Minuit Une IVL Square User manual

www.minuitune.com
104 Avenue de la Résistance, 93100, Montreuil
Email : [e-mail]
Tel. : + 33 (0)1 43 63 65 90
USER MANUAL
IVL™Square

IVL Square –User Manual
© 2019 ARTEFFECT SAS
All rights reserved. Information subject to change without notice. ARTEFFECT and all affiliated companies disclaim
liability for any injury, damage, direct or indirect loss, consequential or economic loss or any other loss occasioned
by the use of, inability to use or reliance on the information contained in this document. Minuit Une, IVL LIGHTING,
IVL Square are registered trademarks of ARTEFFECT SAS.
No part of this document may be used for distribution, reproduction, transmission, transcription, storage in a data
retrieval system, or translated into any language in any form by any means without the prior written permission of
ARTEFFECT. If you are downloading files from our web pages for your personal use, make sure to check for updated
versions. ARTEFFECT cannot take any liability whatsoever for downloaded files, as technical data are subject to
change without notice.
www.minuitune.com | 104 avenue de la résistance 93100 Montreuil –FRANCE | + 33 (0)1 48 97 43 82
[e-mail]
Revision of this manual: AJ

IVL Square –User Manual
Content
................................................................................................................................................................................... 2
Content ...................................................................................................................................................................... 3
Dimensions................................................................................................................................................................. 4
IVL Square and Base Dimensions.........................................................................................................................4
Important Safety Information..................................................................................................................................... 5
Risk Levels and Alert Symbols .............................................................................................................................6
Vital Precautions..................................................................................................................................................6
General Safety Information .................................................................................................................................7
Intended use ........................................................................................................................................................8
Labelling diagram.................................................................................................................................................8
Introduction ..............................................................................................................................................................11
Overview ...................................................................................................................................................................12
Fixture menu and connectors............................................................................................................................ 12
Scanner and Mirror Bars....................................................................................................................................13
Bottom View ......................................................................................................................................................13
Physical Installation...................................................................................................................................................15
To Place the Product on a Flat Surface..............................................................................................................15
To Mount the Product on a Rigging Structure ..................................................................................................15
AC Power...................................................................................................................................................................16
To Link Fixtures to Power in a Chain .................................................................................................................16
Control Data Link.......................................................................................................................................................17
Tips for a Reliable DMX Data Transmission ......................................................................................................17
To Connect the Data Link...................................................................................................................................17
Fixture Menu.............................................................................................................................................................18
Effects........................................................................................................................................................................19
Vibrant Light, smooth RGB ................................................................................................................................19
Tilt, Movement and Frost ..................................................................................................................................19
Beam Control ..................................................................................................................................................... 20
Decoration..........................................................................................................................................................21
Space coverage...................................................................................................................................................21
Dimmer...............................................................................................................................................................21
Colours................................................................................................................................................................ 21
Shutter................................................................................................................................................................21
Maintenance .............................................................................................................................................................22
Cleaning..............................................................................................................................................................22
DMX Protocol ............................................................................................................................................................23
Specification..............................................................................................................................................................26

IVL Square –User Manual
Dimensions
All dimensions are given in millimetres.
IVL Square and Base Dimensions

IVL Square –User Manual
Important Safety Information
1.Read these instructions
2.Keep these instructions
3.Heed all warnings
4.Follow all instructions
5. Do not use this apparatus near water
6. Clean only with dry cloth
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions
8. Do not install near heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your safety. If the provided plug does not
fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11. Only use the attachment/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to
avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled, or
objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.

