Mips technologies Malta development platform User manual

Document Number: MD00141

Revision 6.03

December 20, 2009

MIPS Technologies, Inc.

955 East Arques Avenue

Sunnyvale, CA 94085-4521

MIPS® MaltaTM Developer’s Kit - Getting

Started with Windows® Embedded CE

MIPS® MaltaTM Developer’s Kit - Getting Started with Windows® Embedded CE, Revision 6.03 2

Contents

Section 1: Overview................................................................................................................................ 4

1.1: How to Get Started ...................................................................................................................................... 4

1.2: Target Hardware.......................................................................................................................................... 4

1.3: Host Development PC Requirements.......................................................................................................... 4

1.4: Required Software Tools ............................................................................................................................. 5

Section 2: Target Hardware Setup ........................................................................................................ 6

2.1: Jumper Settings........................................................................................................................................... 7

2.2: DIP Switch Settings ..................................................................................................................................... 7

2.3: Installing PCI Cards..................................................................................................................................... 7

2.3.1: Network Cards............................................................................................................................. 7

Section 3: Host Development PC Setup ............................................................................................... 8

3.1: Installing the Windows Embedded CE Tools............................................................................................... 8

3.2: Installing the MIPS Malta BSP..................................................................................................................... 8

3.3: Verify the Windows Embedded CE Tool Installation ................................................................................... 8

Section 4: Target Software Setup ....................................................................................................... 10

4.1: Installing the Windows Embedded CE Boot loader ................................................................................... 10

4.1.1: Binary installation: BOOT_xxx.fl ................................................................................................ 10

4.1.2: Binary installation: BOOT_xxx.bin ............................................................................................. 12

4.1.3: Binary installation: BOOT_xxx.sre............................................................................................. 14

4.2: Configuring the Windows Embedded CE Boot loader............................................................................... 17

Section 5: Host/Target Connectivity ................................................................................................... 19

Section 6: Support................................................................................................................................ 21

Section 7: Revision History ................................................................................................................. 22

3 MIPS® MaltaTM Developer’s Kit - Getting Started with Windows® Embedded CE, Revision 6.03

MIPS® MaltaTM Developer’s Kit - Getting Started with Windows® Embedded CE, Revision 6.03 4

1 Overview

This document describes how to get started with Microsoft® Windows® Embedded CE version 6.0 operating system

on the MIPS® Malta™development platform.

1.1 How to Get Started

New users of the Malta development platform are recommended to read and follow the guidelines in the document,

"Malta Developers Kit Getting Started" (MD00051), delivered along with the Malta board, to understand the basic

Malta hardware in operation and then continue with the guidelines in this document to proceed with setting up a Win-

dows Embedded CE development environment on Malta.

1.2 Target Hardware

The basic Malta hardware, as delivered, consists of the Malta motherboard and its daughter board, which carries a

suitable CPU (MIPS32-4Kc/4KEc/4KSc/24Kc/24Kf/34K/1004K or MIPS64-5Kc/5Kf/20Kc/25Kf) and System Con-

troller (Galileo GT64120, MIPS Bonito64, or MIPS SOCit™). The daughter board must be equipped with a minimum

32 MB PC100 SDRAM (64 MB is recommended). This release supports the L2 cache.

In addition to the basic Malta hardware, you will need:

• Suitable standard ATX cabinet with power supply. For a power supply with standby capabilities, a minimum cur-

rent of 720 mA is required (1A/1.5A peak recommended) for the 5V standby voltage.

• Windows Embedded CE compatible Video PCI card (the MIPS Malta BSP defaults to the ATI RageXL)

• Optional Windows Embedded CE compatible Audio PCI card (the MIPS Malta BSP defaults to the Ensoniq

ES1371 PDD)

• Optional NE2000 compatible Ethernet PCI card, when booting Windows Embedded CE stand alone applications.

(Nno KITL/VMINI transport)

• PS/2 Keyboard and Mouse

• VGA monitor

• Ethernet cables

• Parallel port cable for downloading Windows Embedded CE 6.0 boot loader

1.3 Host Development PC Requirements

Please see details on the Microsoft product, Windows Embedded CE 6.0, for the current list of requirements for the

host PC. Recent requirements included:

• 600 MHz Pentium (1 GHz recommended) processor

5 MIPS® MaltaTM Developer’s Kit - Getting Started with Windows® Embedded CE, Revision 6.03

• 192 MB RAM (256 MB recommended)

• Without MSDN, an aggragate of 3 GB, 3.8 or 4.8 GB with an MSDN installation

• CD-ROM or DVD-ROM drive is not required

• Graphics display of 800x600 at 256 colors; 1024x768 16-bit color recommended

• Microsoft Mouse or compatible pointing device

1.4 Required Software Tools

To start Windows Embedded CE development on Malta, you will need following software:

• Microsoft Windows Embedded CE version 6.0. This tool package contains Platform Builder 6.0, all the binary

Windows Embedded CE 6.0 OS kernels and system libraries, and the Microsoft® Visual C++® 2005.

