Mitsubishi Electric VL-250CZPVU-R-E User manual

Eng-1
English
Contents
1. Safety Precautions …………………………2
2. Outside Dimensions ………………………6
3. Standard Installation Example ………… 10
3.1 Installation example ………………… 10
3.2 Working space ……………………… 11
4. Installation Procedure …………………… 12
5. Electrical Work …………………………… 15
5.1 Standard use ………………………… 15
5.2 External device connection use …… 15
6. How to use Controller …………………… 17
6.1 Controller button functions ……………… 17
6.2 Menu structure …………………………… 18
6.3 Main menu screen and operation ……… 19
6.4 Commissioning menu …………………… 20
6.5 Function setting …………………………… 12
6.6 How to(Error list) ………………………… 42
6.7 Commissioning …………………………… 42
7. Post-installation Checks ………………… 43
8. Trial operation …………………………… 44
LOSSNAY HEAT RECOVERY VENTILATOR (RESIDENTIAL USE)
MODEL
VL-250CZPVU-R-E
VL-250CZPVU-L-E
VL-350CZPVU-R-E
VL-350CZPVU-L-E
Installation Manual For dealer/contractor
■Thisproductisforresidentialuse.
■Thisproductmustbecorrectlyinstalledtoensurethatitsperformanceandfunctionsareproperlydemonstrated
and to ensure its safe use and operation. Before installation, please read this installation manual thoroughly.
Before using exclusive system components, read the installation manual for the system components thoroughly.
■Forinstallationparts,besuretouseaccessoriesanddesignatedparts.Useofnon-designatedpartsmaybea
cause of malfunction.
■Installationmustbeperformedbydealersandelectricalcontractors.Incorrectinstallationbythecustomermaybe
a cause of equipment malfunction or an accident.
■Electricalworkmustbeperformedbyaproperlyqualiedelectricianofthedealerorelectricalcontractor.
■Pleasenotethatenoughworkingspace(removethecover,replacethelter,etc.)isrequiredaroundtheproduct
for maintenance.
■Installtheunitindoor.
*ThegureshowsVL-350CZPVU-R-E

Eng-2
1. Safety Precautions
WARNING
Prohibited
Do not install the product in hot places, in the direct sunlight and in smoky places.
Failuretoheedthiswarningmayresultinre.
Do not
disassemble
Do not modify or disassemble the product beyond that is necessary.
Failuretoheedthiswarningmayresultinre,electricshockorinjury.
Do not wet
Refrain from immersing in water or splashing the product with water.
Failure to heed this warning could result in short circuit or electric shock.
Do not install
in bathroom
Do not install the Lossnay unit or the remote controller in a bathroom or other humid location.
Failure to heed this warning may result in electric shock or electric leakage.
Be sure to
ground
Be sure to install the ground wire.
Device failure and electric leakage may cause electric shock.
Follow
instructions
Use 220 to 240 V AC power.
Failuretoheadthiswarningmayresultinre,electricshockordamagetothecircuitboards.
For the outside air intake vent, choose a position where combustion gas or other similar exhaust air is not
sucked in and the vent is not buried by snow.
Inability to bring in fresh air may result in lack of oxygen in the room.
Select a place which is strong enough to support the product, and install the product securely.
Injurycouldresultifpartsfall.
Electrical work must be carried out safely and reliably by a professional electrical contractor (properly qualied
electrician) in accordance with internal wiring provisions and electrical-equipment technical standards.
Poorconnectionandfaultyelectricalworkcouldresultinelectricshockorre.
Install an all-pole power supply isolator at the power supply side as per local electrical regulations. All
supply circuits must be disconnected before obtaining access to the terminal devices. Use the specied
cable size and connect the cables securely to prevent disconnection when they are pulled.
Ifthereisadefectintheconnection,thereisapossibilityofre.
Use the designated electric wires, and connect them securely so that they do not come loose.
Defectiveconnectionsmayresultinre.
When metal ducts penetrate through metal-sheeted wooden buildings or structures, install the product so
that there is no electrical contact between the metal ducts and the metal sheeting.
Electric leakage may cause ignition.
Be sure to cover with the terminal block cover after electrical work.
Failuretoheedthiswarningmaycausedust,humidity,etc.toenter,resultinginelectricleakageorre.
Secure duct piping with commercially available xing bands, aluminum tape, etc. to prevent piping from
coming loose. Install outdoor piping from the product so that it is tilted at a downward pitch of at least 1/30
towards the outside.
Failuretoheedthiswarningmaycauserainpenetration,resultinginelectricshock/reorwaterdamageto
household property.
If the product will not be operated for a long period of time after installation, be sure to turn o󰀨 the circuit breaker.
Itcouldcauseelectricalshockbydeterioratedinsulationorrebytheelectricleakage.
For installation work parts, be sure to use only accessories and designated parts
Useofnon-designatedpartsmayresultinequipmentdamageoraccidents.
Symbols used in the text and on the main unit have the
following meanings.
Prohibited Do not install in
bathroom
Do not disassemble Be sure to ground
Do not wet Follow instructions
The following symbols indicate the degree of danger caused
by incorrect handling of the product.
WARNING
Incorrect handling of the
product may result in serious
injuryordeath.
CAUTION
Incorrect handling may result
inminorinjuryorphysical
damage to the house or
household goods.

