Mitsubishi Electric MR-J4-*B-RJ010 Series User manual

General-Purpose AC Servo
CC-Link IE Field Network interface with Motion
MODEL (Servo amplifier)
MR-J4-_B-RJ010
MR-J4-_B4-RJ010
MODEL (CC-Link IE Field Network interface unit)
MR-J3-T10
SERVO AMPLIFIER
INSTRUCTION MANUAL
B

A - 1
Safety Instructions
Please read the instructions carefully before using the equipment.
To use the equipment correctly, do not attempt to install, operate, maintain, or inspect the equipment until
you have read through this Instruction Manual, Installation guide, and appended documents carefully. Do not
use the equipment until you have a full knowledge of the equipment, safety information and instructions.
In this Instruction Manual, the safety instruction levels are classified into "WARNING" and "CAUTION".
WARNING Indicates that incorrect handling may cause hazardous conditions,
resulting in death or severe injury.
CAUTION
Indicates that incorrect handling may cause hazardous conditions,
resulting in medium or slight injury to personnel or may cause physical
damage.
Note that the CAUTION level may lead to a serious consequence according to conditions.
Please follow the instructions of both levels because they are important to personnel safety.
What must not be done and what must be done are indicated by the following diagrammatic symbols.
Indicates what must not be done. For example, "No Fire" is indicated by .
Indicates what must be done. For example, grounding is indicated by .
In this Instruction Manual, instructions at a lower level than the above, instructions for other functions, and so
on are classified into "POINT".
After reading this Instruction Manual, keep it accessible to the operator.

A - 2
1. To prevent electric shock, note the following
WARNING
Before wiring or inspection, turn off the power and wait for 15 minutes or more until the charge lamp
turns off. Then, confirm that the voltage between P+ and N- is safe with a voltage tester and others.
Otherwise, an electric shock may occur. In addition, when confirming whether the charge lamp is off or
not, always confirm it from the front of the servo amplifier.
Ground the servo amplifier and servo motor securely.
Any person who is involved in wiring and inspection should be fully competent to do the work.
Do not attempt to wire the servo amplifier and servo motor until they have been installed. Otherwise, it
may cause an electric shock.
Do not operate switches with wet hands. Otherwise, it may cause an electric shock.
The cables should not be damaged, stressed, loaded, or pinched. Otherwise, it may cause an electric
shock.
During power-on or operation, do not open the front cover of the servo amplifier. Otherwise, it may cause
an electric shock.
Do not operate the servo amplifier with the front cover removed. High-voltage terminals and charging
area are exposed and you may get an electric shock.
Except for wiring and periodic inspection, do not remove the front cover of the servo amplifier even if the
power is off. The servo amplifier is charged and you may get an electric shock.
To prevent an electric shock, always connect the protective earth (PE) terminal (marked ) of the servo
amplifier to the protective earth (PE) of the cabinet.
When using an earth-leakage current breaker (RCD), select the type B.
To avoid an electric shock, insulate the connections of the power supply terminals.
2. To prevent fire, note the following
CAUTION
Install the servo amplifier, servo motor, and regenerative resistor on incombustible material. Installing
them directly or close to combustibles will lead to a fire.
Always connect a magnetic contactor between the power supply and the main circuit power supply (L1,
L2, and L3) of the servo amplifier, in order to configure a circuit that shuts down the power supply on the
side of the servo amplifier’s power supply. If a magnetic contactor is not connected, continuous flow of a
large current may cause a fire when the servo amplifier malfunctions.
When using the regenerative resistor, switch power off with the alarm signal. Not doing so may cause a
fire when a regenerative transistor malfunctions or the like may overheat the regenerative resistor.
Provide adequate protection to prevent screws and other conductive matter, oil and other combustible
matter from entering the servo amplifier, servo motor, and MR-J3-T10.
Always connect a molded-case circuit breaker to the power supply of the servo amplifier.

