SAFETY PRECAUTIONS
For correct use and for your safety, be sure
to read the instruction manual before using
the instrument.
•Be sure to use the specified batteries. Using
improper batteries may cause a fire or
electric shock.
PULSOX®-300i
OXYGEN SATURATION MONITOR
NEW Wristwatch-Sized Pulse Oximeter with Memory Function
Finger Clip Probe
SR-5C (0.3 m)
Spot Check Probe
SP-5C (0.5 m)
Personal Probe
SD-5C/SD-5C (20) Package of 5 (0.5 m)
Monitor Probe
LM-5C (0.3 m)
Extension Cable (optional)
EC-300 (1 m)
For continuous measurements with the main
unit worn on the wrist.
For face-to-face measurements in clinics or
hospitals.
For single-patient use to avoid infection. For continuous measurements over a long period
of time such as while sleeping.
Connects between the probe and main
unit to allow the probe to be positioned
further from the main unit.
4 types of probes are available, so you can select thebest onefor theapplication.
Select from 4 types of optional probes
System Diagrams and Accessories
Main specifications
I Dual-wavelength pulse type (665 nm/880 nm) arterial blood oxygen saturation
measuring instrument
• Name: Oxygen Saturation Monitor
• Model name: PULSOX-300i
I Functions:
• Measuring range: SpO2: 0 to 100% SpO2
Pulse rate: 30 to 230 bpm
• Accuracy: SpO2:±2% SpO2(70 to 100% range, 1S.D.)
Pulse rate: ±2 bpm (30 to 100 range)
or ±2% of value (100 to 230 range)
I Display
Display type: Liquid crystal display (with back-light function)
Oxygen saturation (SpO2), Pulse rate number, Pulse level meter (8 steps),
Battery indication (3 steps), Error messages indication
I Warning functions
SpO2: Low SpO2warning (flashing display)
Battery indication, Error message indication
I Memory function (Up to 300 hours at one-second intervals)
Oxygen saturation (SpO2), pulse rate, measurement date/time
I Operating conditions
Temperature/humidity range
0 to 40°C (32 to 104°F); 30 to 85 % relative humidity with no condensation
Atmospheric pressure/altitude range
700 to 1060 hPa (altitude: –400 to 3000 m)
I Storage conditions
Temperature/humidity range
–10 to 60°C (14 to 140°F); 10 to 95% relative humidity with no condensation
Atmospheric pressure/altitude range
700 to 1060 hPa (altitude: – 400 to 3000 m)
I Power
1 AAA-size battery: 1.5 V , 100 mW (Service life under continual usage:
approx. 30 hours with alkaline battery)
I Dimensions (W XHXD)
68 X 58 X 15 mm
I Weight
56g (including battery/excluding wrist band and probes)
I Usable life
6 years [Verified by KONICA MINOLTA SENSING, INC. (based on own data)]
DS-5 software operating environment
• PC Specifications (in addition to monitor, mouse, and keyboard)
CPU : Intel Pentium 3, 600 MHz or higher
Memory : 128 MB or more
Storage device : One hard disk drive
(Free disk space of 100 MB or more is recommended. *1)
Monitor : 1024 x 768 (SVGA) or more
Other : One optical drive *2 (required for installation)
One USB port or serial port *3
Printer supporting one of the following OS
(When printing is required)
*1: Installing this software requires 40 MB of free space on the drive
where the Windows system has been installed. The amount of free
space required depends on the amount of data to be stored. To
install the software in a location other than the current drive, you
need to reserve the required free space on the destination drive.
*2: An optical drive means a drive supporting CD-ROM media, such as a
CD-ROM drive, a DVD-ROM drive, or a DVD-R drive.
*3: The PULSOX-300i requires a USB port supporting USB 1.1 or higher.
The PULSOX-3i Series requires an RS-232C serial port.
• Applicable OS
Windows®XP Pro(SP2), Windows®XP Home(SP2),
Windows®2000 Pro(SP4), Windows®98SE
*Windows®XP Pro64(Professional x64 Edition) is not supported.
Sleep apnea screening
Flexible evaluation of HOT (Home Oxygen Therapy)/
NIPPV (Non-Invasive Positive Pressure Ventilation) patients
Outpatient guidance and management
Standard
accessories
Standard accessories
Optional accessories
Optional accessories
Extension cable
EC-300
Finger Clip Probe SR-5C
Spot Check Probe SP-5C
Monitor Probe LM-5C
Personal Probe SD-5C
USB adapter
UA-300
Data Analysis Software
DS-5
Wristband
WB-300
AAA-size alkaline
battery
PULSOX®-300i
Advanced high-capacity/high-resolution memory
• Large-capacity memory stores up to 300 hours of data
• SpO2memory resolution: 0.1%
• 1-second interval measurements
Finger Clip Probe
SR-5C
USB adapter
UA-300
• Specifications are subject to change without notice.
