Minuteman Lumina 20 User manual

Parts and Instruction Manual
Lumina 20
Battery Burnisher

Parts
and Instruction Manual
This manual is furnished with each new MINUTEMAN Lumina 20. This provides the necessary operat-
ing and preventive maintenance instructions. Operators must read and understand this manual before
operating or servicing this machine.
This machine was designed to give you excellent performance and efficiency. For best results and
minimal cost, please follow the general guidelines below:
·Operate the machine with reasonable care.
·Follow the manufacturers suggested maintenance instructions as provided in this booklet.
·Use original Minuteman supplied parts.
TECHNICAL SPECIFICATIONS
Model Lumina 20 Brush Drive
Model No. M26036QP / M26036CE
Brush Speed 2600 RPM
Motor 2.5HP
Voltage, Batteries 36 volts, 3-12volt
Battery Capacity 165 AH
Gross Weight 916 lbs (415 kg) with batteries
638 lbs (290 kg) without batteries

Parts
and Instruction
M
anual

Parts
and Instruction Manual
Table of Contents
IMPORTANT SAFETY INSTRUCTIONS.............................................................................................. 1
Operating Instructions ....................................................................................................................... 2
Inspection........................................................................................................................................ 2
Electrical.......................................................................................................................................... 2
Batteries .......................................................................................................................................... 2
Operation ........................................................................................................................................ 2
After Use ......................................................................................................................................... 2
Maintenance.................................................................................................................................... 2
Floor Seal Strip................................................................................................................................ 2
Battery Service and Installation....................................................................................................... 3
Charging of Batteries ...................................................................................................................... 3
Battery Cable Routing ..................................................................................................................... 3
Machine Overview........................................................................................................................... 3
Control Panel .................................................................................................................................. 3
Pad Installation................................................................................................................................ 4
Pad Pressure Adjustments.............................................................................................................. 4
Circuit Breaker Protection ............................................................................................................... 4
Carbon Brush Replacement ............................................................................................................ 4
Carbon Brush Service ..................................................................................................................... 4
Exploded Views .................................................................................................................................. 5
Base Assembly................................................................................................................................ 5
Base Assembly BOM ...................................................................................................................... 6
Mainframe Assembly ....................................................................................................................... 7
Mainframe Assembly BOM.............................................................................................................. 8
Housing Assembly........................................................................................................................... 9
Housing Assembly BOM ............................................................................................................... 10
Pad Driver Assembly..................................................................................................................... 11
Pad Driver Assembly BOM............................................................................................................ 12
Pressure Control Assembly ........................................................................................................... 13
Electrical Assembly ....................................................................................................................... 14
Console Assembly......................................................................................................................... 15
Dashboard Assembly .................................................................................................................... 16
Wiring Diagram ................................................................................................................................. 17
Minuteman International Made Simple Commercial Limited Warranty........................................ 19

Parts and Instruction Manual
Page 1
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: Operators must read and understand this manual before operating or maintaining this
machine.
Keep hands and feet clear of moving parts while machine is in operation.
Disconnect the power to the machine by pressing the Red Emergency Disconnect Button when
charging batteries or during installation or removal of pads.
During operation, loose objects on the floor can become dangerous projectiles if struck by the high
speed pad. Special attention should be paid in removing or avoiding loose floor tile, electrical cables
and telephone connection boxes.
Electrical motors and components can cause an explosion when operated near explosive materials
or vapors. Do not operate this machine near flammable materials such as solvents, thinners, fuels,
grain dust, etc.
Keep machine moving to reduce the risk of damaging floor finish and floor.
Makesure theRed EmergencyDisconnect Buttonis pressedand thebattery connectorisunplugged
from the machine before performing any maintenance procedures.
Store or park this machine on a level surface only.
These machines are designed for level floor operation only. Do not operate on ramps or inclines.
Battery acid can cause burns. When working on or around batteries, wear protective clothing and
safety glasses. Remove metal jewelry. Do not lay tools or metal objects on top of batteries.
Charging batteries generates explosive gases. DO NOT CHARGE BATTERIES WHEN OPEN
FLAMES OR SPARKS ARE PRESENT. DO NOT SMOKE. Make sure the charger is turned off
before disconnecting it from the machine. Charge the batteries in a well-ventilated area with the
battery cover removed completely.
Maintenance and repairs must be performed by authorized personnel.
SAVE THESE INSTRUCTIONS