A - 3
3. To prevent injury, note the following
CAUTION
Only the voltage specified in the Instruction Manual should be applied to each terminal. Otherwise, a
burst, damage, etc. may occur.
Connect cables to the correct terminals. Otherwise, a burst, damage, etc. may occur.
Ensure that polarity (+/-) is correct. Otherwise, a burst, damage, etc. may occur.
The servo amplifier heat sink, regenerative resistor, servo motor, etc. may be hot while power is on or for
some time after power-off. Take safety measures, e.g. provide covers, to avoid accidentally touching the
parts (cables, etc.) by hand.
4. Additional instructions
The following instructions should also be fully noted. Incorrect handling may cause a malfunction, injury,
electric shock, etc.
(1) Transportation and installation
CAUTION
Transport the products correctly according to their mass.
Stacking in excess of the specified number of product packages is not allowed.
Do not hold the front cover when transporting the servo amplifier. Otherwise, it may drop.
Install the servo amplifier and the servo motor in a load-bearing place in accordance with the Instruction
Manual.
Do not get on or put heavy load on the equipment.
The equipment must be installed in the specified direction.
Leave specified clearances between the servo amplifier and the cabinet walls or other equipment.
Do not install or operate the servo amplifier and MR-J3-T10 which have been damaged or have any
parts missing.
Do not block the intake and exhaust areas of the servo amplifier and MR-J3-T10. Otherwise, it may
cause a malfunction.
Do not drop or strike the servo amplifier, servo motor, and MR-J3-T10. Isolate them from all impact
loads.
When you keep or use the equipment, please fulfill the following environment.
Item Environment
Operation 0 °C to 55 °C (non-freezing)
Ambient
temperature Storage -20 °C to 65 °C (non-freezing)
Operation
Ambient
humidity Storage 90 %RH or less (non-condensing)
Ambience Indoors (no direct sunlight), free from corrosive gas, flammable gas, oil mist, dust, and dirt
Altitude 1000 m or less above sea level
Vibration resistance 5.9 m/s2, at 10 Hz to 55 Hz (directions of X, Y and Z axes)
When the product has been stored for an extended period of time, contact your local sales office.
When handling the servo amplifier and MR-J3-T10, be careful about the edged parts such as corners of
them.
The servo amplifier and MR-J3-T10 must be installed in a metal cabinet.
When fumigants that contain halogen materials such as fluorine, chlorine, bromine, and iodine are used
for disinfecting and protecting wooden packaging from insects, they cause malfunction when entering our
products. Please take necessary precautions to ensure that remaining materials from fumigant do not
enter our products, or treat packaging with methods other than fumigation (heat method).Additionally,
disinfect and protect wood from insects before packing products.

A - 4
(2) Wiring
CAUTION
Wire the equipment correctly and securely. Otherwise, the servo motor may operate unexpectedly.
Do not install a power capacitor, surge killer, or radio noise filter (FR-BIF-(H) option) on the servo
amplifier output side.
To avoid a malfunction, connect the wires to the correct phase terminals (U, V, and W) of the servo
amplifier and servo motor.
Connect the servo amplifier power output (U, V, and W) to the servo motor power input (U, V, and W)
directly. Do not let a magnetic contactor, etc. intervene. Otherwise, it may cause a malfunction.
U
Servo motor
M
V
W
U
V
W
U
M
V
W
U
V
W
Servo amplifier Servo motorServo amplifier
The connection diagrams in this installation guide are shown for sink interfaces, unless stated otherwise.
The surge absorbing diode installed to the DC relay for control output should be fitted in the specified
direction. Otherwise, the emergency stop and other protective circuits may not operate.
DOCOM
Control output
signal
24 V DC
Servo amplifier
RA
For sink output interface
DOCOM
Control output
signal
24 V DC
Servo amplifier
RA
For source output interface
When the cable is not tightened enough to the terminal block, the cable or terminal block may generate
heat because of the poor contact. Be sure to tighten the cable with specified torque.
Connecting a servo motor for different axis to U, V, W, or CN2 of the servo amplifier may cause a
malfunction.
(3) Test run and adjustment
CAUTION
Before operation, check the parameter settings. Improper settings may cause some machines to operate
unexpectedly.
Never make a drastic adjustment or change to the parameter values as doing so will make the operation
unstable.
Do not close to moving parts at servo-on status.
(4) Usage
CAUTION
When it is assumed that a hazardous condition may occur due to a power failure or product malfunction,
use a servo motor with an external brake to prevent the condition.
Do not disassemble, repair, or modify the equipment.

A - 5
(4) Usage
CAUTION
Before resetting an alarm, make sure that the run signal of the servo amplifier is off in order to prevent a
sudden restart. Otherwise, it may cause an accident.
Use a noise filter, etc. to minimize the influence of electromagnetic interference. Electromagnetic
interference may be given to the electronic equipment used near the servo amplifier.
Burning or breaking a servo amplifier may cause a toxic gas. Do not burn or break it.
Use the servo amplifier with the specified servo motor.
The electromagnetic brake on the servo motor is designed to hold the motor shaft and should not be
used for ordinary braking.
For such reasons as service life and mechanical structure (e.g. where a ball screw and the servo motor
are coupled via a timing belt), the electromagnetic brake may not hold the motor shaft. To ensure safety,
install a stopper on the machine side.
(5) Corrective actions
CAUTION
When it is assumed that a hazardous condition may occur due to a power failure or product malfunction,
use a servo motor with an electromagnetic brake or external brake to prevent the condition.
Configure an electromagnetic brake circuit so that it is activated also by an external EMG stop switch.
Servo motor
Electromagnetic brake
B
RA
Contacts must be opened
with the EMG stop switch.
Contacts must be opened when ALM
(Malfunction) or MBR (Electromagnetic
brake interlock) turns off.
24 V DC
When any alarm has occurred, eliminate its cause, ensure safety, and deactivate the alarm before
restarting operation.
Provide an adequate protection to prevent unexpected restart after an instantaneous power failure.
(6) Maintenance, inspection and parts replacement
CAUTION
With age, the electrolytic capacitor of the servo amplifier will deteriorate. To prevent a secondary
accident due to a malfunction, it is recommend that the electrolytic capacitor be replaced every 10 years
when it is used in general environment. Please contact your local sales office.
(7) General instruction
To illustrate details, the equipment in the diagrams of this Instruction Manual may have been drawn
without covers and safety guards. When the equipment is operated, the covers and safety guards must
be installed as specified. Operation must be performed in accordance with this Instruction Manual.

