MINN KOTA TRAXXIS User manual

TRAXXIS
TRANSOM-MOUNT TROLLING MOTOR
USER MANUAL

Model:_________________________________________________________________________________________________________________________
Serial Number: _______________________________________________________________________________________________________________
Purchase Date: _______________________________________________________________________________________________________________
Store Where Purchased: ____________________________________________________________________________________________________
NOTE: Do not return your Minn Kota motor to your retailer. Your retailer is not authorized to repair or replace this unit. You may obtain service
by: calling Minn Kota at [phone]; returning your motor to the Minn Kota Factory Service Center; sending or taking your motor to any
Minn Kota authorized service center. A list of authorized service centers is available on our website, at minnkotamotors.com. Please include proof of
purchase, serial number and purchase date for warranty service with any of the above options.
Please thoroughly read this user manual. Follow all instructions and heed all safety and cautionary notices below. Use of this motor is only
permitted for persons that have read and understood these user instructions. Minors may use this motor only under adult supervision.
ATTENTION: Never run the motor out of the water, as this may result in injuries from the rotating propeller. The motor should be disconnected from
the power source when it is not in use or is off the water. When connecting the power-supply cables of the motor to the battery, ensure that they are
not kinked or subject to chafe and route them in such a way that persons cannot trip over them. Before using the motor make sure that the insulation
of the power cables is not damaged. Disregarding these safety precautions may result in electric shorts of battery(s) and/or motor. Always disconnect
motor from battery(s) before cleaning or checking the propeller. Avoid submerging the complete motor as water may enter the lower unit through
control head and shaft. If the motor is used while water is present in the lower unit considerable damage to the motor can occur. This damage will not
be covered by warranty.
CAUTION: Take care that neither you nor other persons approach the turning propeller too closely, neither with body parts nor with objects. The
motor is powerful and may endanger or injure you or others. While the motor is running watch out for persons swimming and for floating objects.
Persons whose ability to run the motor or whose reactions are impaired by alcohol, drugs, medication, or other substances are not permitted to use
this motor. This motor is not suitable for use in strong currents. The constant noise pressure level of the motor during use is less than 70dB(A). The
overall vibration level does not exceed 2,5m/sec2.
THANK YOU
Thank you for choosing Minn Kota. We believe that you should spend more time fishing and less time positioning your boat.
That’s why we build the smartest, toughest, most intuitive trolling motors on the water. Every aspect of a Minn Kota trolling motor
is thought out and rethought until it’s good enough to bear our name. Countless hours of research and testing provide you the
Minn Kota advantage that can truly take you “Anywhere. Anytime.” We don’t believe in shortcuts. We are Minn Kota. And we are
never done helping you catch more fish.
REMEMBER TO KEEP YOUR RECEIPT AND IMMEDIATELY REGISTER YOUR TROLLING MOTOR.
A registration card is enclosed or you can complete registration on the internet at minnkotamotors.com.
LOCATING YOUR SERIAL NUMBER
Your Minn Kota 11-character serial number is very important. It helps to determine the specific model and year of manufacture. When contacting
Consumer Service or registering your product, you will need to know your product’s serial number. We recommend that you write the serial number
down in the space provided below so that you have it available for future reference.
CE MASTER USER MANUAL (FOR CE/C-TICK CERTIFIED MODELS)
Conforms to 89/336/EEC (EMC) under standards EN 55022A, EN 50082-2 since 1996 LN V9677264
2 | minnkotamotors.com ©2014 Johnson Outdoors Marine Electronics, Inc.
The serial number on your Traxxis is located
under the tiller handle.
EXAMPLE
Made by Minn Kota
Johnson Outdoors
Marine Electronics, Inc.
121 Power Drive
Mankato, MN 56001 USA
Trolling Motors
Produced in 2012
Traxxis 45 36”
MODEL 1368707
SER NO M365 MK12345
EXAMPLE

minnkotamotors.com | 3
©2014 Johnson Outdoors Marine Electronics, Inc.
TABLE OF CONTENTS
Two-Year Limited Warranty 4
Features 5
Installation 6
Battery & Wiring Installation 7-8
Boat Rigging & Product Installation 7
Conductor Gauge and Circuit Breaker Sizing Table 7
Push-to-Test Battery Meter 7
Selecting the Correct Batteries 8
Connecting the Batteries 8
Motor Wiring Diagram 9
Using and Adjusting the Motor 10-12
Stowing & Deploying the Motor 10
Adjusting the Bracket 11
Adjusting the Depth of the Motor 11
Adjusting the Steering 11
Adjusting the Tilt/Extend Tiller 12
Controlling Speed & Direction with the Tiller 12
Service & Maintenance 13
Propeller Replacement 13
General Maintenance 13
Troubleshooting & Repair 14
Compliance Statements 15
Parts Diagram 16
Parts List 17

