Mira Mode Maxim User manual

Your Product Guarantee
This product has been designed for domestic use only, it is not recommended for Commercial or
Healthcare use.
For Domestic installations, Kohler Mira guarantee this product against any defect in materials or
workmanship for a period of ve years from the date of purchase (shower ttings for one year). Within
the guarantee period we will resolve defects in materials or workmanship, free of charge, by repairing
or replacing parts or product as we may choose.
This guarantee only applies in the United Kingdom and the Republic of Ireland.
Activating Your Guarantee
Registering your guarantee is quick and simple. To ensure your product is covered, please register
online www.mirashowers.co.uk/support/guarantee-registration.
What is Covered
This guarantee is in addition to your statutory rights and is subject to the following conditions
• The guarantee applies solely to the original installation under normal use and to the original purchaser
only. The product must be installed and maintained in accordance with the instructions given in this
guide.
• Servicing must only be undertaken by us or our appointed representative.
Note! If a service visit is required the product must be fully installed and connected to
services.
• Repair under this guarantee does not extend the original expiry date. The guarantee on any replacement
parts or product ends at the original expiry date.
• For shower ttings or consumable items we reserve the right to supply replacement parts only.
What is Not Covered
• Call out charges for non product faults (such as damage or performance issues arising from inc or rect
installation, improper use, inappropriate cleaning, lack of maintenance, build up of limescale,
frost damage, chemical attack, where no fault has been found with the product.
• Water or electrical supply, waste and isolation issues.
• Compensation for loss of use of the product or consequential or indirect loss of any kind.
• Damage or defects caused if the product is repaired or modied by persons not authorised by us or
our appointed representative.
• Routine maintenance or replacement parts to repaired or modied by persons not authorised by
comply with the requirements of the TMV2 or repaired or modied by persons not authorised by
TMV3 healthcare schemes.
• Accidental or wilful damage.
• Products purchased ex-showroom display.
Any questions regarding your guarantee? Give us a call on 0800 001 4040.
© Kohler Mira Limited, October 2018
Mira is a registered trade mark of Kohler Mira Limited.
The company reserves the right to alter product specications without notice.
UK
T: 0800 001 4040
E: [email protected]
www.mirashowers.co.uk
Eire
T: 01 531 9337
E: customerser[email protected]
www.mirashowers.ie
Mira Mode Maxim
Digital Mixing Valve
Installation and User Guide
Please leave these instructions with the user
1366055-W2-A

Thank you for purchasing a Mira Mode Maxim. To enjoy the
full potential of your new product, please take time to read
this guide thoroughly, having done so, keep it handy for future
reference. For step-by-step installation videos, datasheets or
spares information, please visit the Mira Showers website.
Contents
Important Safety Information 4
Guarantee 6
Recommended Usage 6
Pack Contents 7
Specications 12
General installation Notes 14
Suitable Plumbing Installations 14
Installation
Digital Mixing Valve 17
Controller 22
On/o󰀨 Remote Button 24
Shower ttings 26
Commissioning 39
Set Up 40
Fault Diagnosis 43
Cleaning & Maintenance 47