A - 6
DISPOSAL OF WASTE
Please dispose a servo amplifier, battery (primary battery) and other options according to your local laws and
regulations.
EEP-ROM life
The number of write times to the EEP-ROM, which stores parameter settings, etc., is limited to 100,000. If
the total number of the following operations exceeds 100,000, the servo amplifier may malfunction when the
EEP-ROM reaches the end of its useful life.
Write to the EEP-ROM due to parameter setting changes
Write to the EEP-ROM due to device changes
STO function of the servo amplifier
When using the STO function of the servo amplifier, refer to chapter 13 of "MR-J4-_B_(-RJ) Servo Amplifier
Instruction Manual".
For the MR-J3-D05 safety logic unit, refer to appendix 5 of "MR-J4-_B_(-RJ) Servo Amplifier Instruction
Manual".
Compliance with global standards
For the compliance with global standards, refer to appendix 4 of "MR-J4-_B_(-RJ) Servo Amplifier Instruction
Manual".

A - 7
«About the manual»
You must have this Instruction Manual and the following manuals to use the servo. Ensure to prepare
them to use the servo safely.
Relevant manuals
Manual name Manual No.
MELSERVO-J4 Series Instructions and Cautions for Safe Use of AC Servos
(Packed with 200 V class servo amplifiers)
IB(NA)0300175
MELSERVO-J4 Series Instructions and Cautions for Safe Use of AC Servos
(Packed with 400 V class servo amplifiers)
IB(NA)0300197
MR-J4-_B_(-RJ) AMPLIFIER INSTRUCTION MANUAL SH(NA)030106
MELSERVO-J4 SERVO AMPLIFIER INSTRUCTION MANUAL (TROUBLESHOOTING) SH(NA)030109
MELSERVO Servo Motor Instruction Manual (Vol. 3) SH(NA)030113
EMC Installation Guidelines IB(NA)67310
MELSEC-Q QD77GF Simple motion module User's Manual (Positioning Control) IB(NA)0300202
MELSEC-Q QD77GF Simple motion module User's Manual (Network) IB(NA)0300203
This Instruction Manual does not describe the following items. The followings are the same as MR-J4-_B_
servo amplifiers. For details of the items, refer to each chapter/section of the detailed description field.
"MR-J4-_B_" means "MR-J4-_B_(-RJ) Servo Amplifier Instruction Manual".
Item Detailed explanation
Normal gain adjustment MR-J4-_B_ chapter 6
Special adjustment functions (except gain
switching function)
MR-J4-_B_ chapter 7
Characteristics MR-J4-_B_ chapter 10
Absolute position detection system MR-J4-_B_ chapter 12
Using STO function MR-J4-_B_ chapter 13
«Cables used for wiring»
Wires mentioned in this Instruction Manual are selected based on the ambient temperature of 40 °C.
«U.S. customary units»
U.S. customary units are not shown in this manual. Convert the values if necessary according to the
following table.
Quantity SI (metric) unit U.S. customary unit
Mass 1 [kg] 2.2046 [lb]
Length 1 [mm] 0.03937 [in]
Torque 1 [N•m] 141.6 [oz•in]
Moment of inertia 1 [(× 10-4 kg•m2)] 5.4675 [oz•in2]
Load (thrust load/axial load) 1 [N] 0.2248 [lbf]
Temperature N [°C] × 9/5 + 32 N [°F]

A - 8
MEMO

1
CONTENTS
1. FUNCTIONS AND CONFIGURATION 1- 1 to 1-44
1.1 Summary............................................................................................................................................ 1- 1
1.2 Function block diagram...................................................................................................................... 1- 2
1.3 Standard specifications...................................................................................................................... 1- 8
1.3.1 Servo amplifier............................................................................................................................. 1- 8
1.3.2 MR-J3-T10 Field Network interface unit..................................................................................... 1-10
1.4 Combinations of servo amplifiers and servo motors......................................................................... 1-10
1.5 Function list....................................................................................................................................... 1-12
1.6 Model designation............................................................................................................................. 1-13
1.7 Structure............................................................................................................................................ 1-15
1.7.1 Parts identification ...................................................................................................................... 1-15
1.7.2 Parts identification of MR-J3-T10............................................................................................... 1-27
1.8 Installation and removal of MR-J3-T10............................................................................................. 1-28
1.9 Configuration including peripheral equipment .................................................................................. 1-32
1.9.1 200 V class................................................................................................................................. 1-32
1.9.2 400 V class................................................................................................................................. 1-38
2. INSTALLATION 2- 1 to 2- 4
2.1 Installation direction and clearances.................................................................................................. 2- 2
2.2 Keep out foreign materials................................................................................................................. 2- 4
3. SIGNALS AND WIRING 3- 1 to 3-18
3.1 I/O signal connection example........................................................................................................... 3- 3
3.1.1 For sink I/O interface ................................................................................................................... 3- 3
3.1.2 For source I/O interface............................................................................................................... 3- 5
3.2 Servo motor with an electromagnetic brake ...................................................................................... 3- 6
3.2.1 Safety precautions....................................................................................................................... 3- 6
3.2.2 Timing chart................................................................................................................................. 3- 7
4. STARTUP 4- 1 to 4-12
4.1 Switching power on for the first time.................................................................................................. 4- 2
4.1.1 Startup procedure........................................................................................................................ 4- 2
4.1.2 Wiring check................................................................................................................................ 4- 3
4.1.3 Surrounding environment............................................................................................................ 4- 6
4.2 Switch setting and display of the servo amplifier............................................................................... 4- 6
4.2.1 Switches ...................................................................................................................................... 4- 6
4.2.2 Scrolling display .......................................................................................................................... 4- 9
4.2.3 Status display of a station .......................................................................................................... 4-10
4.3 Display of MR-J3-T10 CC-Link IE Field Network interface unit........................................................ 4-12
5. PARAMETERS 5- 1 to 5-36
5.1 Parameter list..................................................................................................................................... 5- 1
5.1.1 Basic setting parameters ([Pr. PA_ _ ])....................................................................................... 5- 2