Eng-3
WARNING
Follow
instructions
When using duct heaters (supply air preheaters, supply air after-heaters), make sure to use safety devices that
do not have self-return functions. Do not supply the duct heaters with electricity directly from the product.
Failuretoheedthiswarningmayresultinre.
When using duct heaters (supply air preheaters, supply air after-heaters) that do not have temperature
control functions, select duct heaters that have the appropriate capacity according to the airow passing
through the heaters.
Failuretoheedthiswarningmayresultinrebecausetheheaterswilloverheatiftheairowistoolittlecompared
to the capacity of heaters.

Eng-4
CAUTION
Prohibited
Do not install the product at regions or locations that exceed the following operating conditions.
If these operating conditions are exceeded, dew condensation water might drip.
Outdoor air temperature: -15 to 40
ºC
Area around the product and ambient temperature and humidity:0 to 40 ºC 80%RHorlessandatabsolute
humidity or less where the dew point temperature of 12
ºC (20 ºC 60%RHorequivalent)isreachedunderthe
above minimum outdoor air temperature conditions
When installing the product, do not drop or throw the product, or subject the product to impact.
Damage to structures inside the product may result in air or water leakage.
Do not carry with a pipe guide.
Failure to heed this warning may result in damage to pipe guide.
Do not place the unit directly on the oor.
Failure to heed this warning may result in damage to the drain pipe and the circuit case.
Follow
instructions
<Lossnay unit>
The unit is exclusively vertical mounting type.
If the unit is used horizontally, household belongings can get wet by drained water or condensation.
Install the product and the duct piping on the indoor side of the insulation layer/airtight layer.
The temperature of the air after heat is collected on the indoor side of the insulation layer may drop, or drain or dew
condensation might result in the ceiling getting wet.
Install the product (on the wall) in the direction of the duct connecting ange so that it is horizontal (within
± 1°).
Waterleakagemayresultinwaterdamagetotheoor.
Wear gloves when installing.
Failuretoheedthiswarningmayresultininjury.
Securely install parts so that they are not twisted or deformed.
Injurycouldresultifpartsfall.
Install the product by two persons.
Failuretoheedthiswarningmayresultinproductdamageorinjuryiftheproductfalls.
<Duct piping>
Make sure to insulate ducts down to the base of the duct connecting anges.
Exposed parts get cold in winter, which may result in dew condensation forming due to moisture in the room.
Do not allow duct piping to contact the inspection opening,ceiling hanging bolts, beams, pillars, and other
duct piping.
Failure to heed this warning may result in abnormal noise and vibration.
Use an outdoor hood, that makes it less likely for rain water,snow or small animals (e.g. bats) from entering
the ends of the supply air and exhaust air ducts.
To prevent the entry of small animals, install an outdoor hood having louvers 2 cm or less wide.
When the Lossnay unit is anticipated not to be operated continuously, insulate the RA (Return Air) side ducts.
Indoor humidity can cause condensation because exposed parts can become cold in winter.
Place the duct heaters (supply air preheaters, supply air after-heaters) at least 2 m from the product.
Failure to heed this warning may cause damage on the product due to the preheating from the heaters.
<Drain piping>
Make sure to connect drain piping by the following procedure to prevent freezing and dew condensation
forming on the surface of the piping
- Connect the drain piping on the indoor side of the insulation layer
- Insulate the drain piping up to the end of the piping
- Do not let the end of drain piping be immersed in the rain gutter, etc.
(At times of heavy snow, the rain gutter freezes and drain water is not discharged, which results in water leaking
fromtheLossnayunit.)
This appliance is not intended for use by persons (including children) with reduced physical sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance. (This appliance can be used by children
aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.)

