Mitsubishi Heavy Industries SCM60ZF-S User manual

Manual No. '06 • SCM-T-052
INVERTER MULTI-SPLIT SYSTEM
ROOM AIR-CONDITIONER
(Air to air heat pump type)

CONTENTS
1GENERAL INFORMATION ............................................................................... 1
1.1 Specific features ........................................................................................ 1
1.2 How to read the model name .................................................................... 1
2SELECTION DATA ............................................................................................ 2
2.1 Specifications ............................................................................................. 2
2.2 Range of usage & limitations .................................................................. 25
2.3 Exterior dimensions................................................................................. 26
2.4 Piping system ........................................................................................... 29
2.5 Selection chart ......................................................................................... 34
3ELECTRICAL DATA ........................................................................................ 36
3.1 Electrical wiring........................................................................................ 36
4OUTLINE OF OPERATION CONTROL BY MICROCOMPUTER................... 43
5APPLICATION DATA ...................................................................................... 66
5.1 Installation of indoor unit ........................................................................ 67
5.2 Installation of remote control.................................................................. 76
5.3 Installation of outdoor unit...................................................................... 77
5.4 Electrical wiring........................................................................................ 78
5.5 Refrigerant piping .................................................................................... 79
5.6 Test run and handling instruction .......................................................... 81
5.7 Installation of remote control and super link adapter (SC-AD-E)
(Optional parts) ........................................................................................ 82
5.8 Installation of optional parts (Ducted type) ........................................... 89
6MAINTENANCE DATA .................................................................................... 94
6.1 Trouble shooting ...................................................................................... 94
6.2 Servicing ................................................................................................. 108
7REFRIGERANT PIPING INSTALLATION/SERVICING MANUAL
FOR AIR CONDITIONERS USING R410A ................................................... 109
7.1 Outline ..................................................................................................... 109
7.2 Refrigerant piping installation .............................................................. 110
7.3 Installation, removal and servicing ...................................................... 116
7.4 Refrigerant recovery .............................................................................. 121

-
1
-
1GENERAL INFORMATION
1.1 Specific features
(1) The long piping makes the location of the inside and units flexible.
¡No need for additional charge of refrigerant : 40 type · 30m, 45 type · 20m, 48 type · 40m, 60 type · 30m, 80 type · 40m
¡Maximum piping length : 40 type · 30m, 45 type · 30m, 48 type · 40m, 60 type · 40m, 80 type · 70m
(2) Connectable indoor capacity
Number of connectable units : 40 type · 2 units, 45 type · 2 units, 48 type · 3 units, 60 type · 3 units, 80 type · 4 units
Total of indoor units (class kW) : 40 type · 5.6 kW, 45 type · 7.0 kW, 48 type · 8.5 kW, 60 type · 11.0 kW, 80 type · 13.5 kW
(3) Indoor units are available with 7 capacities.
7 capacities ................ 20, 22, 25, 28, 35, 50, 60
Types ......................... Wall mounted type (SKM).
4-way ceiling cassette type (STM).
Ducted type (SRRM).
(4) Inverter (Frequency converter) for multi-steps power control
¡Heating / Cooling
The rotational speed of a compressor is changed in step in relation to varying load, to interlock with the indoor and outdoor unit
fans controlled to changes in frequency, thus controlling the power.
¡Allowing quick heating/cooling operation during start-up period. Constant room temperature by fine-tuned control after the
unit has stabilized.
(5) Fuzzy control
Fuzzy control calculates the amount of variation in the difference between the suction air temperature and the setting temperature
in compliance with the fuzzy rules in order to control the air capacity and the inverter frequency.
(6) Self diagnosis function
We are constantly trying to do better service to our customers by installing such judges that show abnormality of operation as
follows. (See page 95)
1.2 How to read the model name
Example : ST M 25 Z F - S
R410A models
Series No.
Inverter and Heat pump type
Product capacity
Multiple system
Model name SK : Wall mounted type
ST : 4 way ceiling cassette type
SRR : Ducted type
SC : Outdoor unit