IVL Square –User Manual
Risk Levels and Alert Symbols
Safety warnings, safety alert symbols, and signal words in these instructions indicate different risk levels:
Vital Precautions
DANGER indicates an imminent hazardous situation which, if not avoided, will result in death or
serious injury.
WARNING indicates a potentially hazardous situation which, if not avoided, may result in death or
serious injury.
CAUTION indicates an potentially hazardous situation which, if not avoided, may result in minor or
moderate injury.
NOTICE explains practices not related to physical injury. No safety alert symbol appears with this
signal word.
High voltage! Risk of blindness, electric shock and fire.
Read and understand all safety information and operation instructions before you operate or install
the product or the system.
Not to observe the safety information or general rules of safety may cause injury, blindness, burn
hazards, electric shock, falls and death to yourself and others or damage to equipment.
Use solely and exclusively as described in the instructions.
Any usage other than described in this manual is not permitted and can damage the product and lead
to associated risks such as short-circuit, fire, electric shock, etc.
Use of controls or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
Always check that the local AC power matches the voltage and frequency range printed on the type
label of the product before use.
Always earth the fixture electrically. Only use TN or TT one phase power supplies and a power plug
according to IEC 60309-1 or a similar national standard.
Never use the cables for transportation. Never hang the product on its cables.
In case of visible or suspected damage to cables or housings, the product must not be operated any
longer. Never attempt to repair any part of the product on your own. The user is not allowed to modify
the unit or remove protective covers or housings.
The product is not to be operated with the acrylic cover not in place or if the cover is in any way
damaged.
The laser is never to be operated if the unit is defective or the cover or seal is damaged.
Do not bypass or remove any safety feature of the product.
No service is allowed by the customer.

IVL Square –User Manual
General Safety Information
Humidity, Condensation and Moisture.
To reduce the risk of fire or electric shock, Do not expose this apparatus to rain or moisture. Do not
use the product for 2h when it was exposed to big temperature differences as condensed moisture
may damage the product electrically when switched on.
Never expose the product to drip water or water splashes.
Never place an object filled with liquid (e.g. a vase or a bottle filled with liquid) on the product.
Do not bend the power cable directly after the connector. Water could immerse and cause short
circuits and damage the connector.
Risk of electric shock and fire.
Socket outlets or external power switches used to the supply the product with power must be located
near the product and easily accessible to be able to isolate the product from power immediately.
The power cable is equipped with a Neutrik Powercon TRUE1 NAC3FX-W cable connector and bare
ends. You can install a suitable power plug on the power cord. Always use a power plug according to
IEC 60309-1 or a similar national standard.
Disconnect the product from AC power before moving or doing maintenance work on it.
To link several products in one power chain, please observe:
•This fixture has a power consumption of 75W max.
•Always obtain a AWG 14 power input cable and AWG 14 power throughput cables.
•Never link more than 17 products in a power chain when using these cables.
Ensure that the airflow around the product is free and unobstructed.
Provide a minimum clearance of 0,3 m (1 in.) around fans and air vents.
No flame source, like a candle light, must be placed on or nearby the product.
This product is intended to be used in temperate climate.
Do not operate the product if the ambient temperature is above 40° C (104° F) or below
0° C (32° F).
Risk of injury and damage through falls.
Always install the product as described in this manual.
Always follow the safety information when suspending the product. Always use a secondary
attachment as described in this manual to prevent falls when the primary attachment fails.
Block access area during installation of the product due to risk of injury through fall.
Always work from a stable platform.
Class 3R laser product according to IEC 60825-1:2014
Avoid direct eye exposure.
Do not look at laser devices with magnifiers, telescopes, binoculars or similar optical instruments
that may concentrate the light output.
Please refer to ANSI Z136.1 “Standard for Safe Use of Lasers” for guidance on safe
use. This publication is available from Laser Institute of America.
IVLTM Square products are classified under IEC 60825-1 as class 3R extended source lasers.
Note that the national and local recommendations, regulations, standards and codes of practice in
laser show are different from a country to another.
Please contact your provider or Minuit Une’s legal service if you have any interrogation.

IVL Square –User Manual
Intended use
Labelling diagram
The following symbols are used in this manual or on the product to identify important safety
information:
This product is intended for indoor use.
This product is intended to produce lighting effects in a dry environment at an ambient temperature
below 40° C (104° F) and above 0° C (32° F).
This product fulfils national and international legal requirements.

