MiTEC TALK BH39 User manual

BLUETOOTH HEADSET BH39

1. ABOUT BLUETOOTH HEADSET BH39
The Bluetooth Headset BH39 allows you the
freedom to make and receive calls while on
the move or in the office, after you connect
the headset to a compatible phone that
supports Bluetooth wireless technology.
Read this user guide carefully before using
the headset. Also read the user guide for
your phone, which provides important
safety and maintenance information.
2. BLUETOOTH WIRELESS
TECHNOLOGY
Bluetooth wireless technology makes
it possible to connect compatible
communication devices without using
cables. A Bluetooth connection does not
require the phone and the headset be in
line of sight, but both devices should be
within 10 metres (30 feet) of each other.
Connections can be subject to interference
from obstructions, such as walls or other
electronic devices.
The MiTEC BH39 Bluetooth Headset is
compliant with Bluetooth Specification v2.1

supporting Headset Profiles 1.1 and Hands-
Free Profiles 1.5.
There may be restrictions on using
Bluetooth technology in some locations.
Check with your local authorities or service
provider.
3. OVERVIEW
The headset contains the following parts as
shown in the figure:


(1)Call Button /Answer /end a call
(2)Earhook
(3)Power Switch /Power ON/OFF
(Green=ON, Red=OFF)
(4)Charging socket
(5)Microphone
(6)Indicator light (LED) (Red/Blue)
(7)Volume control /Multi-point connection
4. CHARGING THE HEADSET
This device has an internal, rechargeable
battery which must be fully charged before
being used for the first time. It takes about 3
hours to charge the battery fully for the first
time. During charging, the indicator shows
a steady red. When the battery is fully
charged, the red light will turn blue. After the
initial charge, it takes about 90 minutes to
fully charge.
You can charge the headset either by
using the AC travel charger, USB charging
cable or the car charger depending on the
package accessories available. Please
check your package for details. The MiTEC
BH39 Bluetooth Headset is intended for use

with the chargers that are included in the
package.
YOUR PACKAGE HAS A USB CHARGING
CABLE INCLUDED
Plug the charger lead of USB charging
cable into the charging port of your
Bluetooth headset. Then plug the other
end of the USB charging cable into a
computer’s USB port or into a mains
charger with USB socket. When charging is
complete, remove the USB charging cable
and remove the charger lead from your
headset.
The fully charged battery has power for up
to 6 hours of talk time or up to 120 hours
of standby time. However, the talk and
standby times may vary when used with
different mobile phones, products that use
a Bluetooth connection, usage settings,
usage styles, and environments.
When the battery is running out of power,
the blue indicator light starts to flash 3 times
every 30 seconds. This indicates that the

headset needs to be charged as soon as
possible.
5. SWITCHING THE HEADSET ON OR
OFF
To switch on, when BH39 is off, switch the
on/off button to the on position; the blue
indicator light starts to flash for 3 times with
a reminder voice.
To switch off, when BH39 is on, switch the
on/off button to the off position; the red
indicator light flashes for 3 times with a
reminder voice
6. PAIR THE HEADSET WITH A
COMPATIBLE PHONE
Pairing is the process of establishing an
encrypted link between the Bluetooth
Headset BH39 and Bluetooth devices.
Step-1 The headset must be powered on
before you begin to initiate the pairing.
Step-2 Press and hold the Answer/end key
for 6 seconds until the blue and red light
flash alternatively. The headset is now in
pairing mode.
Step-3 Activate the Bluetooth feature on

the phone, and set the phone to search for
Bluetooth devices. Check the user guide of
your phone for instructions.
Step-4 Select the headset (BH39) from the
list of found devices.
Step-5 When asked the PIN code, please
enter “0000” to pair and connect the
headset to your phone. In some phones
you may need to make the connection
separately after pairing. See the user guide
of your phone for details.
If the pairing is successful, the headset
enters idle state and blue light will flash
once every 5 seconds. The headset’s name
appears in the phone menu where you can
view the currently paired Bluetooth devices.
YOU ONLY NEED TO PAIR THE
HEADSET WITH YOUR PHONE ONCE.
NOTE FOR MULTI-POINT USE:
In order to pair a second mobile, please
press the volume - button for 3 seconds
until the red and blue light flashes
alternatively. You can then pair the second

mobile.
To activate the Multi-Point-function, please
press volume -/+ at the same time for 1.5
seconds. The headset will get into the Multi-
Point Mode, the Blue Indicator light indicate
2 seconds
TROUBLESHOOTING
If you cannot connect the headset to your
phone, do as follows:
· Ensure that the headset is charged,
switched on, paired with and connected to
your phone.
· Ensure that the Bluetooth feature is
activated on your phone.
· Check that the headset is within 10 metres
(30 feet) of your phone and that there are
no obstructions between the headset and
the phone, such as walls or other electronic
devices.
If no pairing is made over a period of time,
the headset will retreat pairing mode. You
have to turn off the headset and operate

again.
7. BASIC USE
7.1 MAKE A CALL
To make a call, use your phone in the
normal way when the headset is connected
to your phone. The sound will be
transmitted to the headset automatically.
7.2 ANSWER A CALL
When there is incoming call, press the
answer/end key, or use the phone keys to
answer the call.
7.3 END A CALL
After finishing the call, press the Answer/
end key, or use the phone keys to end the
call.
7.4 REFUSE A CALL
When there is incoming call, press and hold
answer/end button for 3 seconds until you
can hear beep sound from the headset.
7.5 VOICE DIALLING (DIALLING A
NUMBER BY SAYING A NAME)
It is possible to make a call directly from the
headset using voice recognition. To use this
voice dialling function, your mobile phone

must provide this option and corresponding
voice samples must have been recorded.
Step-1 Enable voice recognition function
of your mobile and set the mobile to
handsfree state.
Step-2 When no call is in progress, press
and hold the answer/end button for 3
seconds until you can hear beep sound
from the headset.
Step-3 Speak out the name of the person
you wish to call loudly.
7.6 REDIAL
Press + key 3 seconds and you can hear
beep sound from the headset. Release the
button and the headset will dial the last
diaIndicator light telephone number.
7.9 ADJUST THE EARPHONE VOLUME
Press the volume + key to increase or - to
decrease the volume during a call.
7.10 SWITCH THE CALL BETWEEN
MOBILE AND HEADSET
In call state, press and hold the answer/
end key for about 3 seconds until there is
beep sound from headset. The call will be