Eng-5
Note
- Do not install the product at locations where toxic gas or gas containing corrosive components such as acids, alkaline,
organic solvents, or paints is generated. (Failure to heed this warning may result in malfunction.)
Do not install the product near bedrooms. (Failure to heed this warning may cause complaints about noise.)
- For living rooms (e.g. bed rooms) where it is anticipated that building ambient noise will be below 30 dB(A), use
commercially available ducts that have sound deadening qualities on the supply air side. (Sound from the product
resonatesin inside the ducts and may result abnormal noise being emitted from the air vent.)
- Install supply air and exhaust air grills at locations where they are less likely to reverberate. (Failure to heed this warning
may cause complaints about noise.)
- In cold regions or regions with strong winds, wind outside sometimes gets inside when operation of the product is stopped.
So, we recommend providing a motorized shutter midway along the supply air and exhaust air ducts.
- Installtheproductsothatdischargedgasorexhaustairfromburningappliancesandequipmentdoesnotowbackinside
the product.
- At regions where salt damage is a concern, use an exclusive outdoor hood.
- At regions where salt damage is a concern, parts may have to be replaced sooner because of the deterioration of materials
that are used.
- At the outdoor hood installation position, allow at least 3x the diameter of the duct through holes between the outdoor
hood and the ducts so that exhaust air is not mixed in with supply air. (Preferably a distance of 450 mm or more should be
ensured between the outdoor hood and the ducts.)
- Donotconnectductpipesinthewaysshownbelow.(Failuretoheedthiswarningmaycausetheairowtodecreaseor
result in abnormal noise.)
- Use an exhaust air lter that has a non-woven fabric type lter.
- To reduce the noise of drain discharge, make sure to connect commercially available check valves to the drain
piping. Use check valves in line with their instructions.
- The opening face of the drain piping edge must have a vertical downward lack of water. Make the opening at the
end of the drain piping face down so that water drains well.
- Extremely sharp bends - Many bends - Bending right next to the
duct connection flange
- Extreme narrowing of the
duct diameter

Eng-6
202202
88181
32
595
φ122
224219
86
318
269
115
10 356 20
40
40
228423
30179179179
681
20
242
51
56514
2. Outside Dimensions
Unit(mm)
Drain pipe (EA)
φ22
Drain pipe (SA)
φ22
Power Supply Cord Control box
Pipe Guide (SA)
PipeGuide(RA)
Pipe Guide (EA)
Pipe Guide (OA)
FilterCover(RA)
Filter Cover (OA)
Filter Cover (SA)
Wall Mount Hook Top
Controller
Heat exchanger
■VL-250CZPVU-R-E
Wall Mount Hook Down
Wall Bracket
(Accessory)
Wall Mount Hook Center
Cable strap hole
Accessories
Wall Bracket: 1 Slim-Lossnay
connection cable: 1
(100 mm)
Drainhosexture:2 Washer: 8 Drain hose: 1
(250 mm)
Cable strap: 1

Eng-7
202202
2088181
φ 122
51
56514
242
595
32
681
219224
280
309
126
10 356 20
40
40
30179179179
228423
Unit(mm)
Drain pipe (EA)
φ22 Drain pipe (SA)
φ22
Power Supply Cord Control box
Pipe Guide (EA)
Pipe Guide (OA)
Pipe Guide (SA)
PipeGuide(RA)
Filter Cover (OA)
FilterCover(RA)
Filter Cover (SA)
Wall Mount Hook Top
Controller
Heat exchanger
■VL-250CZPVU-L-E
Wall Mount Hook Down
Wall Bracket
(Accessory)
Wall Mount Hook Center
Accessories
Wall Bracket: 1 Slim-Lossnay
connection cable: 1
(100 mm)
Drainhosexture:2 Washer: 8 Drain hose: 1
(250 mm)
Cable strap: 1
Cable strap hole