2
5.1.2 Gain/filter setting parameters ([Pr. PB_ _ ]) ................................................................................ 5- 3
5.1.3 Extension setting parameters ([Pr. PC_ _ ])................................................................................ 5- 4
5.1.4 I/O setting parameters ([Pr. PD_ _ ])........................................................................................... 5- 5
5.1.5 Extension setting 2 parameters ([Pr. PE_ _ ]).............................................................................5-6
5.1.6 Extension setting 3 parameters ([Pr. PF_ _ ]).............................................................................5-7
5.1.7 Option setting parameters ([Pr. Po_ _) ....................................................................................... 5- 8
5.2 Detailed list of parameters ................................................................................................................ 5-10
5.2.1 Basic setting parameters ([Pr. PA_ _ ])...................................................................................... 5-10
5.2.2 Gain/filter setting parameters ([Pr. PB_ _ ]) ............................................................................... 5-17
5.2.3 Extension setting parameters ([Pr. PC_ _ ])............................................................................... 5-26
5.2.4 I/O setting parameters ([Pr. PD_ _ ]).......................................................................................... 5-31
5.2.5 Extension setting 2 parameters ([Pr. PE_ _ ])............................................................................ 5-33
5.2.6 Extension setting 3 parameters ([Pr. PF_ _ ])............................................................................ 5-34
5.2.7 Option setting parameters ([Pr. Po_ _) ...................................................................................... 5-36
6. TROUBLESHOOTING 6- 1 to 6- 8
6.1 Alarm and warning list........................................................................................................................ 6- 1
6.2 Troubleshooting at power on ............................................................................................................. 6- 6
7. DIMENSIONS 7- 1 to 7-18
7.1 Servo amplifier ................................................................................................................................... 7- 2
7.1.1 200 V class.................................................................................................................................. 7- 2
7.1.2 400 V class................................................................................................................................. 7-11
7.2 MR-J3-T10 CC-Link IE Field Network interface unit......................................................................... 7-18
8. OPTIONS AND PERIPHERAL EQUIPMENT 8- 1 to 8- 4
8.1 Combinations of cable/connector sets............................................................................................... 8- 2
8.2 Cable for CC-Link IE Field Network................................................................................................... 8- 4
APPENDIX App.- 1 to App.- 5
App. 1 Peripheral equipment manufacturer (for reference)................................................................App.- 1
App. 2 Analog monitor ........................................................................................................................App.- 1
App. 3 Special specification ................................................................................................................App.- 4

1. FUNCTIONS AND CONFIGURATION
1 - 1
1. FUNCTIONS AND CONFIGURATION
The following item is the same as MR-J4-_B_ Servo amplifiers. For details of the item, refer to the section of
the detailed description field. "MR-J4-_B_" means "MR-J4-_B_(-RJ) Servo Amplifier Instruction Manual".
Item Detailed explanation
Removal and reinstallation of the front cover MR-J4-_B_ section 1.7.2
1.1 Summary
This instruction manual explains about CC-Link IE Field Network interface AC servo amplifier with Motion
MR-J4-_B_-RJ010 and CC-Link IE Field Network interface unit MR-J3-T10. Refer to "MR-J4-_B_(-RJ) Servo
Amplifier Instruction Manual" for the information not given in this manual.
Always use MR-J4-_B_-RJ010 with MR-J3-T10.
Connecting MR-J4-_B_-RJ010 and MR-J3-T10 to CC-Link IE Field simple motion module QD77GF_
enables you to drive a servo motor using CC-Link IE Field motion function.

