Operator’s Manual
user manual, maintenance instructions and spare parts
28LH-a SELECT Hedgetrimmer
Read this manual carefully before operating the machine
Original Instructions Version June 16
28LH-a_200616

2
Original Instructions Version June 16
28LH-a_200616
28LH-a SELECT Hedgetrimmer
PRODUCT DESCRIPTION
This Hedgetrimmer unit is a 2 stroke fast running power tool and is designed to be used in a
domestic application with the attachment supplied. The Hedgetrimmer attachment is for trimming
new growth on hedges.

3
Original Instructions Version June 16
28LH-a_200616
28LH-a SELECT Hedgetrimmer
Warnings in the Manual
This mark indicates instructions which must be followed in order to prevent accidents which could
lead to serious bodily injury or death.
This mark indicates instructions which must be followed or it leads to mechanical failure,
breakdown, or damage.
This mark indicates hints or useful directions in the use of the product.
IMPORTANT
!
NOTE
Component Location
1. Fuel tank – 2 stroke mixture
2. Engine starter/Recoil
3. Carburettor / air filter
4. Safety lever
5. Throttle control lever
6. Ignition switch
7. Harness hanger
8. Loop handle
9. Transmission shaft
10. Gear box
11. Attachment shaft
12. Cutter Blades
13. Coupling

28LH-a SELECT Hedgetrimmer
4
Original Instructions Version June 16
28LH-a_200616
Safety Symbols
Warning: Danger, Caution
Read the documentation and safety instructions which are
provided in this user manual.
When operating this machine, use protective equipment such
as goggles, helmet and ear defenders.
Wear security shoes and gloves.
Check the condition of the working area to avoid any
accidents from hitting hidden obstacles such as stumps,
stones, cans, or broken glass.
Hot surface: Risk of burn.
Directive 2000-14/CE. Guaranteed noise levels
Beware of objects being thrown from the operating zone
Warning: Keep all people, animals and vulnerable objects at
least 15 metres from the working area.
Beware: Product conducts electricity. Keep the machine and
operator at least 10 metres from electrical sources and over-
head power cables.
Beware: Keep hands and feet away from moving parts.
Always keep a safe distance from the cutting parts.
Beware of blade thrust.

28LH-a SELECT Hedgetrimmer
5
Original Instructions Version June 16
28LH-a_200616
Taking Care of Warning Labels
Always keep warning labels clean and free of scratches, which might make them illegible or
dicult to read. If the warning labels provided with your Hedgetrimmer become damaged, peel
o, or otherwise become illegible or dicult to read, order new labels from the authorised
servicing dealer and replace the damaged labels. When applying new labels, first wipe away any
dirt and dry the surface before applying the new label in the same place as the original label.
Explanation of Symbols on the Machine
For safe operation and maintenance, symbols are carved in relief on the machine:
FUEL TANK
Fuel tank 2 stroke mix
Position: Fuel cap
CHOKE OPERATION
<RUN>
Starting mode when the engine is hot (choke o).
Position: Air cleaner cover.
<START>
Starting mode when the engine is cold (choke on).
Position: Air cleaner cover.

28LH-a SELECT Hedgetrimmer
6
Original Instructions Version June 16
28LH-a_200616
Safety Precautions
Introduction
Read this Owner/Operator Manual carefully. Be sure you understand how to operate this
Hedgetrimmer properly before you use it. Failure to do so could result in serious injury.
Keep this manual handy so that you may refer to it later whenever any questions arise. Also note
that you are able to contact the dealer from whom you purchased the product for assistance.
Always include this manual when selling, lending, or otherwise transferring the ownership of this
product.
This product has been designed to be used as a Hedgetrimmer power tool as described previously
and it should never be used for any other purpose; doing so could result in unforeseen accidents
and injuries occurring. Only approved Mitox accessories should be used with this product.
This Hedgetrimmer is equipped with extremely sharp blades, always wear sturdy gloves when
handling the blades and fit the safety guards when not in use.
When using this Hedgetrimmer for the first time, take it to a wide, clear, open space, start the
engine, and practice handling the Hedgetrimmer until you are sure that you will be able to handle
it properly in actual operation.
You should never use this Hedgetrimmer when under the influence of alcohol, suering from
exhaustion or lack of sleep, suering from drowsiness as a result of having taken medicine, or at
any other time when your judgement might be impaired or that you might not be able to operate
the Hedgetrimmer properly and in a safe manner.
Never allow children or anyone unable to fully understand the directions given in this manual to
use this Hedgetrimmer.
When planning your work schedule, allow plenty of time to perform the work and allow plenty of
time for rest. Limit the amount of time you continuously use the Hedgetrimmer to 30~40 minutes
per session and take 10~20 minutes of rest between work sessions. Also, try to keep the total
amount of work performed in a single day to 2 hours.
Never run the engine indoors as the exhaust gases contain harmful carbon monoxide.