DS-5
High-resolution memory enables significantly improved
screening accuracy for sleep apnea syndrome!
Long-term memory up to 300 hours
Non-volatile memory for data-safe battery replacement
High-speed download via USB
Lightweight, compact body fits well against wrist.
Long battery life: Up to 30 hours with a single AAA alkaline
battery
New software for data analysis is easy to use and offers a
variety of analysis functions

P
U
L
S
O
X
®
-
3
0
0
i
P
U
L
S
O
X
®
-
3
0
0
i
P
U
L
S
O
X
®
-
3
0
0
i
P
U
L
S
O
X
®
-
3
0
0
i
P
U
L
S
O
X
®
-
3
0
0
i
High-resolution memory accurately tracks tiny changes!
Tiny changes and short-cycle fluctuations can be accurately tracked with data collected in the high-resolution
memory at a resolution of 0.1% for SpO2and 1-second intervals.
New Data Analysis Software DS-5 offers a variety of analysis functions with easy operation!
(optional accessory)
* The data analysis functions of the PULSOX-300i are available only with the DS-5 software. The DS-5 software can also be used with the PULSOX-3 memory-type model.
Interactive communication between the main unit and DS-5
software
The clock data in the PC can be used to set the clock in the main unit with one-touch
operation.
The unit's main number can be loaded from the software to the main unit.
The Auto Power Off time can be set on the main unit.
* The above functions are available on the PULSOX-300i only. To use these functions with the PULSOX-3, it
must be connected through the IF-3 interface unit and RS-232C serial port.
Multi-language support
The display, instruction manual, and help are available in six languages: English, Ger-
man, French, Italian, Spanish, and Dutch. The languages can be selected easily.
User-friendly display operation
Graph displays, display range, and display time can be easily changed, not only with the menu bar and toolbar icons, but also by clicking the
right button of the mouse.
A marker indicates the point of DIP/increased pulse rate on the screen.
The various alarm signals are displayed with different event markers, allowing easy rec-
ognition of data characteristics.
Up to five preferred screen configurations can be stored and recalled (montage func-
tion).
Just clicking the icon changes the display screen settings.
A variety of easily-operated analysis functions
Analytical reports can be automatically output when a file is downloaded.
One click of the PDF button automatically created a PDF file of the analysis report
(Not supported by Windows® 98SE).
The information/analysis data of multiple patients can be compiled into a single file,
and the reports of multiple patients can be printed simultaneously.
Large-capacity memory for up to 300 hours of data /High-speed downloading via USB!
A total of 300 hours of high-resolution memory data, collected with 0.1% SpO2resolution at 1-second intervals,
can be stored in the unit.
Up to 399 files can be stored. Large amounts data can be quickly downloaded to the software via a special cable
supporting USB 1.1.
Data for a whole night (8 hours) can be downloaded in only 10 seconds.
Long battery life: 30-hour continuous operation with a single AAA alkaline battery!
Remaining battery life is shown by a three-level status indicator. No need to worry about the battery failing over-
night.
The DS-5 optional data analysis software allows Auto Power Off time to be set.
The non-volatile memory reliably retains data during battery replacement.
Impact-resistant body designed for a perfect fit on the wrist!
The main unit was designed using advanced 3D CAD to achieve double impact resistance versus Konica Minolta's
conventional PULSOX-3 model.
The main unit weighs only 56g including the battery, and its thin profile measures only 15mm at the centre.
The contact surface is contoured for significantly improved stability even when the wearer moves. The large LCD
with backlight allows easy reading of the displayed data.
0.1% resolution and 1-second intervals
Conventional model
(1% resolution and 5-second intervals)
SpO2analysis report
SpO2/pulse rate trend graph
Pulse rate analysis report 12-hour SpO2/pulse rate trend graph
Reports display screen
Event marker screen
Language selection screen
PULSOX-300i
USB
Battery compartment
PULSOX-300i
PULSOX-3i
[Wide range of analytical reports]
• Summary report
• Patient information report
• SpO2analysis report
• Pulse rate analysis report
• SpO2/pulse rate trend graph
• 12-hour SpO2/pulse rate trend graph
• 24-hour SpO2/pulse rate trend graph
• SpO2trend graph
• Pulse rate trend graph
• Selected channel trend graph
