Minnich M-GEN 115V Owner's manual

Minnich
HIGH CYCLE GENERATOR
OWNER/OPERATOR MANUAL
Minnich Manufacturing
1444 ST RT 42
Mansfield,OH 44903
Contact
Phone: [phone]
Email: [email protected]

High cycle Generator Manual 2
TABLE OF CONTENTS
Your new Minnich High Cycle generator was
carefully designed and manufactured to
give years of dependable service. To keep it
running efficiently, read the instructions in this
manual thoroughly. It contains detailed de-
scriptions and instructions for the efficient op-
eration and maintenance of your High Cycle
Generator. Each section is clearly identified
so you can easily find the information that
you need. All instructions are recommended
procedures only.
If there are any questions regarding the ma-
chine or its application which are not covered
in this manual or in other literature accompa-
nying this unit, please contact your Minnich
Dealer or Minnich Manufacturing at 419-903-
0010 or [email protected]
It is Minnich’s policy to constantly strive to
improve our products. The information, spec-
ifications, and illustrations in this publication
are based on the information in effect at the
same time as approval for printing and pub-
lishing. Minnich therefore reserves the right
to make changes in design and improve-
ments whenever it is believed the efficiency
of the machine which has been shipped or
curring any obligation to incorporate such im-
provements in any machine which has been
shipped or is in service. It is recommended
that users contact Minnich or a Minnich Deal-
er for latest revisions.
Chapter 1-Introduction...............................................................................................................................................2
General Warnings............................................................................................................................................3
General Safety..................................................................................................................................................4
General Specifications..................................................................................................................................12
Safety Decal Location...................................................................................................................................14
Chapter 2-Parts Manual............................................................................................................................................15
Parts Manual (115V).......................................................................................................................................15
Parts Manual (230V)......................................................................................................................................16
Motor Parts Sheet..........................................................................................................................................17
Generator Wiring Instructions.....................................................................................................................18
General Specifications (GX270)..................................................................................................................19
General Engine Information........................................................................................................................20
Parts Manual..................................................................................................................................................21
Notes...............................................................................................................................................................35
Warranty..........................................................................................................................................................36
Parts Ordering Online.................................................................................................................................37

3
High cycle Generator Manual
GENERAL WARNINGS
CALIFORNIA PROPOSITION 65
Engine exhaust and some of its constituents,
and some dust created by power sanding,
sawing, grinding, drilling and other construction
activities contains chemicals known to the Sate
of California to cause cancer, birth defects and
other reproductive harm. Some examples of
these chemicals are:
Lead from lead-based paints.
Crystalline silica from bricks.
Arsenic and chromium from chemically treated
lumbar.
Your risk from these exposures caries, depend-
ing on how often you do this type of work. To
reduce your exposure to these chemicals:
ALWAYS work in a well ventilated area, and
work with improved safety equipment, such
as dust masks that are specifically designed to
filter out microscopic particles.
SILICOSIS WARNING
Grinding/cutting/drilling of masonry, concrete,-
metal and other materials with silica in their
composition may give off dust or mist contain-
ing crystalline silica.
Silica is a basic components of sand, quarts,
brick clay, granite and numerous other minerals
and rocks. Repeated and/or substantial inha-
lation of airborne crystalline silica can cause
serious or fatal respirator disease, including sil-
icosis. In addition, California and some author-
ities have listed repairable crystalline silica as a
substance known to cause cancer. When cutting
such materials, always follow the respiratory
precautions mentioned above.
RESPIRATORY HAZARDS
Grinding/cutting/drilling of masonry, concrete,metal and fumes containing
chemicals known to cause serious or fatal injury or illness, such as respirato-
ry disease, cancer, birth defects or other reproduction harm, if you are
unfamiliar with th risks associated with the particular process and/or materi-
al being cut or the composition of the tool being used, review the material
safety data sher and/or consult your employer, the material manufacturer/
supplier, governmental agencies such as OSHA and NIOSH and other
sources on hazardous materials. California and some other authorities, for
instance, have published lists of substances known to cause cancer, repro-
ductive toxicity or other harmful effects.
Control dust, mist and fumes at the source where possible. In this regard use good work practices and
follow the recommendations of the manufactures of suppliers, OSHA/NIOSH, and occupational and
trade associations. Water should be used for dust suppression when wet cutting is feasible. When the
hazards from inhalation of dust, mist and fumes cannot be eliminated, the operator and any bystand-
ers should always wear a respirator approved by NIOSH/MSHA for the materials being used.