1. FUNCTIONS AND CONFIGURATION
1 - 2
1.2 Function block diagram
The function block diagram of this servo is shown below.
(1) 200 V class
(a) MR-J4-500B-RJ010 or less
CC-Link IE
Field Network CC-Link IE Field Network
CN10A CN10B
MR-J3-T10
CN7
Model position
Current
control
Actual
position
control
Actual
speed
control
Virtual
motor
Virtual
encoder
L11
L21
Cooling fan
(Note 3)
Encoder
(Note 4) N-CD
L3
L2
L1
Dynamic
brake
circuit
Power factor improving
DC reactor (Note 5)
Current
detection
Overcurrent
protection
Voltage
detection
(Note 2)
Power
supply
MCMCCB
Base
amplifier
STO
circuit
CN5
USB
USB
Personal
computer
D/A
Analog monitor
(2 channels)
Position
command
input
CN3
Servo amplifier
U
V
W
U
V
W
P3 P4
Diode
stack Relay
P+
+
+B
RA
24 V DC
B1
B2
Optional battery
(for absolute position
detection system)
CN4
STO
switch
Model speed Model torque
M
CN2
CN8
Control
circuit
power
supply
Model
position
control
Model
speed
control
I/F Control
Servo motor
CHARGE
lamp
Regene-
rative
TR
Current
encoder
Digital I/O
control
Regenerative
option
UU
U
Step-
down
circuit
Electromagnetic
brake
(Note 1)
Note 1. The built-in regenerative resistor is not provided for the MR-J4-10B-RJ010.
2. For 1-phase 200 V AC to 240 V AC, connect the power supply to L1 and L3. Leave L2 open.
For power supply specifications, refer to section 1.3.1.
3. Servo amplifiers MR-J4-70B-RJ010 or more have a cooling fan.
4. MR-J4 servo amplifier has P3 and P4 in the upstream of the inrush current suppression circuit. They are different from P1 and
P2 of MR-J3 servo amplifiers.
5. The power factor improving AC reactor can also be used. In this case, the power factor improving DC reactor cannot be used.
When not using the power factor improving DC reactor, short P3 and P4.

1. FUNCTIONS AND CONFIGURATION
1 - 3
(b) MR-J4-700B-RJ010
CC-Link IE
Field Network CC-Link IE Field Network
CN10A CN10B
MR-J3-T10
CN7
L11
L21
Cooling fan
N-C
Power factor improving
DC reactor (Note 3)
(Note 1)
Power
supply
MCMCCB
STO
circuit
CN5
USB
USB
D/A
CN3
Servo amplifier
Diode
stack U
V
W
U
V
W
P3 P4
Relay
(Note 2) P+
+
+B
RA B1
B2
CN4
M
CN2
CN8
Control
circuit
power
supply
CHARGE
lamp
Regene-
rative
TR
Regenerative
option
L3
L2
L1
U U
U
Current
detection
Overcurrent
protection
Voltage
detection
Base
amplifier
STO
switch
Current
encoder
Dynamic
brake
circuit
Servo motor
Electromagnetic
brake
24 V DC
Encoder
Model position
Current
control
Actual
position
control
Actual
speed
control
Virtual
motor
Virtual
encoder
Position
command
input
Model speed Model torque
Model
position
control
Model
speed
control
Step-
down
circuit
Optional battery
(for absolute position
detection system)
I/F Control
Personal
computer Analog monitor
(2 channels) Digital I/O control
Note 1. For power supply specifications, refer to section 1.3.1.
2. MR-J4 servo amplifier has P3 and P4 in the upstream of the inrush current suppression circuit. They are different from P1 and
P2 of MR-J3 servo amplifiers.
3. The power factor improving AC reactor can also be used. In this case, the power factor improving DC reactor cannot be used.
When not using the power factor improving DC reactor, short P3 and P4.

1. FUNCTIONS AND CONFIGURATION
1 - 4
(c) MR-J4-11KB-RJ010/MR-J4-15KB-RJ010/MR-J4-22KB-RJ010
Current
detector
Thyristor
External
dynamic brake
(optional)
U
V
W
U
V
W
L3
L2
L1
U U
U
(Note 4)
Power factor
improving
DC reactor
Charge
lamp
Regene-
rative
TR
Cooling fan
L11
L21
Encoder
N-C
(Note 1)
Power
supply
MCMCCB
CN5
USB
USB
D/A
CN3
Servo amplifier
Diode
stack
P3 P4 (Note 2) P+
+
+B
RA
24 V DC
B1
B2
Optional battery
(For absolute
position detection
system)
CN4
M
CN2
CN8
Servo motor
(Note 3)
External
regenerative resistor
or
regenerative option
Electromagnetic
brake
STO
switch
Control
circuit
power
supply
Current
detection
Overcurrent
protection
Voltage
detection
Base
amplifier
STO
circuit
Step-
down
circuit
Model position
Current
control
Actual
position
control
Actual
speed
control
Virtual
motor
Virtual
encoder
Position
command
input
Model speed Model torque
Model
position
control
Model
speed
control
Personal
computer Analog monitor
(2 channels) Digital I/O control
CC-Link IE
Field Network CC-Link IE Field Network
CN10A CN10B
MR-J3-T10
CN7
I/F Control
Note 1. Refer to section 1.3.1 for the power supply specification.
2. MR-J4 servo amplifier has P3 and P4 in the upstream of the inrush current suppression circuit. They are different from P1 and
P2 of MR-J3 servo amplifiers.
3. Use an external dynamic brake for this servo amplifier. Failure to do so will cause an accident because the servo motor does
not stop immediately but coasts at an alarm occurrence for which the servo motor does not decelerate to stop. Ensure the
safety in the entire equipment. For alarms for which the servo motor does not decelerate to stop, refer to section 6.1.
4. The power factor improving AC reactor can also be used. In this case, the power factor improving DC reactor cannot be used.
When not using the power factor improving DC reactor, short P3 and P4.

