Mirabella International I004777 User manual

Full HD Doorbell Camera
Quick Start Guide
Model I004777
KEYCODE: 43274499

Packaging contents
doorbell indoor chime bracket
battery x2 screw package
Install the memory card
(micro SD 4-128GB, memory card not included)
Install supplied bateries as the direction
shown on above
USB cable

Description
Power Port: DC 5V±10%
Status light: -Blue light blinking quickly: waiting for the pairing
-Blue light blinking slowly: awaiting for the Wi-Fi connection (Pairing)
-Blue light off: connection succeed
SD card slot: Support local SD Card storage (Max.128GB FAT32)
Reset: Press and hold on for 5 seconds to reset the camera
1. Light sensor
2. Video doorbell lens
3. The power indicator light
-Blue light blinking quickly: waiting
for the pariing
-Blue light blinking slowly: awaiting for
the Wi-Fi connection (Pairing)
-Blue light off: connection succeed
4. PIR sensor
5. Microphone
6. Doorbell button
7. Built-in speaker
8. Reset button
9. Type-C USB (for charging)
10.Micro SD cart slot (behind battery cover)
11.Battery compartment
12.Tamper screw hole

Installation
Before installation, please ensure that the installation location is covered by Wi-Fi.
Please use the live preview feature to find the best height to install your doorbell. We
recommend not below shoulder height.
1. Drill 2 holes in the wall.
2. Fit the rubber expansion plugs into the holes.
3. Affix the wall hanging board to the wall with the 2 long screws.
4. Place the doorbell device on the wall mount, then affix the wall mount to the doorbell
using the 2 tamper screws.

Connection Preparation
It is important that your phone is connected to a 2.4Ghz Wi-Fi and not to a 5GHz network.
To verify your mobile device is set to a 2.4Ghz Wi-Fi network, navigate to the Settings
menu and click on Wi-Fi. In this menu you will see all the available networks in your area.
Locate the SSID (the name of your network) and ensure that the Wi-Fi SSID does not end
with a 5G / 5GHz.
Check that you have a strong Wi-Fi signal (at least two bars) in the location where the
smart camera is to be installed.
If you don’t have at least two bars signal on your phone, then you may need to reconsider
relocating the camera to a different location or obtain a Wi-Fi extender to boost the Wi-Fi
signal strength.
Install the Mirabella APP and register Account
To access your camera and it’s functions download the "Mirabella Genio" APP to your
smartphone from the App Store or Google Play then add your device to the APP.
Home Wi-Fi Network
Home Wi-Fi Network 5GHz
Home Wi-Fi Network 2.4GHz
PTCL-BB

Insert a Micro SD card
Please note that the camera will work without an SD card, but it will not be able to record
any footage.
Insert the Micro SD card gently into the SD card slot. Please pay attention to the direction
of the Micro SD card. Do not force it inside. Micro SD card size needs to be between 8GB
and 128Gb, FAT32 format only, This camera doesn’t support NTFS file system.
Insert like this way

Pairing the doorbell using Mirabella Genio App
1.Insert the batteries and wait for the indicator light to start blinking BLUE rapidly.
(1 blink every second) if it fails to blink, press the reset button and hold until you hear
an audible sound, the camera is now ready to pair.
2.Check your mobile phone is connected to the 2.4Ghz Wi-Fi network, (Wi-Fi name should
not end with -5G).
3.Open the Mirabella Genio APP, tap on blue “+” icon, then choose add device, then select
Security & Sensor and select your camera from the list.

4.Confirm that the LED indicator light is still blinking rapidly blue, tap “confirm Indicator
light is blinking BLUE rapidly”, then tap “next” and enter your home network 2.4GHz Wi-Fi
name and password.
Tap next and the QR code will appear on your phone screen, place this QR code in front
of the camera at approximate 15-20cm, until you hear a sound,
example of how to scan QR code
QR code is the code on your phone screen,
（not the barcode on the camera box)
Reset button

Tap on “Beeped /Indicator switched” It will then start to connect your device.
(refer to the 1st & 2nd images).
5. Once the countdown ends, the Camera has now successfully been paired to your APP.
Please refer to the FAQ section for troubleshooting if this method does not connect.
Doorbell camera
if somehow the QR code method does not work,
please reset and retry using the EZ method.

12
Setting the chime
2
1
1
Volume Selector
Adjust Volume/Mute
Chime Selector
Change the Chime Tone
Pairing with the chime:
1. Plug-in the USB chime into a USB 2.0 socket or a USB adapter.
2. If the chime Is connected with power, the indicator will blink twice then turn off.
3. After the chime Is connected to power, hold and press the Vol button until the indicator
blinks quickly, then release the button and press the Ring button of the doorbell.
4. The doorbell and chime will now be paired. Press the ring button again, the chime
will ring accordingly.

