General-Purpose AC Servo
MR-MT2000 SERIES INSTRUCTION MANUAL
HEAD OFFICE : TOKYO BLDG MARUNOUCHI TOKYO 100-8310
MODEL
MR-MT2010
MR-MT2100
MR-MT2200
MR-MT2300
MR-MT2400
INSTRUCTION MANUAL
Sensing module
B
B

A - 1
Safety Instructions
Please read the instructions carefully before using the equipment.
To use the equipment correctly, do not attempt to install, operate, maintain, or inspect the equipment until
you have read through this Instruction Manual, Installation guide, and appended documents carefully. Do not
use the equipment until you have a full knowledge of the equipment, safety information and instructions.
In this Instruction Manual, the safety instruction levels are classified into "WARNING" and "CAUTION".
WARNING Indicates that incorrect handling may cause hazardous conditions,
resulting in death or severe injury.
CAUTION Indicates that incorrect handling may cause hazardous conditions,
resulting in medium or slight injury to personnel or may cause physical
damage.
Note that the CAUTION level may lead to a serious consequence depending on conditions.
Please follow the instructions of both levels because they are important to personnel safety.
What must not be done and what must be done are indicated by the following diagrammatic symbols.
Indicates what must not be done. For example, "No Fire" is indicated by .
Indicates what must be done. For example, grounding is indicated by .
In this Instruction Manual, instructions at a lower level than the above, instructions for other functions, and so
on are classified into "POINT".
After reading this Instruction Manual, keep it accessible to the operator.

A - 2
1. To prevent electric shock, note the following
WARNING
Ground the sensing module securely.
Any person who is involved in wiring and inspection should be fully competent to do the work.
Do not attempt to wire the sensing module until it has been installed. Otherwise, it may cause an electric
shock.
Do not operate switches with wet hands. Otherwise, it may cause an electric shock.
The cables should not be damaged, stressed, loaded, or pinched. Otherwise, it may cause an electric
shock.
To avoid an electric shock, insulate the connections of the power supply terminals.
2. To prevent fire, note the following
CAUTION
Install the sensing module on incombustible material. Installing them directly or close to combustibles will
lead to smoke or a fire.
Always connect a circuit protector between the power supply and the power supply (24 V(+)) of the
sensing module, in order to configure a circuit that shuts down the power supply on the side of the
sensing module power supply. If a circuit protector is not connected, a continuous flow of a large current
may cause smoke or a fire when the sensing module malfunctions.
Provide an adequate protection to prevent screws and other conductive matter, oil and other combustible
matter from entering the sensing module.
3. To prevent injury, note the following
CAUTION
Only the voltage specified in the Instruction Manual should be applied to each terminal. Otherwise, a
burst, damage, etc. may occur.
Connect cables to the correct terminals. Otherwise, a burst, damage, etc. may occur.
Ensure that polarity (+/-) is correct. Otherwise, a burst, damage, etc. may occur.
4. Additional instructions
The following instructions should also be fully noted. Incorrect handling may cause a malfunction, injury,
electric shock, fire, etc.
(1) Transportation and installation
CAUTION
Transport the products correctly according to their mass.
Stacking in excess of the specified number of product packages is not allowed.
Install the sensing module in a load-bearing place in accordance with the Instruction Manual.
Do not get on or put heavy load on the equipment.
The equipment must be installed in the specified direction.