-
2
-
2SELECTION DATA
2.1 Specifications
(1) Indoor unit
Models SKM20ZF-S, 22ZF-S, 25ZF-S
Item
Models
SKM20ZF-S SKM22ZF-S SKM25ZF-S
Cooling capacity W 2000 2200 2500
Heating capacity W 3000 3200 3400
Noise level
Cooling
Hi : 37 Me : 30 Lo : 23
dB
Hi : 53
Heating
Hi : 39 Me : 33 Lo : 27
Hi : 55
Exterior dimensions
Height ×Width ×Depth mm 250 ×815 ×249
Color Cool white
Net weight kg 9.0
Air handling equipment
Fan type & Q’ty Tangential fan ×1
Motor W 16
Cooling 8.0
Air flow (at high)
Heating
CMM
8.7
Air filter, Q’ty Polypropylene net × 2 (Washable)
Operation switch Wireless-Remote control
Room temperature control Microcomputer thermostat
Pilot lamp RUN (Green), TIMER (Yellow), HI POWER (Green), ECONO (Orange)
Safety equipment
O.D mm (in)
φ 6.35 (1/4″)
φ 9.52 (3/8″)
Connecting method Flare connecting
Attached length of piping Liquid line : 0.4m Gas line : 0.33m
Insulation Necessary (Both Liquid & Gas lines)
Drain hose Connectable
Accessories (including) Mounting kit, Clean filter (Natural enzyme filter ×1, Photocatalytic washable deodorizing filter ×1)
Optional parts —
Outdoor unit to be combined SCM40, 45, 48, 60, 80ZF-S
(2) Capacity indicated is the rated capacity with one unit operating under ISO-T1 standards conditions.
Refrigerant
piping
Liquid line
Gas line
Frost protection, Serial error protection
Fan motor error protection
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27°C19°C35°C24°CISO-T1, JIS C9612
Heating 20°C– 7°C6°CISO-T1, JIS C9612
Sound level
Power level
Sound level
Power level

-
3
-
Item
Model
SKM28ZF-S SKM35ZF-S SKM50ZF-S
Cooling capacity W 2800 3500 5000
Heating capacity W 4000 4500 5800
Noise level
Cooling
Sound level
dB
Hi : 38 Me : 31 Lo : 24 Hi : 39 Me : 32 Lo : 25 Hi : 47 Me : 36 Lo : 23
Power level Hi : 54 Hi : 55 Hi : 62
Noise level
Heating
Sound level Hi : 40 Me : 34 Lo : 28 Hi : 41 Me : 35 Lo : 29 Hi : 48 Me : 37 Lo : 27
Power level Hi : 56 Hi : 57 Hi : 63
Exterior dimensions
Height ×Width ×Depth mm 250 ×815 ×249
Color Cool white
Net weight kg 9.0 9.5
Air handling equipment
Fan type & Q’ty Tangential fan ×1
Motor W 16 29
Cooling 8.2 8.4 11
Air flow (at high)
Heating
CMM
9.0 9.2 13.9
Air filter, Q’ty Polypropylene net ×2 (Washable)
Operation switch Wireless-Remote control
Room temperature control Microcomputer thermostat
Pilot lamp RUN (Green), TIMER (Yellow), HI POWER (Green), ECONO (Orange)
Safety equipment
O.D mm (in)
φ 6.35 (1/4″)
φ 9.52 (3/8″)φ 12.7 (1/2″)
Connecting method Flare connecting
Attached length of piping Liquid line : 0.4m Gas line : 0.33m
Insulation Necessary (Both Liquid & Gas lines)
Drain hose Connectable
Accessories (including) Mounting kit, Clean filter (Natural enzyme filter ×1, Photocatalytic washable deodorizing filter ×1)
Optional parts —
Outdoor unit to be combined SCM40, 45, 48, 60, 80ZF-S SCM45, 48, 60, 80ZF-S SCM60, 80ZF-S
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27°C19°C35°C24°CISO-T1, JIS C9612
Heating 20°C– 7°C6°CISO-T1, JIS C9612
(2) Capacity indicated is the rated capacity with one unit operating under ISO-T1 standards conditions.
Refrigerant
piping
Liquid line
Gas line
Frost protection, Serial error protection
Fan moter error protection
Notes (1) The data are measured at the following conditions.
Models SKM28ZF-S, 35ZF-S, 50ZF-S,