54
1. Installation of this product must be carried out in accordance
with these instructions by qualied, competent personnel. Read
all instructions before commencing installation.
2. The electrical installation must comply with BS 7671 (commonly
referred to as the IEE Wiring Regulations) and all relevant
building regulations, or any particular regulation or practice
specied by the local electricity supply company.
3. The plumbing installation must comply with all national or local
water regulations and all relevant building regulations, or any
particular regulation or practice specied by the local water
supply company.
4. Isolate the electrical and water supplies before commencing
installation. Mains connections are exposed when the valve
module cover is removed.
5. The valve module must be earthed, ensure supplementary
bonding is provided in accordance with the wiring regulations.
6. The valve module must be permanently connected to a 3A fused
connection unit and be provided with means for disconnection
incorporated in the xed wiring in accordance with the wiring
regulations.
7. We strongly recommend that a 30mA RCD is included in the
electrical supply to the valve module.
8. DO NOT install the valve module, controller or the On/
O󰀨 Remote Button in areas with high humidity and temperature
(i.e. steam rooms and saunas).
9. DO NOT install the valve module or ttings where they may be
exposed to freezing conditions. Ensure that any pipework that
could become frozen is properly insulated.
10. DO NOT perform any unspecied modications, drill or cut holes
in the product other than instructed by this guide. When servicing
only use genuine Mira Showers replacement parts.
11. DO NOT operate the product if water is leaking from inside the
valve module. Isolate electrical and water supplies to the product
and refer to the fault diagnosis section.
12. DO NOT apply power to the product if it is thought to have been
exposed to freezing conditions. Isolate electrical and water
supplies to the product and contact Kohler Mira Ltd.
13. DO NOT allow children to play with the product.
14. DO NOT allow children to clean or perform any user maintenance
without supervision.
15. DO NOT remotely operate or alter any of the Mira Mode Maxim
shower settings if it is already occupied and / or being used by
another person.
16. If the valve module is dismantled during installation or servicing
then, upon completion, an inspection must be made to ensure
all electrical connections are secure and that there are no leaks.
17. Make sure that you fully understand how to operate this shower
and make sure that it is properly maintained in accordance with
the instructions given in this manual.
Important Safety Information
Products manufactured by Kohler Mira Ltd. are designed to be safe, provided that they are
installed, used and maintained in good working order, in accordance with our instructions
and recommendations. Follow all warnings, cautions and instructions contained in this guide,
and on, or inside the product. Failure to follow the instructions provided with this product
will invalidate the guarantee.
Warning! To reduce the risk of re, electric shock or injury please read the important
information listed below.

76
18. The Mira Mode Maxim can be used by children aged from
8 years and above and persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning the
use of the appliance in a safe way and understand the hazards
involved.
19. Always check the water temperature is safe before bathing or
showering.
20. DO NOT use excessive force when making connections.
21. Avoid layouts where the shower hose will be sharply kinked.
This may reduce the life of the hose.
22. Special consideration should be given to the xing arrangements
when installing onto a dry lined, stud partition, shower cubicle or
laminated panel wall structures. Installers may wish to obtain
alternative proprietary cavity xings, or choose other options,
however, these methods of xing are beyond the scope of this
guide.
23. The position of the shower ttings must provide a minimum air
gap of 25mm between the handshower and the spill over level of
any bath, shower tray or basin. There must be a minimum
distance of 30mm between the handshower and the spill over
level of any toilet, bidet or other appliance with a Fluid Category
5 backow risk.
Guarantee
The Mira Mode Maxim has been designed for domestic use only, it is not recommended for
Commercial or Healthcare use. For domestic installations, Kohler Mira Ltd., guarantee the
Mira Mode Maxim against any defect in materials or workmanship for a period of ve years
from the date of purchase (shower ttings for one year).
For non-domestic installations. Mira Showers
guarantee the Mira Mode Maxim against
any defect in materials or workmanship for a
period of one year from the date of purchase.
Recommended Usage
Domestic 
Light Commercial 
Heavy Commercial 
Healthcare 
Pack Contents
Digital Mixing Valve
Interface
1 x Flow Regulator
Component Pack
1 x Backplate
1 x Component Pack
1 x Installation Template1 x Interface
3 x Wall Plugs
3 x Fixing Screws
2 x Outlet Connectors
OR
2 x Push-Fit Isolators

98
Ceiling Fed Shower Fittings Rear Fed Shower Fittings
1 x Plastic Pipe
1 x Ceiling Plate
2 x Spacers
1 x Extension
1 x Elbow
2 x Wall Plugs
2 x 45 mm Screws
2 x 70 mm Screws
1 x Slide Bar
Assembly
1 x Handset
1 x Component Pack
1 x Hex Key2 x Hex Screws
2 x Brackets
1 x Hose
2 x Rubber Washers
3 x Wall Plugs
3 x Fixings Screws
1 x Component Pack
1 x Slide Bar
Assembly
1 x RAC Assembly
1 x Hose
Retaining Ring
1 x Hex Key
1 x Cover Cap
1 x Screw
1 x ‘O’ Seal
1 x Handset
1 x Hose
2 x Rubber Washers

1110
Ceiling Fed Deluge Head Rear Fed Deluge Head
1 x Concealing Plate1x Elbow
1 x Deluge Head
1 x Brazed Pipe
Assembly
1 x Rain Core
1 x Core Removal Tool
1 x Chrome
Supply Tube
1 x Ceiling
Mount Plate
Assembly
1 x Shower Arm
1 x Concealing Shroud
1 x Deluge Head
2 x Wall Plugs
2 x Fixing Screws
1 x Cable
1 x On/Off Button
1 x Cleaning Wipe
1 x Backplate Assembly
1 x Rain Core
1 x Core Removal Tool
Optional On/O󰀨 Button