Parts and Instruction Manual
Page 2
Operating Instructions
Inspection
Carefully unpack and inspect your burnisher for shipping damage. Each unit is tested and thoroughly
inspected before shipment; any damage is the responsibility of the delivery carrier who should be
notified immediately.
Electrical
This machine is battery operated and designed to operate on 36 volts DC (3) 12 volt batteries.
Batteries
Burnishers are shipped with batteries. (3 required)
Part No. 956701 12V 165AH 20 Hr. Rate (Standard)
Part No. 956210 12V 210AH 20 Hr. Rate (Optional)
We do not recommend mixing AMPhour capacities.Any alternate battery sets can be used if they equal physical
size and capacity. See next page for service and installation.
Operation
Before starting, familiarize yourself with the machine and its controls (see “Machine Overview” and “Dashboard
Control Panel” diagrams). To turn the machine ON, do the following:
1. Make sure 20" high speed pad is used. Make sure the pad is installed on the machine by following
instructions under “Pad Installation.”
2. Make sure that no battery charger is plugged into the recharge port.
3. Lift the red emergency disconnect button so it is in the up position.
4. Lower the pad driver assembly by pushing the pedal slightly outward on the machine (unlock it), and
then release it slowly.
5. Turn the power switch to the ON position. The pad driver will then slowly adjust itself to the floor. Move
forward in a straight line, check the reading on the Operating Range Meter and make sure you are in the
Green Zone.
6. Adjust the pad pressure as needed by turning the knob accordingly. (See Pad Pressure Adjustments.)
After Use
To raise the pad driver, push down until the pedal arm engages into the pedal catch. Turn machine off by
turning the key switch on the control panel. Machine can be cleaned with a mild detergent and a damp cloth.
Batteries should be charged after each use or when the battery condition meter shows a low charge. Once the
battery charger reads 0 amps, the batteries are recharged. This should take approximately 8 hours if the
batteries are completely discharged.
Maintenance
Periodically remove batteries from machine. Clean the batteries and battery tray with a solution of baking soda
and water. Check all battery cables and wiring for signs of damage and wear. Replace as needed. Grease front
wheel and rear caster zerks once a month for best operation.
Floor Seal Strip
When the floor seal strip show signs of excessive wear, seal should be replaced. The strip can be removed by
loosening the screw on the retainer strap until the seal can slide off of the pad shroud housing. To install new
seal, slip the retainer strap over the new seal strip and pad shroud. Make sure the seal is seated equally around
the perimeter and the holes on the floor seal are oriented towards the back portion of the shroud.

Parts and Instruction Manual
Page 3
Battery Service and Installation
WARNING: Battery acid can cause burns. When working on or around batteries, wear protective clothing
and safety glasses. Remove metal jewelry. Do not lay tools or metal objects on top of batteries.
Charging of Batteries
Charging batteries generates explosive gasses. DO NOT CHARGE BATTERIES WHEN OPEN FLAMES OR
SPARKS ARE PRESENT. DO NOT SMOKE. Make sure the charger is turned off before disconnecting it from
the batteries. Charge the batteries in a well-ventilated area with battery cover removed completely. Fluid
levels should be checked before and after charging and maintained at the proper levels. If the burnisher is not
used for extended periods of time, batteries should be kept fully charged with a boost charge once a week.
Battery Cable Routing
Machine Overview Control Panel
1. Pad Pressure Adjust knob
2. Dashboard Control Panel
3. Foot Pedal
4. Circuit Breaker 70 AMP
5. Circuit Breaker 3 AMP
6. Main Power Switch
7. Emergency Button
8. Carbon Brush Indicator
9. Pad Pressure Gauge
10.Battery Gauge
3
4
5
1
2
7
8
6
910