IVL Square –User Manual
5. Manufacturer’s Identification Label
The manufacturer plate is located at
the bottom of the product. It contains
important information about the
type, serial number, and safety.
Please contact your dealer or Minuit
Une when a type plate is missing as it
has to be present on the product and
needs to be replaced.
1. Hazard Warning Symbol Label
Warning! Visible and / or invisible Laser
Radiation can be emitted.
2. Explanatory label
This Laser product is designated as Class
3R during all procedures of operation
Laser parameters:
Wavelength: 448nm, 518nm, 638nm
Emission type: pulsed (340Hz)
Energy: <15,5uJ
3. Protective Housing Non-interlocked Label
Before opening any part of the product,
disconnect the AC power. Otherwise you
may be exposed to a class 4 Laser. MINUIT
UNE cannot be held responsible if this
instruction is not respected
4. Aperture Label
This label indicates the laser aperture. On
this product, the laser aperture is the whole
area above the PMMA shape of the
product.

IVL Square –User Manual
6. Certification Label
7. Power Label

IVL Square –User Manual
Introduction
IVL square is part of IVL Lighting, a new category of lighting created and patented by
Minuit Une.
What is IVL Lighting?
IVL Lighting is the first-ever lighting range specially designed for experience.
IVL lighting by Minuit Une is based on a ground-breaking technology to go further in lighting design.
For the first time ever, create spectacular experiences without heavy logistics:
•Advanced shapes: stunning visual lighting shapes and decors.
•Unique immersive feeling: wide coverage area, calibrated output, enveloping lights covering all the
available space.
•Unlimited versatility: infinite effect combinations; constantly renewed style or atmospheres within a
show.
•Without a custom programming software: Intuitive programming from any DMX console.
•Without heavy infrastructure: IVL products are a concentrate of technology. Small-sized, light-
weighted and robust, they can be hung quickly anywhere and in any direction.
The IVL Lighting is a game-changing lighting product. It creates multidimensional advanced shapes from
one source of light. The IVL Lighting covers a wide area by producing 4 directive light plans perpendicular
to each other. Each plan is adjustable at a 180° angle to create stunning perspectives when combined
together. Each light plan of the IVL Lighting can be divided into 1, 2, 4, 8, 16, 32, 64, 128, or 256 beams.
Welcome to a new world of advanced shapes and infinite possibilities!
In a time where crowds ask more and more for exciting experiences, the IVL Lighting’s advanced shapes
help you create truly immersive designs with their smooth enveloping textures and 3D rendering
perception. It is an infinite playground for your creativity. Multiply your creative output using a standard
DMX controller.
Before using the product
1. Read the “Important Safety Information“ on page 5 before doing anything with the product.
2. Unpack and ensure that there is no transportation damage before using the product. Do not attempt
to operate a damaged product.
3. Check that no part shipped with the product is missing. The product is shipped with:
•A power cable with a Neutrik Powercon TRUE1 connector and bare ends,
•2 omega-type clamps quarter-turn fasteners
Only use the attachments/ accessories specified by the manufacturer
4. If the product is not going to be hard-wired to a mains supply, install a local power plug (not supplied)
on the end of the supplied power cable.
5. Ensure that the voltage and frequency of the power supply match the power requirements of the
product.
Note that whenever AC power is applied to the product, it will reset all effects and functions to their home
positions. A reset usually takes approximately 8 seconds.

IVL Square –User Manual
Overview
Fixture menu and connectors
Menu buttons
ENTER
Press to open the main menu.
Press to open a sub menu.
ESC
Cancel an action without saving any changes.
+ / -
Select an option or change a value.
Display
The Displays shows fixture and menu information.
Indicator LEDs
safety indicator (red, left from display)
Lights up when the scanning speed reach 340Hz.
DMX interlock indicator (green, right from display)
Lights up green when a valid DMX signal is
detected at the DMX input.
DMX connectors
The product is equipped with 5-pin XLR sockets DMX input and output (through to next fixture).
The pinout of the XLR connectors is:
•pin 1 = shield
•pin 2 = cold (-)
•pin 3 = hot (+).
Pins 4 and 5 in the 5-pin XLR connectors are not used in the fixture but are available for possible additional
data signals as required by the DMX512-A standard. Standard pin-out is pin 4 = data 2 cold (-) and pin 5 =
data 2 hot (+).
Main Switch
Flip the main switch to power the product or to switch the product off. After powering the product it
performs a reset which takes approximately 8 seconds.
Menu Buttons
safety Indicator (red
light)
Display
DMX Indicator
(green)
Connector Panel and
Mains Switch