Eng-8
658
623 84
31
95
121
111209
200200200
192 222
221 192
736
15
30
10 20
242242
246
40
40
242
φ 145
20
432
460
Drain pipe (EA)
φ22
Drain pipe (SA)
φ22
Power Supply Cord Control box
Pipe Guide (SA)
PipeGuide(RA)
Pipe Guide (EA)
Pipe Guide (OA)
FilterCover(RA)
Filter Cover (OA)
Filter Cover (SA)
Wall Mount Hook Top
Controller
Heat exchanger
■VL-350CZPVU-R-E
Wall Mount Hook Down
Wall Bracket
(Accessory)
Wall Mount Hook Center
Unit(mm)
Accessories
Wall Bracket: 1 Slim-Lossnay
connection cable: 1
(100 mm)
Drainhosexture:2 Washer: 8 Drain hose: 1
(250 mm)
Cable strap: 1
Cable strap hole

Eng-9
20
192 222
20
222 192
209 112
31
8462315
242
658
242 242
350
377
10 432
200 200 200
40
246460
40
736
30
φ 145
Drain pipe (EA)
φ22 Drain pipe (SA)
φ22
Power Supply Cord
Control box
Pipe Guide (EA)
Pipe Guide (OA)
Pipe Guide (SA)
PipeGuide(RA)
Filter Cover (OA)
FilterCover(RA)
Filter Cover (SA)
Wall Mount Hook Top
Controller
Heat exchanger
■VL-350CZPVU-L-E
Wall Mount Hook Down
Wall Bracket
(Accessory)
Cable strap hole Unit(mm)
Wall Mount Hook Center
Accessories
Wall Bracket: 1 Slim-Lossnay
connection cable: 1
(100 mm)
Drainhosexture:2 Washer: 8 Drain hose: 1
(250 mm)
Cable strap: 1

Eng-10
3. Standard Installation Example
3.1 Installation example
Note
- Be sure that the exhaust air connection has two or more conuence points with the piping from the bathroom.
- Preheaters and electric dampers may be required in your region.
- Read the instructions carefully in advance when using optional components and commercially available components.
EA
SA
RA
OA
Pre-heater
(Localpurchase)
OA shutter
(Localpurchase)
Remotecontroller
(UseP-RCC-E)
WiTablets
Bypass switching
switch
Livingroom
Restoom
Temperature
sensor
Ventilationfan
interlocking lighting
switch Isolator
Co2sensor

Eng-11
Unit(mm)
■VL-250CZPVU-R
■VL-250CZPVU-L
150
300
298
125
500≤
46
300
150
500≤
298
600≤
600≤
60
125
3.2 Working space (required space around the product)
This product requires regular maintenance (lter cleaning, parts replacement). Place the product from any other
obstacles for maintenance.
Unit(mm)
Control box
Control box
Space to pull out
Space to pull out
Note
-Secure about 2 mm of clearance from the side faces of the product to any other obstacles. (If not enough clearance
is secured, maintenance cannot be performed. Plus, vibration can result.)
-Secure space below the product for withdrawing the control box.) (If not enough space is secured, maintenance
cannot be performed.)

Eng-12
■VL-350CZPVU-R
■VL-350CZPVU-L
300
150
580≤
60
678≤
678≤
298
125
580≤
150
125
298
300
46
1010
1010
Unit(mm)
Control box
Control box
Space to pull out
Space to pull out
Note
-Secure about 10 mm of clearance from the side faces of the product to any other obstacles. (If not enough clearance
is secured, maintenance cannot be performed. Otherwise, vibration can result.)
-Secure space for withdrawing the control box below the product.) (If not enough space is secured, maintenance
cannot be performed.)

