ITEMS Action(timeunit:second) Description
1 Tap one time [0.04,1]
Out of network: Z-Wavenetworkinclusion(ADD) (send out NIF of full functionality )
In network: N/A
In/Out of network: controls/toggles output on/off
2 Tap two times [0.04, 1] Out of network: N/A
In network: Z-Wavenetworkexclusion(REMOVE:SendoutNIF).
4 Press and hold [5,10] Enter RF power level test mode
5 Press and hold [15,20] ResettofactorydefaultsettingandthensendDeviceResetLocallytoprimarycontroller.
Note: Please use this procedure only when the network primary controller is missing or otherwise inoperable.
6 Press and hold [22,∞) If still do not release the button, nothing will happen. LED should continue to pulse blue for unpaired state.
Action PressdownActionButton ReleaseActionButton
Tap one time
[0.04,1] Solid Yellow Status
Turns on a solid yellow status, If a new node id is assigned to this device, the yellow LED will keep solid until whole network processing is complete (or
entering. If successful, the LED will flash white -> green -> white -> green (at a rate of 250ms per each color change) for 2 seconds. After 2 seconds have
finished, use typical paired status LED indicators for ON/OFF status from parameter #1. Controlfunction: controls/toggles output on/off
Tap twotimes
Secure / Non-secure network: Purple
LedkeepsONfor2secondsandthen
OFF.
If the exclusion is successful, the Led will pulse a blue LED color based on unpair status.
Press and hold
[1,1]
LED should revert back to LED state if
paired or unpaired.
Press and hold
[2,5] Solid orange status LED should revert back to LED state if paired or unpaired.
Press and hold
[5,9] Solid cyan status cyan led will remain solid upon releasing the button, which indicates the network quality is entering diagnosing, the led will be light up with 1 of 3 colors
for 2 seconds after the diagnosing is complete. (Red = bad, Yellow = ok, Green = Good)
Press and hold
[9,15] Solid red led status
Press and hold
[15,20]
red color will blink on and off at a rate
of 200ms for 2 seconds and then should
pulse blue color based on unpair status.
Reset to factory default setting and then send Device Reset Locally to primary controller
No. 5 / 12