High cycle Generator Manual 4
GENERAL SAFETY
SYMBOL SAFETY HAZARD
Lethal exhaust gas hazards
Explosive fuel hazards
Burn hazard
Overspeed hazards
Electrocution/Shock Hazard
SAFETY SYMBOLS
Potential hazards associated with the operation
of this equipment will be referenced with hazards
symbols witch may appear throughout this manual
in conjunction with safety messages.
Indicates a hazardous situation witch, if not
avoided, COULD result in DEATH or SERI-
OUS INJURY
Indicates a hazardous situation witch, if not
avoided, COULD result in MINOR or MOD-
ERATE INJURY
Indicates a hazardous situation witch, if not
avoided, WILL result in DEATH or SERIOUS
INJURY
Addresses practices not related to personal
injury
SAFETY MESSAGES
The four safety messages shown below will
inform you about potential hazards that could
injure you or others. The safety messages specif-
ically address the level of exposure to the opera-
tor and are preceded by one of four words:
DANGER, WARNING, NOTICE or NOTICE.
Do not operate or service the equipment before
reading the entire manual. Safety precautions
should be followed at all times when operating this
equipment. Failure to read and understand the safe-
ty messages and operating instructions could result
in injury to yourself and others.
This operation manual has been developed to pro-
vide complete instruction for the safe and efficient
operation. Refer to the engine manufactures instruc-
tions for data relative to its safe operation. Before
using, ensure that the operation individual
has read and understood all instructions in
the manual. The surrounding environment and
you, could be damaged if you do not follow instruc-
tions.
DO NOT USE TOOL IF IT IS IN NEED OF SERVICE!

5
High cycle Generator Manual
GENERAL SAFETY
∆ NEVER operate this equipment without
proper protective clothing, shatter proof
glasses, respirator protection, hearing pro-
tection, steel-toes boots and other protec-
tive devises required by the job or city and
sate regulations.
∆ Never operate this equipment
when not feeling well due to
fatigue, illness or when under
medication.
∆ NEVER operate this equipment under the
influence of drugs or alcohol.
∆ ALWAYS check the equipment for loosened
threads or bolts before starting.
∆ NEVER operate around corrosive chemicals
or water containing toxic substances. These
fluids could create serious health and envi-
ronmental hazards. Contact local authorities
for assistance.
∆ DO NOT use the equipment for any purpose
other than its intended purpose or applica-
tions.
∆ This equipment should only be operated by
trained and qualified personnel 18 years of
age and older.
∆ This equipment is for industrial use only.
Whenever necessary, replace nameplate,
operation and safety decals when
they become difficult to read.
∆ Manufacturer does not assume responsibility
for any accident due to equipment modifica-
tions. Unauthorized equipment modifications
will void all warranties. Any modification
which it could lead to change in the original
characteristics of the machine should be
made only by the manufacturer who shall
confirm that the machine is in comfortability
with appropriate safety regulations.
∆ Never use accessories or attachments that are
not recommended by Minnich for the equip-
ment. Damage to the equipment and/or injury
to user may result.
∆ ALWAYS know the location of the
nearest fire extinguisher.
∆ ALWAYS know the location of the
nearest first aid kit.
∆ ALWAYS know the location of the nearest
phone or keep a phone on the job site. Also,
know the phone numbers of the nearest
ambulance, doctor and fire department. This
information will be invaluable in the case of an
emergency.
∆ NEVER operate the equipment in an
explosive atmosphere, near combus-
tible materials, or near flammable or
low flash point fluids. An explosion or
fire could result causing severe bodily
harm or even death.
∆ NEVER disconnect any emergency or safety
devices. These devises are intended for op-
erator safety. Disconnection of these devices
can cause severe injury, bodily harm or even
death. Disconnection of any of these will void
all warranties.
∆ NEVER operate equipment with the covers or
guards removed. Keep fingers, hands, hair and
clothing away from all moving parts to prevent
injury. Wear clothing that will not likely be-
come caught in the equipment or snag on any
moving parts.
∆ALWAYS be sure the operator is familiar
with the proper safety precautions and op-
erating techniques before using.
∆NEVER leave the machine unattended.
Turn off when unattended