Eng-13
4. Installation Procedure
WARNING
Select a place which is strong enough to support the
product, and install the product securely.
Injurycouldresultifpartsfall.
CAUTION
Install the unit in the indoor side of the insulation layer/
airtight layer.
When installed on the outdoor side of the heat insulating
layer, the temperature of the heat-recovered air will drop and
condensationwillform,whichwillcausetheoortogetwet.
The products should be attached to a vertical surface.
The products may not be properly mounted and may cause
deformation of the product.
Transportation and installation of the product is carried
out by two or more people.
Causeofdamageorinjuryoftheproductduetoproductfall.
Wear gloves when installing.
Failuretoheedthiswarningmayresultininjury.
Note
-The unit is designed for wall mounting, only on a solid
wall. (Wall strength is needed more than 250 kg/m2.)
-A gypsum block or stud/plasterboard wall will not
su󰀩ce.
4.1 Wall bracket
Onepatofthewallbracket(supplied)shouldbeo󰀨eredup
tothewall,ensuringit’slocatedhorizontally.Makethexing
points through the pre drilled holes in the bracket and install
with screws (normal diameter 4 mm), whilst ensuring the
interlock side is at the top.
Wall bracket
(Supplied)
Screw (normal diameter 4 mm)
(Field supply)
4.2 Mounting the Unit
CAUTION
Do not carry with a pipe guide.
Failure to heed this warning may result in damage to pipe
guide.
Do not place the product directly on the oor.
Failure to heed this warning may result in damage to the drain
pipe and the control box.
4.3 Fixing the Unit
CAUTION
Install the product on the wall horizontally. (within ±1°)
Water leakage from the product may result in water damage
totheoor.
Note
-Use a washer(supplied), when there is a gap between
the attached surface and the hooks.
Wall bracket
Wall Mount Hook Center
(unit)
Control box
Drain pipe
Screw (normal diameter 4 mm)
(Field supply)

Eng-14
4.4 Connecting pipe
4.4.1 Duct Piping
WARNING
Install the ducts in the indoor side of the insulation layer/
airtight layer.
When installed on the outdoor side of the heat insulating
layer, the temperature of the heat-recovered air will drop and
condensationwillform,whichwillcausetheoortogetwet.
Secure duct piping with commercially available xing
bands, aluminum tape, etc. to prevent piping from loose.
Install outdoor piping from the unit so that it is tilted at a
downward pitch of at least 1/30 towards the outside.
Failure to heed this warning may cause rain penetration,
resultinginelectricshock/reorwaterdamagetohousehold
property.
Note
-When discharging the air from a bathroom, use ducts
made of a material that does not allow water to leak.
-When using PCV ducts or metal ducts for the SA side
ducts, be sure to connect ducts having silencer before
the grill.
-The duct for exhaust from the bathroom and the pipe
guide should be sealed with caulking material.
-When using calking compound, take care to prevent it
from oozing from the ducts. (Otherwise, it could cause
aluminum tape to peel o󰀨.)
-Before connecting the ducts, make sure that there are
no metal chips or other foreign matter (For example
paper or vinyl) inside the ducts or inside the product.
■VL-250CZPVU-R-E
■VL-250CZPVU-L-E
Duct Inner diameter φ150
(Field supply)
Sealant (Field supply)
Aluminum tape
(Field supply)
Pipe guide (unit)
■VL-350CZPVU-R-E
■VL-350CZPVU-L-E
4.4.2 Insulating Ducts
CAUTION
To prevent dew condensation, insulate the ducts and
pipe guide. (glass wool 25 mm or equivalent)
Be sure to insulate up to the base of pipe guide.
When the product is anticipated to be stopped for a long
time, insulate the RA (Return Air) side ducts also. (i.e. not
operated for 24 hours).
Indoor humidity can cause condensation because
exposed parts can become cold in winter.
■VL-250CZPVU-R-E
■VL-250CZPVU-L-E
■VL-350CZPVU-R-E
■VL-350CZPVU-L-E
Duct Inner diameter φ150
(Field supply)
Sealant (Field supply)
EPS(Unit)
Aluminum tape
(Field supply)
Pipe guide (unit)
Insulating (Field supply)
Insulating (Field supply)