IVL Square –User Manual
Power Connectors
The product is equipped with two Neutrik Powercon TRUE1 connectors for power in and power through.
Use only Neutrik Powercon TRUE1 NAC3FX-W cable connectors to connect to power input sockets. Use
only Neutrik Powercon TRUE1 NAC3MX-W cable connectors to connect to power throughtput sockets.
Scanner and Mirror Bars
Bottom View
6 quarter-turn
receptacles
Rubber foot
(4 pieces)
Anchor for
safety cable
360° scanning system
Mirror bar 1
Cover fixing screw –tool only
removable (4 pieces)
Display
Mirror bar 2
Mirror bar 3
Mirror bar 4

IVL Square –User Manual
Quarter-turn Receptacles
The product is shipped with two omega-type brackets to which rigging clamps can be attached to the
quarter-turn receptables duct using the brackets quarter-turn fasteners.
Anchor for Safety Cable
Secure the product with a safety cable (or other secondary attachment) that is approved for the weight
of the product so that the safety cable will hold the fixture if a primary attachment fails.
Loop the safety cable through the anchor for the safety cable on the side of the product (see illustration
above) and around a secure anchoring point.
If a safety cable attachment point becomes damaged or deformed, do not suspend the product above
ground any more. The anchor needs to be replaced by a qualified technician.
Rubber Feet
The product is equipped with for damping rubber feet. Check, if all four rubber feet are present and
undamaged before placing the product on a flat surface. Replace a missing rubber foot as the product
might present a risk of injury when moving during operation.

IVL Square –User Manual
Physical Installation
To Place the Product on a Flat Surface
The product can be placed on a hard, fixed, flat surface. Ensure that the surface can support at least 10
times the weight of all products and equipment they will support.
Do not place the product on a surface or leave it where it can be moved or fall over. If you install the
product in a location where it may cause injury or damage if it falls, secure it as directed below with a
securely anchored safety cable that will hold the product if can move and fall.
To Mount the Product on a Rigging Structure
The product can be fastened to a rigging structure in any orientation. The quarter-turn receptables (see
„Overview“ on page 12) allow the clamp brackets to be fastened in parallel, perpendicular or at a 45°
angle to the front.
The product is supplied with two omega-type brackets to which rigging clamps
can be attached. Check that the rigging clamps are undamaged and approved
for the product’s weight. Bolt a rigging clamp securely to each bracket. The bolts
used must be M12, grade 8.8 steel minimum, and fastened with self-locking
nuts.
Align the first clamp bracket with 2 quarter-turn receptables in the base. Insert
the quarter-turn fasteners in the quarter-turn receptables and turn both lever full 90° to lock them (see
illustration on right). Repeat for the second clamp.
Secure the product against falling when the primary attachment fails with a secondary attachment such
as an approved safety cable that is rated for the weight of the product, using the anchor on the side of
the product. Do not use any other part of the fixture as a safety cable attachment point.
Always read the “Important Safety Information” on page 5 before installing, operating or servicing
the product.
The installation of this product must be validated by a qualified technician before it is operated.
When suspended above ground, the product must be secured with a secondary attachment to prevent
injury or damage by falls when the primary attachment fails.
If suspended, the rigging structure must be able to bear a static suspended load that is ten times the
weight of the product and all installed accessories, especially if the product is installed in a location
where it may cause injury or damage if it falls.
Always use two (2) clamps to fasten the product to the rigging structure. Lock each omega adapter
with both quarter-turn fasteners. Fasteners are locked only when turned fully clockwise.
When installing the fixture hanging vertically down, you can use an open-type clamp such as a G-
clamp. When installing in any other orientation, you must use a closed-type rigging clamp such as half-
coupler clamp that completely encircles the truss chord.