High cycle Generator Manual 6
GENERAL SAFETY
∆ DO NOT expose vibrator to rain.
∆ DO NOT use vibrator motor in damp or wet
locations without proper electrical circuits.
∆ DO NOT immerse the motor part in con-
crete.
∆ ALWAYS keep clear of rotating or moving
parts while operating.
∆ NEVER leave the machine unattended while
running
∆ ALWAYS disconnect the motor from the
power source when not in use, before servic-
ing, and when changing flexible shafting and
vibrator heads.
∆ Allow the machine to cool
before servicing. Contact with
hot components can cause
serious burns.
∆ Before Each use, ALWAYS check the motor
to make certain that there are no damaged
parts and that all parts function properly.
If any damage or malfunctioning parts are
found, have them repaired or replaced by an
authorized service facility.
∆ ALWAYS secure forms. Make sure the form
work is well made and braced to withstand
the stresses made by vibration.
∆ ALWAYS keep vibrator motor clean for bet-
ter and safer operation.
∆ ALWAYS store equipment properly when
it is not being used. Equipment should be
stored in a clean, dry location out of reach
of children and unauthorized personnel.
∆ Use only factory authorized replacement
parts.
∆ Store idle vibrator motor. When not in use,
motor should be stored in a dry, safe stor-
age area.
ELECTRICAL SAFETY
∆ Power tools must match the outlet. NEVER
modify the plug in any way. DO NOT use the
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets
will reduce risk of electric shock.
∆ Avoid contact with earthed or grounded
surfaces such as pipes, radiators ranges and re-
frigerators. There is an increase risk of electric
shock if your body is earthed or grounded.
∆DO NOT expose power tools to rain or wet
conditions. Water entering a power tool will
increase risk of electric shock.
∆DO NOT abuse power cord. NEVER use the
cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil
sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric
shock.
∆ When operating a power tool outside use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk
of electric shock.
∆ This unit is double-insulated. The double in-
sulation between the electric-conducting part
and the outside frame makes grounding un-
necessary. However, if parts are replaced with
wrong parts or assembled incorrectly, the ma-
chine may become unsafe to operate. Use only
Minnich Recommended replacement parts.
∆ When applicable, use a protection wiring de-
vice such as a Ground Fault Circuit Interrupter,
for the protection of personnel.
∆ Operate electric motor only at the specific volt-
age indicated on the nameplate.
∆DO NOT spray water onto electric motor.
∆DO NOT yank the cord to disconnect it from
the receptacle. Grasp the plus itself to discon-
nect it.
∆ALWAYS make sure the ON/OFF switch is in
the OFF position hen not in use, and before
inserting the power plug into an AC replace-
ment.
∆ Before plugging the motor into a power source,
ALWAYS remove any wrenches or other tools
from the motor, shaft, and head that were used
for assembly.
∆ When operating a power tool outside, use
Outdoor extension cords marked “W-A” or
“W”. These cords are rated for outdoor use
And reduce the risk of electric shock.
∆ DO NOT abuse the cord. Never use the
cord to carry the tools or pull the plug from
an outlet. Keep cord away from heat, oil,
sharp edges, or moving parts. Replace dam-
aged cords immediately. Damaged cords
increase the risk of electric shock.

7
High cycle Generator Manual
GENERAL SAFETY
POWER CORD/CABLE SAFETY
∆ ALWAYS use a grounded 3-wire extension
cord that has a 3-prong grounding plug, and
a 3-pole receptacle that accepts the plug on
the concrete vibrator motor. DO NOT REMOVE
THE GROUNDING PIN FROM THE PLUG!
∆ NEVER let power cords or cables lay in water.
∆ NEVER use damaged or worn cables or cords
when connecting equipment to generator.
Inspect for cuts in the insulation.
∆ NEVER grab or touch a live pow-
er cord or cable with wet hands.
The possibility exists of electrical
shock, electrocution or death
∆ Make sure power cables are securely connect-
ed. Incorrect connections may cause electrical
shock and damage to the machine.
∆ Ensure that cables and cords will not be
tripped over.
∆ ALWAYS make certain that proper power or
extension cord has been selected for the job.
∆ Use only extension cords that are intended for
outdoor use and so marked
∆ Use only the gauge wire and length of cord
recommended for the motor size. If in doubt,
go to the next heavier gauge. (The smaller the
gauge the heavier the cord.)
POWER TOOL USE AND CARE
∆ DO NOT use the vibrator if the switch does
not turn it on and off. Any vibrator than cannot
be controlled with the switch is dangerous and
must be repaired.
∆ Disconnect the plug from the power cord
source before making any adjustments, chang-
ing accessories, or storing vibrators. Such
preventative safety measures reduce the risk of
starting the vibrators accidentally.
∆ Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts
and any other condition that may effect the
power tools operation. If damaged, have the
vibrator tool repaired before use.
SERVICE
∆ Have your vibrators serviced by a qualified
repair person using Minnich replacement
parts. This will ensure the safety of the vibra-
tor/generator is maintained.
∆ DO NOT pour waste or oil directly on to
the ground, down a drain or into any water
source.
ENVIRONMENTAL SAFETY/DECOMMISSIONING
∆ Contact you country department
of Public Works or recycling
agency in your area and arrange
for proper disposal of any elec-
trical components, waste or oil
associated with this equipment.
ELECTRICAL SAFETY
∆ Turn generator OFF before preforming main-
tenance on the generator or making contact
with the output receptables.
∆NEVER insert any objects into the output re-
ceptables during operation. This is extremely
dangerous. The possibility exists of electrical
shock, Electrocution or death.
GROUNDING SAFETY
∆ ALWAYS make sure that electrical circuits
are properly grounded to a suitable earth
ground (ground rod) per the National Elec-
trical Code (NEC) and local codes before
operating generator. Serve injury or death by
electrocution can result from operating an
ungrounded generator.
∆ NEVER use gas piping as an electrical
ground.
Electric shock can occur when vi-
brators are used. Pay close atten-
tion to handling when operating
vibrators and always use rubber
boots and gloves to insulate the
body from a short circuit.