28LH-a SELECT Hedgetrimmer
7
Original Instructions Version June 16
28LH-a_200616
Never use the Hedgetrimmer in conditions as described
below:
When the ground is slippery or when other conditions exist which might make it dicult to
maintain a steady posture while using the Hedgetrimmer.
At night, at times of heavy fog, or at any other times when your field of vision is limited and it
would be dicult to gain a clear view of the area where the Hedgetrimmer is to be used. In heavy
rain, during lightning storms, at times of strong or gale-force winds, or at any other times when
weather conditions might make it unsafe to use this product.
Lack of sleep, tiredness, or physical exhaustion results in lower attention spans, and this in turn
can lead to accidents and injury.
Work Clothing and Safety Equipment
When using the product, you should wear proper clothing and protective equipment.
• Helmet
• Protection goggles or face protector
• Ear protectors
• Thick work gloves
• Non-slip sole work boots
• When using your Hedgetrimmer, always wear strong, durable, work clothing; shirts should be
long-sleeved and trousers should be full-length.
Safety and Operation
This Hedgetrimmer is equipped with very sharp blades, and when used incorrectly the blades can
be extremely dangerous.
Improper handling can cause accidents which may in turn lead to serious injury or death. For
this reason, you should always be careful to adhere to the following instructions when using your
Hedgetrimmer.

28LH-a SELECT Hedgetrimmer
8
Original Instructions Version June 16
28LH-a_200616
Never hold the Hedgetrimmer in a way in which the blades are pointing towards someone else.
Never allow the blades to come into contact with your body.
Always turn o the engine before adjusting the Hedgetrimmer, or at any time when coming into
close proximity with the hedgetrimmer blades.
Always wear thick work gloves when adjusting the Hedgetrimmer.
Safe Handling of Fuel
The engine of the Hedgetrimmer is designed to run on a two stroke oil/fuel mixture.
This fuel is highly flammable; never store cans of fuel or refill the fuel tank in any place where
there is a source of heat or fire, which might ignite the fuel.
Do not smoke whilst operating the Hedgetrimmer or refilling, keep lit cigarettes away from the
Hedgetrimmer at all times.
When refilling the fuel tank always stop the engine first and carefully make sure that there are no
sparks or naked flames anywhere nearby before refuelling.
If any fuel spillage occurs during refuelling, use a dry rag to wipe any fuel which has been spilled
onto the Hedgetrimmer before starting the engine.
After refuelling, screw the fuel cap back tightly onto the fuel tank and carry the Hedgetrimmer to a
spot 5 metres or more away from where it was refuelled before starting the engine.

28LH-a SELECT Hedgetrimmer
9
Original Instructions Version June 16
28LH-a_200616
Before Operating the Hedgetrimmer
Before beginning work, carefully check the work area and remove any obstacles. Within a
perimeter of 15 metres of the work area should be considered a hazardous area into which no-
one should enter while the Hedgetrimmer is being used, and when necessary this area should be
marked with a warning rope, warning signs, or other forms of warning.
When work is to be performed simultaneously by two or more operators, care should also be
taken to constantly look around to check the presence and locations of other operators within the
work area to maintain a safe distance between each operator.
Before beginning work, each component of the Hedgetrimmer should be checked to make sure
that it is in proper working order, make sure that there are no loose screws or bolts, fuel leaks,
ruptures, dents, broken guards or any other problems which might interfere with safe operation.
Keep all parts of your body away from the cutting head when the engine is running.
Before Starting the Engine
Carefully check the work area to make sure that no obstacles exist within a perimeter of 15
metres around the Hedgetrimmer before starting the engine.
To start the engine, place the Hedgetrimmer onto the ground in a flat clear area and hold it firmly
in place to ensure that neither the blades nor the throttle come into contact with any obstacles
when the engine starts.
After starting the engine, make sure that the blades stop moving when the throttle trigger is
released (idle). If the blades continue to move when the engine is at idle, adjust the idle screw
on the carburettor to a point where the blades stops moving, if this cannot be achieved, take the
hedgetrimmer to your authorised service dealer for adjustment.

28LH-a SELECT Hedgetrimmer
10
Original Instructions Version June 16
28LH-a_200616
Avoid Noise Problems
Check and follow the local regulations for sound levels and hours of operation for garden
machinery.
In general, operate Hedgetrimmers between 8 am and 5 pm on week days and 9 am to 5 pm at
weekends.
Avoid using the Hedgetrimmer late at night and/or early in the morning.
Safety when using the Hedgetrimmer
When using the Hedgetrimmer, grip the handles firmly with both hands, place your feet slightly
apart so your weight is distributed evenly across both legs, and always maintain a steady even
posture while working. Do not use on ladders or if the ground surface is slippery or uneven.
Never attempt to cut directly overhead or with one hand.
• Maintain full engine speed when cutting.
• Never allow other persons to come within the work area as doing so
might expose them to danger.
• Keep work area clear of all persons, particularly small children and pets.
Injury may result from flying debris.
• If grass or other objects get caught in the Hedgetrimmer during operation,
always stop the engine before removing the object.
• Never touch the spark plug or plug HT cable while the engine is in
operation, doing so may result in an electrical shock.
• Never touch the exhaust, spark plug, or any metallic parts while the
engine is in operation or immediately after shutting down the engine.
These parts reach high temperatures during operation and doing so
could result in serious burns.
• When you finish cutting in one location and wish to continue work in another area, stop the
engine and fit the blade safety guards.
• Always remove fuel from the fuel tank before transportation to prevent fuel spillage.
• Never leave the Hedgetrimmer exposed to direct sunlight as this can heat the fuel tank and may
cause a discharge of fuel, and flood the engine.
• Be careful not to hit the blades against stones or the ground.