1312
Specications
Standards and Approvals
The Mira Mode Maxim complies with all relevant directives for CE marking.
The Mira Mode Maxim is a type 1 electronic, independently mounted control for surface
mounting. The Mira Mode Maxim is in compliance with the essential requirements of the RED
directive 2014/53/EU. A copy of the declaration of conformity may be obtained by visiting
www.mirashowers.co.uk/for-the-expert/resources/product-approvals.
Mira Digital Mixing Valve High Pressure (Not suitable for pumped gravity systems)
Mira Digital Mixing Valve Pumped (Not suitable for mains pressure systems)
Shower Fittings
General
Pollution Degree 2
Rated Impulse Voltage 2.5 kV
Connections 15mm Compression/Pusht
Pressures
Maximum Static Pressure 1000 kPa (10 bar)
Maximum Maintained Pressure 500 kPa (5 bar)
Minimum Maintained Pressure 100 kPa (1 bar)
Supply Pressure Di󰀨erential Nominally Equal
Temperatures
Maximum Temperature (setting range) 35°C - 45°C (Factory Preset 45°C)
Minimum Temperature Thermostatic control down to 30°C
Full Cold also selectable
Hot Water Range - Supply 55°C - 65°C
Cold Water Range - Supply 1°C - 20°C
Temperature Stability ± 1°C at recommended supply conditions
Ambient Temperature 1°C - 40°C
Maximum Relative Humidity 95% non-condensing
Flow Rates
Nominal Flow Rate* Valve capable of up to 16 l/min @ 1 bar
Electrical
Supply Voltage 230V ac 50 Hz
Maximum Load 20W
Pressures
Maximum Static Pressure 100 kPa (1 bar) 10m head
Maximum Maintained Pressure 100 kPa (1 bar) 10m head
Minimum Maintained Pressure 1 kPa (0.01 bar) 0.01m head
Supply Pressure Di󰀨erential Nominally Equal
Temperatures
Maximum Temperature (setting range) 35°C - 45°C (Factory Preset 45°C)
Minimum Temperature Thermostatic control down to 30°C
Full Cold also selectable
Hot Water Range - Supply 55°C - 65°C
Cold Water Range - Supply 1°C - 20°C
Temperature Stability ± 1°C at recommended supply conditions
Ambient Temperature 1°C - 40°C
Maximum Relative Humidity 95% non-condensing at 30°C
Flow Rates
Nominal Flow Rate* Valve capable of up to 16 l/min @ 0.01 bar
Electrical
Supply Voltage 230V ac 50 Hz
Maximum Load 200W
Controller
Electrical Supply 12 Vdc SELV 2W max. Derived from valve module
Ingress Protection IP X4 - Suitable for installation in Zone 1
Maxim Ambient Temperature 40°C
On/O󰀨 Remote Button
Electrical Supply 3.3 Vdc SELV 2mW max. Derived from valve module
Ingress Protection IP X4 - Suitable for installation in Zone 1
Maxim Ambient Temperature 40°C
Minimum maintained water pressure 0.1 bar (10 kPa)
Maximum maintained water pressure 5.0 bar (500 kPa)