High cycle Generator Manual 8
GENERAL SAFETY
∆ Store fuel in appropriate containers, in well- ven-
tilated areas and away from sparks and flames.
∆ NEVER use fuel as a cleaning agent.
TRANSPORTING
∆ ALWAYS shut down engine before transporting.
∆ Tighten fuel cap securely and close fuel cock to
prevent fuel from spilling.
∆ ALWAYS use proper lifting techniques when
using or moving the machine assembly.
∆ Contact your country’s Department
of Public Works or recycling agency
in your area and arrange for proper
disposal of any electrical compo-
nents, waste or oil associated with
this equipment.
∆ When the life cycle of this equipment is over,
remove battery (if equip) and bring to appro-
priate facility for lead reclamation. Use safety
precautions when handling batteries that
contain sulfuric acid.
∆ When the life cycle of this equipment is over,
it is recommended that the unit frame and
all other metal parts be sent to a recycling
center.
Metal recycling involves the collection of
metal from discarded products and its trans
formation into raw materials to use in many
Manufacturing a new product.
Recyclers and manufactures alike promote the
process of recycling center promotes energy
cost savings.
EMISSIONS INFORMATION
∆ DO NOT smoke around or
near the equipment. Fire or
explosion could result from
fuel vapors or if fuel is spilled
on hot engine.
Decommissioning is a controlled process used to
safely retire a piece of equipment that is no longer
serviceable. If the equipment poses an unaccept-
able and unrepairable safety risk due to wear or
damage or is no longer cost effective to maintain
(beyond life-cycle reliability) and is to be decommis-
sioned (demolition and dismantlement), be sure to
follow rules below.
∆ ALWAYS observe all applicable compulsory reg-
ulations relevant to environmental protection,
especially fuel storage, the handling of hazard-
ous substances, and the wearing of protective
clothing and equipment. Instruct the user as a
necessary, or, as the user, request this informa-
tion and training.
∆ ALWAYS Dispose of hazardous waste properly.
Examples of potentially hazardous waste include
used motor oil, fuel, and fuel filters.
∆ DO NOT use food or plastic containers to dis-
pose hazardous waste.
∆ DO NOT pour waste or oil directly onto the
ground, down or drain or into any waste source.
The gasoline engine used in this equipment has
been designed to reduce harmful levels of carbon
monoxide (CO), hydrocarbons (HC) and nitrogen
oxides (NOx) contained in gasoline exhaust emis-
sions.
This engine has been certified to meet US EPA
Evaporative emission requirements in the installed
configuration.
Attempting to modify or make adjustments to the
engine emission, system by unauthorized per-
sonnel without proper training could damage the
equipment or create an unsafe condition.
Additionally, modifying the fuel system may ad-
versely affect evaporative emissions, resulting in
fines or other penalties.
EMISSION CONTROL LABEL
The emission control label is an integral part of the
emission system and is strictly controlled by regula-
tion(s).
The label must remain with the engine for its entire
life.
If a replacement emission label is needed, please
contact your authorized Honda Engine Distributor.
If Applicable....
DO NOT USE TOOL IF IT IS IN NEED OF SERVICE!

9
High cycle Generator Manual
GENERAL SAFETY
∆ NEVER lubricate components or attempt service
on a running machine.
∆ ALWAYS allow the machine a proper amount of
time to cool before servicing.
∆ ALWAYS keep the machine in proper running
condition.
∆ ALWAYS become familiar with the components
of the machine before operation.
∆ Fix damage to machine and replace any broken
parts immediately.
∆ ALWAYS store equipment properly when it is
not being used. Equipment should be stored in
a clean, dry location out of the reach of children
and unauthorized personnel.
ENGINE SAFETY
∆ The engine fuel exhaust gases contain poison-
ous carbon monoxide. This gas is colorless and
odorless, and can cause death if inhaled.
∆ The engine of this equipment requires an ade-
quate free flow of cooling air. NEVER operate
this equipment in any enclosed or narrow area
where free flow of the air is restricted. If the air
flow is restricted it will cause injury to people
and property and serous damage to the equip-
ment or engine. Remember the engine gives off
deadly gases.
∆ NEVER operate the engine with heat shields or
guards removed.
∆ DO NOT remove the engine oil drain plug while
the engine is hot. Hot oil will gush out of the
engine crankcase and severely scald any persons
in the general area of the machine.
∆ NEVER touch the hot exhaust mani-
fold, muffler or cylinder. Allow these
parts to cool before servicing equip-
ment.
∆ ALWAYS place the engine ON/OFF switch in
the OFF position when the machine is not in
use.
∆ Refer to the engine Owners Manual for
engine technical questions or information (if
applicable).
∆NEVER run engine without an air filter or with
a dirty air filter. Severe engine damage may
occur. Service air filter frequently to prevent
engine malfunction (if applicable).
∆ State health safety codes and Public Resourc-
es Code specify that in certain locations, spark
arrester must be used on internal combustion
engines the used hydrocarbon fuels. A spark
arrester is a device designed to prevent acci-
dental discharge of sparks or flames from the
engine exhaust. Spark arrestors are qualified
and rated by the United States Forecast Ser-
vice for this purpose. In order to comply with
local laws regarding spark arresters, consult
the engine distributor of the local Health and
Safety Administrator (if applicable).
Fuel Safety
∆ DO NOT add fuel to equipment if it is placed
inside truck bed with plastic liner. Possibility
exist of explosion or fire due to static electric-
ity.
∆ DO NOT start the engine near spilled fuel or
combustion fluids. Gasoline fuel is extremely
flammable and its vapors can cause an explo-
sion if ignited.
∆ ALWAYS refuel in a well-ventilated area, away
from sparks and open flames.
∆ ALWAYS use extreme caution when working
with flammable liquids.
∆ DO NOT fill the fuel tank while the engine is
running or hot.
∆ DO NOT overfill tank, since spilled fuel could
ignite if it come into contact with hot engine
parts or sparks from the ignition system.
∆ NEVER tamper with the factory
settings of the engine or en-
gine governor. Damage to the
engine or equipment can result
in operation in speed ranges
above the maximum allowabil-
ity.

