Diagonal Size Width Height
inch cm inch cm inch cm inch cm inch cm
12 30 9.6 24 7.2 18 15.0 38 1.9 5.0
16 41 12.8 33 9.6 24 20.9 52 2.6 7.0
20 51 16.0 41 12.0 30 26.2 66 3.2 8.0
30 76 24.0 61 18.0 46 39.4 100 4.9 12.0
40 102 32.0 81 24.0 61 52.6 134 6.5 16.0
50 127 40.0 102 30.0 76 65.8 168 8.1 21.0
60 152 48.0 122 36.0 91 79.0 203 9.7 25.0
DISPLAY TECHNOLOGY
RESOLUTION
BRIGHTNESS
CONTRAST RATIO
ZOOM/FOCUS
PROJECTION LENS
THROW RATIO
OFF SET AXIS
PICTURE SIZE
SOURCE LAMP
PC COMPATIBILITY
VIDEO COMPATIBILITY
INPUT TERMINALS
OUTPUT TERMINAL
SCANNING RATE
AUDIO SPEAKER
POWER CONSUMPTION
DIMENSION
WEIGHT
POWER REQUIREMENTS
FAN NOISE
SUPPLIED ACCESSORIES
OPTIONAL ACCESSORIES
WARRANTY
0.55" 1-Chip DMD, DDP2000
800 x 600 (Total 480,000 pixels)
25 Lumens
1000 : 1 (on/off)
Manual Focus without Zoom
F=2.0
1.6
3:1
12" to 60" inch diagonal (optimal display at 40"to 50")
8 LED rated to last up to 10000 hours
Resolution; 640x400 – 800x600 + Compressed 1024x768, Sync on green available
NTSC / NTSC 4.43 / PAL (including PAL-M, N) / SECAM / PAL-60; Component Video;
480i/p(525i/p), 576i/p(625i/p), 720p(750p), 1080i(1125i 60Hz), 1080i(1125 50Hz)
15pin VGA, RCA, S-Video, SD Card reader, Audio stereo mini jack, DC Power input jack
Audio stereo mini jack
(H) 31-70 kHz for RGB, (V) 50-85 Hz for RGB, (Dot Clock) max. 100 MHz
0.2 W Mono
37W (LED 23W + System 14W)
Approximately 3.82" x 4.84" x 1.90" (LxWxH) (97x123x48.2mm)
1.10lbs/500g
AC 100-240V, 50/60Hz for AC adapter.
30dBA
Protective slip cover, AC/DC adapter including AC Power cord, Composite cable, Tri-pod
attachment, CD User Manual, Quick start and safety manual, remote control
Lithium-ion rechargeable battery (BT-PK20R), Optional battery operational for
approximately 2 hours
1-year parts and labor
©2006 Mitsubishi Digital Electronics America, Inc. Standard features,
options and specifications subject to change without notice. The
DLP™ logo and DLP™ medallion are trademarks of Texas Instruments.
Microsoft, Windows, and the Windows logo are registered trademarks
of Microsoft Corporation. Mac and the Mac logo are trademarks of
Apple Computer, Inc, registered in the U.S. and other countries. All
other trademarks are the property of their respective holders.
*The projector lamp contains mercury. Please dispose of properly.
PP6044-09/06-LITPK20E
Canada
Mitsubishi Electric Sales Canada Inc.
Information Technologies Group
Phone: 905.475.7728
www.mitsubishielectric.ca
MITSUBISHI DIGITAL ELECTRONICS AMERICA, INC.
Presentation Products Division
Toll Free: 888.307.0349
www.mitsubishi-presentations.com
PK20 SVGA DLP™ PROJECTOR
1. S-Video In
2. Composite Video In
3. PC/Component RGB Input
4. SD card reader
5. Audio out
6. Audio in
7. DC IN
12 3
45 6 7
SCREEN Hd
Distance
from Screen
(D)
inch cm inch cm inch cm inch cm inch cm
12 30 10.5 27 5.9 15 15.0 38 1.1 2.9
16 41 13.9 35 7.8 20 22.8 52 1.5 3.9
20 51 17.4 44 9.8 25 28.6 66 1.9 4.8
30 76 26.1 66 14.7 37 42.9 100 2.8 7.2
40 102 34.9 89 19.6 50 57.3 134 3.8 9.6
50 127 43.6 111 24.5 62 71.7 168 4.7 12.0
60 152 52.3 133 29.4 75 86.0 203 5.7 14.4
4:3
16:9
Unit measured in inches. *Hd is distance from lens axis to image bottom.
CAMCORDER
GAMING CONSOLE
LAPTOP
PDA
DVD/VHS PLAYER
DIGITAL CAMERA
VIDEO-MP3 PLAYER
123mm (4.8") •
•
97mm (3.8") •
•
48mm
(1.9")
•
•
Image represent the PK20 with a battery pack