1. FUNCTIONS AND CONFIGURATION
1 - 5
(2) 400 V class
(a) MR-J4-350B4-RJ010 or less
Model position
Current
control
Actual
position
control
Actual
speed
control
Virtual
motor
Virtual
encoder
L11
L21
Cooling fan
(Note 2)
Encoder
N-CD
L3
L2
L1
Dynamic
brake
circuit
Current
detection
Overcurrent
protection
Voltage
detection
(Note 1)
Power
supply
MCMCCB
Base
amplifier
STO
circuit
CN5
USB
USB
Personal
computer
D/A
Analog monitor
(2 channels)
Position
command
input
CN3
Servo amplifier
U
V
W
U
V
W
P3 P4 (Note 3)
Diode
stack Relay
P+
+
+B
RA
24 V DC
B1
B2
Optional battery
(For absolute
position detection
system)
CN4
STO
switch
Model speed Model torque
M
CN2
CN8
Control
circuit
power
supply
Model
position
control
Model
speed
control
Servo motor
Charge
lamp
Regene-
rative
TR
Current
detector
Digital I/O
control
Regenerative
option
U U
U
Step-
down
circuit
(Note 4)
Power factor
improving
DC reactor
Electromagnetic
brake
CC-Link IE
Field Network CC-Link IE Field Network
CN10A CN10B
MR-J3-T10
CN7
I/F Control
Note 1. Refer to section 1.3.1 for the power supply specification.
2. Servo amplifiers MR-J4-200B4(-RJ) or more have a cooling fan.
3. MR-J4 servo amplifier has P3 and P4 in the upstream of the inrush current suppression circuit. They are different from P1 and
P2 of MR-J3 servo amplifiers.
4. The power factor improving AC reactor can also be used. In this case, the power factor improving DC reactor cannot be used.
When not using the power factor improving DC reactor, short P3 and P4.

1. FUNCTIONS AND CONFIGURATION
1 - 6
(b) MR-J4-500B4-RJ010/MR-J4-700B4-RJ010
Dynamic
brake
circuit
Current
detector
Virtual
motor
Virtual
encoder
L11
L21
Cooling fan
Encoder
N-C
Current
detection
Overcurrent
protection
Voltage
detection
(Note 1)
Power
supply
MCMCCB
Base
amplifier
STO
circuit
CN5
USB
USB
D/A
Position
command
input
CN3
Servo amplifier
Diode
stack U
V
W
U
V
W
P3 P4 (Note 2)
Relay
P+
+
+B
RA
24 V DC
B1
B2
Optional battery
(For absolute
position detection
system)
CN4
STO
switch
M
CN2
CN8
Control
circuit
power
supply
Model
position
control
Model
speed
control
Servo motor
Regenerative
option
L3
L2
L1
U U
U
Step-
down
circuit
(Note 3)
Power factor
improving
DC reactor
Charge
lamp
Regene-
rative
TR
Electromagnetic
brake
Model position Model speed Model torque
Current
control
Actual
position
control
Actual
speed
control
Personal
computer Analog monitor
(2 channels) Digital I/O control
CC-Link IE
Field Network CC-Link IE Field Network
CN10A CN10B
MR-J3-T10
CN7
I/F Control
Note 1. Refer to section 1.3.1 for the power supply specification.
2. MR-J4 servo amplifier has P3 and P4 in the upstream of the inrush current suppression circuit. They are different from P1 and
P2 of MR-J3 servo amplifiers.
3. The power factor improving AC reactor can also be used. In this case, the power factor improving DC reactor cannot be used.
When not using the power factor improving DC reactor, short P3 and P4.