WARRANTY ON MINN KOTA FRESHWATER TROLLING MOTORS
Johnson Outdoors Marine Electronics, Inc. (“JOME”) extends the following limited warranty to the original retail purchaser only. Warranty coverage is not
transferable.
MINN KOTA LIMITED TWO-YEAR WARRANTY ON THE ENTIRE PRODUCT
JOME warrants to the original retail purchaser only that the purchaser’s new Minn Kota freshwater trolling motor will be materially free from defects in materials
and workmanship appearing within two (2) years after the date of purchase. JOME will (at its option) either repair or replace, free of charge, any parts found by
JOME to be defective during the term of this warranty. Such repair, or replacement shall be the sole and exclusive liability of JOME and the sole and exclusive
remedy of the purchaser for breach of this warranty.
MINN KOTA LIMITED LIFETIME WARRANTY ON COMPOSITE SHAFT
JOME warrants to the original retail purchaser only that the composite shaft of the purchaser’s Minn Kota trolling motor will be materially free from defects in
materials and workmanship appearing within the original purchaser’s lifetime. JOME will provide a new composite shaft, free of charge, to replace any composite
shaft found by JOME to be defective during the term of this warranty. Providing a new composite shaft shall be the sole and exclusive liability of JOME and the
sole and exclusive remedy of the purchaser for breach of this warranty; and purchaser shall be responsible for installing, or for the cost of labor to
install, any new composite shaft provided by JOME.
EXCLUSIONS & LIMITATIONS
This limited warranty does not apply to products that have been used in saltwater or brackish water, commercially or for rental purposes. This limited warranty
does not cover normal wear and tear, blemishes that do not affect the operation of the product, or damage caused by accidents, abuse, alteration, modification,
shipping damages, acts of God, negligence of the user or misuse, improper or insufficient care or maintenance. DAMAGE CAUSED BY THE USE OF
OTHER REPLACEMENT PARTS NOT MEETING THE DESIGN SPECIFICATIONS OF THE ORIGINAL PARTS WILL NOT BE COVERED BY
THIS LIMITED WARRANTY. The cost of normal maintenance or replacement parts which are not in breach of the limited warranty are the responsibility
of the purchaser. Prior to using products, the purchaser shall determine the suitability of the products for the intended use and assumes all related risk and
liability. Any assistance JOME provides to or procures for the purchaser outside the terms, limitations or exclusions of this limited warranty will not constitute
a waiver of the terms, limitations or exclusions, nor will such assistance extend or revive the warranty. JOME will not reimburse the purchaser for any expenses
incurred by the purchaser in repairing, correcting or replacing any defective products or parts, except those incurred with JOME’s prior written permission.
JOME’S AGGREGATE LIABILITY WITH RESPECT TO COVERED PRODUCTS IS LIMITED TO AN AMOUNT EQUAL TO THE PURCHASER’S
ORIGINAL PURCHASE PRICE PAID FOR SUCH PRODUCT.
MINN KOTA SERVICE INFORMATION
To obtain warranty service in the U.S., the product believed to be defective, and proof of original purchase (including the date of purchase), must be presented
to a Minn Kota Authorized Service Center or to Minn Kota’s factory service center in Mankato, MN. Any charges incurred for service calls, transportation or
shipping/freight to/from the Minn Kota Authorized Service Center or factory, labor to haul out, remove, re-install or re-rig products removed for warranty service,
or any other similar items are the sole and exclusive responsibility of the purchaser. Products purchased outside of the U.S. must be returned prepaid with
proof of purchase (including the date of purchase and serial number) to any Authorized Minn Kota Service Center in the country of purchase. Warranty service
can be arranged by contacting a Minn Kota Authorized Service Center or by contacting the factory at 1-800-227-6433 or email [e-mail].
Products repaired or replaced will be warranted for the remainder of the original warranty period [or for 90 days from the date of repair
or replacement, whichever is longer]. For any product that is returned for warranty service that JOME finds to be not covered by or not
in breach of this limited warranty, there will be a billing for services rendered at the prevailing posted labor rate and for a minimum of at
least one hour.
NOTE: Do not return your Minn Kota product to your retailer. Your retailer is not authorized to repair or replace products.
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THESE LIMITED WARRANTIES. IN NO EVENT SHALL ANY IMPLIED
WARRANTIES INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR PARTICULAR PURPOSE, EXTEND
BEYOND THE DURATION OF THE RELEVANT EXPRESS LIMITED WARRANTY. IN NO EVENT SHALL JOME BE LIABLE FOR PUNITIVE,
INDIRECT, INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES. Without limiting the foregoing, JOME assumes no responsibility for
loss of use of product, loss of time, inconvenience or other damage.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above
limitations and/or exclusions may not apply to you. This warranty gives you specific legal rights and you may also have other legal rights which vary from state
to state.
4 | minnkotamotors.com ©2014 Johnson Outdoors Marine Electronics, Inc.
TWO-YEAR LIMITED WARRANTY

WARRANTY ON MINN KOTA FRESHWATER TROLLING MOTORS
Johnson Outdoors Marine Electronics, Inc. (“JOME”) extends the following limited warranty to the original retail purchaser only. Warranty coverage is not
transferable.
MINN KOTA LIMITED TWO-YEAR WARRANTY ON THE ENTIRE PRODUCT
JOME warrants to the original retail purchaser only that the purchaser’s new Minn Kota freshwater trolling motor will be materially free from defects in materials
and workmanship appearing within two (2) years after the date of purchase. JOME will (at its option) either repair or replace, free of charge, any parts found by
JOME to be defective during the term of this warranty. Such repair, or replacement shall be the sole and exclusive liability of JOME and the sole and exclusive
remedy of the purchaser for breach of this warranty.
MINN KOTA LIMITED LIFETIME WARRANTY ON COMPOSITE SHAFT
JOME warrants to the original retail purchaser only that the composite shaft of the purchaser’s Minn Kota trolling motor will be materially free from defects in
materials and workmanship appearing within the original purchaser’s lifetime. JOME will provide a new composite shaft, free of charge, to replace any composite
shaft found by JOME to be defective during the term of this warranty. Providing a new composite shaft shall be the sole and exclusive liability of JOME and the
sole and exclusive remedy of the purchaser for breach of this warranty; and purchaser shall be responsible for installing, or for the cost of labor to
install, any new composite shaft provided by JOME.
EXCLUSIONS & LIMITATIONS
This limited warranty does not apply to products that have been used in saltwater or brackish water, commercially or for rental purposes. This limited warranty
does not cover normal wear and tear, blemishes that do not affect the operation of the product, or damage caused by accidents, abuse, alteration, modification,
shipping damages, acts of God, negligence of the user or misuse, improper or insufficient care or maintenance. DAMAGE CAUSED BY THE USE OF
OTHER REPLACEMENT PARTS NOT MEETING THE DESIGN SPECIFICATIONS OF THE ORIGINAL PARTS WILL NOT BE COVERED BY
THIS LIMITED WARRANTY. The cost of normal maintenance or replacement parts which are not in breach of the limited warranty are the responsibility
of the purchaser. Prior to using products, the purchaser shall determine the suitability of the products for the intended use and assumes all related risk and
liability. Any assistance JOME provides to or procures for the purchaser outside the terms, limitations or exclusions of this limited warranty will not constitute
a waiver of the terms, limitations or exclusions, nor will such assistance extend or revive the warranty. JOME will not reimburse the purchaser for any expenses
incurred by the purchaser in repairing, correcting or replacing any defective products or parts, except those incurred with JOME’s prior written permission.
JOME’S AGGREGATE LIABILITY WITH RESPECT TO COVERED PRODUCTS IS LIMITED TO AN AMOUNT EQUAL TO THE PURCHASER’S
ORIGINAL PURCHASE PRICE PAID FOR SUCH PRODUCT.
MINN KOTA SERVICE INFORMATION
To obtain warranty service in the U.S., the product believed to be defective, and proof of original purchase (including the date of purchase), must be presented
to a Minn Kota Authorized Service Center or to Minn Kota’s factory service center in Mankato, MN. Any charges incurred for service calls, transportation or
shipping/freight to/from the Minn Kota Authorized Service Center or factory, labor to haul out, remove, re-install or re-rig products removed for warranty service,
or any other similar items are the sole and exclusive responsibility of the purchaser. Products purchased outside of the U.S. must be returned prepaid with
proof of purchase (including the date of purchase and serial number) to any Authorized Minn Kota Service Center in the country of purchase. Warranty service
can be arranged by contacting a Minn Kota Authorized Service Center or by contacting the factory at 1-800-227-6433 or email [e-mail].
Products repaired or replaced will be warranted for the remainder of the original warranty period [or for 90 days from the date of repair
or replacement, whichever is longer]. For any product that is returned for warranty service that JOME finds to be not covered by or not
in breach of this limited warranty, there will be a billing for services rendered at the prevailing posted labor rate and for a minimum of at
least one hour.
NOTE: Do not return your Minn Kota product to your retailer. Your retailer is not authorized to repair or replace products.
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THESE LIMITED WARRANTIES. IN NO EVENT SHALL ANY IMPLIED
WARRANTIES INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR PARTICULAR PURPOSE, EXTEND
BEYOND THE DURATION OF THE RELEVANT EXPRESS LIMITED WARRANTY. IN NO EVENT SHALL JOME BE LIABLE FOR PUNITIVE,
INDIRECT, INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES. Without limiting the foregoing, JOME assumes no responsibility for
loss of use of product, loss of time, inconvenience or other damage.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above
limitations and/or exclusions may not apply to you. This warranty gives you specific legal rights and you may also have other legal rights which vary from state
to state.
Steering Tension Knob
minnkotamotors.com | 5
©2014 Johnson Outdoors Marine Electronics, Inc.
FEATURES
Specifications subject to change without notice.
*This diagram is for reference only and may differ from your actual motor.
Power Propeller*
Tilt/Extend Tiller
Multi-Position
Mounting Bracket
Lifetime Warranty
Flexible Composite Shaft
Cool Quiet Power Motor
Battery Meter
Quick Release
Depth Collar
Transom Clamp Screws