-
4
-
Item
Models
STM25ZF-S STM35ZF-S STM50ZF-S STM60ZF-S
Cooling capacity W 2500 3500 5000 6000
Heating capacity W 3400 4500 5800 6800
Noise level
Cooling
35 38 40 47
dB
51 54 56 63
Heating
35 38 40 47
51 54 56 63
Exterior dimensions Main unit 248 ×570 ×570
Height ×Width ×Depth Panel
mm
35 ×700 ×700
Color –
Net weight
Main unit
kg
14 14.5
Panel 3.5
Air handling equipment
Fan type & Q’ty Turbo fan ×1
Motor W 40
Cooling 8.0 9.0 10.0 13.0
Air flow (at high)
Heating
CMM
9.0 10.0 11.0 14.0
Air filter, Q’ty Long life filter ×1 (Washable)
Operation switch Wireless-Remote control
Room temperature control Microcomputer thermostat
Pilot lamp RUN (Green), TIMER (Yellow), HI POWER (Green), ECONO (Orange)
Safety equipment
O.D mm (in)
φ 6.35 (1/4″)
φ 9.52 (3/8″)φ 12.7 (1/2″)
Connecting method Flare connecting
Attached length of piping —
Insulation Necessary (Both Liquid & Gas lines)
Drain hose Connectable
Accessories (including) Mounting kit
Optional parts Wired remote control
Outdoor unit to be combined SCM40, 45, 48, 60, 80ZF-S SCM45, 48, 60, 80ZF-S SCM60, 80ZF-S
Models STM25ZF-S, 35ZF-S, 50ZF-S, 60ZF-S
(2) Capacity indicated is the rated capacity with one unit operating under ISO-T1 standards conditions.
Refrigerant
piping
Liquid line
Gas line
Frost protection, Serial error protection
Fan motor error protection, Drain error protection
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27°C19°C35°C24°CISO-T1, JIS C9612
Heating 20°C– 7°C6°CISO-T1, JIS C9612
Sound level
Power level
Sound level
Power level

-
5
-
Models SRRM25ZF-S, 35ZF-S, 50ZF-S, 60ZF-S
Item
Models
SRRM25ZF-S SRRM35ZF-S SRRM50ZF-S SRRM60ZF-S
Cooling capacity W 2500 3500 5000 6000
Heating capacity W 3400 4500 5800 6800
Noise level
Cooling
38 40 46 49
dB
53 55 60 63
Heating
39 41 46 49
54 56 60 63
Exterior dimensions
Height ×Width ×Depth mm 230 ×740 ×455
Color —
Net weight kg 22.0 23.0
Air handling equipment
Fan type & Q’ty Centrifugal fan ×2
Motor W 51
Cooling 8.5 9.0 10.5 12.5
Air flow (at high)
Heating
CMM
10.0 11.0 13.0 15.0
Air filter, Q’ty Polypropylene net × 1
Operation switch Wireless-Remote control
Room temperature control Microcomputer thermostat
Pilot lamp RUN (Green), TIMER (Yellow), HI POWER (Green), ECONO (Orange)
Safety equipment
O.D mm (in)
φ 6.35 (1/4″)
φ 9.52 (3/8″)φ 12.7 (1/2″)
Connecting method Flare connecting
Attached length of piping –
Insulation Necessary (Both Liquid & Gas lines)
Drain hose Connectable
Accessories (including) Mounting kit
Optional parts Wired remote control
Outdoor unit to be combined SCM40, 45, 48, 60, 80ZF-S SCM45, 48, 60, 80ZF-S SCM60, 80ZF-S
(2) Capacity indicated is the rated capacity with one unit operating under ISO-T1 standards conditions.
Refrigerant
piping
Liquid line
Gas line
Frost protection, Serial error protection
Fan motor error protection, Drain error protection
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27°C19°C35°C24°CISO-T1, JIS C9612
Heating 20°C– 7°C6°CISO-T1, JIS C9612
Sound level
Power level
Sound level
Power level