IVL Square –User Manual
AC Power
The product can be hard-wired to a building electrical installation if you want to install it permanently, or
a power plug (not supplied) that is suitable for the local power outlets can be installed on the power cable.
If you install a power plug on the power cable, install a grounding type (earthed) plug with integral cable
grip that is rated minimum 18 A at a suitable voltage for your local power system and which is compliant
with your local and national requirement. . Follow the plug manufacturer’s instructions and connect the
wires in the power cable as shown in this table:
Live or L
Neutral or N
Earth, Ground or
US system
Black
White
Green
EU system
Brown
Blue
Yellow/green
The product has an auto-ranging power supply that accepts AC mains power at 100-240 V at 50/60 Hz. Do
not apply AC mains power at any other voltage or frequency to the product.
To Link Fixtures to Power in a Chain
The product has a power consumption of 75 W max. Do not connect products to power in a chain that
will exceed the electrical ratings of any cable or connector used in the chain. Connect only the same
fixtures into an interconnected chain.
If you wish to connect IVL Square products to power in a linked chain, you must obtain a AWG14 power
input cable and AWG14 throughput cables.
Using these gauge cables, you can link maximum 17 IVL Square by Minuit Une.
High voltage! Risk of electric shock and fire.
Read the “Important Safety Information” on page 5
before connecting the product to AC mains power.
Always connect the product directly to AC power.
Use only a Neutrik Powercon TRUE1 NAC3FX-W cable connector to connect the power cable to the
power input socket. Use only a Neutrik Powercon TRUE1 NAC3MX-W cable connector to connect the
power link cable to the power throughput socket.
Only use the power cable provided by the manufacturer with the product.
For protection from electric shock, the product must be grounded (earthed) electrically.
Socket outlets or external power switches used to supply the product with power must be located
near the product and easily accessible so that the product can easily be disconnected from power.

IVL Square –User Manual
Control Data Link
A DMX 512 data link with a ferrite (ref: 742 712 22 S) on it is required to control the product via DMX. The
fixture has a 5-pin XLR connector for DMX data input and output.
A single daisy chain can consist of up to 32 devices. The total number of products in one 512-channel DMX
universe is limited by the number of DMX channels required by the products. Note that if independent
control of a product is required, it must have its own DMX channel range. Products that are required to
behave identically can share the same DMX address and channels. To add more products or groups of
products when the above limits are reached, add a DMX universe and/or split the daisy-chained link into
branches using a powered DMX splitter.
Tips for a Reliable DMX Data Transmission
Use shielded twisted-pair cable designed for RS-485 devices: standard microphone cable cannot transmit
control data reliably over long runs. 24 AWG cable is suitable for runs up to 300 meters (1000 ft.). Heavier
gauge cable and/or an amplifier is recommended for longer runs.
A valid DMX signal is the safety interlock of the device. Please check, if every DMX cable used in the control
data link is in perfect condition if the safety signal (red LED) is switching on and off constantly whereas
other products in the control data link are reacting correct on DMX commands.
The pin-out of the connectors is:
•pin 1 = shield
•pin 2 = cold (-)
•pin 3 = hot (+).
Pins 4 and 5 in the 5-pin XLR connectors are not used by the product but are available for possible
additional data signals as required by the DMX512-A standard. Standard pin-out is pin 4 = data 2 cold (-)
and pin 5 = data 2 hot (+).
To split the link into branches, use an opto-isolated, powered DMX splitter. Terminate the link by installing
a termination plug in the output socket of the last product of a DMX data link. The termination plug, which
is a male XLR plug with a 120 Ohm, 0.25-watt resistor soldered between pins 2 and 3, “soaks up” the
control signal so it does not reflect and cause interference. If a splitter is used, terminate each branch of
the link.
To Connect the Data Link
To connect the product to the DMX data link:
1. Connect the DMX data output from the controller to the closest product’s male XLR DMX input
connector.
2. Connect the first product’s DMX output to the DMX input of the next product and continue connecting
products output to input.
3. Terminate the last product on the link with a DMX termination plug. If the last product in the control
data link is an IVL product, you do not need to use a DMX termination plug as a termination resistor is
integrated in the electronics board.