High cycle Generator Manual 10
GENERAL SAFETY
To find the latest revision of this publication,
visit our website at: www.minnich-mfg.com
THIS MANUAL MUST ACCOMPANY THE
EQUIPMENT AT ALL TIMES.
Specifications and part numbers are subject
to change without notice.
∆ Stay alert, watch what you are doing, and use
common sense when operating the Minnich
Equipment.
∆ DO NOT use the Minnich equipment while
tired or under the influence of drugs, alcohol,
or medication. A moment of inattention while
operating power tools may result in serious
personal injury or death.
∆ Dress properly. DO NOT wear loose clothing or
jewelry. Tie up long hair. Keep your hair, cloth-
ing and gloves away from moving parts. Loose
clothes, jewelery, or long hair can be caught in
moving parts.
∆ DO NOT overreach. Keep proper footing and
balance at all times. Proper footing and balance
enables better control in unexpected situations.
∆ DO NOT force any tool. Use the correct tool for
your application. The correct tool will do the
job better and safer at the rate for which it is
designed.
∆ DO NOT use the tool if the switch does not
turn on or off. Any tool that cannot be con-
trolled with the switch is dangerous and must
be repaired.
∆ Check misalignment or binding of moving
parts, breakage of parts and any other con-
dition that may effect the tools operation. If
damaged, have your Minnich equipment ser-
viced before using. Many accidents are caused
by poorly maintained equipment.
∆ Use only accessories that are recommended by
the manufacturer for you model. Accessories
that may be suitable for one tool may become
hazardous when used on another.
PERSONAL SAFETY
TOOL USE AND CARE
SERVICE
∆ Equipment service must be preformed only
by qualified repair personnel. Service or main-
tained preformed by unqualified personnel
could result in injury or death
∆ When servicing a Minnich equipment, use
only identical replacement parts. Use of un-
authorized parts may create a risk of injury or
death.
∆ The engine fuel exhaust gases contain poisonous
carbon monoxide. This gas is colorless and odor-
less, and can cause death if inhaled.
∆ The engine of this equipment requires an ade-
quate free flow of cooling air. NEVER operate this
equipment in any enclosed or narrow area were
free flow of the air is restricted it will cause injury
to people and property and serious damage to
the equipment or engine.
∆ NEVER operate the equipment in
an explosive atmosphere or near
combustible materials. An explo-
sive or fire could result causing
severe bodily harm.
∆ DO NOT start the engine near spilled fuel or
combustible fluids. Fuel is extremely flammable
and its vapors can cause an explosion if ignited.
∆ ALWAYS refuel in a well-ventilated area, away
from sparks and open flames
∆ ALWAYS use extreme caution when working with
flammable liquids.
∆ DO NOT fill the fuel tank while the engine is run-
ning or not.

11
High cycle Generator Manual
GENERAL SAFETY
CONNECTING GENERATOR TO THE THE GROUND
The nut and ground terminal on the generator should
always be used to connect the generator to the suit-
able ground. The ground cable should be #8 size wire
(aluminum) minimum. If copper wire is used, #10 size
wire minimum should be used.
At the generator, connect the terminal of the ground
cable between the look washer and the nut and tight-
en the nut fully. Connect the other end of the ground
cable to a suitable earth ground (ground rod).
Electric shock can occur when vi-
brators are used. Pay close atten-
tion to handling when operating
vibrators and always use rubber
boots and gloves to insulate the
body from a short circuit.
To guard against electric shock and possible dam-
age to the equipment, it is important to promote a
god EARTH ground.
Article 250 (grounding) of the National Electri-
cal Code (NEC) provides guide lines for proper
grounding and connect to the grounding system of
the building as close to the point of cable entry as
practice;
NEC article 250-64(b) and 250-66 set of the follow-
ing grounding requirements:
1.Use one of the following wire types to connect
the generator to the earth ground.
•Copper - 10 AWG (5.3 mm^2) or larger.
•Aluminum - 8 AWG (8.4 mm^2) or larger
2.When grounding the generator connect the
ground cable between the lock washer and the
nut on the generator and tighten the nut fully.
Connect the other end of the ground cable to
the earth ground.
3.NEC article 250-52(c) specifies that the earth
ground rod should be buried a minimum of 8
ft. into the ground.
When any generator to any buildings electri-
cal system ALWAYS with a licensed electrocu-
tion