NOTE: To get more information and to submit an order for the package, you may go to Microsoft’s website to

Products and Related Technologies, to Develop Tools, to Windows Embedded.

• MIPS Malta Development Platform BSP (release 06.00.00 or higher) for the Windows Embedded CE 6.0 operat-

ing system

NOTE: Please send an email request to "[email protected]om" with subject "Request for MIPS Malta Windows

Embedded CE 6.0 BSP".

• A terminal emulation program for communicating with the Target Malta board via its Debug Serial port. We do

not recommend using HyperTerm, as it can be confusing when used in this system to determine the order of lines

displayed from the target. Alternatives include Tera Term, which is a free terminal emulator (see The Tera Term

Home Page) and Procomm Plus32, which can be purchased from Datastorm Technologies.

MIPS® MaltaTM Developer’s Kit - Getting Started with Windows® Embedded CE, Revision 6.03 6

2 Target Hardware Setup

The diagram in Figure 1 shows the layout of the Malta board.

Figure 1 Location of Essential Features of Malta Board

12345678910

1 2 3 4 5 6 7 8

12 45 6 7 83

1 2 43

U42

J17

J15

J16

J14

J13

J12

J2 J4

JP4

JP2

J10

J22

J20

J19 J18

J21

JP1

JP3

S2 D28

ON/NMI

RESET

RST

STBY

3V3

ATX ON

FPGA

SPD100

J31

PCI SLOT#1

PCI SLOT#2

PCI SLOT#3

PCI SLOT#4

7 MIPS® MaltaTM Developer’s Kit - Getting Started with Windows® Embedded CE, Revision 6.03

For Windows Embedded CE on Malta, following locations are important to notice:

• ’JP4’ (left side): jumpers to control the PCI clock frequency

• ’S5-0’ (right side): dip switch "PROG" controls programming of on-board flash via the parallel port

• ’S5-1’ (right side): dip switch "BIGEND" controls endianness and must be set ’OFF’ = ’little endian’, as the

Windows Embedded CE operating system is available (compiled) for ’little endian’ only

• ’J12’-’J15’: PCI slots 1-4

2.1 Jumper Settings

By default, no jumpers are fitted on the Malta board.

NOTE: When using a Malta daughter board with a core bus speed slower than the default PCI-clock of 33 MHz, the

PCI-clock speed must be adjusted via jumper block JP4 to be the same or slower than the core bus speed. See "Malta

User’s Manual" (MD00048) Table 23 "Jumpers" for a list of available PCI-clock speeds and jumper combinations.

2.2 DIP Switch Settings

The dip switch, S5-1 BIGEND, must be set to OFF to set endianness = little. (The Windows Embedded CE operating

system is always compiled for little endianness.)

2.3 Installing PCI Cards

PCI cards may be installed in any slot on the Target Malta board, but some slots share interrupt lines with other

devices on the PCI bus. PCI card placement may affect interrupt priority and latency.

PCI devices map to the following interrupts:

• PCI slot 1 maps to PCI INTA which is steered to IRQ5 on the PIIX4E South Bridge Interrupt Controller

• PCI slot 2 and the on-board AMD Ethernet Controller (AM79C973) map to PCI INTB which is steered to IRQ10

on the PIIX4E South Bridge Interrupt Controller

• PCI slot 3 and the on-board Crystal Audio Controller (CS4281) map to PCI INTC which is steered to IRQ11 on

the PIIX4E South Bridge Interrupt Controller

• PCI slot 4 and the on-board PIIX4E USB Host Controller map to PCI INTD which is steered to IRQ9 on the

PIIX4E South Bridge Interrupt Controller

2.3.1 Network Cards

When using the Malta board with Platform Builder, the Malta on-board Ethernet Controller is supported by the shared

Ethernet driver of the MIPS Malta BSP, providing download and debug network traffic and application network traf-

fic as well. However, the shared Ethernet driver cannot be used for stand alone Windows Embedded CE applications,

when booting Windows Embedded CE images in non-debug mode. Therefore, to obtain network access for stand

MIPS® MaltaTM Developer’s Kit - Getting Started with Windows® Embedded CE, Revision 6.03 8

alone applications, an NE2000-compatible PCI Ethernet Controller may be installed in an available PCI slot. See the

Windows Embedded CE documentation for a list of supported PCI Ethernet Controllers.

