Minuteman C46310-00 User manual

Model: C46310-00
C46310-02
C46310-02CE
Motorized Tool
Wall Unit
Revised 8/01
OPERATION SERVICE PARTS CARE

1

2
FOR COMMERCIAL USE ONLY
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be followed, including the
following:
READ ALL INSTRUCTIONS BEFORE USING
WARNING - To reduce the risk of fire, electric shock, or injury:
• Do not leave appliance when plugged in. Unplug from outlet when not
in use and before servicing.
WARNING
To reduce the risk of electrical shock, do not expose to rain. Store indoors.
• Do not immerse.
•Never allow children or untrained adults to operate this equipment.
•Keep the area of operation clear of all persons, particularly small children,
and pets. Keep bystanders at least 25 feet away from the area of operation.
• Use only as described in this manual. Use only manufacturer’s recommended
attachments.
• Do not use with damaged cord or plug. If appliance is not working as it
should, has been dropped, damaged, left outdoors, or dropped into water,
return it to a service center. If the supply cord is damaged, it must be replaced
by the manufacturer or its service agent or a similarly qualified person in order
to avoid a hazard.
• Do not pull or carry by cord, use cord as a handle, close a door on cord, or
pull cord around sharp edges or corners. Do not run appliance over cord.
Keep cord away from heated surfaces.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
• Do not handle plug or appliance with wet hands.
• Do not put any object into openings. Do not use with any opening blocked;
keep free of dust, lint, hair, and anything that may reduce air flow.
• Keep hair, loose clothing, fingers, and all parts of body away from openings
and moving parts.
• Do not pick up anything that is burning or smoking, such as cigarettes,
matches, or hot ashes.
• Turn off all controls before unplugging.
• Use extra care when cleaning on stairs.
• Do not use to pick up flammable or combustible liquids such as gasoline or
use in areas where they may be present.
• Connect to a properly grounded outlet only. See grounding instructions.
• This machine is not suitable for picking up health endangering dust.
• Do not use for general wet pick up applications - use only on carpet moistened
by the cleaning process.
• If foam or liquid comes out of ventilation openings switch off immediately.
SAVE THESE INSTRUCTIONS

3
INSPECTION
Carefully unpack and inspect your machine for shipping damage. Each unit is tested and
thoroughly inspected before shipment, and any damage is the responsibility of the delivery
carrier who should be notified immediately.
ELECTRICAL - Model C46310-00 (115V)
This machine is designed to operate on a standard 15 amp. 115 volt, 60 hz, AC circuit. Voltages
below 105 volts AC or above 125 volts AC could cause serious damage to the motor.
ELECTRICAL - Model C46310-02 and C46310-02CE (230V)
This machine is designed to operate on a standard 16 amp. type L fused 230 volt, 50 hz, AC
circuit. Voltages below 200 volts AC or above 250 volts AC could cause serious damage to the
motor. I.E.C. Class 1.
WARNING
Electric motors can cause explosions when operated near explosive materials or vapors. Do not
operate this machine near flammable materials such as solvents, thinners, fuels, grain dust, etc.
GROUNDING INSTRUCTIONS
This appliance must be grounded. If it should malfunction or breakdown, grounding provides a
path of least resistance for electric current to reduce the risk of electric shock. This appliance is
equipped with a cord having an equipment-grounding conductor and grounding plug. The plug
must be plugged into an appropriate outlet that is properly installed and grounded in accordance
with all codes and ordinances.
DANGER - Improper connection of the equipment-grounding conductor can result in a risk
of electric shock. Check with a qualified electrician or service person if you are in doubt as to
whether the outlet is properly grounded. Do not modify the plug provided with the appliance —
if it will not fit the outlet, have a proper outlet installed by a qualified electrician.
GROUNDING INSTRUCTIONS (C46310-00 Only)
This appliance is for use on a nominal 120-volt circuit and has a grounding plug that looks like
the plug illustrated in sketch A below. Make sure that the appliance is connected to an outlet
having the same configuration as the plug. No adapter should be used with this appliance.