Parts and Instruction Manual
Page 4
Pad Installation
The red emergency disconnect button and the key switch must be in the OFF position before installation and the
pad driver assembly in the RAISED position. Remove center cup locking device by gripping on outer edges and
turning clockwise. NOTE: Center cup cannot be pulled out; it must be unscrewed. After removing used pad, place
new pad on pad driver assembly using outer flange of pad driver to center the pad. Push centering locking cup
through the pad and into the pad driver assembly. The ratchet teeth on the center cup will engage into the pad
driver assembly and should be pushed in as far as possible. If further tightening is needed, rotate the center-locking
cup counter-clockwise
Pad Pressure Adjustments
The pad pressure adjust knob is located on the top of the control console. Counter-clockwise rotation increases pad
pressure,the opposite rotationdecreases.Differentfloors,conditions,and pads produce carryingpadloadconditions.
Ideal burnishing conditions are maintained while the operating range meter remains in the Green Zone. If the
meter reads in the Red Zone decrease the pad pressure. When the machine is operated in the Red Zone for a long
period of time motor overload will occur and the 70-amp circuit breaker for the motor will trip. If the motor circuit
trips:
1. Check pad condition.
2. Decrease pad pressure.
3. Reset circuit breaker.
Circuit Breaker Protection
70 amp circuit breaker protects pad driver motor from excessive overload conditions. 3.0 amp circuit breaker
protects control circuits against possible electrical shorts. If either circuit breaker trips, first determine the cause
and correct the condition before resetting the breakers.
Carbon Brush Replacement
Design life of carbon brushes is between 1800-2000 hours. Replace brushes if worn to 3/8" or less, broken, or
chipped. All carbon brushes should be replaced when motor is serviced. Four (4) are required, P/N 572003. Red
indicator on control panel (above Emergency Disconnect Button, below the Dashboard) will glow when carbon
brush service is required.
Carbon Brush Service
1. Disconnect batteries from machine.
2. Remove two screws that hold dust control housing and motor cover to motor.
3. Blow out top of motor with air line.
4. Loosen screw and remove carbon brush lead.
5. Slide brush spring off the back of carbon brush and remove brush.
6. Reverse order for installation of new carbon brushes.

Parts and Instruction Manual
Page 5
Exploded Views
Base Assembly

Parts and Instruction Manual
Page 6
ITEM PART NO. REQ'D DESCRIPTION
1 200154 1 PANEL COVER WELDMENT
2 200250 1 AXLE WELDMENT
3 200345 2 CASTER, 3-1/2 POLYURETHANE
4 260224 1 18" HOSE
5 260536 1 BASE PLATE WELDMENT
6 260537 1 LUMINA BATTERY SPACER
7 260549 1 PRESSURE ADJ ASSEMBLY
8 260558 1 BATTERY BOX
9 260568 1 CONSOLE ASSEMBLY
10 260570 1 ELECTRICAL PANEL ASSEMBLY
11 260579 1 TOOL CLIP, 1.5" HOSE
12 320271 1 NOZZLE BODY-ELBOW
13 320272 2 NOZZLE BODY LOCKNUT
14 320273 1 HOSE SHUT-OFF CLAMP
15 711124 6 PAN HEAD ST #10 X.37 NI
16 711160 10 #10 X5/8 HI-LO
17 711203 4 BLT-HH 1/4-20 X0.62 STPL
18 711228 4 BLT-HH 5/16-18 X.75 ST PL
19 711504 6 WSR-FLAT 1/4 ID SS
20 711505 13 WSR-FLAT 1/4
21 711507 4 WSR-FLAT .37 X1.12 X .06
22 711519 4 WSR- FLAT .25 X 1.01 X.06
23 711544 23 WSR-HELICAL 1/4
24 711545 4 WSR-HELICAL 5/16
25 711575 2 WSR-FLT .31x.75x..06ST
26 712042 2 BLT-WSR HH 5/16-18 X .62
27 712318 2 WSR- FLAT.75 X1.12 X .12 PL
28 712562 11 BOLT-HH 1/4-20X3/4 SS
29 712759 2 WSR- FLT .31 X1.37 X.06 SS
30 713002 8 BLT-HH 1/4-20 UNC-2A X 3/4 STL#5
31 715430 1 DECAL, BATTERY ROUTING
32 762332 2 WHEEL 8 X2 X.75 W/BEARING
33 809444 1 CLIP-CORD
34 200102MCH 1 BASE MACHINED
BILL OF MATERIAL
Base Assembly BOM

