MINN KOTA RIPTIDE POWERDRIVE User manual

RIPTIDE POWERDRIVE
BOW-MOUNT TROLLING MOTOR
Installation Instructions

2 | minnkotamotors.com ©2023 Johnson Outdoors Marine Electronics, Inc.
INTRODUCTION
NOTICE: The serial number on your Riptide PowerDrive is
located inside the mount below the motor rests.
THANK YOU
Thank you for choosing Minn Kota. We believe that you should spend more time fishing and less time positioning your boat. That’s why
we build the smartest, toughest, most intuitive trolling motors on the water. Every aspect of a Minn Kota trolling motor is thought out and
rethought until it’s good enough to bear our name. Countless hours of research and testing provide you the Minn Kota advantage that
can truly take you “Anywhere. Anytime.” We don’t believe in shortcuts. We are Minn Kota. And we are never done helping you catch more fish.
REGISTRATION
Remember to keep your receipt and immediately register your
trolling motor on our website at minnkotamotors.com/register.
SERIAL NUMBER
Your Minn Kota 11 character serial number is very important. It
helps to determine the specific model and year of manufacture.
When Contacting consumer service or registering your product
you will need to know your products serial number. A duplicate
copy of your serial number label has been included which can
also be entered in the One-Boat Network App for future reference.
NOTICE: Do not return your Minn Kota motor to your retailer. Your retailer is not authorized to repair or replace this unit. You may
obtain service by: calling Minn Kota at [phone]; returning your motor to the Minn Kota Factory Service Center; sending
or taking your motor to any Minn Kota authorized service center. A list of authorized service centers is available on our website,
at minnkotamotors.com. Please include proof of purchase, serial number and purchase date for warranty service with any of the
above options.
Use of the Made for Apple badge means that an accessory has been designed to connect specifically to the Apple product(s) identified in the
badge, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or
its compliance with safety and regulatory standards. iPhone is a trademark of Apple Inc., registered in the U.S. and other countries. The trademark
“iPhone” is used in Japan with a license from Aiphone K.K.
AndroidTM is a trademark of Google LLC. The Android robot is reproduced or modified from work created and shared by Google and used according
to terms described in the Creative Commons 3.0 Attribution License.
Made for iPhone®11 and iPhone X
For updated iOS, Humminbird®and Minn Kota®compatibility,
visit minnkotamotors.com
Made for
Android
Android
™
™
EXAMPLE
Model Serial Number: ________________________________________________________________________________________
Controller Serial Number: _____________________________________________________________________________________
Purchase Date: _____________________________________________________________________________________________
Store Where Purchased: ______________________________________________________________________________________
MOTOR INFORMATION (For Consumer Reference Only)

minnkotamotors.com | 3
©2023 Johnson Outdoors Marine Electronics, Inc.
SAFETY CONSIDERATIONS
Please thoroughly read the user manual. Follow all instructions and heed all safety and cautionary notices. Use of this motor is only
permitted for persons that have read and understood these user instructions. Minors may use this motor only under adult supervision.
WARNING
You are responsible for the safe and prudent operation of your vessel. We have designed your Minn Kota product to be an accurate
and reliable tool that will enhance boat operation and improve your ability to catch fish. This product does not relieve you from the
responsibility for safe operation of your boat. You must avoid hazards to navigation and always maintain a permanent watch so you
can respond to situations as they develop. You must always be prepared to regain manual control of your boat. Learn to operate your
Minn Kota product in an area free from hazards and obstacles.
WARNING
Never run the motor out of the water, as this may result in injuries from the rotating propeller. The motor should be disconnected from
the power source when it is not in use or is o the water. When connecting the power-supply cables of the motor to the battery, ensure
that they are not kinked or subject to chafe and route them in such a way that persons cannot trip over them. Before using the motor
make sure that the insulation of the power cables is not damaged. Disregarding these safety precautions may result in electric shorts
of battery(s) and/or motor. Always disconnect motor from battery(s) before cleaning or checking the propeller. Avoid submerging the
complete motor as water may enter the lower unit through control head and shaft. If the motor is used while water is present in the lower
unit considerable damage to the motor can occur. This damage will not be covered by warranty.
WARNING
Take care that neither you nor other persons approach the turning propeller too closely, neither with body parts nor with objects. The
motor is powerful and may endanger or injure you or others. While the motor is running watch out for persons swimming and for floating
objects. Persons whose ability to run the motor or whose reactions are impaired by alcohol, drugs, medication, or other substances
are not permitted to use this motor. This motor is not suitable for use in strong currents. The constant noise pressure level of the motor
during use is less than 70dB(A). The overall vibration level does not exceed 2,5 m/sec2.
WARNING
It is recommended to only use Johnson Outdoors approved accessories with your Minn Kota motor. Using non-approved accessories
including to mount or control your motor may cause damage, unexpected motor operation and injury. Be sure to use the product and
approved accessories, including remotes, safely and in the manner directed to avoid accidental or unexpected motor operation. Keep all
factory installed parts in place including motor and accessory covers, enclosures and guards.
WARNING
When stowing or deploying the motor, keep fingers clear of all hinge and pivot points and all moving parts. In the event of unexpected
operation, remove power leads from the battery.