4
USER MAINTENANCE INSTRUCTIONS
All service and repair should be performed by qualified vacuum service representative or
electrician. No user serviceable components are employed in the electrical assembly. No
lubrication of the motor is required.
DAILY MAINTENANCE
1. The powerhead should be cleaned daily. Flush pumping system with
1 gallon of clean water after use.
2. Check and clean vacuum inlet and solution inlet daily.
3. Brushes should be cleaned after each use.
4. Spray jet should be checked for correct spray pattern and cleaned if plugged.
Do not clean out spray tip with pins or wire, this may cause damage to the jet
spray pattern and cause streaking.
5. Protect equipment from freezing. Severe pumping system damage can occur if
allowed to freeze.
6. Inspect vacuum hoses for tight connections. Check electrical cable for abrasion
or cuts in jacket. Cord should be replaced if worn or damaged.
MONTHLY/BI-MONTHLY MAINTENANCE
The Solution Pump System should be purged monthly to remove alkaline residue build-up. To
flush system out, use 1 quart of white vinegar to 1 1/2 gallons of clean hot water, followed by a
clear 1 1/2 gallon rinse. Clean spray jets if required.
CORD STORAGE
While not in use storage can be accomplished by winding cord around machine. Cord hooks
are provided.
• Do not use with damaged cord or plug. If appliance is not working as it should, has
been dropped, damaged, left outdoors, or dropped into water, return to service center.
• Do not pull or carry by cord, use cord as handle, close a door on cord, or pull cord
around sharp edges or corners. Do not run appliance over cord. Keep cord away
from heated surfaces.
• Do not unplug by pulling cord. To unplug, grasp the plug, not the cord.
• Do not handle plug or appliance with wet hands.
This equipment should be stored indoors and not exposed to rain.

5
OPERATING INSTRUCTIONS
1. Connect the vac/solution hose assembly to
the carpet extractor. A quick connect coupling
. adapter is available for use on machines
equipped with ¼ auxiliary couplings.
2. Plug power cord into wall outlet.
3. This tool is equipped with a 3-position power
switch. The single bar position is for “low” speed.
The center position is “off”. Double bar position
is for “high” speed. (See fig. 1).
4. Minuteman recommends using the ”stiff”
bristled brush for carpet and the “soft” bristled
brush for upholstery. See fig. 5 for brush
replacement instructions.
FIG. 1
WARNING:
NOT RECOMMENDED FOR
USE WITH 100 PSI PUMPS

6
EXTENSION WAND INSTALLATION
1. Detach power cord from the trigger guard
and the cable clip.
2. Disengage powerhead from handle
assembly by depressing the burgundy
locking button and disconnecting
coupling 1. (see fig. 3).
3. Insert the stainless steel extension wand
curved end, (see fig. 4) into the powerhead
assembly until the locking button is
engaged. Connect coupling 2 to the
hose assembly on the powerhead.
4. At the other end of the extension wand,
(fig. 4) insert the handle assembly to the
flared end until the locking button is
engaged. Connect coupling 1 from
handle assembly to the hose assembly
on the extension wand.
5. Reposition the power cord to the trigger
guard and secure it to the cable clip.
FIG. 3
FIG. 5
BRUSH REPLACEMENT
Before reinstalling the brush, make sure that
the drive lugs on the pulley are oriented as
shown. Align notches on brush to engage with
lugs on pulley. Position brush to reinstall brush
shaft.
FIG. 4

7

8
ITEM PART NO QTY DESCRIPTION
1 450260 1 Powerhead Assy
2 715339 1 Decal, Switch
3 742298 1 Switch, 3-Position
4 450274 1 Knob Assembly
5 715336 1 Decal, Brush Removal
6 711158 2 SCR-Hi/Lo #7-19 x 3/8
7 450287 1 Brush Assembly, Carpet
7A 450288 1 Brush Assembly, Upholstery
8 450273 1 Pulley
9 850042 1 Bearing 6000 Sealed
10 711163 2 SCR-Hi/Lo #10-16 x ½
11 450264 1 Belt Cover
12 450269 1 Brushing Shaft Support
13 450276 1 Flat Belt
14 712822 2 SCR-MC #10-24 x ½ SS
15 712764 2 WSR-Flat #10 SS
16 742370 1 Motor Assembly 120V
16A 742373 1 Motor Assembly 230V
17 450285 2 Standoff
18 711551 3 WSR-Internal Lock #6
19 710305 3 SCR-MC #6-32 x 3/4 ST
20 741034 1 Cord Assembly 115V
20A 742374 1 Cord Assembly 230V
21 711157 6 SCR-Hi/Lo #7-19 x ½
22 715338 1 Decal, Service Warning
23 450293 1 Standoff-Nylon
24 380032 1 Strain Relief
25 450223 1 1/8 Barb x 1/8 FPT Brass
26 450294 1 WSR-Special
27 450278 1 Vee Jet Spray Nozzle
28 830082 2 Hose Clamp 3/8
29 450282 1 Hose, Powerhead
30 450279 1 Quick Connect Nipple 1/8
31 715337 1 Decal, Warning
32 450263 1 Back Cover
33 711597 1 WSR-Nylon Flat #6 x 3/8
34 712068 1 SCR-Nylon BH #6-32 x 3/8
35 740099 5 Wire Tie Small
36 450290MCH 1 Snap-In Fastener
37 711530 1 Thrush Bearing
38 715342 1 Decal, Warning
39 450277 2 Press Bearing
Parts Listing