3 Host Development PC Setup

3.1 Installing the Windows Embedded CE Tools

Windows Embedded CE 6.0 is delivered in conjuction with Microsoft Visual Studio 2005. To install, you will first

install the Microsoft Visual Studio Suite, and then install Windows Embedded CE 6.0. Follow the installation instruc-

tions for Microsoft Visual Studio 2005 first, which will lead you through two discs.

During installation configuration of Windows Embedded CE 6.0 , you will be asked to select which CPUs will be

supported. Please select all of the following:

• MIPSII

• MIPSII_FP

• MIPSIV

• MIPSIV_FP

3.2 Installing the MIPS Malta BSP

You can download the MIPS Malta BSP from the MIPS Technologies web site: http://www.mips.com/products/soft-

waretools/system_software/Windows_CE_BSP.php.

The download includes:

• This document (MD00141 – MaltaTM Developer’s Kit – Getting Started with Windows Embedded Embedded CE

6.0)

• Release Notes, in readme.txt

• Microsoft Installation package

The MIPS Malta BSP source, a Platform Builder CEC description file, and a readme.txt file detailing use of the BSP

with the Malta development board, are located in the Microsoft Installation package.

Double-click on the MSI file to begin installing the MIPS Malta BSP and follow the Package Wizard instructions to

complete the installation.

3.3 Verify the Windows Embedded CE Tool Installation

Now everything should be installed on the Host Development PC and the Windows Embedded CE development envi-

ronment for MIPS Malta BSP should be ready. The installation should be verified by building a Windows Embedded

9 MIPS® MaltaTM Developer’s Kit - Getting Started with Windows® Embedded CE, Revision 6.03

CE sample image. The following example describes how to build a sample image with the ready to use sample plat-

form, "Internet Appliance", and built for a "MIPSII" kernel, which is compliant with all supported MIPS CPU cards

on Malta.

Lauch Start-> All Programs-> Microsoft Visual Studio 2005-> Microsoft Visual Studio 2005, and execute the follow-

ing steps:

1. Enter File -> New-> Project

2. Select “Platform Builder for CE 6.0” in the left pane, and “OS Design” in the right. Enter a name for your new

design, and press OK.

3. Press Next.

4. Select “MIPS Malta: MIPSII”, and press Next.

5. Select Industrial Device and press Next.

6. Select Internet Appliance and press Next.

7. Press Finish,

8. The pop-up “Catalog Item Notification” is a standard Microsoft security warning; press Acknowledge.

9. Select “Build Solution” from the Build pull-down menu to build the Windows Embedded CE sample image and

await build completion. For those with prior experience with Microsoft CE products, avoid the “Advanced Build

Commands” -> “Build and Sysgen” option; it rebuilds code for which libraries are shipped that you do not need

to rebuild.

Verify that the image builds to completion with no errors.

You can change build options by selecting the Project -> Properties pull-down. In the pop-up window, select Config-

uration Properities -> Build Options. For example, if you are doing a release build, you may still want to enable the

Debugger.

NOTE: For Step 9, a potential risk exists, especially when building big images like debug images, to get build errors

like "Error: Too much data space used by DLLs in MODULES section....". The reason is that more static memory

than the default (min. 32 MB device) is required and must be assigned by setting a predefined environment variable

"IMGRAM64" to "1" (min. 64 MB device). This Build Option can be found on the same pop-up window as described

in the previous paragraph – it is labeled “Run-time image can be larger than 32 MB (IMGRAM64=1)”.

Once you have done a build, you can modify the build options, or the BSP code, and need not recompile the entire

Windows Embedded CE space. You can rebuild just the BSP by going into the Solution Explorer, expand your solu-

tion name, and the top of the Windows Embedded CE tree, expand PLATFORM, and you will see “MIPS_MALTA”.

If you right-click on MIPS_MALTA, you can do a build (or re-build) just from there, for a great savings of time. Note

this will not work if you have not already completed a build, or if you have changed anything outside the scope of the

BSP.