4 | minnkotamotors.com ©2023 Johnson Outdoors Marine Electronics, Inc.
KNOW YOUR BOAT
Keel
Bow
Hull
Bow
Stern
Stern
Port
Port Starboard
Starboard
Gunwale
Gunwale
Transom
Inboard
Outboard

Item /
Assembly Part # Description Qty.
A
Includes
1 - 4 2994864 BAG ASSEMBLY - (BOLT, NUT, WASHERS) 1
12263462 BOLT-MOUNTING-1/4X2 W/STG 6
22261713 WASHER-1/4 6
32263103 NUT NYLOK 1/4-20 MTG 6
42301720 WASHER-MOUNTING RUBBER 6
U
Includes
5 - 8 1378170 PROP KIT 2091170 PWR PRP 1
52091170 PROP-PRW (3 5/8") REAMED 1
62151726 WASHER-5/16 SS 1
72053101 NUT-PROP,NYLOC (MED) 5/16 SS 1
82092600 PIN-DRIVE 1.06" LG SS 1
9✖MOTOR ASSEMBLY 1
10 2390802 tLANYARD W/CARABINR, IP RMT 1
11 2994175 tREMOTE ASM, MICRO REMOTE 1
12 411690-1 tIPILOT 4.0 REMOTE 1
13 2394110 tTAG, MICRO REMOTE 1
14 490384-4 tCABLE, ETHERNET (M12-M12) 30' 1
15 490380-1 tCABLE, ETHERNET PIGTAIL-700 HD 1
D
Includes 16 2996300 TIE WRAP ASM, 60" 1
16 2206300 TIE WRAP, LOW PROFILE 4" 10
p2394911 tQCK REF.GUIDE, iP MICRO RMT BT 1
p2397115 tGUIDE-QCK REFERENCE IP 4.0 1
p2317127 INSTRC-INSTALL, RT PD SW 1
p2297165 MANUAL-DISCLAIMER,DWNLOAD INFO 1
p2294950 OBN & REMOTE PAIR INSTRUCT 1
p2207131 STANDARD QS SETUP GUIDE 1
2
3
5
7
9
13
11
4
1
12
A
U
pNot shown on Parts Diagram.
✖This part is included in an assembly and cannot be ordered individually.
tOnly available with models factory installed with GPS.
15
14
8
10
6
16
D
minnkotamotors.com | 5
©2023 Johnson Outdoors Marine Electronics, Inc.
INSTALLATION
INSTALLING THE RIPTIDE POWERDRIVE
Your new Riptide PowerDrive comes with everything you’ll need to directly install it to the boat. This motor can be directly mounted
to the boat or coupled with a Minn Kota quick release bracket for ease of mounting and removal. For installation with a quick release
bracket, refer to the installation instructions provided with the bracket. For compatible quick release mounting brackets and to locate
your nearest dealer, visit minnkotamotors.com. To install the motor directly to the boat, please follow the instructions provided in this
manual. Please review the parts list, mounting considerations and tools needed for installation prior to getting started. For additional
product support, please visit minnkotamotors.com.
INSTALLATION PARTS LIST

6 | minnkotamotors.com ©2023 Johnson Outdoors Marine Electronics, Inc.
INSTALLING THE RIPTIDE POWERDRIVE
• #3 and #2 Phillips Screw Driver
• Drill
• 9/32” Drill Bit
• 7/16” Box End Wrench
• A second person to help with the
installation
• Pliers or Vice Grip
It is recommended that the motor be mounted as close to the centerline of the boat as
possible. Make sure the area under the mounting location is clear to drill holes and install
nuts and washers. Make sure the motor rest is positioned far enough beyond the edge of
the boat. The motor must not encounter any obstructions as it is lowered into the water
or raised into the boat when stowed and deployed. Consider a quick release or adapter
bracket with the installation of your motor. To view a list of accessories, please visit
minnkotamotors.com.
INSTALLING THE RIPTIDE POWERDRIVE
MOUNTING CONSIDERATIONS
TOOLS AND RESOURCES REQUIRED
View accessories
available for your
trolling motor at
minnkotamotors.com.
INSTALLATION
a. Make sure that the Power Cables from the battery
are disconnected, or that the breaker, if equipped,
is "o". Power CablesPower Cables
1
WARNING
Make sure the motor is mounted on a level surface and is not
connected to a power source.
NOTICE: The Riptide PowerDrive has no power switch. When the Power Cables are connected to a battery, the Riptide
PowerDrive is "on". When the Power Cables are disconnected from the battery, the Riptide PowerDrive is "o". If the Power
Cables are connected to a breaker, the Riptide PowerDrive is "on" when the breaker is "on" and "o" when the breaker is "o".

