiencing interference with your fishfinder:
• You may, in some applications, experience interference in your depth finder display. We recommend that you use a seperate
deep cycle marine battery for your trolling motor and that you power the depth finder from the starting/cranking battery. If
problems still persist, call our service department at 1-800-227-6433.
NOTE: For all other malfunctions, visit an Authorized Service Center. You can search for an Authorized Service Center in your
area by visiting our Authorized Service Center page, found online at minnkotamotors.com, or by calling our customer service
number, 800-227-6433.
FOR FURTHER TROUBLESHOOTING AND REPAIR
We offer several options to help you troubleshoot and/or repair your product. Please read through the options listed below.
FREQUENTLY ASKED QUESTIONS
We have FAQs available on our website to help answer all of your Minn Kota questions. Visit minnkotamotors.com and click on
“Frequently Asked Questions” to find an answer to your question.
CALL US (FOR U.S. AND CANADA)
Our consumer service representatives are available Monday – Friday between 7:00 a.m. – 4:30 p.m. CST at 800-227-6433.
If you are calling to order parts, please have the 11-character serial number from your product, specific part numbers, and credit
card information available. This will help expedite your call and allow us to provide you with the best consumer service possible.
You can reference the parts list located in your manual to identify the specific part numbers.
EMAIL US
You can email our consumer service department with questions regarding your Minn Kota products. To email your question, visit
minnkotamotors.com and click on “Support”.
AUTHORIZED SERVICE CENTERS
Minn Kota has over 300 authorized service centers in the United States and Canada where you can purchase parts or get your
products repaired. Please visit our Authorized Service Center page on our website to locate a service center in your area.
ENVIRONMENTAL COMPLIANCE STATEMENT:
It is the intention of JOME to be a responsible corporate citizen, operating in compliance with known and applicable
environmental regulations, and a good neighbor in the communities where we make or sell our products.
WEEE DIRECTIVE:
EU Directive 2002/96/EC “Waste of Electrical and Electronic Equipment Directive (WEEE)” impacts most distributors, sellers,
and manufacturers of consumer electronics in the European Union. The WEEE Directive requires the producer of consumer
electronics to take responsibility for the management of waste from their products to achieve environmentally responsible
disposal during the product life cycle.
WEEE compliance may not be required in your location for electrical & electronic equipment (EEE), nor may it be required
for EEE designed and intended as fixed or temporary installation in transportation vehicles such as
automobiles, aircraft, and boats. In some European Union member states, these vehicles are considered
outside of the scope of the Directive, and EEE for those applications can be considered excluded from the
WEEE Directive requirement.
This symbol (WEEE wheelie bin) on product indicates the product must not be disposed of with other
household refuse. It must be disposed of and collected for recycling and recovery of waste EEE. Johnson
Outdoors Inc. will mark all EEE products in accordance with the WEEE Directive. It is our goal to comply
in the collection, treatment, recovery, and environmentally sound disposal of those products; however, these requirement do
vary within European Union member states. For more information about where you should dispose of your waste equipment for
recycling and recovery and/or your European Union member state requirements, please contact your dealer or distributor from
which your product was purchased.
DISPOSAL:
Minn Kota motors are not subject to the disposal regulations EAG-VO (electric devices directive) that implements the WEEE
directive. Nevertheless never dispose of your Minn Kota motor in a garbage bin but at the proper place of collection of your local
town council.
Never dispose of battery in a garbage bin. Comply with the disposal directions of the manufacturer or his representative and
dispose of them at the proper place of collection of your local town council.
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects
or other reproductive harm.
COMPLIANCE STATEMENTS

Rev K 10/15
This page provides Minn Kota® WEEE compliance disassembly instructions.
For more information about where you should dispose of your waste equipment
for recycling and recovery and/or your European Union member state require-
ments, please contact your dealer or distributor from which your product was
purchased.
Tools required, but not limited to: flat head screw driver,
Phillips screw driver, socket set, pliers, wire cutters.
RIPTIDE MAXXUM 55/SC LATCH & DOOR
55 LBS THRUST - 12 VOLT - 42”/52” SHAFT
286
570
575
580
590
585
586
275
295
290
270
310
135
136
425
280
285
300
5
10
85
15
100
35
40
80
90
1010
75
50
55
60
1
70
20
95
30
45
25
1000
1015
1020
65
200
205
212
210
400
395
265
530
555
595
700
235
230
410
220
260
390
360
365
370 375
380
385
505
500
515
545
610
510
520
525
535
540
560
600
605
702
900
565
615
620
550
240
250
415
625
701
703
405
208
PARTS DIAGRAM