MIPS® MaltaTM Developer’s Kit - Getting Started with Windows® Embedded CE, Revision 6.03 10

4 Target Software Setup

4.1 Installing the Windows Embedded CE Boot loader

After the MIPS Malta BSP has been installed into Platform Builder, The Windows Embedded CE boot loader binary

files and a readme.txt file detailing the installation of the boot loader, is located in the following directory:

%_WINCEROOT%\PLATFORM\MIPS_MALTA\bin

This directory contains the boot loader images for the Target Malta board in Motorola S-record format, Yamon BIN

format and MIPS Malta 1284 Flash Download format. There are two types of BOOT images delivered with the MIPS

Malta BSP. One supports at least 32 MB of RAM, and the other supports at least 64 MB of RAM. Please choose the

appropriate image for your application.

The MIPS Malta boot loader for Windows Embedded CE 6.0 is not backwards-compatible with OS images built on

an older version of Windows CE.

4.1.1 Binary installation: BOOT_xxx.fl

The MIPS Malta Flash Download binary file, BOOT_xxx.fl, may be downloaded via the Parallel port to the Target

Malta board.

Before you begin, you must attach a Parallel port cable between the Target Malta board and the Host Development

PC. You should also have a serial cable attached between the Debug Serial port (TTY0) on the Target Malta board and

the Host Development PC, and your preferred terminal emulator connected directly to the COM port where the cable

is connected on the Host Development PC.

Having attached all cables to the Target Malta board, you should now power up the Malta board and a YAMON

prompt, like the example below, should be displayed in your terminal emulator.

YAMON ROM Monitor, Revision 02.13.

For a list of available commands, type ’help’.

Compilation time = Dec 7 2006 19:22:35

Board type/revision = 0x02 (Malta) / 0x00

Core board type/revision = 0x0a (Core24K) / 0x00

System controller/revision = MIPS SOC-it 101 OCP / 1.3 SDR-FW-2:1

FPGA revision = 0x0001

MAC address = 00.d0.a0.00.01.4e

Board S/N = 0000000086

PCI bus frequency = 33.33 MHz

Processor Company ID/options = 0x01 (MIPS Technologies, Inc.) / 0x00

Processor ID/revision = 0x93 (MIPS 24Kc) / 0x64

Endianness = Little

CPU/Bus frequency = 266 MHz / 133 MHz

Flash memory size = 4 MByte

SDRAM size = 128 MByte

First free SDRAM address = 0x800b7360

11 MIPS® MaltaTM Developer’s Kit - Getting Started with Windows® Embedded CE, Revision 6.03

YAMON>

Please verify from the prompt that Endianness = Little. If not, set Malta DIP-switch S5-2=OFF.

1. Enable Flash Download mode by setting DIP switch S5-0 (PROG) to ON. The Alpha display should read:

Flash DL

2. On the Host Development PC side enter the BIN directory in the MIPS Malta BSP. From the command line, exe-

cute the following command:

For the 32 Mbyte image:

%_WINCEROOT%\PLATFORM\Mips_malta\Bin> ..\Scripts\go_32MB.bat

For the 64 Mbyte image:

%_WINCEROOT%\PLATFORM\Mips_malta\Bin> ..\Scripts\go_64MB.bat

3. When completed, the Alpha display should read:

FINISHED

4. Disable Flash Download mode by setting DIP switch S5-0 (PROG) to ’OFF’. A YAMON prompt like the exam-

ple below, should be displayed on the terminal emulator.

YAMON ROM Monitor, Revision 02.13.

For a list of available commands, type ’help’.

Compilation time = Aug 12 2002 11:22:06

Board type/revision = 0x02 (Malta) / 0x00

Core board type/revision = 0x03 (Core20K) / 0x02

System controller/revision = Bonito64 / 1-10f-e2 02/06/25/10:49

FPGA revision = 0x0001

MAC address = 00.d0.a0.00.00.91

Board S/N = 0000000024

PCI bus frequency = 33.33 MHz

Processor Company ID/options = 0x01 (MIPS Technologies, Inc.) / 0x04

Processor ID/revision = 0x82 (MIPS 20Kc) / 0x60

Endianness = Little

CPU/Bus frequency = 500 MHz / 100 MHz

Flash memory size = 4 MByte

SDRAM size = 64 MByte

First free SDRAM address = 0x800adc80^

YAMON>

5. Setup YAMON to execute the boot loader program after reset:

YAMON> set start ’go be100000’

6. Now, reset the Target Malta board (either YAMON-cmd: ’reset’ or press front reset button)

The boot loader will come up with the following display on the Debug Serial port:

MIPS® MaltaTM Developer’s Kit - Getting Started with Windows® Embedded CE, Revision 6.03 12

Microsoft Windows CE Ethernet Bootloader Common Library Version 6.0 Built

May 29 2007 at 13:21:28

Microsoft Windows CE Ethernet Bootloader Version 6.0 for MIPS Malta Built

May 29 2007 at 15:38:47

Processor Info: Company MIPS Technologies Inc., Implementation 20Kc.