A - 3
CAUTION
Leave specified clearances between the sensing module and cabinet walls or other equipment.
Do not install or operate the sensing module which has been damaged or has any parts missing.
Do not block intake and exhaust areas of the sensing module. Otherwise, it may cause a malfunction.
Do not drop or strike the sensing module. Isolate it from all impact loads.
When you keep or use the equipment, please fulfill the following environment.
Item Environment
Ambient
temperature
Operation 0 °C to 60 °C (non-freezing)
Storage -20 ˚C to 65 ˚C (non-freezing)
Ambient
humidity
Operation 5 %RH to 90 %RH (non-condensing)
Storage
Ambience Indoors (no direct sunlight); no corrosive gas, inflammable gas, oil mist or dust
Altitude
2000 m or less above sea level
(When using the MR-MT2000 series at an altitude exceeding 1000 m and up to 2000 m above sea
level, the ambient temperature must be 0 °C to 55 °C.)
Vibration resistance 5.9 m/s2, at 10 Hz to 55 Hz (directions of X, Y and Z axes)
When the product has been stored for an extended period of time, contact your local sales office.
When handling the sensing module, be careful with the sharp edges of the sensing module.
The sensing module must be installed in a metal cabinet.
When fumigants that contain halogen materials, such as fluorine, chlorine, bromine, and iodine, are used
for disinfecting and protecting wooden packaging from insects, they cause malfunction when entering our
products. Please take necessary precautions to ensure that remaining materials from fumigant do not
enter our products, or treat packaging with methods other than fumigation, such as heat treatment.
Additionally, disinfect and protect wood from insects before packing the products.
(2) Wiring
CAUTION
Wire the sensing module correctly and securely. Otherwise, the equipment may operate unexpectedly.
The connection diagrams in this Instruction Manual are shown for sink interfaces, unless stated
otherwise.
The surge absorbing diode installed to the DC relay for control output signals of the sensing module
should be fitted in the specified direction. Otherwise, the emergency stop and other protective circuits
may not operate.
DOCOM
Control output
signal
24 V DC
Sensing module
RA
For sink output interface
DOCOM
Control output
signal
24 V DC
Sensing module
RA
For source output interface

A - 4
(3) Test run and adjustment
CAUTION
Before operation, check and adjust the parameter settings. Improper settings may cause some machines
to operate unexpectedly.
(4) Usage
CAUTION
Immediately turn off the power if smoke, unusual noise, or strange odor is emitted from the sensing
module.
Do not disassemble, repair, or modify the equipment.
Burning or breaking a sensing module may cause a toxic gas. Do not burn or break it.
Connect the sensing module to the specified controller.
(5) Corrective actions
CAUTION
Ensure safety by confirming the power off, etc. before performing corrective actions. Otherwise, it may
cause an accident.
When an alarm occurs, eliminate its cause, ensure safety, and deactivate the alarm to restart operation.
Provide an adequate protection to prevent unexpected restart after an instantaneous power failure.
(6) Maintenance, inspection and parts replacement
CAUTION
Do not touch the connector contacts.
It is recommended that the sensing module be replaced every 10 years when it is used in general
environment.
When using the sensing module that has not been energized for an extended period of time, contact your
local sales office.
(7) General instruction
To illustrate details, the equipment in the diagrams of this Instruction Manual may have been drawn
without covers and safety guards. When the equipment is operated, the covers and safety guards must
be installed as specified. Operation must be performed in accordance with this Instruction Manual.

A - 5
DISPOSAL OF WASTE
Please dispose a sensing module and other options according to your local laws and regulations.
EEP-ROM life
The number of write times to the EEP-ROM, which stores parameter settings, etc., is limited to 100,000. If
the total number of the following operations exceeds 100,000, the sensing module may malfunction when the
EEP-ROM reaches the end of its useful life.
Write to the EEP-ROM due to parameter setting changes
Compliance with global standards
Refer to app. 1 for the compliance with global standards.
«About the manual»
You must have this Instruction Manual and the following manual to use this sensing module. Ensure to
prepare them to use the sensing module safely.
Relevant manuals
Manual name Manual No.
MELSEC iQ-R Motion Controller Programming Manual (Common) IB-0300237
«Cables used for wiring»
Wires mentioned in this Instruction Manual are selected based on an ambient temperature of 40 ˚C.
«U.S. customary units»
U.S. customary units are not shown in this manual. Convert the values if necessary according to the
following table.
Quantity SI (metric) unit U.S. customary unit
Mass 1 [kg] 2.2046 [lb]
Length 1 [mm] 0.03937 [inch]
Torque 1 [N•m] 141.6 [oz•inch]
Moment of inertia 1 [(× 10-4 kg•m2)] 5.4675 [oz•inch2]
Load (thrust load/axial load) 1 [N] 0.2248 [lbf]
Temperature N [°C] × 9/5 + 32 N [°F]

A - 6