1. FUNCTIONS AND CONFIGURATION
1 - 7
(c) MR-J4-11KB4-RJ010/MR-J4-15KB4-RJ010/MR-J4-22KB4-RJ010
Current
detector
Thyristor
External
dynamic brake
(optional)
U
V
W
U
V
W
L3
L2
L1
U U
U
(Note 4)
Power factor
improving
DC reactor
Charge
lamp
Regene-
rative
TR
Cooling fan
L11
L21
Encoder
N-C
(Note 1)
Power
supply
MCMCCB
CN5
USB
USB
D/A
CN3
Servo amplifier
Diode
stack
P3 P4 (Note 2) P+
+
+B
RA
24 V DC
B1
B2
Optional battery
(For absolute
position detection
system)
CN4
M
CN2
CN8
Servo motor
(Note 3)
External
regenerative resistor
or
regenerative option
Electromagnetic
brake
STO
switch
Control
circuit
power
supply
Current
detection
Overcurrent
protection
Voltage
detection
Base
amplifier
STO
circuit
Step-
down
circuit
Model position
Current
control
Actual
position
control
Actual
speed
control
Virtual
motor
Virtual
encoder
Position
command
input
Model speed Model torque
Model
position
control
Model
speed
control
Personal
computer Analog monitor
(2 channels) Digital I/O control
CC-Link IE
Field Network CC-Link IE Field Network
CN10A CN10B
MR-J3-T10
CN7
I/F Control
Note 1. Refer to section 1.3.1 for the power supply specification.
2. MR-J4 servo amplifier has P3 and P4 in the upstream of the inrush current suppression circuit. They are different from P1 and
P2 of MR-J3 servo amplifiers.
3. Use an external dynamic brake for this servo amplifier. Failure to do so will cause an accident because the servo motor does
not stop immediately but coasts at an alarm occurrence for which the servo motor does not decelerate to stop. Ensure the
safety in the entire equipment. For alarms for which the servo motor does not decelerate to stop, refer to section 6.1.
4. The power factor improving AC reactor can also be used. In this case, the power factor improving DC reactor cannot be used.
When not using the power factor improving DC reactor, short P3 and P4.

1. FUNCTIONS AND CONFIGURATION
1 - 8
1.3 Standard specifications
1.3.1 Servo amplifier
Model: MR-J4-_-RJ010 10B 20B 40B 60B 70B 100B 200B 350B 500B 700B 11KB 15KB 22KB
Rated voltage 3-phase 170 V AC
Output Rated current [A] 1.1 1.5 2.8 3.2 5.8 6.0 11.0 17.0 28.0 37.0 68.0 87.0 126.0
Voltage/Frequency 3-phase or 1-phase
200 V AC to 240 V AC, 50 Hz/60 Hz 3-phase 200 V AC to 240 V AC, 50 Hz/60 Hz
Rated current [A] 0.9 1.5 2.6
3.2
(Note
5)
3.8 5.0 10.5 16.0 21.7 28.9 46.0 64.0 95.0
Permissible voltage
fluctuation
3-phase or 1-phase
170 V AC to 264 V AC 3-phase 170 V AC to 264 V AC
Permissible frequency
fluctuation Within ±5%
Power supply
capacity [kVA] MR-J4-_B_(-RJ) Servo Amplifier Instruction Manual section 10.2
Main circuit
power supply
input
Inrush current [A] MR-J4-_B_(-RJ) Servo Amplifier Instruction Manual section 10.5
Voltage/Frequency 1-phase 200 V AC to 240 V AC, 50 Hz/60 Hz
Rated current [A] 0.2 0.3
Permissible voltage
fluctuation 1-phase 170 V AC to 264 V AC
Permissible frequency
fluctuation Within ±5%
Power
consumption [W] 30 45
Control circuit
power supply
input
Inrush current [A] MR-J4-_B_(-RJ) Servo Amplifier Instruction Manual section 10.5
Voltage 24 V DC ± 10%
Interface power
supply Current capacity [A] (Note 1) 0.3 (including CN8 connector signals)
Control method Sine-wave PWM control, current control method
Dynamic brake Built-in External option (Note 6)
Communication function USB: connection to a personal computer or others (MR Configurator2-compatible)
Encoder output pulses Compatible (A/B/Z-phase pulse)
Analog monitor 2 channels
Protective functions
Overcurrent shut-off, regenerative overvoltage shut-off, overload shut-off (electronic thermal), servo motor
overheat protection, encoder error protection, regenerative error protection, undervoltage, instantaneous
power failure protection, overspeed protection, and error excessive protection
Safety function STO (IEC/EN 61800-5-2)
Standards certified by CB EN ISO 13849-1 category 3 PL d, IEC 61508 SIL 2, EN 62061 SIL CL 2, and EN 61800-5-2 SIL 2
Response performance 8 ms or less (STO input off →energy shut off)
Safety
performance (Note 3)
Test pulse input (STO)
Test pulse interval: 1 Hz to 25 Hz
Test pulse off time: Up to 1 ms
CE marking
LVD: EN 61800-5-1
EMC: EN 61800-3
MD: EN ISO 13849-1, EN 61800-5-2, EN 62061
Compliance to
standards
UL standard UL 508C
Structure (IP rating) Natural cooling, open (IP20) Force cooling, open (IP20) Force cooling, open
(IP20) (Note 4)
Close mounting (Note 2) Possible Impossible
Operation 0 °C to 55 °C (non-freezing)
Ambient
temperature Storage -20 °C to 65 °C (non-freezing)
Operation
Ambient
humidity Storage 90 %RH or less (non-condensing)
Ambience Indoors (no direct sunlight), free from corrosive gas, flammable gas, oil mist, dust, and dirt
Altitude 1000 m or less above sea level
Environment
Vibration resistance 5.9 m/s2, at 10 Hz to 55 Hz (directions of X, Y and Z axes)
Mass [kg] 0.8 1.0 1.4 2.1 2.3 4.0 6.2 13.4 18.2
Note 1. 0.3 A is the value applicable when all I/O signals are used. The current capacity can be decreased by reducing the number of
I/O points.
2. When closely mounting the servo amplifier of 3.5 kW or less, operate them at the ambient temperatures of 0 °C to 45 °C or at
75% or smaller effective load ratio.
3. Test pulse is a signal which instantaneously turns off a signal to the servo amplifier at a constant period for external circuit to
self-diagnose.
4. Except for the terminal block.
5. The rated current is 2.9 A when the servo amplifier is used with UL or CSA compliant servo motor.
6. Use an external dynamic brake for this servo amplifier. Failure to do so will cause an accident because the servo motor does
not stop immediately but coasts at emergency stop. Ensure the safety in the entire equipment.