High cycle Generator Manual 12
GENERAL SPECIFICATION
High cycle Generator Models
MODEL M-GEN 115V M-GEN 230V
Type of Power Honda 8 HP 1 Cycle Honda 8 HP 1 Cycle
Power 8.0 HP (6.0kw) 8.0 HP (6.0kw)
RPM 3600 3600
Volta @ 180 Cycle 150V 230V
AC Output 4kw 180cy 3ph 4kw 180cy 3ph
Number of Receptacles 2 2
Weight 170 lbs (77.1kg) 170 lbs (77.1kg)

13
High cycle Generator Manual
SAFETY DECAL LOCATION
All safety labels on Minnich Manufacturing
units have been carefully placed so they can
be easily seen at all times. There are several
different types of labels on the units. Always
keep these warnings free of dirt, concrete,
or anything else that restricts visibility. Never
remove the labels for any reason. If the label
on your machine become worn or in any way
difficult to read, call our parts department for
replacements.
ABE
Gc
THE ENGINE EXHAUST FROM THIS PRODUCT CONTAINS
CHEMICALS KNOWN TO THE STATE OF CALIFORNIA
TO CAUSE CANCER, BIRTH DEFECT, OR OTHER
REPRODUCTIVE HARM
.
2
3
0
v
-
1
8
0
H
z
m
i
n
n
i
c
h
-
m
f
g
.
c
o
m
4
1
9
-
9
0
3
-
0
0
1
0
F
H
d
1
1
5
v
-
1
8
0
H
z

High cycle Generator Manual 14
SAFETY DECAL LOCATION
D
GH
EF
c
B
A
2
3
0
v
-
1
8
0
H
z
m
i
n
n
i
c
h
-
m
f
g
.
c
o
m
4
1
9
-
9
0
3
-
0
0
1
0
THEENGINEEXHAUST FROM THIS PRODUCT CONTAINS
CHEMICALSKNOWNTO THE STATEOF CALIFORNIA
TOCAUSECANCER, BIRTH DEFECT, OR OTHER
REPRODUCTIVEHARM
.

15
High cycle Generator Manual
PARTS MANUAL (115V)
NOT SHOWN: A12566-1 DECAL KIT, 115V M-GEN
30
36
25
11
27
34
2
19
23 32
20
8
6
33
10
22
1 21
5
26
28
3
4
29
7
24
13
12
9
14
15
18
16
17
31
These size and tolerances are
for holes drilled with drilling
machines such as mills or
lathes, drill presses, or waterjet
operations. The following are
standard tolerances for
general machine work and
apply in all cases except
where greater or lesser
accuracy is required by
design and noted.
Drilled Hole Size
Tolerance
.0135 THRU .125
+.004/-.001
.1260 THRU .250
+.005/-.001
.2510 THRU .500
+.006/-.001
.5010 THRU .750
+.008/-.001
.7510 THRU 1.00
+.010/-.001
1.001 THRU 2.00
+.012/-.001
ITEM NO.
PART NUMBER
DESCRIPTION
QTY.
1 708
SERIAL TAG
1
2
3016-44
HANDLE - GRIP
1
3
3016-125
GROUND CONNECTOR
2
4
3016-126
GROUND WIRE
7in.
5
3016-141
VOLT METER 0-300 VAC
1
6
3017-19 WHEEL
2
7
3018-28
ISOLATOR
5
8 4674
AXEL WASHER
3
9
6036-.75
1/4-20 X 3/4 HHCS GR.5 1
10
6036-1.00 HHCS 1/4-20 X 1"
4
11
6038-2.25
HHCS, 3/8-16 X 2.25 GR.5
1
12
6057-0.625
HHCS, 5/16-24 X 5/8 GR.5 2
13
6057-0.75
HHCS, 5/16-24 X 3/4 GR.5 3
14
6057-1.25
HHCS, 5/16-24 X 1.25 GR.5
4
15 6070
1/4-20 HEX NUT
1
16 6106
WASHER 5/16"
8
17 6147
LOCKWASHER 1/4
1
18 6148
LOCKWASHER 5/16
9
19 6149
LOCK WASHER 3/8"
1
20
6174-1.00
COTTER PIN 1/8" X 1"
2
21
6262-1
SCREW, DRIVE HD RD. #4 X 1/4"
2
22 6402
1/4-20" LOCKNUT
4
23 6404
LOCKNUT 3/8"
1
24
6780-7
WING NUT 3/8-16
1
25 7282
CHAIN, SINGLE JACK #12
8in.
26
7724-9
NUT, HEX #10-32 BRASS
4
27
8479-3
LOCK PIN
1
28 10284
RINF TERMINAL
2
29 11561
SPACER
1
30 36037
HONDA ENGINE 8 H.P.
1
31 36038
GENERATOR (REF. ONLY)
1
32
36073-4
AXLE
1
33
36124-1
BENT FOOT
1
34
A11487
HANDLE WELDMENT
1
35
A13566-1
DECAL KIT, 115V M-GEN
1
36
A36031
FRAME WELDMENT
1
TOLERANCES
(EXCEPT AS NOTED) .X
.060
.XX
.030
.XXX
.005
X/X
1/16"
<
1
TITLE:
DRAWING NUMBER:
FIXTURE NO.
LOCATION
DO NOT SCALE DRAWING
DRAWN BY: CHECKED BY:
APPROVED BY:
ORIG DATE:
MINNICH MFG. CO., INC
.
THE INFORMATION SHOWN ON THIS DRAWING IS CONFIDENTIAL TO MINNICH MFG. & OUR CUSTOMERS & SHALL NOT BE
DISTRIBUTED TO THIRD PARTIES WITHOUT WRITTEN PREMISSION OF MINNICH MFG.
#
M-GEN 115V GENERATOR
A36033
05/28/2020
RJ
Dimension in accordance
with ANSI Y14
REV. LEVEL
RAWMATERIAL
MATERIAL
STOCKSIZE
ROUTING NO.
-