L1 ICache Info: SetsPerWay 256, NumWays 4, LineSize 32, Size 32768.

L1 DCache Info: SetsPerWay 256, NumWays 4, LineSize 32, Size 32768.

TLB Entries: 48.

CPU Frequency: 267 MHz

SDRAM Size: 64 MBytes

System ready!

Preparing for download...

INFO: Predownload....

INFO: No boot configuration found at 0x9e180000

Hit space to enter configuration menu 5...

Hit space to enter configuration menu 4...

...

You have now completed installation of the Windows Embedded CE boot loader.

4.1.2 Binary installation: BOOT_xxx.bin

The YAMON binary file, BOOT_xxx.bin, may be downloaded via the Ethernet port (TFTP download) to the Target

Malta board.

Before you begin, you must copy the Windows Embedded CE 6.0 boot loader image, BOOT_xxx.bin, to your TFTP

host’s TFTP boot directory. Attach an Ethernet port cable to the Target Malta board so it resides on a network that can

access the TFTP host. You should also have a serial cable attached between the Debug Serial port (TTY0) on the Tar-

get Malta board and the Host Development PC, and your preferred terminal emulator connected directly to the COM

port where the cable is connected on the Host Development PC.

Having attached all cables to the Target Malta board, you should now power up the Malta board and a YAMON

prompt like the example below should be displayed in your terminal emulator.

YAMON ROM Monitor, Revision 02.13.

For a list of available commands, type ’help’.

Compilation time = Aug 12 2002 11:22:06

Board type/revision = 0x02 (Malta) / 0x00

Core board type/revision = 0x03 (Core20K) / 0x02

System controller/revision = Bonito64 / 1-10f-e2 02/06/25/10:49

FPGA revision = 0x0001

MAC address = 00.d0.a0.00.00.91

Board S/N = 0000000024

PCI bus frequency = 33.33 MHz

Processor Company ID/options = 0x01 (MIPS Technologies, Inc.) / 0x04

Processor ID/revision = 0x82 (MIPS 20Kc) / 0x60

Endianness = Little

CPU/Bus frequency = 500 MHz / 100 MHz

13 MIPS® MaltaTM Developer’s Kit - Getting Started with Windows® Embedded CE, Revision 6.03

Flash memory size = 4 MByte

SDRAM size = 64 MByte

First free SDRAM address = 0x800adc80

YAMON>

Please verify from the prompt, that ’Endianness = Little’. If not, set Malta DIP-switch S5-2=OFF.

1. Get a reserved IP-address from your network administrator for YAMON’s IP-stack.

Setup YAMON IP-address:

YAMON> set ipaddr 192.168.201.52

Setup YAMON subnetmask:

YAMON> set subnetmask 255.255.255.0

When needed, setup YAMON IP-gateway (ask your network administrator):

YAMON> set gateway 192.168.201.254

Setup TFTP-hostserver:

YAMON> set bootserver 192.168.201.197

Now you have completed the YAMON network setup and are ready to start the download and install procedure of

the Windows Embedded CE 6.0 boot loader image.

2. Initially, clear 128 KB of user FLASH area:

YAMON> erase be100000 20000

3. Download the boot loader image via TFTP from the TFTP host into the Target Malta board RAM:

YAMON> fread tftp://<tftphost>/BOOT_xxx.bin 80100000

About to binary read tftp://<tftphost>/BOOT_xxx.bin

Press Ctrl-C to break

Start = 0x80100000, range = (0x80100000,0x80119FC0), format = BIN

4. Flush the downloaded image to memory:

YAMON> flush

5. Copy the boot loader image from RAM to user FLASH:

YAMON> copy 80100000 be100000 20000

6. Configure YAMON to execute the boot loader program after reset:

MIPS® MaltaTM Developer’s Kit - Getting Started with Windows® Embedded CE, Revision 6.03 14

YAMON> set start ’go be100000’

7. Now, reset the Target Malta board (either YAMON-cmd: ’reset’ or press front reset button)

The boot loader will come up with the following display on the Debug Serial port:

Microsoft Windows CE Ethernet Bootloader Common Library Version 1.0 Built

May 29 2007 at 13:21:28

Microsoft Windows CE Ethernet Bootloader Version 5.0 for MIPS Malta Built

May 29 2007 at 15:38:47

Processor Info: Company MIPS Technologies Inc., Implementation 20Kc.

L1 ICache Info: SetsPerWay 256, NumWays 4, LineSize 32, Size 32768.