1. FUNCTIONS AND CONFIGURATION
1 - 9
Model: MR-J4- 60B4 100B4 200B4 350B4 500B4 700B4 11KB4 15KB4 22KB4
Rated voltage 3-phase 323 V AC
Output Rated current [A] 1.5 2.8 5.4 8.6 14.0 17.0 32.0 41.0 63.0
Voltage/Frequency 3-phase 380 V AC to 480 V AC, 50 Hz/60 Hz
Rated current [A] 1.4 2.5 5.1 7.9 10.8 14.4 23.1 31.8 47.6
Permissible voltage
fluctuation 3-phase 323 V AC to 528 V AC
Permissible frequency
fluctuation Within ±5%
Power supply
capacity [kVA] MR-J4-_B_(-RJ) Servo Amplifier Instruction Manual section 10.2
Main circuit
power supply
input
Inrush current [A] MR-J4-_B_(-RJ) Servo Amplifier Instruction Manual section 10.5
Voltage/Frequency 1-phase 380 V AC to 480 V AC, 50 Hz/60 Hz
Rated current [A] 0.1 0.2
Permissible voltage
fluctuation 1-phase 323 V AC to 528 V AC
Control circuit
power supply
input Permissible frequency
fluctuation Within ±5%
Power consumption [W] 30 45
Inrush current [A] MR-J4-_B_(-RJ) Servo Amplifier Instruction Manual section 10.5
Voltage 24 V DC ± 10%
Interface power
supply Current capacity [A] (Note 1) 0.3 (including CN8 connector signals)
Control method Sine-wave PWM control, current control method
Dynamic brake Built-in External option (Note 4)
Communication function USB: connection to a personal computer or others (MR Configurator2-compatible)
Encoder output pulses Compatible (A/B/Z-phase pulse)
Analog monitor Two channels
Protective functions
Overcurrent shut-off, regenerative overvoltage shut-off, overload shut-off (electronic thermal), servo
motor overheat protection, encoder error protection, regenerative error protection, undervoltage
protection, instantaneous power failure protection, overspeed protection, error excessive protection
Functional safety STO (IEC/EN 61800-5-2)
Standards certified by CB EN ISO 13849-1 category 3 PL d, IEC 61508 SIL 2, EN 62061 SIL CL 2, and
EN 61800-5-2 SIL 2
Response performance 8 ms or less (STO input off →energy shut off)
(Note 2)
Test pulse input (STO) Test pulse interval: 1 Hz to 25 Hz
Test pulse off time: Up to 1 ms
Mean time to dangerous
failure (MTTFd) 100 years or longer
Safety
performance
Diagnosis converge (DC) Medium (90% to 99%)
Average probability of
dangerous failures per hour
(PFH)
1.68 × 10-10 [1/h]
CE marking
LVD: EN 61800-5-1
EMC: EN 61800-3
MD: EN ISO 13849-1, EN 61800-5-2, EN 62061
Compliance to
standards
UL standard UL 508C
Structure (IP rating) Natural cooling, open
(IP20)
Force cooling, open
(IP20) Force cooling, open (IP20) (Note 3)
Close mounting Impossible
Operation 0 ˚C to 55 ˚C (non-freezing)
Ambient
temperature Storage -20 ˚C to 65 ˚C (non-freezing)
Operation
Ambient
humidity Storage 90 %RH or less (non-condensing)
Ambience Indoors (no direct sunlight),
free from corrosive gas, flammable gas, oil mist, dust, and dirt
Altitude 1000 m or less above sea level
Environment
Vibration resistance 5.9 m/s2, at 10 Hz to 55 Hz (directions of X, Y and Z axes)
Mass [kg] 1.7 2.1 3.6 4.3 6.5 13.4 18.2
Note 1. 0.3 A is the value applicable when all I/O signals are used. The current capacity can be decreased by reducing the number of
I/O points.
2. Test pulse is a signal which instantaneously turns off a signal to the servo amplifier at a constant period for external circuit to
self-diagnose.
3. Except for the terminal block.
4. Use an external dynamic brake for this servo amplifier. Failure to do so will cause an accident because the servo motor does
not stop immediately but coasts at emergency stop. Ensure the safety in the entire equipment.