minnkotamotors.com | 7
©2023 Johnson Outdoors Marine Electronics, Inc.
INSTALLING THE RIPTIDE POWERDRIVE
d. Remove the Right Sideplate.
e. Swing the Left Sideplate out and away from the
Base Extrusion.
Right SideplateRight Sideplate
LeftLeft
SideplateSideplate
Base ExtrusionBase Extrusion
3
3d
3e
b. Place the mount on an elevated, level surface such
as a workbench or the tailgate of a pickup. The
motor, as removed from the box, should be in the
stowed position.
c. Remove the four sideplate screws using a #3 or #2
Phillips screwdriver. Two of these screws will be
located on each side of the mount.
DeployedDeployed StowedStowed
Sideplate ScrewSideplate Screw
NOTICE: This motor weighs approximately 30 lbs.
We recommend having a second person help with
the installation.
2
2c
2b

8 | minnkotamotors.com ©2023 Johnson Outdoors Marine Electronics, Inc.
INSTALLING THE RIPTIDE POWERDRIVE
f. Place the mount as close to the centerline or keel of
the boat as possible. The motor can be installed on
either the Port or Starboard side of the boat based
on personal preference. Check
placement with the
motor in the stowed and deployed positions.
Review
the mounting considerations at the beginning of
the installation.
Deck of Boat
KeelKeel
4
g. When the motor is in the deployed position, make
sure that the Shaft is 1-1/2" out past the Gunwale of
the boat. The lower unit, when stowed and deployed
must not encounter any obstructions.
h. Check to be sure that the mount is level. Use the
Rubber Washers (Item #4) provided to create a level
surface if necessary.
i. It is recommended to mark at least 6 of the 12 holes
in the Base Extrusion and to have a minimum of
two bolts on each side that are located the farthest
apart. Ideal installation would allow for 6 bolts to be
used, with a minimum of 4.
j. Drill through the deck of the boat using a 9/32" Drill
Bit on the marked locations.
ITEM(S) NEEDED
#4 x 6
Drilling Locations
Drilling Locations
1-1/2"1-1/2"
MinimumMinimum
GunwaleGunwale
Shaft
Base Extrusion
5
6

minnkotamotors.com | 9
©2023 Johnson Outdoors Marine Electronics, Inc.
INSTALLING THE RIPTIDE POWERDRIVE
k. Put a 1/4-20 x 3-1/2" (Item #1) Mounting Bolt in
each of the drilled locations. The Mounting Bolt
should pass through the Base Extrusion and the
boat deck. If the Rubber Washers (Item #4) are
used, they should sit between the Base Extrusion
and boat deck. Make sure to secure the motor with
screws on each side of the Base Extrusion.
ITEM(S) NEEDED
#1 x 6
#4 x 6
7
l. Place a Flat Washer (Item #2) and then a Nylock Nut
(Item #3) at the end of each Mounting Bolt as shown
and secure. Make sure all hardware is secure.
#2 x 6 #3 x 6
NOTICE: To prevent seizing of the stainless steel
hardware, do not use high speed installation tools.
Wetting the screws or applying an anti-seize may help
prevent seizing.
8ITEM(S) NEEDED
Mounting Bolt
Rubber WasherRubber Washer
Boat DeckBoat Deck
Mounting Bolt
Rubber WasherRubber Washer
Nylock Nut
Flat Washer Boat DeckBoat Deck

10 | minnkotamotors.com ©2023 Johnson Outdoors Marine Electronics, Inc.
INSTALLING THE RIPTIDE POWERDRIVE
m. Replace the Right Sideplate.
n. Swing the Left Sideplate back into its correct
position on the Base Extrusion.
9
Right SideplateRight Sideplate LeftLeft
SideplateSideplate
Base ExtrusionBase Extrusion
9m
9n
o. Replace the four Sideplate Screws using a #3 or
#2 Phillips screwdriver. Two of these screws will be
located on each side of the mount.
10
Sideplate ScrewSideplate Screw