L1 DCache Info: SetsPerWay 256, NumWays 4, LineSize 32, Size 32768.

TLB Entries: 48.

CPU Frequency: 267 MHz

SDRAM Size: 64 MBytes

System ready!

Preparing for download...

INFO: Predownload....

INFO: No boot configuration found at 0x9e180000

Hit space to enter configuration menu 5...

Hit space to enter configuration menu 4...

...

You have now completed installation of the Windows Embedded CE boot loader.

4.1.3 Binary installation: BOOT_xxx.sre

The Motorola S-record file, BOOT_xxx.sre, may be downloaded either via the Debug Serial port or Ethernet port

(TFTP download) to the Target Malta board.

Before you begin, you must copy the Windows Embedded CE 6.0 boot loader image, BOOT_xxx.sre, to your termi-

nal emulator’s download directory or your TFTP host’s TFTP boot directory, depending on your preferred download

type. If you select TFTP download, attach an Ethernet port cable to the Target Malta board so it resides on a network

that can access the TFTP host. You should also have a serial cable attached between the Debug Serial port (TTY0) on

the Target Malta board and the Host Development PC, and your preferred terminal emulator connected directly to the

COM port where the cable is connected on the Host Development PC.

Having attached all cables to the Target Malta board, you should now power up the Malta board and a YAMON

prompt like the example below should be displayed in your terminal emulator.

YAMON ROM Monitor, Revision 02.13.

For a list of available commands, type ’help’.

Compilation time = Aug 12 2002 11:22:06

Board type/revision = 0x02 (Malta) / 0x00

Core board type/revision = 0x03 (Core20K) / 0x02

System controller/revision = Bonito64 / 1-10f-e2 02/06/25/10:49

15 MIPS® MaltaTM Developer’s Kit - Getting Started with Windows® Embedded CE, Revision 6.03

FPGA revision = 0x0001

MAC address = 00.d0.a0.00.00.91

Board S/N = 0000000024

PCI bus frequency = 33.33 MHz

Processor Company ID/options = 0x01 (MIPS Technologies, Inc.) / 0x04

Processor ID/revision = 0x82 (MIPS 20Kc) / 0x60

Endianness = Little

CPU/Bus frequency = 500 MHz / 100 MHz

Flash memory size = 4 MByte

SDRAM size = 64 MByte

First free SDRAM address = 0x800adc80

YAMON>

Please verify from the prompt, that Endianness = Little. In case not, set Malta DIP-switch S5-2=OFF.

1. If you are going to download via TFTP, get a reserved IP-address from your network administrator for YAMON’s

IP-stack.

Setup YAMON IP-address:

YAMON> set ipaddr 192.168.201.52

Setup YAMON subnetmask:

YAMON> set subnetmask 255.255.255.0

When needed, setup YAMON IP-gateway (ask your network administrator):

YAMON> set gateway 192.168.201.254

Setup TFTP-hostserver:

YAMON> set bootserver 192.168.201.197

Now you have completed the YAMON network setup and are ready to start the download and install procedure of

the Windows Embedded CE 6.0 boot loader image.

2. Initially, clear 128 KB of user FLASH area:

YAMON> erase be100000 20000

3. Download the boot loader image via Serial/TFTP from the Host Development PC/TFTP host into the Target

Malta board RAM:

Serial download:

YAMON> load asc://tty0

About to load asc://tty0

Press Ctrl-C to break

Start dump from terminal program

NOTE: Now download/dump the BOOT_xxx.sre file from your terminal emulator. If you are using TeraTerm,

select the pulldown menu option File -> Send File..., and select the file to send. With Hyperterminal, you must

MIPS® MaltaTM Developer’s Kit - Getting Started with Windows® Embedded CE, Revision 6.03 16

enter the menu Transfer-> SendTextFile

TFTP download:

YAMON> load tftp://<tftphost>/BOOT_xxx.sre

About to load tftp://<tftphost>/BOOT_xxx.sre

Press Ctrl-C to break

The load message for the 32 MB image:

Start = 0x81F80004, range = (0x81F80000,0x81F99FC0), format = SREC

The load message for the 64 MB image:

Start = 0x83F80004, range = (0x83F80000,0x83F99FC0), format = SREC

4. Flush the downloaded image to memory:

YAMON> flush

5. Copy the boot loader image from RAM to user FLASH:

The 32 MB image:

YAMON> copy 81F80000 be100000 20000

The 64 MB image:

YAMON> copy 83F80000 be100000 20000

6. Configure YAMON to execute the boot loader program after reset:

YAMON> set start ’go be100000’

7. Now, reset the Target Malta board (either YAMON-cmd: ’reset’ or press front reset button)

The boot loader will come up with the following display on the Debug Serial port:

Microsoft Windows CE Ethernet Bootloader Common Library Version 1.0 Built

May 29 2007 at 13:21:28

Microsoft Windows CE Ethernet Bootloader Version 6.0 for MIPS Malta Built

May 29 2007 at 15:38:47

Processor Info: Company MIPS Technologies Inc., Implementation 20Kc.