6 | minnkotamotors.com ©2014 Johnson Outdoors Marine Electronics, Inc.
INSTALLATION
MOTOR INSTALLATION
1. Find a transom area of the boat that is free from obstructions.
2. Open the clamp screws on the bracket enough so that it will fit over the top of the
boat transom.
3. Place the mounting bracket over the top of the boat transom so that the bracket is
resting on top of the transom.
4. Verify that there are no obstacles that the control box, handle, or prop might hit
while in use, or when stowed, that would restrict steering or cause damage
to the motor.
5. Tighten down the clamp screws to the transom by hand only. Do not use any tools
to tighten the clamp screws as this may damage the bracket or your boat.
6. We recommend the tilt angle of the motor to be adjusted so that the motor shaft is
perpendicular to the water surface when the motor is in use.
7. For transport, always tilt the motor into the boat, such that the motor and prop
assembly are completely out of the water and the motor is positioned up close to
the lever lock bracket.
NOTE: When setting the depth be sure the top of the motor is submerged at least
12” to avoid churning or agitation of surface water. The propeller must be completely
submerged.
CAUTION:
• Never operate your motor when it is out of the water.
• Over-tightening the clamp screws can damage the bracket.

BOAT RIGGING & PRODUCT INSTALLATION
For safety and compliance reasons, we recommend that you follow American Boat and Yacht Council (ABYC) standards when
rigging your boat. Altering boat wiring should be completed by a qualified marine technician. The following specifications are for
general guidelines only:
CAUTION: These guidelines apply to general rigging to support your Minn Kota motor. Powering multiple motors or additional
electrical devices from the same power circuit may impact the recommended conductor gauge and circuit breaker size. If you are
using wire longer than that provided with your unit, follow the conductor gauge and circuit breaker sizing table below. If your wire
extension length is more than 25 feet, we recommend that you contact a qualified marine technician.
An over-current protection device (circuit breaker or fuse) must be used. Coast Guard requirements dictate that
each ungrounded current-carrying conductor must be protected by a manually reset, trip-free circuit breaker or fuse. The type
(voltage and current rating) of the fuse or circuit breaker must be sized accordingly to the trolling motor used. The table below gives
recommended guidelines for circuit breaker sizing.
Reference:
United States Code of Federal Regulations: 33 CFR 183 – Boats and Associated Equipment
ABYC E-11: AC and DC Electrical Systems on Boats
CONDUCTOR GAUGE AND CIRCUIT BREAKER SIZING TABLE
Motor Thrust /
Model Max Amp Draw Circuit Breaker Wire Extension Length *
5 feet 10 feet 15 feet 20 feet 25 feet
30 lb. 30 50 Amp @ 12 VDC 10 AWG 10 AWG 8 AWG 6 AWG 4 AWG
40 lb., 45 lb. 42 10 AWG 8 AWG 6 AWG 4 AWG 4 AWG
50 lb., 55 lb. 50 60 Amp @ 12 VDC 8 AWG 6 AWG 4 AWG 4 AWG 2 AWG
70 lb. 42 50 Amp @ 24 VDC 10 AWG 10 AWG 8 AWG 8 AWG 6 AWG
80 lb. 56 60 Amp @ 24 VDC 8 AWG 8 AWG 8 AWG 6 AWG 6 AWG
101 lb. 46 50 Amp @ 36 VDC 8 AWG 8 AWG 8 AWG 8 AWG 8 AWG
Engine Mount 101 50 60 Amp @ 36 VDC 8 AWG 6 AWG 4 AWG 4 AWG 2 AWG
112 lb. 52 60 Amp @ 36 VDC 8 AWG 8 AWG 8 AWG 8 AWG 8 AWG
Engine Mount 160 116 (2) x 60 Amp @ 24 VDC 2 AWG 2 AWG 2 AWG 2 AWG 2 AWG
E-Drive 40 50 Amp @ 48 VDC 10 AWG 10 AWG 10 AWG 10 AWG 10 AWG
This conductor and circuit breaker sizing table is only valid for the following assumptions:
1. No more than 3 conductors are bundled together inside of a sheath or conduit outside of engine spaces.
2. Each conductor has 105° C temp rated insulation.
3. No more than 5% voltage drop allowed at full motor power based on published product power requirements.
*Wire Extension Length refers to the distance from the batteries to the trolling motor leads.
minnkotamotors.com | 7
©2014 Johnson Outdoors Marine Electronics, Inc.
BATTERY WIRING & INSTALLATION
PUSH-TO-TEST BATTERY METER
This motor is equipped with a “push to test” battery meter. The LED provides an accurate
display of the remaining charge in the battery. It is only accurate when the motor is off.
The meter reads as:
• One light indicates recharge.
• Two lights indicate low charge.
• Three lights indicate good charge.
• Four lights indicate full charge.
lbs. thrust
12 volts
33
Testwith
Motor Off

