Mitsubishi ST200 Series Installation instructions

ST200TSM02
ST200 Series
(ST211, ST221M & ST251)
Satellite Communication Systems
Technical Support Manual
Mitsubishi Electronics America, Inc.
Mitsubishi Electronics America, Inc. All rights reserved.
Specifications and information within this document are subject to change without prior notice.

MITSUBISHI ELECTRONICS AMERICA, INC.
ST200 Series Technical Support Manual January 2000
ii
1.0 Introduction ............................................................................................................................................................1
2.0 System Overview....................................................................................................................................................1
2.1 Satellite Segment................................................................................................................................................1
2.2 Communications Ground Segment.....................................................................................................................2
2.3 Mobile Terminal Segment..................................................................................................................................3
3.0 Product Overview....................................................................................................................................................3
3.1 General Overview...............................................................................................................................................3
3.2 Key Features.......................................................................................................................................................5
3.3 Product Positioning.............................................................................................................................................5
3.3.1 Target Markets.............................................................................................................................................5
3.3.2 Applications.................................................................................................................................................6
4.0 Product Description.................................................................................................................................................7
4.1 General ...............................................................................................................................................................7
4.2 Antenna Units.....................................................................................................................................................9
4.2.1 Dome Antenna Unit.....................................................................................................................................9
4.2.2 Fixed Site Antenna Unit ..............................................................................................................................9
4.3 Common Transceiver Unit..................................................................................................................................9
4.4 CTU Cradle and Junction Box..........................................................................................................................10
4.5 Beam Steering Unit...........................................................................................................................................11
4.6 CTU Power Components..................................................................................................................................11
4.7 OmniQuest® Description .................................................................................................................................11
4.8 Basic Handset ...................................................................................................................................................15
4.9 Push-to-Talk Handset .......................................................................................................................................16
4.10 Other Accessories........................................................................................................................................17
5.0 Product Operation.................................................................................................................................................17
5.1 Design Overview..............................................................................................................................................17
5.2 Signaling and Communications Channels ........................................................................................................18
5.2.1 Pilot Signal ................................................................................................................................................18
5.2.2 GC-S Channel............................................................................................................................................18
5.2.3 MET-ST Channel.......................................................................................................................................19
5.2.4 MET-SR Channel ......................................................................................................................................19
5.2.5 MET-C Channel.........................................................................................................................................19
5.2.6 FES-C Channel..........................................................................................................................................19
5.3 Modulation & Encoding ...................................................................................................................................20
5.4 Signal Processing..............................................................................................................................................20
5.4.1 Scrambling.................................................................................................................................................20
5.4.2 Interleaving................................................................................................................................................21
5.4.3 Forward Error Correction..........................................................................................................................21
5.5 Security Functions............................................................................................................................................21
5.5.1 Electronic Features ....................................................................................................................................21
5.5.2 Authentication............................................................................................................................................22
5.5.3 Scrambling.................................................................................................................................................22
5.6 Network Data Distribution & Storage ..............................................................................................................22
5.7 Shutdown Conditions........................................................................................................................................22
5.8 Operation..........................................................................................................................................................23
5.8.1 Initialization...............................................................................................................................................23
5.8.2 OmniQuest® Setup..............................................................................................................................24
5.8.3 Placing a Telephone Call...........................................................................................................................24
5.8.4 Receiving a Telephone Call.......................................................................................................................24
5.8.5 Data Communication.................................................................................................................................24
5.8.6 Net Radio/Dispatch Operation...................................................................................................................26
5.9 Possible Cable Extensions................................................................................................................................26
5.10 Multiple Handsets...........................................................................................................................................27
5.11 Other Operational Considerations...................................................................................................................27
6.0 Installation............................................................................................................................................................29
6.1 Fixed Site (ST221M)........................................................................................................................................30
6.1.1 Occupant and Site Safety...........................................................................................................................30
6.1.2 General Installation Standards...................................................................................................................31