-
6
-
Item
Models
SCM40ZF-S SCM45ZF-S
Cooling capacity W 4000 (1900 ~ 4900) 4500 (700 ~ 5600)
Heating capacity W 5000 (1300 ~ 5200) 5600 (700 ~ 6800)
Power source 1 Phase 220/230/240V 50Hz
Power consumption
Cooling
W
970 (470 ~ 1470) 1390 (200 ~ 2160)
Heating 1150 (450 ~ 1260) 1540 (200 ~ 2340)
Running current
Cooling 4.5/4.3/4.1 6.4/6.1/5.9
Heating
A
5.3/5.1/4.8 7.1/6.8/6.5
Sound level Cooling : 45 Heating : 47 Cooling : 45 Heating : 47
Noise level
Power level
dB
Cooling : 60 Heating : 62 Cooling : 60 Heating : 62
Exterior dimensions
Height ×Width ×Depth mm 640 ×850 ×290
Color Stucco white
Net weight kg 43 44
Refrigerant equipment
Compressor type & Q’ty [Rotary] ×1 [Scroll] ×1
Motor kW 0.7 0.7
Starting method Direct start
Refrigerant control Capillary tubes +Electric expansion valve
Refrigerant kg R410A 1.4 (Pre-charged up to the piping length of 30m) R410A 1.6 (Pre-charged up to the piping length of 20m)
Refrigerant oil R0.32 (RB68A) 0.48 (RB68A)
Air handling equipment
Fan type & Q’ty Propeller fan ×1
Motor W 34
Air flow (at high) CMM 40
Shock & vibration absorber Rubber (for compressor)
Safety equipment
Size ×Core ×Number mm (in)
Liquid line: φ6.35 (1/4″) ×2
Gas line: φ 9.52 (3/8″) ×2
Connecting method Flare connecting
Attached length piping —
Insulation Necessary (Both Liquid & Gas lines)
Power source supply Terminal block (Screw fixing type)
Size ×Core number 1.5 mm2×4 cores (Including earth cable) ×2
Connecting method Terminal block (Screw fixing type)
Accessories (included) Installation sheet, Manual instruction
SKM20, 22, 25, 28 type, SKM20, 22, 25, 28, 35 type,
Indoor units to be combined STM25 type, STM25, 35 type,
SRRM25 type SRRM25, 35 type
(2) Outdoor unit
Models SCM40ZF-S, 45ZF-S
Compressor overheat protection, Overcurrent protection
Serial signal error protection
Notes (1) The data are measured at the following conditions.
Refrigerant
piping
Connec-
tion wiring
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27°C19°C35°C24°CISO-T1, JIS C9612
Heating 20°C– 7°C6°CISO-T1, JIS C9612
(2) The values for capacity and power consumption shown in a range ( ) indicate the minimum and maximum of the range.
(3) The refrigerant quantity to be charged includes the refrigerant in 30 m connecting piping. (SCM40ZF-S)
(4) If the piping length exceeds 20 m, additional charging is required. (20g/m, SCM45ZF-S)