Parts and Instruction Manual
Page 7
Mainframe Assembly

Parts and Instruction Manual
Page 8
Mainframe Assembly BOM
ITEM PART NO. REQ'D DESCRIPTION
1 210142 1 PEDAL PAD
2 260211 2 HOBBY SPRING
3 260511 1 UPPER WMT
4 260513 1 MOTOR LIFT WELDMENT
5 260519 4 PIVOT PIN
6 260521 1 GUIDE TUBE
7 260522 1 SPRING GUIDE
8 260523 1 SPRING SPACER 1.50 X.632 X.84
9 260524 2 ADJUSTMENT LINK
10 260525 1 ADJUSTMENT NUT
11 260528 1 LINK
12 260529 2 TRAILING LINK
13 260536 1 BASE PLATE WELDMENT
14 260576 1 LINK
15 260610 1 SHROUD ASS'Y, NEW - LUMINA 20
16 670605 2 ROLLER PIN
17 710307 2 SCR-MC 6-32 X1.0 ST PL PAN HD
18 711350 2 NUT NYLOC 10-32
19 711380 1 NUT-NYLOC 3/8-16 NUT
20 711430 1 NUT-TINNERMAN TWIN 6-32
21 711501 2 WSR-FLAT # 6
22 711503 2 WSR, FLAT#10
23 711506 8 WSR-FLT .344 X .690 X.062 STL ZINC
24 711509 2 WSR-FLAT 1/2 (.54X1.082X.087)
25 711511 1 WSR-FLAT .62 X1.31 X.09
26 711515 2 WSR-FLAT .406 X .812 X.0625
27 711519 6 WSR- FLAT .25 X1.01 X.06
28 711524 6 WSR-WAVE .52 X.87 X.01
29 711592 2 WSR-FLAT .50 X.9 X.075 NYL
30 711713 14 RETAINING RING - "E" TYPE EXT .500
31 711717 2 RETAINING RING- E TYPE .37
32 711721 4 RET RING-E TYPE .312
33 711808 1 COTTER PIN-HAIR #13
34 712102 1 BLT- SHLDR 1/2 X 1-1/2
35 712301 1 WSR-FLAT .87 X.38 X .06
36 712310 28 WSR- FLAT .52 X.87 X.06 PL
37 712565 6 SCR-MC 1/4-20X.63 SS TR HD
38 712905 1 NUT-HEX10-24 NIPL
39 740830 1 SWITCH SPST NC CONTACT
40 762339 1 SPRING COMPRESSION
41 831965 1 3/8 x 1.63" CLEVIS PIN
42 260577-1 1 SWITCH INTERLOCK BRACKET
BILL OF MATERIAL

Parts and Instruction Manual
Page 9
Housing Assembly

Parts and Instruction Manual
Page 10
ITEM PART NO. REQ'D DESCRIPTION
1 260501 1 FIXED TOP COVER
2 260502 1 MOVING TOP COVER
3 260503 1 BAG COVER
4 260504 1 FILTER COVER WELDMENT
5 260560 1 HINGE 9.75"
6 260590 1 HOSE ASSY DUSTCONTROL
7 260592 1 EXHAUSTFILTER DUST CONTROL
8 260596 1 INSERT FITTING, 1-1/2"PVC, FPT
9 310008 1 O RING BUNA 2201510561
10 450037 1 ADAPTER MACHINED
11 450081 1 WSR-SS 1.908 x 2.41 x .03
12 450207 1 LATCH, SOFT #C7-10
13 710180 3 SCR-MC TR HD 1/4-20x.75 STL ZINC
14 711160 10 #10 X5/8 HI-LO
15 711228 4 BLT-HH 5/16-18 X.75 ST PL
16 711373 3 NUT-NYLOC 1/4-20
17 711374 4 NUT-NYLOC 5/16-18
18 711506 4 WSR-FLT .344 X.690 X.062 STL ZINC
19 711516 4 WSR- FLAT .31 X1.25 X.05
20 711519 3 WSR- FLAT .25 X1.01 X.06
21 828970 1 WSR-NEOP 1.87 X 2.4 X.125
22 831001 1 CRIMP CLAMP, 440R
BILL OF MATERIAL
Housing Assembly BOM