1514
General Installation
The installation must be carried out in accordance with these instructions, and must be
conducted by designated, qualied and competent personnel.
The Digital Mixing Valve may be installed in a loft space, under the bath or in a convenient
cupboard space, provided there is enough room for maintenance (e.g. Removal of
Digital Mixer Valve lid). Failure to do so may result in an inability to carry out any maintenance.
Safe and easy access to the product should be available at all times.
When planning your installation, make sure that the Controller is installed within the cable
length range supplied (Cable length 9.5 metres).
When installing a mixer valve in an area not regularly accessed, consideration for potential
leaks must be taken into account. While such events are unlikely, it is advisable to periodically
check the installation for traces of water on or around the product.
If possible, site the valve in a location where any leak would be contained or routed to avoid
areas sensitive to water damage.
Full bore isolating valves must be installed to both inlets (supplied) and it is recommended
to t isolators on the outlet, close to the Digital Mixing Valve for ease of maintenance.
Caution! Risk of product and property damage. The Digital Mixing Valve must be
installed in a dry, ventilated area where it will not freeze.
The shower control must be fed from a cold water storage cistern and a hot water cylinder
providing nominally equal pressures. Pipework layouts and connections must be such that
other draw-o󰀨s will not e󰀨ect water supplies to the shower, shared supplies may lead to
airlocking or water starvation. It is therefore best practice to have independent hot and cold
supplies to the Low Pressure (pumped) Digital Mixing Valve.
Suitable Plumbing Installations
Dual Digital Mixing Valve (High Pressure)
1. Gas Heated System - The Digital HP shower can be installed with a combination boiler.
2. Unvented Mains Pressure System - The Digital HP shower can be installed with an
unvented, stored hot water system.
3. Mains Pressurised Instantaneous Hot Water System - The Digital HP shower can be
installed with systems of this type with balanced pressures.
4. Gravity Fed Showers
Caution! Risk of product damage. Do not t the Mira Digital Mixing - High Pressure/
Combi Valve with Gravity Fed Systems.
cold
30°- 60°
Air Separation
100 mm from lowest
level of water in tank
Outlet 1 (Overhead)
Outlet 2 (Handshower)
Dual Outlet Valve (Pumped)
cold
cold
Cistern
Minimum 230 litres
hot
hot
1 metre
minimum

1716
Use of Flow Regulators with Combination Boilers
The Digital Mixing Valve can demand hot water quicker than some instantaneous water
heaters/combination boilers can provide, especially in winter when the mains water is colder.
A Hot inlet ow regulator may need to be used to ensure that the Digital Mixing Valve can
deliver a full range of water temperatures.
Note: The Mira Dual outlet Digital Mixing Valves do not have a factory t ted hot inlet ow
regulator. These are supplied in the component pack. The table indicates which ow
regulator should be tted in the hot water inlet of the Digital Mixing Valve if installing
to a combination boiler system.
Boiler Rating 24 kW (80,000 Btu/h) 30 kW (100,000 Btu/h) 36 kW (120,000 Btu/h)
Flow Regulator 7 litres/min 9 litres/min Not required
Colour White/Green White/Orange N/A
1. Unscrew hot inlet plastic nuts and remove pipe and seal to gain access to the checkvalve
cartridge and lter.
2. Use at blade screwdriver to carefully lever cartridge out.
3. Fit/remove the ow regulator from checkvalve cartridge behind lter as required.
4. Ret seal, pipe and plastic nut. Plastic nuts require hand tightening only.
Installation: Digital Mixing Valve
User Interface Cable
Remote On/Off Cable
To Remote
ON/OFF
Remote On/Off Button
User Interface
Coupler Cable
To Digital
Mixing Valve
To Remote
ON/OFF Button
To Interface
j
h
g
f
e2
Note! The remote ON/OFF
button is optional and not
necessary for the product
to operate.
A
B
C
D
F
G
H
J
E
Green
Dual outlet
valve shown
Orange