High cycle Generator Manual 16
PARTS MANUAL (230V)
NOT SHOWN: A12566 DECAL KIT, 230V M-GEN
30
36
25
11
27
34
2
19
23 32
20
8
6
33
10
22
1
21
5
2628
3
4
29
7
24
13
12
9
14
15
18
16
17
31
These size and tolerances are
for holes drilled with drilling
machines such as mills or
lathes, drill presses, or waterjet
operations. The following are
standard tolerances for
general machine work and
apply in all cases except
where greater or lesser
accuracy is required by
design and noted.
Drilled Hole Size
Tolerance
.0135 THRU .125
+.004/-.001
.1260 THRU .250
+.005/-.001
.2510 THRU .500
+.006/-.001
.5010 THRU .750
+.008/-.001
.7510 THRU 1.00
+.010/-.001
1.001 THRU 2.00
+.012/-.001
ITEM NO.
PART NUMBER
DESCRIPTION
QTY.
1 708
SERIAL TAG
1
2
3016-44
HANDLE - GRIP
1
3
3016-125
GROUND CONNECTOR
2
4
3016-126
GROUND WIRE
7in.
5
3016-141
VOLT METER 0-300 VAC
1
6
3017-19 WHEEL
2
7
3018-28
ISOLATOR
5
84674
AXEL WASHER
3
9
6036-.75
1/4-20 X 3/4 HHCS GR.5 1
10
6036-1.00 HHCS 1/4-20 X 1"
4
11
6038-2.25
HHCS, 3/8-16 X 2.25 GR.5
1
12
6057-0.625
HHCS, 5/16-24 X 5/8 GR.5 2
13
6057-0.75
HHCS, 5/16-24 X 3/4 GR.5 3
14
6057-1.25
HHCS, 5/16-24 X 1.25 GR.5
4
15
6070
1/4-20 HEX NUT
1
16
6106
WASHER 5/16"
8
17
6147
LOCKWASHER 1/4
1
18
6148
LOCKWASHER 5/16
9
19
6149
LOCK WASHER 3/8"
1
20
6174-1.00
COTTER PIN 1/8" X 1"
2
21
6262-1
SCREW, DRIVE HD RD. #4 X 1/4"
2
22
6402
1/4-20" LOCKNUT
4
23
6404
LOCKNUT 3/8"
1
24
6780-7
WING NUT 3/8-16
1
25
7282
CHAIN, SINGLE JACK #12
8in.
26
7724-9
NUT, HEX #10-32 BRASS
4
27
8479-3
LOCK PIN
1
28
10284
RINF TERMINAL
2
29
11561
SPACER
1
30
36037
HONDA ENGINE 8 H.P.
1
31
36038
GENERATOR (REF. ONLY)
1
32
36073-4
AXLE
1
33
36124-1
BENT FOOT
1
34
A11487
HANDLE WELDMENT
1
35
A13566
DECAL KIT, 230V M-GEN
1
36
A36031
FRAME WELDMENT
1
TOLERANCES
(EXCEPT AS NOTED) .X
.060
.XX
.030
.XXX
.005
X/X
1/16"
<
1
TITLE:
DRAWING NUMBER:
FIXTURE NO.
LOCATION
DO NOT SCALE DRAWING
DRAWN BY: CHECKED BY:
APPROVED BY:
ORIG DATE:
MINNICH MFG. CO., INC
.
THE INFORMATION SHOWN ON THIS DRAWING IS CONFIDENTIAL TO MINNICH MFG. & OUR CUSTOMERS & SHALL NOT BE
DISTRIBUTED TO THIRD PARTIES WITHOUT WRITTEN PREMISSION OF MINNICH MFG.
#
M-GEN 230V GENERATOR
A36035
05/29/2020
RJ
Dimension in accordance
with ANSI Y14
REV. LEVEL
RAWMATERIAL
MATERIAL
STOCKSIZE
ROUTING NO.
-