Eng-15
4.5 Connecting drain piping
CAUTION
Make sure to connect drain piping by the following
procedure to prevent freezing and dew condensation
forming on the surface of the piping
- Connect the drain piping on the indoor side of the insulation
layer
Insulate the drain piping up to the end of the piping
- Do not let the end of drain piping be immersed in the rain
gutter, etc.
(At times of heavy snow, the rain gutter freezes and
drain water is not discharged, which results in water
leaking from the Lossnay unit.).
This unit has two drain pipes for EA and SA.
EA means Exhaust Air side, SA means Supply Air side.
EA drain pipe : Piping required
SA drain pipe : Depend on temperature and humidity, see
the following conditions.
EA drain pipe
connection
EA drain pipe
connection
SA drain pipe
connection
SA drain pipe
connection
Rtype Ltype
100
95
90
85
80
75
70
65
60
55
50
45
40
35
30
25
20
15
10
5
0
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 40
Indoor temperature ( ºC ) 25
Piping require area
Outdoorhumidity(%RH)
Outdoor temperature ( ºC )
4.5.1 Connection method of drain hose (EA drain
pipe)
1)Securely connect the accessary drain hose to the root of
the connection port.
 Securelyxtheaccessoryhosebandbytighteningwith
aatheadscrewdriver.(Otherwise,waterleakagecan
result.)
2)Connect one edge of the drain hose to the commercially
availabledrainpipe(Drainpipeforbuilding:hardPVCpipe
(outsidediameter:φ22)).
 Securelyxtheaccessoryhosebandbytighteningwitha
atheadscrewdriver.
3)Connect the drain pipe so that it has at least three degree
of downward gradient from the lower part of the unit.
(Otherwise, water leakage can result.)
4)Make sure to attach commercially available check valves.
For how to use, follow their instructions. (If not used
properly, water leakage can result.)
Note
-Do not adhere drain hoses with drain connection ports.
(Otherwise, maintenance cannot be performed.)
-Do not place the drain piping nearby the space for
withdrawing the control box. (If the control box
cannot be pulled out, product maintenance cannot be
performed.)
4.5.2 Connection method of drain hose (SA drain
pipe)
1)Extract the drain cap from the connection port of the SA
drain.Thecapisxwithtape.
2)Do the piping following the same procedures as the EA
drain pipe.
Drain hoses are not included; contact your dealer or
contractor.
Space for withdrawing the control box
Outside Diameter
φ22Drainpipe
(Localpurchase)
CheckValve
(Localpurchase)
More than 3°
Drain hose (Included)
Drainhosexture(Included)
SA drain pipe
connection
Drain cap

Eng-16
WARNING
Electrical work must be carried out safely and reliably by
a professional electrical contractor (properly qualied
electrician) in accordance with internal wiring provisions
and electricalequipment technical standards.
Poor connection and faulty electrical work could result in
electricshockorre.
Use 220 to 240 V AC power.
Failuretoheadthiswarningmayresultinre,electricshock
or damage to the circuit boards.
Make sure to install the ground wire.
In case of product failure and electric leakage, it may cause
an electric shock.
Note
-A power supply isolator must be installed.
Please understand that expenses incurred in
recovery work to deal with the above malfunction
shall be borne by the contractor.
5.1 Standard use
Power cord (unit)
Note
-LS (Black cord) means Live switch for kitchen and bath
room. When you use LS, remove protective tube.
Example:Unitservingakitchenandabathroom.
Ｎ
EARTH(Green/Yellow)
LS(Black):coverdbya
protective tube
N (Blue)
L(Brown)
L
N
L
N
LS
Power supply
220-240V/50Hz
220V/60Hz
Bath room
SW
Kitchen
SW
Isolator
(Field suplly)
Bath room
light
Power cord from unit
GREEN/
YELLOW
BROWN
BLUE
BLACK
5. Electrical Work
5.2 External device connection use
Connect the each cable for external devices to control board
according to the way below.
1)Remove2screws.Pullthecontrolbox.(Itstopsinthe
middle)
2) Removeaninsulatingsheet.(Becarefuloftheprotrusions
on both sides of the control box)
3) Connect the cables.
Please see ** about how to connect.
CN 105: IT interconnection Wi-Fi
TM2001-2:Analoginput1forSensor0-10V
 3-4:Analoginput2forSensor0-10V
TM201 1-2: Not available
3-4:Volt-freecontactforBoostSwitch
TM3: Signal output
(Pre-heater, Malfunction, Operation monitor)
TM4: Operation controller
If you use it, conntact to your dealer.
4) Make a cut in the Bush. Then pass the cord of the external
device through the Bush.
Attach the insulating sheet on the control box.
Insert the control box to the unit, attach two screws. (Don't
forget to place the insulating sheet)
Bind the external device wirings with a cable strap
(supplied) and attach it under the unit. (It is recommended
toinstallitwithexibilitysothatitwillnotbeloadedfrom
the outside.)
Controll box
Screw
Controll box
Insulating sheet
TM3 TM4 CN105
TM200
TM201
Controll box
Screw
Bush
Insert the cutting
Cable strap