IVL Square –User Manual
Fixture Menu
The IVL Square support two different DMX Modes. The active DMX Mode (DMX1 / DMX2 / DMX3 / DMX4)
is displayed in the display on the front panel of the product.
The DMX address is also displayed. It is indicated by an “A:”. “A:001” indicates, that the product is set to
DMX start address 1. The recent internal temperature of the product is shown on the display.
To Change the DMX Mode
1. Press ENTER
2. Press ENTER again to open the DMX mode menu.
3. Press + or - to scroll through the DMX modes.
4. Press ENTER to select a DMX mode.
5. Press ESC to cancel the action without changing settings.
To Change the DMX Address
1. Press ENTER.
2. Press +.
3. Press ENTER to open the DMX address menu.
4. Press + or - to scroll to the hundreds digit. Press ENTER to select a digit.
5. Press + or - to scroll through the tens digit.Press ENTER to select a digit.
6. Press + or - to scroll through the ones digit. Press ENTER to select a digit.
7. Press ESC to cancel the action without changing settings.
Temperature and Lifetime Readout
1. Press ESC to call up the main screen.
2. Press –short to display the highest internal temperature since production, the hour counter and the
software version.
DMX Channel Value Readout
1. Press ESC to call up the main screen.
2. Press –long to display the values of the DMX start address and the next three DMX channels received
by the product.

IVL Square –User Manual
Effects
The IVL fixture creates four light plans from a laser-based light source split at very high speed by a smart
mirror system. A PMMA cover in a specific shape to release a vibrant light with a smooth RGB colour
spectrum and enveloping texture.
Each light plane can be played independently with various modes: full plane, beam, frost, décor,
projection with a 180° angle.
This is not a laser effect, this is a new category of lighting with unique shapes, unique textures, unique
immersive feeling and standard safety.
Vibrant Light, smooth RGB
The super-fast scanning system of the IVL Lighting range (333Hz frequency rate) allows the human eye to
see every single nuance of colour: A vibrant and smooth RGB colour spectrum to perfectly complete the
best LED’s and HALOGEN’s chromatic range, with a vivid colour combination, as well as a wide range of
pastel colours.
Tilt, Movement and Frost
4 brushless stepper motors control the movement of the 4 mirrors on each side independently (4
separated tilts in the DMX chart). Unlimited immersive positions can be programmed and achieved just
by playing with different groups of mirrors from a group of IVL Lightings.
A specific electronically augmented resolution driver allows to achieve a really smooth movement: you
can create smooth movement with a really small range (%1) around your immersive advanced shapes.
Each mirror has an angle of position from 0° to 360°, this allows the creation of an infinity of advanced
shapes, immersive, decoration and wash effects.
The tilt channels are used to control the angle of the four mirror bars. One side of the mirror is highly
reflective while the opposite site is diffusely reflective. DMX values from 0 –50% (0 –127) create a single
light plan at different angles. DMX values from 51 –100% (128 –255) convert the IVL to a diffuse light
source.
DMX channels 11 to 18 control single mirror bars as shown below:
DMX channel coarse
DMX channel fine
Mirror bar (see “
Scanner and Mirror Bars” on page
13)
11
12
1
13
14
2
15
16
3
17
18
4
Example
•Open immersive position (11% tilt DMX value)
•Eye-capturing position (12.5 % tilt DMX value)
•Close immersive position (14% tilt DMX value)
•Decorative position (15 % tilt DMX value)
•Wash effect position: frost mode (62.5 % tilt DMX value).
•Reset function by optical sensors.

IVL Square –User Manual
Beam Control
An intelligent electronic software synchronised in real time with the frequency rate of the scanning system
allows to cut the light plan into several beams: 1, 2, 4, 8, 16, 32, 64, 128, 256 beams to create an infinity
of effects such as:
•Even more intense advanced shapes,
•Beam looking effects,
•Parallel effects,
•Flower effects,
•And many more.
These beams can be positioned anywhere on the mirrors, either static or in rotation, with control on the
size of the beam.
These specifications are converted via DMX consoles as an intuitive gobo system with the following
equivalence:
•Gobo type: number of beams
•Gobo size: width of the beam
•Gobo indexation: position of the beam on the mirrors
•Gobo rotation: speed and direction of rotation.
The origin (index = 0°) is located at the upper right side between mirror bars 2 and 3. Increasing the index
shifts the origin of the beams counter-clockwise from 0 to 360°:
DMX mode 2 gives the creativity to control the beam parameters for the blue, the green and the red
source independently.
Origin / 0°
Display
0 –90°
91° –180°
181° - 270°
271° - 360°