FAQ
Q. LED indicator is not blinking rapidly as per APP screen
A. Power off the camera, wait for 20 sec, depress the reset button until you hear a sound, then
release the button, wait for another 30-40 sec until the light starts to blink Blue rapidly again (1
blink every second).
Q. Camera doesn’t scan the QR code
A. Please ensure camera is in the pairing mode, indicator light is blinking blue rapidly as per the
APP screen, if you are unsure, please simply reset it.
Q. I am using Telstra NBN, I disabled the 5Ghz and still can’t get it to pair?
A. Please follow the Guest Network paring instructions at https://mirabellagenio.net.au/faqs
Q: Camera will not connect to my Wi-Fi network
A: Make sure the Wi-Fi network is a 2.4GHz network, device will not connect to a 5GHz
network.Also make sure your Wi-Fi name has no space, your Wi-Fi network password is case
sensitive, make sure you are entering it correctly.
Refer to our website’s FAQ and check for your router Is listed as some routers are set up
differently.
Q: The camera is off-line
A: There could be a temporary issue with your internet connection (e.g., service disruption).
Please try again in a few minutes.
Make sure your Wi-Fi router is turned On.
Make sure the camera is getting a good signal from your Wi-Fi router. Use your phone to check
range, it is recommended to have at least 2 signal bars showing proper connection.
Q: How to reset the camera to renter pairing mode?
A: Press and hold reset button (see Product Details section) until you hear an audible tone.
Q: Live video stream is slow to load
A: Camera streaming issues may be caused by any of the following: Your phone’s cellular
connection, which relies on mobile overage.Limited internet bandwidth at home, for example, other
video streaming services running at the same time on your network can cause congestion slowing
down the internet upload and download speeds.Wi-Fi reception may not be stable or work reliably if
the camera’s Wi-Fi signal strength is less than 2 signal bars. You may need to install a Wi-Fi repeater
or extender to boost the Wi-Fi signal.
Q: The camera is not recording?
A: Make sure that the microSD card is installed correctly. To confirm the camera is recognizing
the microSD card, go to storage Settings in the Settings menu and make sure the microSD
Card capacity shows Total capacity, Used and Free space.
If this does not appear you may consider reformatting the microSD card. WARNING:
Reformatting microSD card will delete all videos stored on card. Once SD card is formatted,
your recordings will be stored on the card and can be accessed via the playback button.
Q: What happens when the microSD card reaches full capacity?
A: Once the microSD card reaches full capacity, new videos will start rewriting (deleting) over
the oldest
videos.
Q: Why I can’t get the notifications with my cell phone App?
A: Confirm that the App has been running on the phone, and the relevant reminder
function has been opened; Message notification and authority confirmation in the mobile
phone system have been enabled.