1918
Key to Installation Schematic
Description
AElectrical Cable from the Controller to the Valve - 9.5 metres
BOn/O󰀨 Remote Button cable from the On/O󰀨 Remote Button to the Valve - 9.5 metres
COn/O󰀨 Remote Button - placed outside of the enclosure
DController
ECoupler Cable - for connection between the valve and the remote lead and/or the
Controller
FDigital Mixing Valve
GMira Mode Maxim Ceiling Fed shower ttings - Rear Fed options are available
HDeluge showerhead
J3 AMP Switched Fused Spur - Outside of the bathroom - enables you to isolate the shower.
Should be easily accessible for resetting product.
Important Installation Considerations
• Ensure Pumped for Gravity showers are not connected to any mains water pressure
e.g. stored gravity hot water and cold mains water.
• High Pressure/Combi Valves should not be tted to a Pumped Gravity System.
• The Digital Mixing Valve should not be installed where it can become frozen or be subjected
to ambient temperatures in excess of 40ºC.
• Position the Digital Mixing Valve so that there is enough room for maintenance (e.g.
removal of the valve lid) and make sure safe and easy access is available at all times.
• Installing the Digital Mixing Valve onto shared water supplies may reduce its flow
performance.
• Avoid installations where air locking could occur.
• Cold water cisterns should hold no less than 230 litres and Hot water cylinders no less
than 210 litres. (Gravity system only).
• Your water supply system must be capable of delivering up to 16 l/min mixed water.
• Ensure water supply temperatures are within specication. Hot water 55˚C to 65˚C, Cold
water 1˚C to 20˚C.
• To reduce any e󰀨ects of water hammer secure all pipe work rigidly.
• Do not t the valve in a position where Bluetooth® communication with the Digital Mixer Valve
is poor e.g. mixer valve installed under metal bath, in front of metal cistern, on foil backed
plasterboard.
• Water supply pipes must be ushed prior to connecting the mixing valve to the system
so debris cannot enter the mixing valve internals.
• Fully commission the product after installation taking care to look for any leaks and
correct operation.
General Installation Requirements
The installation must be carried out in accordance with these instructions, and must be
conducted by designated, qualied and competent personnel.
A separate, permanently connected supply must be taken from the ring main to the appliance
through a 3 AMP double pole switched fused spur providing a minimum 3mm contact
separation gap in each pole.
The use of supply-line or zone strainers will reduce the need to remove debris at the
Digital Mixer Valve. The recommended maximum mesh aperture dimension for such
strainers is 0.5mm.
Pipework must be rigidly supported to avoid any strain on the connections.
Long outlet pipework (dead-legs) should be kept to a minimum to avoid temperature uctuations.
Supply pipework layout must be arranged to minimize the e󰀨ect of other outlet usage upon
the dynamic pressures at the Digital Mixing Valve inlets.
To eliminate pipe debris it is essential that supply pipes are thoroughly ushed through before
connection to the Digital Mixing Valve.
Cables routed through wall cavities, chased into solid walls, directed under baths or in
attic spaces must be tted in such a way that they can later be removed. To facilitate this
appropriate cable conduit/trunking must be used at all times. The conduit/trunking must be
at least 20mm diameter/square to allow for the safe removal of the connectors.
Failure to do so may result in an inability to carry out any maintenance or service. Safe and
easy access to the product should be available at all times.

2120
Valve Installation Orientation
The Digital Mixing Valve (which contains the thermostatic mixing valve)may only be orientated
in the positions shown below. Failure to do so will compromise the ability of the unit to fail-safe
and deliver constant blend. If the power supply cable is damaged, it must be replaced by
the manufacturer or a service engineer.
Warning! Turn o󰀨 the electrical and water supplies before proceeding with the installation
of the appliance. The electricity must be turned o󰀨 at the mains and the appropriate
circuit fuse electrically isolated, if applicable. Caution! Risk of product damage. Do
not run Pumped Valve (low pressure version) without a water supply.
1. Isolate the electrical supply to Digital Mixing Valve.
2. Mark the xing holes in the required positions. Drill and plug the xing holes.
Note: Installers may wish to use alternative cavity xings, when installing onto a dry
lined, stud partition, shower cubicle or laminated panel wall structures. However, these
methods of xing are beyond the scope of this guide.
3. Secure the Digital Mixing Valve in position with the xing screws (supplied).
Caution! Risk of product damage. Make sure both hot and cold supply pipes are ushed
thoroughly prior to connection to the Digital Mixing Valve. Any product malfunction
caused by pipework debris is not covered under the guarantee.
4. Connect the hot and cold water supply pipes to the Digital Mixing Valve.
5. Remove the anti-tamper plate and the rubber bung from the Digital Mixing Valve.
6. Connect the coupler cable to the valve. Make sure that it is connected correctly.
7. Fit the rubber bung over the cable and t into the socket to seal the connection.
Note: The ttings of the anti-tamper plate may di󰀨er from the one illustrated. Make
sure that you install it in the correct orientation to suit your product.
8. Re-install the anti-tamper plate and lock in position with the screw.
9. Install the Controller and Shower Fittings. Refer to the appropriate section in this manual.
Outlets
Mounting on a vertical surface Mounting on a horizontal surface
Inlets
Outlets
Inlets
Wiring to Fused Spur Box.
Make sure that the fused
spur is easily accessible.
(see installation schematic)
Cold Inlet
Push-fit Isolators
fitted to both inlets
Push-fit Connector
to the Shower
Anti tamper plate may
differ from the one shown
Rubber Bung
Coupler Cable
Hot Inlet