CONNECTING THE BATTERIES
12 VOLT SYSTEMS:
1. Make sure that the motor is switched off (speed selector on “OFF” or “0”).
2. Connect positive ( + ) red lead to positive ( + ) battery terminal.
3. Connect negative ( – ) black lead to negative ( – ) battery terminal.
4. For safety reasons do not switch the motor on until the propeller is in the water.
CAUTION:
For safety reasons, disconnect the motor from the battery/batteries when the motor is not in use or while the
battery/batteries are being charged.
SELECTING THE CORRECT BATTERIES
The motor will operate with any lead acid, deep cycle marine 12 volt battery/batteries. For best results, use a deep cycle, marine
battery with at least a 105 ampere hour rating. Maintain battery at full charge. Proper care will ensure having battery power
when you need it, and will significantly improve the battery life. Failure to recharge lead-acid batteries (within 12-24 hours) is the
leading cause of premature battery failure. Use a multi-stage charger to avoid overcharging. We offer a wide selection of chargers
to fit your charging needs. If you are using a crank battery to start a gasoline outboard, we recommend that you use a separate
deep cycle marine battery/batteries for your Minn Kota trolling motor.
Advice Regarding Batteries:
• Never connect the (+) and the (–) terminals of the battery together. Take care that no metal object can fall onto the battery and
short the terminals. This would immediately lead to a short and extreme fire danger.
• It is highly recommended that a circuit breaker or fuse be used with this trolling motor. Refer to “Conductor Gauge and Circuit
Breaker Sizing Table” in the previous section to find the appropriate circuit breaker or fuse for your motor. For motors requiring
a 60-amp breaker, the Minn Kota MKR-19 60-amp circuit breaker is recommended.
CONNECTING THE BATTERIES IN SERIES
(IF REQUIRED FOR YOUR MOTOR)
24 VOLT SYSTEMS:
1. Make sure that the motor is switched off (speed selector on “0”).
2. Two 12 volt batteries are required.
3. The batteries must be wired in series, only as directed in wiring
diagram, to provide 24 volts.
a. Connect a connector cable to the positive ( + ) terminal of
battery 1 and to the negative ( – ) terminal of battery 2.
b. Connect positive ( + ) red lead to positive ( + ) terminal on battery 2.
c. Connect negative ( – ) black lead to negative ( – ) terminal of battery 1.
4. For safety reasons do not switch the motor on until the propeller is in the water. If installing a leadwire plug, observe proper
polarity and follow instructions in your boat owner’s manual. See wiring diagram on following pages.
CAUTION
• For safety reasons, disconnect the motor from the battery or batteries when the motor is not in use or while
the battery/batteries are being charged.
• Improper wiring of 24/36 volt systems could cause battery explosion!
• Keep leadwire wing nut connection tight and solid to battery terminals.
• Locate battery in a ventilated compartment.
To trolling motor negative
24 Volt Connection
Battery #1 (Low Side)
Neg - Neg -Pos + Pos +
Battery #2 (High Side)
+24 Volts to trolling motor
positive (or circuit breaker)
24 Volt Series Connection
8 | minnkotamotors.com ©2014 Johnson Outdoors Marine Electronics, Inc.
BATTERY WIRING & INSTALLATION

CONNECTING THE BATTERIES
12 VOLT SYSTEMS:
1. Make sure that the motor is switched off (speed selector on “OFF” or “0”).
2. Connect positive ( + ) red lead to positive ( + ) battery terminal.
3. Connect negative ( – ) black lead to negative ( – ) battery terminal.
4. For safety reasons do not switch the motor on until the propeller is in the water.
CAUTION:
For safety reasons, disconnect the motor from the battery/batteries when the motor is not in use or while the
battery/batteries are being charged.
SELECTING THE CORRECT BATTERIES
The motor will operate with any lead acid, deep cycle marine 12 volt battery/batteries. For best results, use a deep cycle, marine
battery with at least a 105 ampere hour rating. Maintain battery at full charge. Proper care will ensure having battery power
when you need it, and will significantly improve the battery life. Failure to recharge lead-acid batteries (within 12-24 hours) is the
leading cause of premature battery failure. Use a multi-stage charger to avoid overcharging. We offer a wide selection of chargers
to fit your charging needs. If you are using a crank battery to start a gasoline outboard, we recommend that you use a separate
deep cycle marine battery/batteries for your Minn Kota trolling motor.
Advice Regarding Batteries:
• Never connect the (+) and the (–) terminals of the battery together. Take care that no metal object can fall onto the battery and
short the terminals. This would immediately lead to a short and extreme fire danger.
• It is highly recommended that a circuit breaker or fuse be used with this trolling motor. Refer to “Conductor Gauge and Circuit
Breaker Sizing Table” in the previous section to find the appropriate circuit breaker or fuse for your motor. For motors requiring
a 60-amp breaker, the Minn Kota MKR-19 60-amp circuit breaker is recommended.
CONNECTING THE BATTERIES IN SERIES
(IF REQUIRED FOR YOUR MOTOR)
24 VOLT SYSTEMS:
1. Make sure that the motor is switched off (speed selector on “0”).
2. Two 12 volt batteries are required.
3. The batteries must be wired in series, only as directed in wiring
diagram, to provide 24 volts.
a. Connect a connector cable to the positive ( + ) terminal of
battery 1 and to the negative ( – ) terminal of battery 2.
b. Connect positive ( + ) red lead to positive ( + ) terminal on battery 2.
c. Connect negative ( – ) black lead to negative ( – ) terminal of battery 1.
4. For safety reasons do not switch the motor on until the propeller is in the water. If installing a leadwire plug, observe proper
polarity and follow instructions in your boat owner’s manual. See wiring diagram on following pages.
CAUTION
• For safety reasons, disconnect the motor from the battery or batteries when the motor is not in use or while
the battery/batteries are being charged.
• Improper wiring of 24/36 volt systems could cause battery explosion!
• Keep leadwire wing nut connection tight and solid to battery terminals.
• Locate battery in a ventilated compartment.
To trolling motor negative
24 Volt Connection
Battery #1 (Low Side)
Neg - Neg -Pos + Pos +
Battery #2 (High Side)
+24 Volts to trolling motor
positive (or circuit breaker)
24 Volt Series Connection
minnkotamotors.com | 9
©2014 Johnson Outdoors Marine Electronics, Inc.
MOTOR WIRING DIAGRAM
12v
24v
36v
BLACK M-
RED M+
RED B+
MOTOR
CONTROL BOARD
SPEED
ADJUSTMENT
KNOB
BATTERY GAUGE
RED
12V BATT 1
12V BATT 1 12V BATT 2
12V BATT 1 12V BATT 2 12V BATT 3
BLACK
BLACK B-
VARIABLE SPEED SWITCH