RIPTIDE MAXXUM 55/SC LATCH & DOOR
55 LBS THRUST - 12 VOLT - 42”/52” SHAFT
ITEM QTY PART
NUMBER DESCRIPTION
1 1 2097097 12V MOTOR SW
5 1 2-100-121 ARMATURE ASSEMBLY
10 1140-010 BEARING
15 1788-015 RETAINING RING
20 12-200-301 CENTER HOUSING ASSEMBY
25 12-300-337 BRUSH END HOUSING ASSEMBLY
30 12-400-337 PLAIN END HOUSING ASSEMBLY
35 1144-049 FLANGE BEARING
40 1880-003 SEAL
45 1880-006 SEAL WITH SHIELD
50 2188-036 BRUSH
55 1725-050 PAPER TUBE
60 1738-036 BRUSH PLATE ASSEMBLY
65 2975-040 BRUSH SPRING
70 1337-036 GASKET
75 1701-081 O-RING, MOTOR
80 2701-008 O-RING, THRU-BOLT
85 2830-007 SCREW, 8-32
90 2830-042 THRU-BOLT
95 2990-067 WASHER, STEEL
100 2990-070 WASHER, NYLATRON
135 1640-008 LEADWIRE, BLACK
136 1640-107 LEADWIRE, RED
n2888460 SEAL AND O-RING KIT
200 12195656 DECAL, C-BOX COVER
205 12060296 C-BOX COVER
208 22325666 DECAL - MINNKOTA
210 12074080 BATTERY METER, 12V SW
212 12070304 WIRE, BATTERY METER BLK
12070305 WIRE, BATTERY METER RED
220 12064028 SWITCH 5 SPEED
230 12062506 CONTROL BOX, 5 SPD, SW
235 12062905 STRAIN RELIEF
240 62303412 SCREW, #6 X 5/8 SS
250 12033403 SCREW, #10-24 X 2 SS
260 12383124 NUT, 10-24, NYLOCK, SS
265 12991521 CAM LOCK/DEPTH COLLAR ASSY
n12991808 HINGE & DOOR ASSEMBLY [270-300]
270 12151532 HINGE SLEEVE
275 12991782 HINGE BASE ASSEMBLY
280 22232315 EYELET SS
285 12264706 INSERT, HINGE BASE
286 42236001 BUSHING, NYLINER
290 12262642 PIN, HINGE DOOR
295 12260902 KNOB, DOOR
300 12261859 HINGE DOOR
310 12002013 TUBE COMPOSITE 42”
12002014 TUBE COMPOSITE 52”
n12990956 HANDLE ASSY, 5SPD [360-410]
360 12990451 GRIP/HANDLE ASSY, 5SPD [360-375]
365 22060015 BEARING, HANDLE
ITEM QTY PART
NUMBER DESCRIPTION
370 12063405 SCREW, #6 PFH SS
375 12884091 YOKE / SPIDER ASSY, 5SPD
380 12302742 SPRING, DETENT, OFF
385 22060005 BEARING, HANDLE PIVOT
390 12060900 HANDLE PIVOT, TOP
395 12302745 SPRING, RELEASE BUTTON
400 12063700 BUTTON, RELEASE
405 12060905 HANDLE PIVOT, BOTTOM
410 62303412 SCREW, #6 X 5/8 SS
415 12062715 SPRING, HANDLE PIVOT
425 12992523 LEADWIRE ASSY SC
n12991845 MOUNT, BOW ASSY W/ BOWGUARD (500-625)
500 12251601 ROPE
505 12150400 PULL GRIP
510 12151700 WASHER
515 12264244 ARM, UPPER, STD, SW
520 12262604 PIN, BOWGUARD, UPPER
525 22261722 WASHER, 1/4”, ZP
530 22223100 NUT, 5/16-18 SS
535 22263500 BOLT, SHOULDER
540 22293501 BUSHING, SS
545 12994351 ARM, LOWER, STD, SW
550 12262622 PIN, CLEVIS ZP
555 12263011 E-CLIP
560 22267318 BUSHING, NYLINER
565 22261708 WASHER, SPACER, .010 THK
570 12153603 EYESHAFT
575 12262703 SPRING STOP
580 12152701 SPRING, LOCK BAR
585 12233621 LOCK BAR, FRONT
586 12233623 LOCK BAR, BACK
590 22152612 SPRING PIN
595 12773983 BOWPLATE W/ INSERT, STD, SW
600 12260505 HINGE PIN, ZP
605 12293811 YOKE, MAX
610 12263917 MOTOR REST, STD, SW
615 62261505 SPACER, MOTOR REST
620 22263434 SCREW, #8, SS
625 22065677 DECAL, MOTOR REST
n12994830 BAG ASSEMBLY
700 62263431 SCREW, 1/4-20 X 3 1/2” PPH, SS
701 62301720 WASHER, RUBBER MOUNTING
702 62261713 WASHER, 1/4 SS
703 62263101 NUT, 1/4-20 NYLOCK, SS
900 12263804 STRAP, HOLD DOWN
n1378131 PROPELLER KIT WW2
n2994875 PROPELLER BAG ASSY
1000 12091160 PROPELLER WW2
1010 12092600 DRIVE PIN, SMALL
1015 12151726 WASHER, PROP, SMALL
1020 12198400 NUT, NYLOCK, PROP, ANODE
nTHIS ITEM IS PART OF AN ASSEMBLY.
*THIS ITEM IS PART OF A KIT AND ONLY LISTED FOR VIEWING PURPOSES.
PARTS LIST

• 60-Amp Circuit Breaker
• Mounting Brackets
• Stabilizer Kits
• Extension Handles
• Battery Connectors
• Battery Boxes
• Quick Connect Plugs
RECOMMENDED ACCESSORIES
ON-BOARD & PORTABLE BATTERY CHARGERS
Stop buying new batteries and start taking care of the ones you’ve got. Many chargers can actually damage your battery
over time – creating shorter run times and shorter overall life. Digitally controlled Minn Kota chargers are designed to provide the
fastest charge that protect and extend battery life.
TALON SHALLOW WATER ANCHOR
Talon deploys faster, holds stronger and runs quieter than any other shallow water anchor. Available in depths up to 12’ and bold color
options including camo, it boasts an arsenal of features and innovations that no other anchor can touch:
MINN KOTA ACCESSORIES
We offer a wide variety of trolling motor accessories, including:
MK210DMK345PC MK110P
• Vertical, Multi-Stage Deployment
• User-Selectable Anchoring Modes
• 2x Anchoring Force
• Fast Deploy
• Auto Up/Down
• Triple Debris Shields
• Built-In Wave Absorption
• Noise Dissipation
• Versatile Adjustments
