Mitel TA7100 Series User manual

Mitel TA7100
58014901 REV00
PORTS AND PROTOCOL SETTINGS

NOTICE
The information contained in this document is believed to be accurate in all respects but is not warranted
by Mitel Networks™ Corporation (MITEL®). The information is subject to change without notice and should
not be construed in any way as a commitment by Mitel or any of its affiliates or subsidiaries. Mitel and its
affiliates and subsidiaries assume no responsibility for any errors or omissions in this document. Revisions
of this document or new editions of it may be issued to incorporate such changes.
No part of this document can be reproduced or transmitted in any form or by any means - electronic or
mechanical - for any purpose without written permission from Mitel Networks Corporation.
Trademarks
The trademarks, service marks, logos and graphics (collectively "Trademarks") appearing on Mitel's
Internet sites or in its publications are registered and unregistered trademarks of Mitel Networks
Corporation (MNC) or its subsidiaries (collectively "Mitel") or others. Use of the Trademarks is prohibited
without the express consent from Mitel. Please contact our legal department at l[email protected] for
additional information. For a list of the worldwide Mitel Networks Corporation registered trademarks, please
refer to the website: http://www.mitel.com/trademarks.
Mitel TA7100 Ports and Protocol Settings
58014901 REV00 - May 2016
®,™ Trademark of Mitel Networks Corporation
© Copyright 2016, Mitel Networks Corporation
All rights reserved

Table of Contents
iii
Default Ports Used by DGW 2.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Calculating the RTP Port Range for Voice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Mitel TA7100 Series Port Range for Voice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Calculating T.38 Port Range for Fax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Mitel TA7100 Series Port Range for Fax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Default Ports Used by DGW 2.0
4
Default Ports Used by DGW 2.0
Connection Type Default Port Number Transport Protocol
Debug Signaling Log Host 6000 UDP
DHCP 68 UDP
FTP 21 TCP
HTTP 80 TCP
HTTPS 443 TCP
Persistent TLS Base Port 6,000 TCP
Radius default port for accounting 1813 TCP
Radius default port for the
authentication
1812 TCP
RTCP 5005 UDP
RTP 5004 UDP
Secure SIP 5061 TCP
SIP 5060 UDP
SNMP Listening 161 UDP
SNMP Trap 162 UDP
SNTP 123 UDP
SRTCP 5005 UDP
SRTP 5004 UDP
SSH 22 TCP
Syslog 514 UDP
T.38 6004 UDP
Telnet 23 TCP
TFTP 69 UDP

Calculating the RTP Port Range for Voice
5
Calculating the RTP Port Range for Voice
By default, the RTP port used for voice is 5004 i.e. IpTransportRtpBasePort = 5004
To calculate the RTP port range used for voice :
• RTP range min =IpTransportRtpBasePort
• RTP range max = IpTransportRtpBasePort + 4 * [Number of FXS ports] + 2 * [Number of FXO,
BRI or PRI channels] - 1 , or
• RTP range max = IpTransportRtpBasePort + 2 * [N] - 1 where
• N= 2* nbr of FXS ports + 2* nbr of BRI ports + nbr of FXO ports + 30 nbr of PRI E1 ports +
23 * nbr of PRI T1 ports + 24 * nbr of PRI T1 CAS ports
To calculate the RTP port range used for voice when SRTP and RTP are activated:
• RTP with SRTP range min = IpTransportRtpBasePort
• RTP with SRTP range max = IpTransportRtpBasePort+ 8 * [Number of FXS ports] 4 * [Number
of FXO, BRI or PRI channels] - 1, or
• RTP range max = IpTransportRtpBasePort + 4 * [N] - 1 where
• N= 2* nbr of FXS ports + 2* nbr of BRI ports + nbr of FXO ports + 30 nbr of PRI E1 ports +
23 * nbr of PRI T1 ports + 24 * nbr of PRI T1 CAS ports
Mitel TA7100 Series Port Range for Voice
Platform Interfaces # of FXS Ports
Port Range
(inclusively)
SRTP and RTP
activated Port
Range (inclusively)
TA7102 • 2 FXS 2 5004 to 5011 5004 to 5019
TA7104 • 4 FXS 4 5004 to 5019 5004 to 5035
TA7108 • 8 FXS 8 5004 to 6035 5004 to 5067

Calculating T.38 Port Range for Fax
6
Calculating T.38 Port Range for Fax
By default the T.38 base port used for fax is 6004 i.e IpTransportT38BasePort= 6004
To calculate the allocated T.38 port range:
• T.38 range min = IpTransportT38BasePort (default value = 6004)
• T.38 range max = IpTransportT38BasePort+ [Number of channels] - 1
Mitel TA7100 Series Port Range for Fax
Platform Interfaces # of Channels Port Range (inclusively)
TA7102 • 2 FXS 2 6004 to 6005
TA7104 • 4 FXS 4 6004 to 6007
TA7108 • 8 FXS 8 6004 to 6011