MITSUBISHI ELECTRONICS AMERICA, INC.
ST200 Series Technical Support Manual January 2000
iii
6.1.3 Installation Planning..................................................................................................................................32
6.1.4 Antenna Unit..............................................................................................................................................34
6.1.5 Transceiver ................................................................................................................................................35
6.1.6 Power Connection......................................................................................................................................37
6.1.7 Cable Runs.................................................................................................................................................38
6.1.8 Junction Box..............................................................................................................................................39
6.1.9 Handsets and Accessories..........................................................................................................................40
6.2 Land Mobile (ST211).......................................................................................................................................42
6.2.1 Occupant and Vehicle Safety.....................................................................................................................42
6.2.2 General Installation Standards...................................................................................................................44
6.2.3 Installation Planning..................................................................................................................................45
6.2.4 Dome Antenna Unit...................................................................................................................................49
6.2.5 Transceiver ................................................................................................................................................50
6.2.6 Power Connection......................................................................................................................................54
6.2.7 Junction Box..............................................................................................................................................55
6.2.8 Handsets and Accessories..........................................................................................................................55
6.2.9 Beam Steering Unit....................................................................................................................................56
6.2.10 Horn Alert................................................................................................................................................57
7.0 Programming & Commissioning..........................................................................................................................58
7.1 General Process and Procedures.......................................................................................................................58
7.2 Initialization......................................................................................................................................................59
7.3 Number Assignment Module (NAM) Programming........................................................................................60
7.4 Manual Pilot/GC-S Selection............................................................................................................................63
7.5 Commissioning.................................................................................................................................................65
7.6 Commissioning Problems.................................................................................................................................66
7.7 Other Procedures ..............................................................................................................................................67
7.7.1 Reactivation...............................................................................................................................................67
7.7.2 Re-commissioning.....................................................................................................................................68
8.0 Product Support....................................................................................................................................................69
8.1 Product Distribution..........................................................................................................................................69
8.2 Marketing & Sales Support...............................................................................................................................69
8.3 Technical Support.............................................................................................................................................69
8.4 Limited Warranty..............................................................................................................................................70
8.4.1 Limited Warranty Terms ...........................................................................................................................70
8.4.2 Mitsubishi Limited Warranty Statement....................................................................................................72
8.4.3 Limited Warranty Administration..............................................................................................................74
8.5 Out-Of-Warranty Repairs.................................................................................................................................74
9.0 Problem Resolution ..............................................................................................................................................75
9.1 First Line Problem Analysis.............................................................................................................................78
9.2 Trouble Checklists............................................................................................................................................80
10.0 Key Contact Directory........................................................................................................................................85
11.0 System Specifications.........................................................................................................................................87
GLOSSARY................................................................................................................................................................90
APPENDIX A - STATUS MONITOR REFERENCE................................................................................................92
APPENDIX B - INITIALIZATION AND COMMISSIONING PROCEDURES......................................................94
APPENDIX D - DATA OPERATION......................................................................................................................100

MITSUBISHI ELECTRONICS AMERICA, INC.
ST200 Series Technical Support Manual 1January 2000
1.0 Introduction
This manual provides the basic information required to successfully sell, distribute, and maintain
the Mitsubishi ST200 Series satellite terminals. The ST200 Series include the following
configurations:
•ST211 land mobile
•ST221M fixed site
•ST251 OmniQuest®transportable
This document, ST200TSM02, replaces all Technical Support Manuals previously published by
Mitsubishi Electronics America, Inc. (MELA) as it combines and updates the contents of the
ST200TSM01 and the ST251TSM01 into one comprehensive manual.
Distributors and other sales/service agents should use this reference document for training staff
and addressing typical questions and problems from the field. Two portions of this manual
warrant special attention: Sections 8.0 and 9.0. The first details MELA’s product support
policies and procedures. The second describes key operational considerations that can prove
useful in addressing frequently asked questions. This manual is posted on MELA’s web site
(www.melamsat.com) in PDF format. Distributors are encouraged to download, print and
distribute copies to all personnel involved in the MSAT business.
For consistency with previous manuals and concise notation this document uses the terms
Mobile Terminal (MT), Mobile Earth Terminal (MET), satellite terminal, satellite
communications system and satellite telephone interchangeably.
2.0 System Overview
The Mitsubishi mobile satellite telephone products are designed to work on the MSAT (L-Band)
satellite system anywhere in North and Central America including Alaska, Hawaii, the
Caribbean, and 200 miles of coastal waters. There are currently three satellite network
providers: American Mobile (AMSC) located in Reston, Virginia, TMI Communications Ltd.,
located in Ottawa, Canada and Telecomunicaciones De Mexico (Telecom), located in Mexico
City, Mexico. The Mitsubishi MSAT products addressed in this manual are sold and distributed
in North and Central America by authorized distributors and resellers.
The MSAT system comprises a satellite segment, communications ground segment (CGS) and a
mobile terminal segment.
2.1 Satellite Segment
The satellite segment acts as a relay site, similar to a cellular communications base station. It
passes signals to and from the CGS and MTs. AMSC launched its satellite (AMSC-1) into