Parts and Instruction Manual
Page 11
Pad Driver Assembly

Parts and Instruction Manual
Page 12
ITEM PART NO. REQ'D DESCRIPTION
1 260573 1 MOTOR GRILL ASSY
2 260597 1 KEY, 3/16 X.906
3 260611 1 PAD DRIVER SHROUD - 20"
4 260615 1 MOTOR PLATE WELDMENT - NEW
5 260616 1 DUST SKIRT - NEW
6 260619 2 PAD DRIVER STRAP
7 670075 1 PAD DRIVER ASSY
8 710857 1 SCR-SC 5/16-24 X 1.00
9 711124 2 PAN HEAD ST #10 X .37 NI
10 711505 3 WSR-FLAT 1/4
11 711512 4 WSR-FLAT .75X1.37X.08
12 711516 1 WSR- FLAT .31 X1.25 X.05
13 711544 7 WSR-HELICAL 1/4
14 711545 1 WSR-HELICAL 5/16
15 712070 4 BLT, SHLDR 5/16 X .75
16 712537 14 10-24 X.75 SS TRUSS HD SCR
17 713003 3 BLT-HH 1/4-20 X1 #5
18 760401 1 CENTER CUP, NEW STYLE
19 809857 4 TRIGGER SPRING
20 260581MC H 1 GRABBER RING, MACHINED
21 742461-2 1 MOTOR 66 FRAME 36V HI SPD
BILL OF MATERIAL - 260610
Pad Driver Assembly BOM

Parts and Instruction Manual
Page 13
Pressure Control Assembly
ITEM PART NO. REQ'D DESCRIPTION
1 260066 1 OILITE BUSHING
2 260547 1 PRESS ADJ MOUNT WELD
3 260554 1 PRESS ADJ SCREW
4 260557 1 PRESS ADJ SLIDE
5 260562 1 PRESS ADJ RET BRKT
6 260563 1 PRESS ADJ RET BRKT
7 260564 1 ROLL PIN 3/16"X3/4"
8 710353 4 SCR-MC 10-32 X.37 ST PL
9 711391 1 NUT-HEXJAM 3/8-16 ST PL
10 712536 1 SCR-MC 10-24 X.62 TH SS
11 715038 1 DECAL, PAD PRESSURE
12 760034 1 KNOB, ADJ (SET SCREW)
13 762253 1 CABLE, ASSY PRESSURE
14 833102 1 SPRING, .62 X.75 X1.75
BILL OF MATERIAL - 260549

Parts and Instruction Manual
Page 14
Electrical Assembly
ITEM PART NO. REQ'D DESCRIPTION
1 260542 1 BACK PANEL WELDMENT
2 710356 2 SCR-MC 10-32X.62 STPL
3 711425 2 NUT, HEX1/4-20 WIZNUT
4 740131 1 CIRCUIT BREAKER - 70AMP
5 740132 2 INSULATOR, GLASTIC
6 740243 1 CONTACTOR 36V 124-117111
7 742749 2 HEYCO, HOLE PLUG
8 743464 1 SHUNT CALIBRATED ASSY
9 746006 1 CIRCUIT BREAKER - 3A
10 833638 2 BRASS STUD
BILL OF MATERIAL - 260570

Parts and Instruction Manual
Page 15
Console Assembly
ITEM PART NO. REQ'D DESCRIPTION
1 200104 1 HANDLE CONSOLE 200
2 260538 1 FRONT BRKT HANDLE WELDMT
3 260541 1 REAR HANDLE BRKT
4 260544 1 PANEL COVER
5 260569 1 DASH BRD ASSY, BURNISHER
6 710195 6 SCR- MC 5/16-18 X.50
7 711505 6 WSR-FLAT 1/4
8 711544 6 WSR-HELICAL 1/4
9 712540 8 SCR-MC TR HD 10-24 X.37 SS
10 713002 6 BLT-HH 1/4-20 UNC-2A X 3/4 STL#5
BILL OF MATERIAL - 260568

Parts and Instruction Manual
Page 16
Dashboard Assembly
ITEM PART NO. REQ'D DESCRIPTION
1 260546 1 DASHBOARD, BURNISHER
2 715297 1 DECAL, LUMINA 20
3 740135 1 METER, 100A DC (PRESSURE)
4 740136 1 METER, VOLT 22V45V BATTERY
5 742202 1 EMERGENCY STOP SWITCH
6 809754 1 SWITCH, ROCKER
7 746100-1 1 LIGHT ASSEMBLY
BILL OF MATERIAL - 260569