10 | minnkotamotors.com ©2014 Johnson Outdoors Marine Electronics, Inc.
USING & ADJUSTING THE MOTOR
STOWING AND DEPLOYING THE MOTOR
WARNING:
When raising or lowering the motor, keep fingers clear of all hinge and pivot points and all moving parts.
HORIZONTAL
Stowing
1. Grab the back of the motor head or the motor shaft and lift up. If motor needs to be
pulled into boat more, loosen the steering tension knob to adjust shaft.
2. While lifting up, tilt the motor into the boat (the motor must be lifted approximately 1/2”
to disengage locking pins).
3. The bracket will ratchet into a locked position.
4. Retighten the steering tension knob and slide the quick release depth collar down to the
top of the steering tension knob for transport.
Deploying
1. Loosen the quick release collar.
2. Reposition and retighten to desired depth location.
3. Hold the motor shaft or head firmly, and loosen the steering tension knob.
4. Press the tilt lock button while holding control head and gently lower the motor into
the water.
5. Retighten the quick release collar.
6. Retighten the steering tension knob to the desired steering tension.
VERTICAL STOW:
Stowing
1. Firmly grasp the motor shaft.
2. Loosen the steering tension knob and lift up on the motor.
3. Retighten the steering tension knob to retain the vertical stow position of the motor.
4. Slide the quick release depth collar down to the top of the steering tension knob for
added security.
Deploying
1. Loosen the quick release collar.
2. Hold the motor shaft firmly, and loosen the steering tension knob.
3. Gently lower the motor into the water.
4. Retighten the quick release collar.
5. Retighten the steering tension knob to the desired steering tension.
UP
OVER
DOWN
UP
OVER
DOWN

minnkotamotors.com | 11
©2014 Johnson Outdoors Marine Electronics, Inc.
STOWING AND DEPLOYING THE MOTOR
WARNING:
When raising or lowering the motor, keep fingers clear of all hinge and pivot points and all moving parts.
HORIZONTAL
Stowing
1. Grab the back of the motor head or the motor shaft and lift up. If motor needs to be
pulled into boat more, loosen the steering tension knob to adjust shaft.
2. While lifting up, tilt the motor into the boat (the motor must be lifted approximately 1/2”
to disengage locking pins).
3. The bracket will ratchet into a locked position.
4. Retighten the steering tension knob and slide the quick release depth collar down to the
top of the steering tension knob for transport.
Deploying
1. Loosen the quick release collar.
2. Reposition and retighten to desired depth location.
3. Hold the motor shaft or head firmly, and loosen the steering tension knob.
4. Press the tilt lock button while holding control head and gently lower the motor into
the water.
5. Retighten the quick release collar.
6. Retighten the steering tension knob to the desired steering tension.
VERTICAL STOW:
Stowing
1. Firmly grasp the motor shaft.
2. Loosen the steering tension knob and lift up on the motor.
3. Retighten the steering tension knob to retain the vertical stow position of the motor.
4. Slide the quick release depth collar down to the top of the steering tension knob for
added security.
Deploying
1. Loosen the quick release collar.
2. Hold the motor shaft firmly, and loosen the steering tension knob.
3. Gently lower the motor into the water.
4. Retighten the quick release collar.
5. Retighten the steering tension knob to the desired steering tension.
UP
OVER
DOWN
UP
OVER
DOWN
USING & ADJUSTING THE MOTOR
ADJUSTING THE BRACKET
You can lock your motor in a vertical position, angle it for shallow water or tilt it
completely out of the water.
1. Firmly grasp the control head of the motor. (Do not lift up on the motor for
angular adjustment)
2. Press down and hold the Tilt Lock Button.
3. Tilt the motor forward or back to the desired position within the
mounting bracket.
4. Release the Tilt Lock Button and ensure the motor is locked into the
desired position.
Quick Release
Depth Collar
Steering Tension Knob
Tilt Lock Button
Transom Clamp Screws
ADJUSTING THE DEPTH OF THE MOTOR
When setting the depth be sure the top of the motor is submerged at least 12” to
avoid churning or agitation of surface water. The propeller must be completely
submerged.
1. Firmly grasp the motor shaft and hold it steady.
2. Loosen steering tension knob.
3. Open the lever arm to loosen the Quick Release Depth Collar.
4. Vertically adjust the height of the motor to the desired position.
5. Bring the depth collar to the top of the steering tension knob, and close the
lever arm to lock the depth collar into position.
6. Tighten the steering tension knob to achieve the desired steering resistance.
NOTE: The tension of the quick release depth collar can be adjusted with a screw
driver to obtain the proper feel.
CAUTION:
• Never operate your motor when it is out of the water.
• Over-tightening the clamp screws can damage the bracket.
ADJUSTING THE STEERING
• Adjust the steering tension knob to provide enough tension to allow the motor to turn freely, yet remain in any position without
being held
OR
• Tighten the knob to place the motor in a preset position to leave your hands free for fishing.
Quick Release
Depth Collar
Steering Tension
Vertical Stow Knob
12” Minimum
Depth
Lever Arm

12 | minnkotamotors.com ©2014 Johnson Outdoors Marine Electronics, Inc.
USING & ADJUSTING THE MOTOR
ADJUSTING THE TILT/EXTEND TILLER
Your trolling motor features 7 usable handle tilt positions: 45°, 30°, and 15° up and
down from the 0° (horizontal) position. To use the down positions, you must first press
the release button located on the left underside of the pivot handle.
Your trolling motor handle also features a unique stow
position, that is useful for limiting the amount of space
required for storage or travel.
Important: BEFORE attempting to put the
handle in the stowed position, the speed selector
must be in the OFF/STOW position . Failure to do
so will damage the internal mechanism.
First press the release button located on the left underside of the pivot handle,
then push the handle down until you feel the handle “lock in” to the stowed
position. This will be almost parallel to the motor shaft.
To extend the handle, pull the handle towards you to the desired position.
The handle will extend a full 6 inches. To retract, push the handle in until it
meets the face of the motor control head.
Handle Controls:
Off/On, Steering, and
Forward/Reverse
Release Button
CONTROLLING SPEED & STEERING WITH THE TILLER
This motor offers variable forward and reverse speeds. The speed control may be operated in either
direction, forward or reverse. Turn the tiller handle counterclockwise from (OFF) to increase reverse
speed and clockwise from (OFF) to increase forward speed. Speed decreases as you approach (OFF)
from either direction.
Forward
Reverse