2322
Position the installation template (supplied) at the position on the wall where you
intend to install the Controller.
Make sure that the template is level and mark the positions of the xing holes on the wall.
Fit the backplate to the wall in the orientation shown using the xing screws (supplied).
Tighten by hand, do not over tighten.
Connect the cable on the back of the Controller to the cable that comes from the valve.
Locate the top of the Controller in the backplate and press down on the bottom button
as you install in position.
Installation: Controller
1
3
4
5
For solid walls drill the xing holes for the backplate with a 6mm drill and insert the
wall plugs (supplied). For other types of wall structure alternative fixings may be
required (not supplied).
Note: The Controller must be installed on a at and even wall surface avoiding
any grout lines.
Using a suitable hole saw, drill the hole for the Controller cable as per the dimensions
given. Route the cable from the digital valve through the wall.
2
29 - 30 mm
6.0 mm
DO NOT Drill
into buried pipes
DO NOT Drill
into buried cables

2524
Decide on a suitable location for the ON/OFF button. Mark the centre position and
draw a ver tical line using a spirit level to assist in the alignment of the ON/OFF button.
Using a suitable hole saw, drill a 29-30mm diameter hole to a minimum depth of 50mm.
Note: The ON/OFF button must be installed on a flat and even wall surface
avoiding any grout lines.
Connect the cable to the back of the On/O󰀨 Remote Button and push the rubber
grommet into place.
The alignment of the On/O󰀨 Remote Button cannot be adjusted when it is tted.
Make sure to test tment before removing the tape. This will ensure that there is no
clearance issue.
Installation: On/O󰀨 Remote Button
1
3
Route the cable from the digital valve through the hole in the wall.
Note: Make sure that you use appropriate cable conduit / trunking to facilitate
maintenance.
Using the cleaning wipe (supplied) clean the surface around the mounting hole.
Note: Do not remove the line at this stage.
2Carefully remove the paper from the adhesive back.
Carefully, visually align the symbol to the vertical line on the wall. Locate into the hole
in the wall and push rmly. Clean o󰀨 the vertical line once the On/O󰀨 Remote Button
is correctly installed. If required, the On/O󰀨 Remote Button can be removed from the
backplate by rotating anticlockwise.
4
29 - 30mm

2726
Installation: Shower Fittings
Installation: Ceiling Fed Shower Fittings
Mark the positions of the xing holes
for the slide bar.
1Mark the position of the hole on the
ceiling. Cut the hole in the ceiling to a
diameter of 29mm.
2
Use of Flow Regulators
It is recommended that appropriate ow regulators should be tted to the handset and
deluge head.
Note: The ow regulator in the deluge head should always be greater than the handset.
The customer can use a combination of the provided ow regulators to meet their
system and user requirements. The ow regulators provided are as follows:
Fix at convenient height for all the family. Position the ttings so that water sprays down the
centre of the bath, or away from the opening of a shower cubicle. Water should spray away
from the Controller when the handshower is held on the slide bar.
Drill the xing holes in the wall. Fit the wall plugs and the slide bar suppor ts and install
the slide bar assembly to the wall.
Important! If supplied slide bar spacers are required, centre distance for ceiling
hole will increase to 75mm from wall. Use longer xing screws if you are using
the spacers.
3
Optional
Spacers
(supplied)
DO NOT Drill
into buried pipes
DO NOT Drill
into buried cables
7.0 mm
Direction of flow
Colour
White
Lilac
Pink
Flow Rate
12 litres/min
9 litres/min
6 litres/min
645mm Max.
600mm
50 mm

2928
Install the screws top and bottom to
secure the slide bar in position.
4Install the falling supply tube.
Note: The falling supply tube may
need to be shortened, use a hacksaw
to shorten tube. Make sure the rough
end is concealed in the ceiling.
5Note: When shortening pipework for use with any push-fit fitting, follow
manufacturer’s guidelines for nishing and cleaning the pipe.
7
a. Fit the shower hose to the end of the slide bar assembly.
Note: Do not fit the handshower until after pipework has been fully flushed
through. Refer to ‘Commissioning’.
b. Fit the shower hose to the handset. Make sure that you t the shower hose and
ow regulator.
8
a. Feed the plastic tube up through the slide bar and into the ceiling.
b. Push and twist plastic pipe end until it “clicks” and locks in place.
Caution! Do not allow any debris to block the plastic pipe.
Note: If plastic pipe requires shortening make sure there is enough length to
t elbow (supplied) or alternative push-t/compression ttings (not supplied).
6
Elbow
(supplied)
Flow Regulator
Washer
Washer
Elbow (supplied)