MITSUBISHI ELECTRONICS AMERICA, INC.
ST200 Series Technical Support Manual 2January 2000
geosynchronous orbit (~ 22,300 miles / 36,000 km altitude). The MSAT satellite is one of the
most powerful communications satellites on-orbit (>500,000 Watts) and is capable of seamless
North American and Central American coverage. Hughes Communications designed the MSAT
satellite with relatively large antennas, allowing for relatively small MT antennas.
2.2 Communications Ground Segment
The CGS routes all MT calls and provides the interface to the Public Switched Telephone
Network (PSTN). The ground segment also provides feeder communications to the satellite,
establishes channels for end-user calls, and managing system resources. AMSC’s CGS is
located at AMSC headquarters in Reston, Virginia with a backup facility located 26 miles south
of this location. TMI’s CGS is located in Ottawa, Ontario and Telecom’s CGS is located in
Mexico City.
CGS subsystems include the Feederlink Earth Station (FES), Network Communication
Controller (NCC), and Network Operations Center (NOC). The FES links the signaling channels
between the satellite and the NCC and communications channels between the satellite and the
PSTN. The NCC uses these signaling channels to manage all communication system resources
through a variable number of Control Groups (CG). Each control group uses specific signaling
channels for specific MTs. The NOC oversees the entire operation, including billing and
customer service.

MITSUBISHI ELECTRONICS AMERICA, INC.
ST200 Series Technical Support Manual 3January 2000
To Satellite
Communications Ground Segment (CGS)
NCC FES
NOC
PSTN
2.3 Mobile Terminal Segment
As end-user equipment, MTs transmit and receive signals to and from the CGS via the satellite.
MSAT terminals include land mobile, transportable, fixed, maritime, and aeronautical
applications. Each Mitsubishi MT comprises three functional units: Antenna Unit (AU),
Transceiver Unit (TU), and one or more user interfaces (like handsets or a personal computer).
3.0 Product Overview
3.1 General Overview
The ST211 terminal includes a transceiver, beam steering unit, and handset or user terminal
options. The beam steering unit is a small gyroscope that determines vehicle motion for mobile
satellite tracking.
The ST221M fixed site terminal comprises the same major components as the land mobile
configuration, minus the beam steering unit. The parabolic antenna in this high gain
configuration replaces the dome type antenna in the land mobile unit. The ST221M also
includes an AC/DC power supply.
Standard items and optional accessories provide basic digital voice, wide area dispatch and data
capabilities. Mitsubishi land mobile and fixed site antennas physically incorporate the radio
frequency electronics, easing installation and troubleshooting. The following figures show the
primary elements of the ST211 and ST221M configurations respectively.

MITSUBISHI ELECTRONICS AMERICA, INC.
ST200 Series Technical Support Manual 4January 2000
ST211
ST221M
The ST251 OmniQuest®transportable terminal is one of the most versatile satellite
communications systems available to date offering many unique features and capabilities.
OmniQuest® is an integrated portable terminal containing the transceiver, antenna, battery and
handset as depicted below.