Propeller
Slot End
Drive Pin
Prop Nut
Washer
PROPELLER REPLACEMENT
TOOLS AND RESOURCES REQUIRED:
• 7/16” Box End Wrench
• Screwdriver (optional)
CAUTION:
Disconnect the motor from the battery
before beginning any prop work or
maintenance.
NOTE: The propeller on your motor may differ from
the one pictured.
1. Disconnect the motor from all sources of power
prior to changing the propeller.
2. Hold the propeller and loosen the prop nut with pliers or a wrench.
3. Remove the prop nut and washer. If the drive pin is sheared or broken, you will need to hold the shaft stationary with a blade
screwdriver pressed into the slot on the end of the shaft.
4. Turn the old prop to horizontal (as illustrated) and pull it straight off. If drive pin falls out, push it back in.
5. Align the new propeller with the drive pin.
6. Install the prop washer and prop nut.
7. Tighten the prop nut 1/4 turn past snug [25-35 inch lbs.] Do not over tighten as this can damage the prop.
GENERAL MAINTENANCE
1. After use, the entire motor should be rinsed with freshwater, then wiped down with a cloth dampened with an aqueous based
silicone spray. This series of motors is not equipped for saltwater exposure.
2. The propeller must be inspected and cleaned from weeds and fishing line after every use.
Fishing line and weeds can get behind the prop, damage the seals and allow water to enter the motor.
3. Verify the prop nut is secure each time the motor is used.
4. To prevent accidental damage during transportation or storage, disconnect the battery whenever the motor is off of the water.
For prolonged storage, lightly coat all metal parts with an aqueous based silicone spray.
5. For maximum battery life recharge the battery(s) as soon as possible after use. For maximum motor performance restore
battery to full charge prior to use.
6. Keep battery terminals clean with fine sandpaper or emery cloth.
7. The propeller is designed to provide weed free operation with very high efficiency. To maintain this top performance, the
leading edge of the blades must be kept smooth. If they are rough or nicked from use, restore to smooth by sanding with fine
sandpaper.
minnkotamotors.com | 13
©2014 Johnson Outdoors Marine Electronics, Inc.
SERVICE & MAINTENANCE
CONTROLLING SPEED & STEERING WITH THE TILLER
This motor offers variable forward and reverse speeds. The speed control may be operated in either
direction, forward or reverse. Turn the tiller handle counterclockwise from (OFF) to increase reverse
speed and clockwise from (OFF) to increase forward speed. Speed decreases as you approach (OFF)
from either direction.
Forward
Reverse

FOR FURTHER TROUBLESHOOTING AND REPAIR
We offer several options to help you troubleshoot and/or repair your product. Please read through the options listed below.
FREQUENTLY ASKED QUESTIONS
We have FAQs available on our website to help answer all of your Minn Kota questions. Visit minnkotamotors.com and click on
“Frequently Asked Questions” to find an answer to your question.
CALL US (FOR U.S. AND CANADA)
Our consumer service representatives are available Monday – Friday between 7:00 a.m. – 4:30 p.m. CST at 800-227-6433.
If you are calling to order parts, please have the 11-character serial number from your product, specific part numbers, and credit
card information available. This will help expedite your call and allow us to provide you with the best consumer service possible.
You can reference the parts list located in your manual to identify the specific part numbers.
EMAIL US
You can email our consumer service department with questions regarding your Minn Kota products. To email your question, visit
minnkotamotors.com and click on “Support”.
AUTHORIZED SERVICE CENTERS
Minn Kota has over 300 authorized service centers in the United States and Canada where you can purchase parts or get your
products repaired. Please visit our Authorized Service Center page on our website to locate a service center in your area.
1. Motor fails to run or lacks power:
• Check battery connections for proper polarity.
• Make sure terminals are clean and corrosion free. Use fine sandpaper or emery cloth to clean terminals.
• Check battery water level. Add water if needed.
2. Motor loses power after a short running time:
• Check battery charge. If low, restore to full charge.
3. Motor is difficult to steer:
• Loosen the steering tension knob on the bracket
• Lubricate the composite shaft.
4. You experience prop vibration during normal operation:
• Remove and rotate the prop 180°. See removal instructions in the Propeller Replacement section.
5. Experiencing interference with your fishfinder:
• You may, in some applications, experience interference in your depth finder display. We recommend that you use a seperate
deep cycle marine battery for your trolling motor and that you power the depth finder from the starting/cranking battery. If
problems still persist, call our service department at 1-800-227-6433.
NOTE: For all other malfunctions, visit an Authorized Service Center. You can search for an Authorized Service Center in your
area by visiting our Authorized Service Center page, found online at minnkotamotors.com, or by calling our customer service
number, 800-227-6433.
14 | minnkotamotors.com ©2014 Johnson Outdoors Marine Electronics, Inc.
TROUBLESHOOTING & REPAIR

ENVIRONMENTAL COMPLIANCE STATEMENT:
It is the intention of JOME to be a responsible corporate citizen, operating in compliance with known and applicable
environmental regulations, and a good neighbor in the communities where we make or sell our products.
WEEE DIRECTIVE:
EU Directive 2002/96/EC “Waste of Electrical and Electronic Equipment Directive (WEEE)” impacts most distributors, sellers,
and manufacturers of consumer electronics in the European Union. The WEEE Directive requires the producer of consumer
electronics to take responsibility for the management of waste from their products to achieve environmentally responsible
disposal during the product life cycle.
WEEE compliance may not be required in your location for electrical & electronic equipment (EEE), nor may it be required
for EEE designed and intended as fixed or temporary installation in transportation vehicles such as
automobiles, aircraft, and boats. In some European Union member states, these vehicles are considered
outside of the scope of the Directive, and EEE for those applications can be considered excluded from the
WEEE Directive requirement.
This symbol (WEEE wheelie bin) on product indicates the product must not be disposed of with other
household refuse. It must be disposed of and collected for recycling and recovery of waste EEE. Johnson
Outdoors Inc. will mark all EEE products in accordance with the WEEE Directive. It is our goal to comply
in the collection, treatment, recovery, and environmentally sound disposal of those products; however, these requirement do
vary within European Union member states. For more information about where you should dispose of your waste equipment for
recycling and recovery and/or your European Union member state requirements, please contact your dealer or distributor from
which your product was purchased.
DISPOSAL:
Minn Kota motors are not subject to the disposal regulations EAG-VO (electric devices directive) that implements the WEEE
directive. Nevertheless never dispose of your Minn Kota motor in a garbage bin but at the proper place of collection of your local
town council.
Never dispose of battery in a garbage bin. Comply with the disposal directions of the manufacturer or his representative and
dispose of them at the proper place of collection of your local town council.
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects
or other reproductive harm.
minnkotamotors.com | 15
©2014 Johnson Outdoors Marine Electronics, Inc.
COMPLIANCE STATEMENTS