3130
Installation: Ceiling Fed Deluge Head
Fix Deluge Head to the ceiling at a convenient height for all the family. Position so that water
sprays down over the centre of the bath, or away from the opening of a shower cubicle. The
tting of the Deluge Head into the ceiling will be easier with two persons. When you are
working within the bath or shower tray area use a towel or blanket to protect the surface
from damage.
Decide on a suitable position for the Ceiling-Fed Arm avoiding cables and pipes
hidden between joists or rafters.
Note: A timber noggin or plywood plinth securely xed to the joist should be
used to mount the Ceiling-Fed Arm.
1
Push the brass pipe through the
ceiling mount plate then push the
threaded end of the brass pipe down
through the hole made in the ceiling.
2
Note: Make sure that the deluge head
is not installed over the handshower.
O󰀨er the ceiling-fed arm to the brass
pipe and determine the showering
height required. Push or pull the brass
pipe using a twisting motion to adjust
the height. Check the height is correct
and use a 15mm pipe cutter to cut the
pipe to the desired length.
Note: Cut the brass pipe at least
75mm above the ceiling mount plate
to allow room to fit the olive, nut
and elbow.
4
O󰀨er the chrome shroud to the brass
pipe and determine the length required
to allow the shroud to conceal the brass
pipe and protrude into the ceiling space
a minimum of 15mm. Use a pipe cutter
to cut the shroud to the desired length.
6Push the chrome shroud into the ceiling
plate then slide the chrome shroud over
the threaded end of the brass pipe and
up through the hole until the ceiling
plate is secured in the hole and the
ceiling plate is at against the ceiling.
Note: If the hole in the ceiling
is oversize use silicone on the
underside of the ceiling plate to
retain it.
7
Secure the brass pipe to the ceiling
mount plate with the olive and 1/2”
BSP nut.
Note: This is not a water tight
connection, tighten su󰀩ciently to
clamp the pipe in place.
5
Centralise the brass pipe in the hole
then screw the ceiling mount plate to
the wooden support.
3
Drill 29 mm
diameter hole
Timber noggin or
plywood plinth
Caution! Drill
holes in line
Ceiling Mount Plat
e
Brazed Pipe
1/2” BSP Nut
Olive
Chrome Shroud
Brazed Pipe
Minimum
15 mm
Threaded
end of pipe
Ceilin
g
Plate
Determine the
showering height
75 mm

3332
Connect the shower control outlet
pipework to the elbow. Fit an isolating
valve between the shower control
outlet and the elbow to enable easy
maintenance. (Pipe and isolating valve
not supplied). Lock pipe to elbow using
clip supplied. Follow manufacturers
guidelines for tting alternative push-
t connections and exible pipework.
Connect the elbow (supplied) onto the
end of the brass pipe. Push all parts
together fully and lock elbow onto pipe
using clip supplied
8
10 Ensure pipework is thoroughly ushed through before tting the deluge head.
Screw the xed shower head onto the brass pipe outlet.
Note: Use two suitably sized wrenches to tighten (approximately 1/4 turn).
Slide the chrome shroud down to conceal the brass pipe. Turn on the shower
control and check for leaks.
The CloudCore™ spray plate can be removed for cleaning or changed to the
RainCore™ spray plate which is more suitable for hard water areas. Refer to
‘Cleaning and Maintenance’.
9Installation: Rear Fed Shower Fittings
Suitable for solid, dry-lined, stud partition, shower cubicle or laminated panel walls. Plan
installation location of the handshower and deluge showerhead before installing ttings kit.
Note: Make sure that the deluge head is not installed over the handshower.
Fix at convenient height for all users. Position so that water sprays down the centre of the
bath, or away from the opening of a shower cubicle. Water should spray away from the
Controller when the Handshower is held on the slide bar.
The right angle connector must be tted to a waterproof, at and even wall surface. The
screws and wall plugs supplied are suitable for most solid wall installations. Alternative
xing screws for panel structures are not supplied. Use both xing points to secure the
right angle connector, be sure to use xings appropriate for the chosen wall structure.
1
Using a suitable pipe cutter, trim the pipework back to the required depth from the
nished wall surface. Remove all burrs and sharp edges.
1300 mm Minimum to
achieve a comfortable
shower height for all users
90°
31 - 34 mm
Shower Arm
Deluge Head
Note! Make sure that the
flow regulator is fitted in
the correct orientation.
Flow Regulator