17
High cycle Generator Manual
MOTOR PARTS SHEETS
High Cycle Generator Electric Motor Parts Sheets
Part # Description Qty.
036745-00000 Inboard Endbell 1
036038-00001 Fan Assembly 1
036038-00002 Fan Spacer 3
036038-00003 Main Rotor Assembly 1
036038-00005 Main Stator Assembly 1
036038-00006 Exciter Field 1
036038-00007 Outboard Endbell 1
036038-00008 Outboard Bearing 1
036038-00009 Field Assembly Clamp 2
036038-00010 Rotor Retainer Bolt 1
036038-00011 Terminal Box 1
036038-00012 Terminal Box Cover 1
003016-00033 Outlet 2

High cycle Generator Manual 18
PARTS MANUAL
Generator Wiring Instructions
230 Volts:
Connect #4 and #7 wires together, #5
and #8 wires together, and #6 and #9
wires together.
Connect #1 wire to terminal X, #2 wire
to terminal Y, and #3 wire to terminal Z
of outlet.
115 Volt:
Connection #4, #5, and #6 wires to-
gether. Connect #1 and #7 wires to
terminal X, #2 and #8 wires to terminal
Y, and #3 and #9 wires to terminal Z of
outlet.
115 volts generator requires heavier gauge
wires from outlet to outlet in order to carry
higher current between outlets. #10 gauge
stranded wire is recommended.
If rotation of vibrator is wrong, the rotation
can be changing by switched any two current
carrying leads at the generator outlets.

19
High cycle Generator Manual
GENERAL SPECIFICATION
GX250
Engine Type Air-Cooled 4-stroke OHV
Bore X Stroke 77 X 58 mm
Displacement 270 cm2
Net Power Output* 8.5 HP (6.3 kW) @ 3,600 rpm
Net Tourque 14.1 lb-ft (19.1 Nm) @ 2,500 rpm
PTO Shaft Rotation Counterclockwise (from PTO shaft side)
Compression Ratio 8.5:1
Air Cleaner Dual element
Oil Cleaner 1.16 US qt (1.1 L)
Fuel Tank Capacity 5.6 U.S. qts (5.3 liters)
Fuel Unleaded 86 octane or higher
Dry Rate 55lb (25 kg)
GX270

High cycle Generator Manual 20
GENERAL ENGINE INFORMATION
∆Keep your fuel tank and fuel storage tank filled
with fresh fuel and out of direct sunlight.
∆Use a fuel stabilizer along with fresh fuel when
your engine is stored
∆Use a gas station with a reputation for quality
fuel.
FUEL INFORMATION:
∆Honda engines are certified
and designed to run on regular
unleaded gasoline.
∆Do not use gasoline containing
more than 10% ethanol in your
Honda powered equipment.
∆Keep your engine’s air filter
properly serviced. Check it be-
fore each use.
∆E85 contains 85% ethanol and must not be
used in Honda engines.
Is there Fuel in the tank? Fill with fuel.
Is the fuel value “ON” or “OPEN”? Turn the fuel value to the “ON” or “OPEN”
position.
Is the engine stop switch at “ON”? Turn the switch to the “ON” position.
Is the engine equipped with a battery? Check the charge on the battery. Charge or
replace as necessary.
Is the choke lever at the “ON” position? Move the choke lever to the “ON” position.
Does the carburetor float chamber contain stale
glass.
Drain the oil fuel. Fill the tank with fresh
gasoline.
Fill With recommended amount of oil.
Is the oil level sufficient?
Is the air cleaner clogged?
Is th spark plug fouled?
If the engine still does not start, take it to am authorized Honda Engine Dealer.
Clean or replace if necessary.
Clean the air cleaner or replace if necessary.
Is the sparkplug fouled?
Is the air cleaner clogged?
Is the carburetor clogged?
If the engine still does not preform properly, take it to an authorized Honda
Engine dealer.
Inspect and replace if necessary.
Clean the air cleaner or replace if necessary.
Clean the carburetor or consult a Honda
dealer
ENGINE DOESN’T STARTS OR IS HARD TO START:
ENGINE LACKS POWER:
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
No
No
No
No