L1 ICache Info: SetsPerWay 256, NumWays 4, LineSize 32, Size 32768.

L1 DCache Info: SetsPerWay 256, NumWays 4, LineSize 32, Size 32768.

TLB Entries: 48.

CPU Frequency: 267 MHz

SDRAM Size: 64 MBytes

System ready!

17 MIPS® MaltaTM Developer’s Kit - Getting Started with Windows® Embedded CE, Revision 6.03

Preparing for download...

INFO: Predownload....

INFO: No boot configuration found at 0x9e180000

Hit space to enter configuration menu 5...

Hit space to enter configuration menu 4...

...

You have now completed installation of the Windows Embedded CE boot loader.

4.2 Configuring the Windows Embedded CE Boot loader

After installation completion, the Windows Embedded CE 6.0 boot loader must be configured to communicate with

the Host Development PC. During boot loader initialization, the following messages will be displayed on the terminal

emulator:

Hit space to enter configuration menu 5...

Hit space to enter configuration menu 4...

Hit space to enter configuration menu 3...

Hit space to enter configuration menu 2...

...

Hit the spacebar within the terminal emulator window and navigate the boot loader menus to setup the Boot/Debug

device and Network settings. The top level menu options are as follows:

----------------------------------------------------------

Main Menu

----------------------------------------------------------

[1] Show Current Settings

[2] Set Device Id

[3] Select Boot Device

[4] Select Debug Device

[5] Network Settings

[6] Save Settings

[0] Exit and Continue

When finished, save your settings and exit. The boot loader will continue with its initialization and attempt to connect

with your Host Development PC. You should see something similar to the following output to your terminal emula-

tor:

Am79c973: Wait for link... Link detected

INFO: Boot device uses MAC 00:d0:a0:00:03:1c

INFO: *** Device Name MALTA796 ***

InitDHCP():: Calling ProcessDHCP()

ProcessDHCP()::DHCP_INIT

Got Response from DHCP server, IP address: 172.20.4.2

ProcessDHCP()::DHCP IP Address Resolved as 172.20.4.2, netmask: 255.255.255.224

Lease time: 90060 seconds

Got Response from DHCP server, IP address: 172.20.4.2

No ARP response in 2 seconds, assuming ownership of 172.20.4.2

MIPS® MaltaTM Developer’s Kit - Getting Started with Windows® Embedded CE, Revision 6.03 18

+EbootSendBootmeAndWaitForTftp

Sent BOOTME to 255.255.255.255

Take note of the Device Name, as you will need it later when connecting the Target Malta board to the Host Develop-

ment PC.

After configuration has completed, the Malta development board provides standard Windows CE SDB development

services, accessible from the Host Development PC via the Platform Builder tools.

19 MIPS® MaltaTM Developer’s Kit - Getting Started with Windows® Embedded CE, Revision 6.03

5 Host/Target Connectivity

After the Host Development PC and Target Malta board have been set up and configured, Windows Embedded CE

6.0 images can be downloaded and debugged using the KITL transport and debug services in Platform Builder. To

verify KITL is working, performing the following steps:

1. Check that the Target Malta Board is still sending "BOOTME" messages. If not, then reset the board and allow

the Windows Embedded CE 6.0 boot loader to reinitialize.

2. On the Host Development PC side, start Microsoft Visual Studio 2005, and open the Sample Project that you

made. Then enter the pull-down menu Target -> Connectivity Options …. Bring the Connectivity Options pop-up

window the foreground.

3. Set Download and Transport both to Ethernet and press ’Settings’ beside the ’Download’ pane to enter the

"Ethernet Download Settings" submenu to select the target device (the target device name should appear in the

selection pane), while the target issues the ’BOOTME’ messages.