16 | minnkotamotors.com ©2014 Johnson Outdoors Marine Electronics, Inc.
PARTS DIAGRAM
This page provides Minn Kota® WEEE compliance disassembly
instructions. For more information about where you should
dispose of your waste equipment for recycling and recovery and/
or your European Union member state requirements, please
contact your dealer or distributor from which your product was
purchased.
Tools required, but not limited to: flat head screw driver, Phillips
screw driver, socket set, pliers, wire cutters.
TRAXXIS 45
45 LBS THRU - 12 VOLT - 36” SHA
2064967 rev K ECN 35970 8 /14
1
5
15
40 45
50
75
80
70
85
90
100
65
1010
20
95
25
1015
60
1000
1020
10
30
35
350 356
208
200
205
210
400
395
220
225
245
265
270
275
290
295
320
325
330
305
310
135
136
235
215
410
260 255
335
230
390
360
365
370 375
380
385 420
425
280 285
315
240
250
415
355
405
317
316

minnkotamotors.com | 17
©2014 Johnson Outdoors Marine Electronics, Inc.
PARTS LIST
ITEM QTY PART
NUMBER DESCRIPTION
1 1 2069288 12V MOTOR 36” FW
5 1 2-100-202 ARMATURE SEMBLY
10 1140-010 BEARING
15 1788-015 RAINING RING
20 12-200-079 CENTER HOUSING SEMBY
25 1421-132 BRUSH END HOUSING SEMBLY
30 12-400-128 PIN END HOUSING SEMBLY
35 1144-049 FNGE BEARING
40 1880-003 SEAL
45 1880-006 SEAL WITH SHIELD
50 2188-052 BRUSH
60 1738-030 BRUSH PTE SEMBLY
65 2975-032 BRUSH SPRING
70 1701-041 O-RING, MOTOR, FRONT
75 1701-039 O-RING, MOTOR, REAR
80 2701-007 O-RING, THRU-BOLT
85 2830-001 SCREW, #8-32
90 2830-078 THRU-BOLT
95 1990-067 WHER, EEL
100 1990-070 WHER, NYTRON
135 1640-001 LEADWIRE, BCK
136 1640-101 LEADWIRE, RED
n2883460 SEAL AND O-RING KIT
200 12065679 DEL, C-BOX COVER
205 12060295 C-BOX COVER
208 22325665 DEL - MINNKOTA
210 12074070 BATTERY MER, 12V FW
215 22043427 SCREW, #8 X 7/8 SS
220 12184016 CONTROL BOARD, 12V
n12888411 POTENTIOMER REPCEMENT KIT
225 22303434 SCREW, #8-32 X 5/8 SS
230 12062501 CONTROL BOX, VARS, FW
235 12062905 RAIN RELIEF
240 62303412 SCREW, #6 X 5/8 SS
245 22263434 SCREW, #8-18 X 1
250 12383407 SCREW, #10-24 X 2 SS
255 12061515 COLR, C-BOX
260 12383124 NYLOCK NUT #10-24
265 12991521 M LOCK/DEPTH COLR SY
n12991795 BRACK SY, COMPOSITE [270-356]
ITEM QTY PART
NUMBER DESCRIPTION
270 12060100 KNOB, EERING TENSION, SO
275 12068400 COLL
280 12064200 LOCK ARM
285 12062701 SPRING, LOCK ARM
290 12061821 HINGE
295 22062602 PIN, LOCK, ZINC
305 12037301 BUSHING, HINGE
310 12032052 TUBE 36”
315 32063500 BOLT 1/4-20 X 2 3/8”, ZINC
316 22061300 SCREW - CMP
317 22011710 WHER - CMP SCREW
320 12771950 BRACK, RIGHT, FW
325 12067905 M DEAIVATOR
330 32067306 BUSHING, DOWEL 1/4 X 1/2
335 12062702 SPRING, M DEAIVATOR
n22881380 CMP SCREW KIT
350 12771955 BRACK, LE, FW
355 32263104 NUT, 1/4-20, NYLOCK, ZINC
356 12062604 PIN, OP
n12990957 HANDLE SY, VARS [360-410]
360 12990456 GRIP/HANDLE SY, VARS [360-375]
365 22060015 BEARING, HANDLE
370 22063405 SCREW, #6 X 1/2
375 12884092 YOKE / SPIDER SY, VARS
380 12302742 SPRING, DENT, OFF
385 22060005 BEARING, HANDLE PIVOT
390 12060900 HANDLE PIVOT, TOP
395 12302745 SPRING, RELEE BUTTON
400 12063700 BUTTON, RELEE
405 12060905 HANDLE PIVOT, BOTTOM
410 62303412 SCREW, #6-20 X 5/8 SS
415 12062715 SPRING, HANDLE PIVOT
420 12061700 WHER, POT HOLDER
425 12992523 LEADWIRE SY, INCLUD [235]
n1378121 PROPELLER KIT
1000 12061122 PROPELLER
1010 12092600 DRIVE PIN, RGE
1015 12151726 WHER, PROP, ANDARD
1020 12053101 NUT, NYLOCK, PROP, MEDIUM
TRAXXIS 45
45 LBS THRU - 12 VOLT - 36” SHA
nTHIS ITEM IS PART OF AN SEMBLY.
*THIS ITEM IS PART OF A KIT AND ONLY LIED FOR VIEWING PURPOS.

A Johnson Outdoors Company
Minn Kota Consumer & Technical Service
Johnson Outdoors Marine Electronics, Inc.
PO Box 8129
Mankato, MN 56001
121 Power Drive
Mankato, MN 56001
Phone [phone]
Fax [phone]
minnkotamotors.com ©2014 Johnson Outdoors Marine Electronics, Inc.
All rights reserved.
Part #2067135 Rev H 8/14 ECN 35970
For a complete listing of Minn Kota accessories, visit minnkotamotors.com
• 60-Amp Circuit Breaker
• Mounting Brackets
• Stabilizer Kits
• Extension Handles
• Battery Connectors
• Battery Boxes
• Quick Connect Plugs
RECOMMENDED ACCESSORIES
ON-BOARD & PORTABLE BATTERY CHARGERS
Stop buying new batteries and start taking care of the ones you’ve got. Many chargers can actually damage your battery
over time – creating shorter run times and shorter overall life. Digitally controlled Minn Kota chargers are designed to provide the
fastest charge that protect and extend battery life.
TALON SHALLOW WATER ANCHOR
Talon deploys faster, holds stronger and runs quieter than any other shallow water anchor. Available in depths up to 12’ and bold color
options, it boasts an arsenal of features and innovations that no other anchor can touch:
MINN KOTA ACCESSORIES
We offer a wide variety of trolling motor accessories, including:
MK212DMK345PC MK105P
Follow us:
• Vertical, multi-stage deployment
• User-Selectable Anchoring Modes
• 2x Anchoring Force
• Fast Deploy
• Auto Up/Down
• Triple Debris shields*
• Built-In Wave Absorption
• Noise Dissipation
• Versatile Adjustments
*available on 10’ and 12’ models only