Q. LED indicator is not blinking rapidly as per APP screen
A. Power off the camera, wait for 20 sec, depress the reset button until you hear a sound, then
release the button, wait for another 30-40 sec until the light starts to blink Blue rapidly again (1
blink every second).
Q. Camera doesn’t scan the QR code
A. Please ensure camera is in the pairing mode, indicator light is blinking blue rapidly as per the
APP screen, if you are unsure, please simply reset it.
Q. I am using Telstra NBN, I disabled the 5Ghz and still can’t get it to pair?
A. Please follow the Guest Network paring instructions at https://mirabellagenio.net.au/faqs
Q: Camera will not connect to my Wi-Fi network
A: Make sure the Wi-Fi network is a 2.4GHz network, device will not connect to a 5GHz
network.Also make sure your Wi-Fi name has no space, your Wi-Fi network password is case
sensitive, make sure you are entering it correctly.
Refer to our website’s FAQ and check for your router Is listed as some routers are set up
differently.
Q: The camera is off-line
A: There could be a temporary issue with your internet connection (e.g., service disruption).
Please try again in a few minutes.
Make sure your Wi-Fi router is turned On.
Make sure the camera is getting a good signal from your Wi-Fi router. Use your phone to check
range, it is recommended to have at least 2 signal bars showing proper connection.
Q: How to reset the camera to renter pairing mode?
A: Press and hold reset button (see Product Details section) until you hear an audible tone.
Q: Live video stream is slow to load
A: Camera streaming issues may be caused by any of the following: Your phone’s cellular
connection, which relies on mobile overage.Limited internet bandwidth at home, for example, other
video streaming services running at the same time on your network can cause congestion slowing
down the internet upload and download speeds.Wi-Fi reception may not be stable or work reliably if
the camera’s Wi-Fi signal strength is less than 2 signal bars. You may need to install a Wi-Fi repeater
or extender to boost the Wi-Fi signal.
Q: The camera is not recording?
A: Make sure that the microSD card is installed correctly. To confirm the camera is recognizing
the microSD card, go to storage Settings in the Settings menu and make sure the microSD
Card capacity shows Total capacity, Used and Free space.
If this does not appear you may consider reformatting the microSD card. WARNING:
Reformatting microSD card will delete all videos stored on card. Once SD card is formatted,
your recordings will be stored on the card and can be accessed via the playback button.
Q: What happens when the microSD card reaches full capacity?
A: Once the microSD card reaches full capacity, new videos will start rewriting (deleting) over
the oldest
videos.
Q: Why I can’t get the notifications with my cell phone App?
A: Confirm that the App has been running on the phone, and the relevant reminder
function has been opened; Message notification and authority confirmation in the mobile
phone system have been enabled.
How to connect camera to another router
Go to the camera settings page, look for “remove device” Remove it and reset the
camera, pair it again to the new router through the app.
Poor performance, takes a long time to load the live footage
Please check the Wi-Fi signal, if it is less than 60%, you will need consider changing the
camera location or purchasing a Wi-Fi extender to boost the signal.
Camera went offline and doesn’t reconnect back online by itself
Go the camera’ settings page, look for “remove device” Remove it and reset the camera
and pair it again through the app.
Followed the pairing process but still receive the error Cannot find Device
Manually disable the 5Ghz Wi-Fi signal on the router setting
Ensure that the 2.4Ghz Wi-Fi signal is on.
Ensure the indicator light is blinking BLUE rapidly as per APP screen (1 blink per second).
Please check you have entered the correct 2.4Ghz Wi-Fi SSID and password.
I am using Telstra NBN, I disabled 5Ghz and I still cannot get it to pair
Please follow the Guest Network paring instructions on https://mirabellagenio.net.au/faqs
If you have done all of the above, ensuring that 5Ghz is disabled.
How to turn on or turn off movement notification
On the Genio APP home screen, Tap on Me -> Settings -> App Notification -> turn on/off
Enable notifications.
On the iphone, Settings -> Notifications -> turn on/off Allow Notifications for the Mirabella
Genio app.
For multiple camera setup, change camera view or arrange device set up sequences and
manage rooms
On the genio APP home screen, tap on on the top right corner, to access these
options, tap on V to switch below rooms. Tap on x to exit this mode.

Need more help or need further technical assistance from Mirabella engineer
On the genio APP home screen, tap on, Me, -> FAQ & Feedback -> Report issue
Fill the fault information or suggestion for the APP/product, then submit
please detail the problem in here
upload the screenshot
if possible
Remember the performance of your Wi-Fi camera is relies heavily on the
performance of your router,
If you are using Telstra NBN or a dual-band router, you must disable the 5GHz Wi-Fi
in order to make
a successful connection and for best overall performance, as MOST smart products
in Australia only
work on the 2.4Ghz signal.

All trademarks are used for reference purposes only. Made in China
ANKO, HOME&CO AND AUDIOSONIC® ARE TRADEMARKS OF KMART AUSTRLIA LIMITED.
MIRABELLA INTERNATIONAL PTY LTD
1 MIRABELLA DRIVE, TULLMARINE, VIC, AUSTRALIA 3043
TOLL FREE: 1800 636 528, www.mirabellagenio.com.au
Always read the instruction manual and any warnings on the device before using a
lithium-ion battery.
Rechargeable lithium-ion batteries can explode, release flames, and/or cause burns if
disassembled, punctured, cut, crushed, short-circuited, incinerated, recharged
incorrectly, or exposed to water, fire, or high temperatures.
1.Use the battery charger and AC adapter specified for use with the lithium-ion battery.
2.Do not force the lithium-ion battery into a battery charger or device if it does not fit.
3.Do not throw lithium-ion batteries into a fire or heat source also lead to overheating,
explosion or fire.
4.Do not connect the positive and negative terminals of the lithium-ion battery with a
metal object.
5.Do not throw lithium-ion batteries, drop them from high places, or otherwise subject
them to strong impacts
6.Do not put a lithium-ion battery in a microwave oven,pressure container, or other such
devices.
7.Do not place combustible materials on top of or over a lithium-ion battery when
charging or discharging.
8.Do not disassemble or modify a lithium-ion battery.
9.When the electric device is not being used for an extended.