4. Finally go to submenu Target->Attach Device to start the download.

5. You should now see the following debug messages on the terminal emulator:

Sent BOOTME to 255.255.255.255

Packet has the following data:

boot.bin[NULL]octet[NULL]

TFTP packet could have 1 name/value pairs

Locked Down Link 1

Src IP 192.168.1.4 Port 03D4 Dest IP 192.168.1.6 Port 0493

Default TFTP block size set to: 512 bytes

There were no options detected in the TFTP

EthDown::TFTPD_OPEN::boot.bin

-EbootSendBootmeAndWaitForTftp

BL_IMAGE_TYPE_BIN

TFTP: Desktop losing ACK, block number = 28628, Ack again

rom_offset=0x0.

ImageStart = 0x80002000, ImageLength = 0x18FE0CC, LaunchAddr = 0x80002004

Completed file(s):

------------------------------------------------------------------------------

[0]: Address=0x80002000 Length=0x18FE0CC Name="" Target=RAM

ROMHDR at Address 80002044h

INFO: Lauch Windows CE .NET by jumping to 0x80002004...

Windows CE Kernel for MIPS Built on May 14 2007 at 16:15:00

+OEMInit

+OALMIPSGetProcessorId()=0x1954C

Processor Info: Company MIPS Technologies Inc., Implementation Unknown.

L1 ICache Info: SetsPerWay 512, NumWays 4, LineSize 32, Size 65536.

MIPS® MaltaTM Developer’s Kit - Getting Started with Windows® Embedded CE, Revision 6.03 20

L1 DCache Info: SetsPerWay 512, NumWays 4, LineSize 32, Size 65536.

TLB Entries: 32.

CPU frequency: 50 MHz

SDRAM size: 128 MBytes

DeviceId................. MALTA871

pArgs->flags............. 0xD

pArgs->devLoc.IfcType.... 5

pArgs->devLoc.LogicalLoc. 0xB00

pArgs->devLoc.PhysicalLoc 0x0

pArgs->devLoc.Pin........ 5

pArgs->ip4address........ 1

pDevice->Name............ s

pDevice->ifcType......... 5

pDevice->id.............. 0x20001022

pDevice->resource........ 1

pDevice->type............ 2

pDevice->pDriver......... 0x81908000

Am79c973: Wait for link...

Link detected

Am79c973: Enable Tx ... KITL: *** Device Name MALTA871 ***

KITL: using sysintr 0x10

-OALKitlEthInit: Getting DCHP address

KITL: DHCP get/renew device IP: 1

-OALKitlEthInit: Got DCHP address

VBridge:: built on [Sep 6 2006] time [19:28:01]

VBridgeInit()...TX = [16384] bytes -- Rx = [16384] bytes

Tx buffer [0xA193EEE0] to [0xA1942EE0].

Rx buffer [0xA1942F00] to [0xA1946F00].

VBridge:: NK add MAC: [0-D0-A0-0-3-67]

Connecting to Desktop

KITL: Connected host IP: 1 Port: 1169

KITL: Leaving polling mode... 0x8192EBC0

Closing Handle of Timer Thread

VBridge:: VB_INITIALIZED returns [1]

VBridge:: RESET_BUFFER received.

VBridge:: built on [Sep 6 2006] time [19:28:01]

VBridgeInit()...TX = [16384] bytes -- Rx = [16384] bytes

Tx buffer [0xA193EEE0] to [0xA1942EE0].

Rx buffer [0xA1942F00] to [0xA1946F00].

VBridge:: Current VMini packet filter = [0xB]

NOTE: Your example configuration has been built with the KITL support, selected before build in the submenu Plat-

form-> Settings and ’Build Options’ with click-select in the ’Enable KITL’.

Table of contents

Popular Microcontroller manuals by other brands

mikroElektronika

mikroElektronika CLICKER PIC32MX manual

Freescale Semiconductor

Freescale Semiconductor TWR-K21F120M quick start guide

mikroElektronika

mikroElektronika clicker STM32 M4 manual

Silicon Laboratories

Silicon Laboratories Si4311-DB user guide

Renesas

Renesas DK-S128 user manual

Altera

Altera MAX 10 series user guide

Lattice

Lattice Versa ECP5-5G quick start

Microsemi

Microsemi UG0557 user guide

Sino Wealth

Sino Wealth SH79F6441 manual

ZiLOG

ZiLOG Z8F08200100KIT user manual

Pro-face

Pro-face PS Series Developer's manual

Co2meter

Co2meter SE-11 manual

M-TI

M-TI M200-RS quick start guide

Renesas

Renesas M16C/29 user manual

Pololu

Pololu A-Star 32U4 Series Schematic diagram

Adafruit

Adafruit ESP32-S3 manual

Chipcon

Chipcon CC1010DK Quick start instructions

ST STR71xF manual

Mips Technologies Malta development platform User manual

Popular Microcontroller manuals by other brands