-
7
-
Models SCM48ZF-S, 60ZF-S
Item
Models
SCM48ZF-S SCM60ZF-S
Cooling capacity W 4800 (1100~6700) 6000 (1400~6900)
Heating capacity W 6000 (780~7100) 7000 (750~7200)
Power source 1 Phase 220/230/240V 50Hz
Power consumption
Cooling
W
1190 (200~2340) 1860 (400~3000)
Heating 1380 (200~2180) 1740 (320~2700)
Running current
Cooling 5.2/5.2/5.0 8.5/8.2/7.8
Heating
A
6.3/6.1/5.8 8.0/7.6/7.3
Sound level Cooling : 48 Heating : 49 Cooling : 48 Heating : 50
Noise level
Power level
dB
Cooling : 63 Heating : 64 Cooling : 63 Heating : 65
Exterior dimensions
Height ×Width ×Depth mm 640 ×850 ×290
Color Stucco white
Net weight kg 46 51
Refrigerant equipment
Compressor type & Q’ty [Scroll] ×1 [Twin rotary] ×1
Motor kW 0.7 1.3
Starting method Direct start
Refrigerant control Capillary tubes +Electronic expansion valve
Refrigerant kg R410A 1.95 (Pre-charged up to the piping length of 40m) R410A 2.2 (Pre-charged up to the piping length of 30m)
Refrigerant oil R0.48 (RB68A) 0.67 (MEL56)
Air handling equipment
Fan type & Q’ty Propeller fan ×1
Motor W 34
Air flow (at high) CMM 42
Shock & vibration absorber Rubber (for compressor)
Safety equipment
Size ×Core ×Number mm (in)
Liquid line: φ6.35 (1/4″) ×3
Gas line: φ 9.52 (3/8″) ×3
Connecting method Flare connecting
Attached length piping —
Insulation Necessary (Both Liquid & Gas lines)
Power source supply Terminal block (Screw fixing type)
Size ×Core number 1.5 mm2×4 cores (Including earth cable) ×3
Connecting method Terminal block (Screw fixing type)
Accessories (included) Union : (φ9.52 /φ12.7) ×2
Installation sheet, Manual instruction Installation sheet, Manual instruction
SKM20, 22, 25, 28, 35 type SKM20, 22, 25, 28, 35, 50 type
Indoor units to be combined STM25, 35 type STM25, 35, 50, 60 type
SRRM25, 35 type SRRM25, 35, 50, 60 type
Compressor overheat protection, Overcurrent protection
Serial signal error protection
Notes (1) The data are measured at the following conditions.
Refrigerant
piping
Connection
wiring
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27°C19°C35°C24°CISO-T1, JIS C9612
Heating 20°C– 7°C6°CISO-T1, JIS C9612
(2) The values for capacity and power consumption shown in a range ( ) indicate the minimum and maximum of the range.
(3) If the piping length exceeds 30 m, additional charging is required. (20g/m, SCM60ZF-S)

-
8
-
Item
Model
SCM80ZF-S
Cooling capacity W 8000 (1000~9300)
Heating capacity W 9300 (950~9500)
Power source 1 Phase 220/230/240V 50Hz
Power consumption
Cooling
W
2380 (280~3200)
Heating 2430 (250~3500)
Running current
Cooling 10.9/10.5/10.0
Heating
A
11.2/10.7/10.2
Sound level Cooling : 51 Heating : 52
Noise level
Power level
dB
Cooling : 65 Heating : 66
Exterior dimensions
Height ×Width ×Depth mm 750 ×880 ×340
Color Stucco white
Net weight kg 66
Refrigerant equipment
Compressor type & Q’ty [Twin rotary] ×1
Motor kW 1.3
Starting method Direct start
Refrigerant control Capillary tubes +Electronic expansion valve
Refrigerant kg R410A 3.15 (Pre-charged up to the piping length of 40m)
Refrigerant oil R0.67 (MEL56)
Air handling equipment
Fan type & Q’ty Propeller fan ×1
Motor W 86
Air flow (at high) CMM 55
Shock & vibration absorber Rubber (for compressor)
Safety equipment
Size ×Core ×Number mm (in)
Liquid line: φ6.35 (1/4″) ×4
Gas line: φ 9.52 (3/8″) ×4
Connecting method Flare connecting
Attached length piping —
Insulation Necessary (Both Liquid & Gas lines)
Power source supply Terminal block (Screw fixing type)
Size ×Core number 1.5 mm2×4 cores (Including earth cable) ×4
Connecting method Terminal block (Screw fixing type)
Accessories (included) Union : (φ9.52 /φ12.7) ×2
Installation sheet, Manual instruction
SKM20, 22, 25, 28, 35, 50 type
Indoor unit to be combined STM25, 35, 50, 60 type
SRRM25, 35, 50, 60 type
Compressor overheat protection, Overcurrent protection
Serial signal error protection
Refrigerant
piping
Connection
wiring
Model SCM80ZF-S
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27°C19°C35°C24°CISO-T1, JIS C9612
Heating 20°C– 7°C6°CISO-T1, JIS C9612
(2) The values for capacity and power consumption shown in a range ( ) indicate the minimum and maximum of the range.
(3) If the piping length exceeds 40 m, additional charging is required. (20g/m)