9
ITEM PART NO QTY DESCRIPTION
1 450256 1 Pick-Up Tube
2 450258 1 Trigger Guard, Right
3 450249 1 Spotter Hose Assembly Complete
4 711163 5 SCR-Hi/Lo #10-16 x ½
5 450257 1 Trigger Guard, Left
6 390053 1 Trigger Solution Valve
7 711803 1 Cotter Pin .06 x .75
8 390063 2 Grove Stud Rd. Hd. #2427
9 712323 1 WSR-Flat .195 x .281 x .03 SS
10 450267 1 Spring Valve SS
11 450265 3 0-Ring, Brown
12 450221 1 Quick Connect Coupler
13 450261 1 Brass Valve Stem
14 450262 1 Locking Button
15 833725 1 Cord Clip
16 450301 1 Washer, Nylon

LIMITED WARRANTY
Minuteman International, Inc. warrants to the original purchaser/user that this product is free from defects in workmanship
and materials under normal use and service for a period of one year from date of purchase. In addition, Minuteman
International, Inc. will, at its option, honor labor warranty claims for the first 12 months from date of sale, provided such claims
are submitted through and approved by factory authorized repair stations. Minuteman International, Inc. will, at its option,
repair or replace without charge, except for transportation costs, parts that fail under normal use and service when operated
and maintained in accordance with the applicable operation and instruction manuals.
This warranty does not apply to normal wear, or to items whose life is dependent on their use and care, such as belts, cords,
switches, hoses, rubber parts, electrical motor components or adjustments. Parts not manufactured by Minuteman International,
Inc. such as engines, batteries, battery chargers, hydraulic pumps, and tires are covered by and subject to the warranties and/
or guarantees of their manufacturers. Please contact Minuteman International, Inc. for procedures in warranty claims against
these manufacturers.
Special warning to purchaser — Use of replacement filters and/or prefilters not manufactured by Minuteman International,
Inc. or its designated licensees, will void all warranties expressed or implied.
A potential health hazard exists without exact original equipment replacement.
All warranteed items become the sole property of Minuteman International, Inc. or its original manufacturer, whichever the
case may be.
Minuteman International, Inc. disclaims any implied warranty, including the warranty of merchantability and the warranty of
fitness for a particular purpose. Minuteman International, Inc. assumes no responsibility for any special, incidental or
consequential damages.
This limited warranty is applicable only in the U.S.A. and Canada, and is extended only to the original user/purchaser of this
product. Customers outside the U.S.A. and Canada should contact their local distributor for export warranty policies. Minuteman
International, Inc. is not responsible for costs or repairs performed by persons other than those specifically authorized by
Minuteman International, Inc. This warranty does not apply to damage from transportation, alterations by unauthorized
persons, misuse or abuse of the equipment, use of non-compatible chemicals, or damage to property, or loss of income due
to malfunctions of the product.
If a difficulty develops with this machine, you should contact the dealer from whom it was purchased.
This warranty gives you specific legal rights, and you may have other rights which vary from state to state. Some states do not
allow the exclusion or limitation of special, incidental or consequential damages, or limitations on how long an implied
warranty lasts, so the above exclusions and limitations may not apply to you.
World Headquarters Minuteman Canada, Inc.
Minuteman International, Inc. 2210 Drew Road
111 South Rohlwing Road Mississauga, Ontario
Addison, Illinois 60101 L5S 1B1
[phone] [phone] 988613
FAX [phone] FAX [phone] Printed in U.S.A.