Eng-17
Diagram for control board
Control circuit board
Signal interface circuit board (VL-40S)
CN217 CN232
1 2 3 4
TM201
TM200
＋－ －＋
1 2
VL-40
(DC)
Fieldsupplysensor,etc.(Volt-free)
Contact rating
15VDC0.1A
Minimum applicable load 1 mA
Externaldevice(DC0-10V)
Make sure of correct polarity
Sensor
Bypass
7
8
9
10
S
A
B
1
2
1
2
TH1(OA)
TH2(RA)
CN19
CN18
CN22
CN5
SA2
SA1SW5
SW7
SW6
SW2
3
TM2
TB5
TM4
TM3
CN20 (GR)
CN26 (WH)
CN32 (WH)
CN17 (RE)
CN105 (RE)
LED3
LED4
LED2
LED1
COM
Bypass monitor or Pre heater signal
Malfunction monitor output
Operation monitor output
IT interconnection Wi-Fi
Controller
Printed Circuit
Board(CONTROL)

Eng-18
1ON/OFF button
O󰀨operationisdisabledatthefactorydefaultsetting.
Please see 6.4.2.7 Control mode.
2SELECT button
3RETURN button
4MENU button
The «Main menu» screen is displayed.
Please see 6.2 Menu structure.
5Backlit LCD
The screen displays operation settings.
Press any button to turn on the backlight.
Youwillbeabletooperatebuttons.
After turning on the backlight for a certain period of time,
thebacklightturnso󰀨.
6ON/OFF lamp
The lamp lights up in green while the product is
operated. It blinks in green, while the product has an
error.
7Function buttons ( , , , )
Usetoselecteachsettingsoneachscreen.
The functions of the buttons change depending on the
screen.
See the “function button guide”at the bottom of the
screen.
6. How to use Controller
Function buttons
5
6
1234
7
Note
- If the function is not set in the function button , the function button guide will not be displayed.
Main
Main display:
Cursor
Main menu
User options
Commissioning
Maintenance
F1 F2 F3 F4
The function button
guide
6.1 Controller button functions

Eng-19
6.2 Menu structure
Main menu
Main operation
Press the button.
Move the cursor to the
desired item with the
, , and
buttons, and press the
button.
Useroptions
Commissioning
Maintenance
Boost/Purge preset
Silent mode
Manual bypass mode
Holiday mode
Please see Instruction manual
Clock
Commissioning menu (1/2)
Initial setting menu (1/2)
Initial setting
Airflow
External input
Auto bypass
Service
Initial setting menu (2/2)
Main/Sub
Model infromation
Maintenance information
Analog input 1
Languageselection
Clock
Serial No. information
Function setting
Analog input 2
Control mode
Contrast
Dealer information
Initializing
Liveswitch
Volt-freecontact
Display details
Resetmaintenanceinfo.
Administrator password
Commissioning menu (2/2)
Restriction(Nofunction)
Error history
Error information
Runtime
Maintenance interval
Service menu item
Navigating through the screens
• To go back to the «Main menu» screen ......
• To return to the previous screen .................
Note
- If no buttons are touched for 10 minutes (service menu item: 2
hours), the screen will automatically return to the «Main operation»
screen.
- Any settings that have not been saved will be lost.

Eng-20
6.3 «Main menu»screen and operation
6.3.1 Turning on the power
Before turning on the power:
1) Make sure that the connection is properly installed according to the Installation Manual.
2) Make sure that the product has been installed completely.
6.3.2 When the power is supplied, the screen below will appear.
Normal start up (indicating the percentage of process completion)
Please Wait
10%
6.3.3 Main operation
After the successful startup, the «Main operation» will appear.
6.3.4 Main menu
Press button, this screen appear.
The product is not in operation. The product is in operation.
Lossnay 12:00 Sun
Fan Mode
HeatEXBoost
Lossnay 12:00 Sun
Note
- Onlythersttime,the«Languageselection»screenwillbeappeared.
- The product will not start-up without language selection.
- See6.4.2.6Languageselection.
6.4 Commissioning menu
-YoucanuseCommissioningmenu.
Press , , , to move the cursor.
Press to go to the next screen.
- Administrator password is required. See 6.4.1 Administrator password.
F1 F2 F3 F4 F1 F2 F3 F4
Commissioning menu 1/2
Initial setting
Airflow
Auto bypass
External input
Service
Cursor Page
Main menu:
Initial setting menu 2/2
Language selection
Control mode
Cursor Page
Main menu:
F1 F2 F3 F4
Main
Main display:
Cursor
Main menu
User options
Commissioning
Maintenance
Press , to move the cursor.
Press to go to the next screen.