MITSUBISHI ELECTRONICS AMERICA, INC.
ST200 Series Technical Support Manual 5January 2000
3.2 Key Features
All Mitsubishi MTs are easy to operate. The basic handset, for point-to-point calling, looks and
operates like a cellular phone. There are three one-touch speed dial keys and 99 alphanumeric
memory locations. The handset permits any key answering, displays received signal strength,
and lets users enable special features from a menu of functions. Optional accessories also allow
users to operate in a hands-free mode.
All MTs accommodate service offering for wide area dispatch with an optional push-to-talk
handset (shown above) and circuit switched data at 4800 bits per second.
Three new features have been added to these second-generation MTs: Horn Alert, Auto-Power-
On and Echo Cancellation. Horn Alert is ideal for those with Land Mobile applications who
need to be able to hear the MT ringing while away from their vehicle but while still nearby.
Auto-Power-On allows the user to set the MT to automatically power on once the vehicle’s
engine is started (just like a car radio when left on). The software–based echo cancellation
feature allows users to avoid having to install an echo canceler board in the TU.
3.3 Product Positioning
The mobile, fixed and portable terminals deliver communication where there is no existing
infrastructure; or when other systems fail or become overloaded. These MTs do not compete
with terrestrial offerings like cellular or PCS. However, for those companies and industries that
need seamless communication, Mitsubishi MTs are a viable solution. Seamless coverage and a
flat airtime rate are important for prospects who operate in multiple locations on an on-going
basis.
These MTs offer top-notch brand name recognition, reliability, and quality that Mitsubishi
supports with an in-warranty replacement program.
3.3.1 Target Markets
Mitsubishi mobile, fixed and portable configurations effectively address several niche markets:
♦Industries that operate expansive networks like telecommunications, energy, and
utilities can more efficiently manage their field units with Mitsubishi land mobile
terminals.
♦Remote site industries, like those involved in construction or natural resource
extraction, can employ Mitsubishi fixed site MTs for communicating with isolated
management or operation centers. This market also extends to the tourist industry
with remote hunting and fishing lodges.
♦All configurations also address large corporations or institutions—that because of
geography or regulation—require back-up or contingency communications.

MITSUBISHI ELECTRONICS AMERICA, INC.
ST200 Series Technical Support Manual 6January 2000
Companies in California and Florida in the US and other locations throughout Canada
and Central America are especially receptive to this concept. Further, companies
involved in transporting or working with hazardous materials like nuclear power
generation and HAZMAT transportation must have an emergency mode of
communications.
3.3.2 Applications
Specific MSAT applications for land mobile, fixed site and portable MTs exist throughout North
and Central America today. The following examples may provide some additional insight for
sales and marketing forces. The list is not exhaustive:
♦Telecommunications companies have purchased land mobile and transportable MTs
for operating and maintaining land lines, both fiber optic and wire. Mitsubishi MTs
can improve the efficiency of field units responding to fiber optic cable failure, saving
a lot of money. These companies typically use dispatch service.
♦Oil and gas companies use land mobile MTs for regular pipeline maintenance
operations. Maintenance trucks testing pressures and physical integrity throughout
the extent of a pipeline or segment of pipeline can remain in constant
communications. This concept is very similar to that employed in the
telecommunication industry.
♦Mining and construction companies can more effectively conduct day-to-day
business from even the most remote locations. Their business may require continuous
communications with other remote sites, fleets on the road, and headquarters through
the PSTN. Day-to-day business may just entail a report at the end of each day—
either voice or data.
♦Any large corporation in regions prone to natural disasters, like the West Coast or
Gulf States, can use MTs for contingency communications. This application is not
the same as back-up communications for conducting business operations. Rather,
contingency communications link key executives and decision-makers for
implementing already existing recovery and response plans.
♦Hospitals, nuclear facilities, and HAZMAT trucks require some form of
emergency communications for public safety reasons. Dedicated channels or high
availability channels can save lives during emergency situations that can disable or
degrade the existing terrestrial infrastructure. As a simple example, any cellular
telephone user in a major metropolitan area knows that even a minor traffic accident
on a commuter route can saturate capacity as hurried drivers begin making calls.
More severe emergencies exponentially degrade consumer-type systems.