3534
Fit the cover over the elbow and tighten
the screw anti-clockwise.
8
Mark the positions for the xing holes
for the RAC back plate.
Temporarily hold the top support in
position. Make sure that it is level and
mark through the position of the xing
hole in the top support
2 6
4 5
Drill the xing holes, t the wall plugs
and secure the backplate to the wall
with two xing screws.
3Drill the xing hole for the top support and
t the wall plug
7
Fit all the components onto the slide
bar and t the slide bar assembly in
position, making sure that it locates
correctly.
9
8.0 mm
Optional hole position
(Only one required)
621 mm to top
hole position
7.0 mm

3736
Carefully remove the slide bar
assembly and tighten the screw
on the back of the top bracket to
secure in position.
Ret the t the slide bar assembly
in position.
The outlet pipe must protrude 18mm
(± 2mm) from the nished wall surface
and a minimum 35mm from the ceiling.
Note: Cut the pipe to the correct
length and remove any burrs.
Mark the positions of the backplate
xing holes.
Caution! Be aware of hidden pipes
or cables.
For solid walls drill the xing holes for
the backplate with a 6mm drill and
insert the wall plugs (supplied). For
other types of wall structure alternative
xings may be required (not supplied).
10
2 3
Installation: Rear Fed Deluge Head
Fix at convenient height for all users. Position so that water sprays down the centre of the
bath, or away from the opening of a shower cubicle. Make sure that the water sprays away
from the Controller.
Note: Make sure that the deluge head is not installed over the handshower.
1
Secure the assembly in position with
the screws. The top securing screw
tightens clockwise, the bottom one
anti-clockwise. Do not overtighten.
Fit the shower hose to the handset.
Make sure that you t the shower
hose and ow regulator.
Fit the cap to the top of the slide bar
and t the hose to the bottom outlet.
Note: Do not t the handshower
until after pipework has been
fully flushed through. Refer to
‘Commissioning’.
11
1312
Top Bracket
Tighten screw
to secure.
Note! Do not
overtighten
Rear view of
Top Bracket
Flow Regulato
r
Washer
Minimum distance
to ceiling 35 mm
18 ±2 mm

3938
Ensure pipework is thoroughly ushed through before tting the deluge head.
Screw the xed shower head onto the brass pipe outlet.
Note: Use two suitably sized wrenches to tighten (approximately 1/4 turn).
Slide the chrome shroud down to conceal the brass pipe. Turn on the shower
control and check for leaks.
The CloudCore™ spray plate can be removed for cleaning or changed to the
RainCore™ spray plate which is more suitable for hard water areas. Refer to
‘Cleaning and Maintenance’.
3
Carefully fit the backplate over the
outlet pipe and secure with the xing
screws (supplied).
Caution! Take care not to damage the
‘O’ Seal in the back of the backplate.
Fit the olive and compression nipple
over the outlet pipe and tighten the
compression nipple.
Turn on electrical supply
to Digital Mixer Valve.
Make sure the end of the hose is in
either the bath, shower tray or other
water catchment area.
Press the button to turn the shower on and reduce temperature to full cold. For Low
Pressure (pumped) version, let shower run in order to prime the pump. For long pipe
runs, allow 3 - 4 minutes for priming.
Caution! Risk of product damage. Do not run Pumped Valve (low pressure version)
without a water supply for longer than 5 minutes during priming.
Press the Controller button to turn shower on. Test operation of shower by increasing/
decreasing the temperature.
Fit the concealing shroud, the
compression nut and the olive onto the
shower arm. Fit the shower arm into
the compression nipple and tighten
the compression nut. Hand tighten the
concealing shroud onto the backplate.
4
1
2
5
6
5Commissioning
Run cold water through (approximately 2 minutes) and check entire installation for
water leaks. Press the Controller button to turn the shower o󰀨. Fit the second hose
washer and handshower.
4
Backplate
Oliv
e
Compression
Nipple
Oliv
e
Compression Nu
t
Concealing Shroud
Shower Arm
Shower Arm
Deluge Head
Note! Make sure that the
flow regulator is fitted in
the correct orientation.
Flow Regulator