TRAXXIS
PROPULSEUR ÉLECTRIQUE À MONTAGE SUR ARCASSE
MANUEL DE L’UTILISATEUR
For a complete listing of Minn Kota accessories, visit minnkotamotors.com
• 60-Amp Circuit Breaker
• Mounting Brackets
• Stabilizer Kits
• Extension Handles
• Battery Connectors
• Battery Boxes
• Quick Connect Plugs
RECOMMENDED ACCESSORIES
ON-BOARD & PORTABLE BATTERY CHARGERS
Stop buying new batteries and start taking care of the ones you’ve got. Many chargers can actually damage your battery
over time – creating shorter run times and shorter overall life. Digitally controlled Minn Kota chargers are designed to provide the
fastest charge that protect and extend battery life.
TALON SHALLOW WATER ANCHOR
Talon deploys faster, holds stronger and runs quieter than any other shallow water anchor. Available in depths up to 12’ and bold color
options, it boasts an arsenal of features and innovations that no other anchor can touch:
MINN KOTA ACCESSORIES
We offer a wide variety of trolling motor accessories, including:
MK212DMK345PC MK105P
Follow us:
• Vertical, multi-stage deployment
• User-Selectable Anchoring Modes
• 2x Anchoring Force
• Fast Deploy
• Auto Up/Down
• Triple Debris shields*
• Built-In Wave Absorption
• Noise Dissipation
• Versatile Adjustments
*available on 10’ and 12’ models only

Modèle :_________________________________________________________________________________________________________________________
Numéro de série : ______________________________________________________________________________________________________________
Date de l’achat : ________________________________________________________________________________________________________________
Magasin où l’achat a été effectué :____________________________________________________________________________________________
REMARQUE : ne pas retourner le moteur Minn Kota au détaillant. Le détaillant n’est pas autorisé à réparer ou à remplacer cet appareil. Pour le service
: communiquer avec Minn Kota au [phone]; retourner le moteur au Centre de service de l’usine de Minn Kota; envoyer ou apporter le moteur
à un centre de service agréé de Minn Kota. Une liste de centres de service agréés est disponible sur notre site Web minnkotamotors.com. Pour obtenir
un service au titre de la garantie, y compris toutes les options susmentionnées, veuillez inclure la preuve d’achat, le numéro de série et la date de l’achat.
Veuillez lire attentivement ce manuel de l’utilisateur. Suivre toutes les instructions et tenir compte de toutes les consignes de sécurité et
les mises en garde décrites ci-dessous. L’utilisation de ce moteur n’est autorisée que pour les personnes qui ont lu et compris ces consignes pour
l’utilisateur. Les personnes mineures peuvent utiliser ce moteur uniquement sous la supervision d’un adulte.
ATTENTION : ne jamais faire fonctionner le moteur hors de l’eau, puisque cela entraînerait des blessures causées par l’hélice en rotation. Le moteur
doit être débranché de la source d’alimentation lorsqu’il n’est pas utilisé ou lorsqu’il est hors de l’eau. Au moment de brancher les câbles d’alimentation
du moteur à la batterie, veiller à ce qu’ils ne soient pas entortillés ou exposés au frottement, puis les placer de telle manière que les personnes ne
puissent pas faire trébucher. Avant d’utiliser le moteur, s’assurer que l’isolant des câbles d’alimentation n’est pas endommagé. Ne pas tenir compte de
ces mesures de sécurité peut entraîner des courts-circuits avec les batteries et/ou le moteur. Toujours débrancher le moteur des batteries avant le
nettoyage ou la vérification de l’hélice. Éviter de submerger complètement le moteur, car l’eau pourrait pénétrer dans l’unité inférieure par la tête de
contrôle et l’arbre. Si le moteur est utilisé alors que de l’eau est présente dans l’unité inférieure, ce dernier pourrait subir des dommages considérables.
Ces dommages ne seront pas couverts par la garantie.
ATTENTION : veillez à ce que ni vous, ni les autres personnes ne s’approchent trop près de l’hélice en rotation, que ce soit seulement avec une partie
du corps ou des objets. Le moteur est puissant et pourrait provoquer des situations périlleuses ou des blessures, pour vous ou les autres. Lorsque le
moteur est en marche, se méfier des objets flottants ou des personnes qui pourraient être en train de nager. Les personnes, dont les réactions ou la
capacité à faire fonctionner le moteur est/sont affaiblie (s) par l’alcool, la drogue, les médicaments ou d’autres substances, ne sont pas autorisées à
utiliser ce moteur. Ce moteur n’est pas adapté à l’utilisation dans de forts courants. Le niveau de pression sonore constant du moteur au moment de
l’utilisation est inférieur à 70 dB (A). Le niveau de vibration général ne dépasse pas 2,5 m/s².
MERCI
Nous vous remercions d’avoir choisi Minn Kota. Nous sommes persuadés que vous devriez consacrer plus de temps à pêcher et
moins de temps à amarrer votre embarcation. C’est pourquoi nous construisons les propulseurs électriques les plus intelligents,
les plus solides et les plus intuitifs. Chaque aspect d’un propulseur électrique Minn Kota est envisagé et étudié jusqu’à ce qu’il
soit digne de porter notre nom. Des heures incalculables de recherche et d’essai vous assurent les avantages d’un article Minn
Kota qui vous mènera n’importe où, et n’importe quand. Notre principe est simple, nous faisons les choses selon les règles. Nous
sommes Minn Kota. Et nous ne cesserons jamais de vous aider à pêcher plus de poissons.
N’OUBLIEZ PAS DE CONSERVER VOTRE REÇU ET D’ENREGISTRER IMMÉDIATEMENT VOTRE PROPULSEUR ÉLECTRIQUE.
Un formulaire d’enregistrement est compris ou vous pouvez remplir le formulaire d’enregistrement par Internet sur le site Web
minnkotamotors.com.
LOCALISATION DU NUMÉRO DE SÉRIE
Le numéro de série à 11 caractères Minn Kota est très important. Il permet de déterminer le modèle spécifique et l’année de fabrication. Lorsque vous
contactez le service à la clientèle ou que vous enregistrez votre article, vous aurez besoin du numéro de série de votre article. Nous vous suggérons
d’inscrire le numéro de série dans l’espace fourni ci-dessous afin qu’il soit disponible ultérieurement.
MANUEL CE D’UN MASTER (CE/C-TICK CERTIFIED MODELS)
Conforme à la norme 89/336/EEC (EMC) selon les normes EN 55022A, EN 50082-2 depuis 1996 LN V9677264
20 | minnkotamotors.com ©2014 Johnson Outdoors Marine Electronics, Inc.
Le numéro de série de votre Traxxis se
trouve sous la barre d’inclinaison.
EXAMPLE
Made by Minn Kota
Johnson Outdoors
Marine Electronics, Inc.
121 Power Drive
Mankato, MN 56001 USA
Trolling Motors
Produced in 2012
Traxxis 45 36”
MODEL 1368707
SER NO M365 MK12345
EXEMPLE