MITSUBISHI ELECTRONICS AMERICA, INC.
ST200 Series Technical Support Manual 7January 2000
4.0 Product Description
4.1 General
The land mobile MT consists of a Common Transceiver Unit (CTU), a medium gain antenna,
handset, cradle and junction box (J-box), Beam Steering Unit (BSU) and all required cabling.
The fixed site configuration also includes a CTU, handset, parabolic antenna, AC/DC power
converter, all required cabling, cradle, and junction box. The ST221M standard kit includes a 50
foot (15 meter) CTU to AU cable set. Other cable options might be available through certain
distributors.
The OmniQuest®ST251 is a complete communications terminal containing a Transceiver Unit
(TU), Antenna Unit (AU), Handset, Battery and an AC Adapter/Charger. The antenna unit is
conveniently mounted in the notebook lid providing a very efficient design that allows for quick
and easy setup. All standard equipment fits in the soft carrying case provided with OmniQuest®.
Optional accessories are available for all terminals for added functions and capability. Wide-
area or digital dispatch requires an optional Push-To-Talk (PTT) handset. Note: availability of
system features may vary based on service provider offerings. The following tables summarize
standard and optional MT components, respectively.
Standard ST211 Land Mobile MT Components
Part Number Description
TU200A CTU, Mounting Kit
AU201A AU, Mounting Kit, 18’ (5.5m) AU-TU Cable
AU1200A(S) BSU, Mounting Kit
SZ130A Cradle-3, Junction Box, Mounting Kit
SZ460A 20’ (6m) Power Cable
SZ100A Basic Handset
ST200N02 Owner’s Manual
Standard ST221M Fixed Site MT Components
Part Number Description
TU200A CTU, Mounting Kit
AU601B AU, Mounting Kit
SZ130A Cradle-3, Junction Box, Mounting Kit
PUP-55-13-J9 AC/DC Converter
FSC50 50’ (15m) AU-TU Cable Kit
SZ100A Basic Handset
ST200N02 Owner’s Manual

MITSUBISHI ELECTRONICS AMERICA, INC.
ST200 Series Technical Support Manual 8January 2000
Standard ST251 MT Components
Part Number Description
NT100A Base Unit (includes integrated antenna, antenna electronics and
removable transceiver unit)
SZ100A Handset w/ Curl Cord
OQ-CRADLE Cradle
SZ511A NiMH Battery Pack
SZ503A AC Adapter/Charger
ME-SN Carrying Case
ME-COM Compass
OQ-REF1 Quick Reference Card
ST251NO1 Operating Instructions
Optional Components
Part Number Description
SZ300A PTT Handset; for wide-area dispatch
FZ1283A Monitoring Speaker; for hands free operation
FZ806A External Microphone; for hands free operation
OQFAU50 Fixed Dish Antenna w/50 ft cable for OmniQuest fixed site use
OQFAU100 Fixed Dish Antenna w/100 ft cable for OmniQuest fixed site use
SZ351A Junction Box for wide-area dispatch w/OmniQuest
SZ601A Cigarette Lighter Adapter for OmniQuest
SZ511A Additional Battery for OmniQuest

MITSUBISHI ELECTRONICS AMERICA, INC.
ST200 Series Technical Support Manual 9January 2000
4.2 Antenna Units
4.2.1 Dome Antenna Unit
The Dome AU (AU201A) contains a single helical antenna element mounted on a ground plane
which is fixed in elevation angle and mechanically steerable in azimuth. The AU201A houses
the RF Electronics Unit (RFU) underneath the antenna. The RFU includes a high power
amplifier, low noise amplifier, diplexer, and control electronics. The antenna gain is
approximately 9 dBi, with nominally 20 Watts of L-Band RF energy (~1.6 GHz). The Dome
AU receives steering commands from the BSU, through the CTU.
WARNING: Stay 6 inches (15 cm) away from the antenna while transmitting
NOTE: The AU antenna cable connection at the CTU must be firmly secure prior to operation.
Loose or improper connection may render the terminal inoperable (not able to power
on) or result in error messages.
4.2.2 Fixed Site Antenna Unit
The Fixed Site AU (AU601B) is a parabolic antenna (with feed horn) which physically
incorporates the RFU, including high power amplifier, low noise amplifier, and diplexer. The
AU601B provides a gain of approximately 20 dBi and nominally emits 20 Watts in L-Band (~1.6
GHz).
WARNING: Stay 26 inches (60 cm) away from the antenna while transmitting
NOTE: The AU cable connections at the antenna and at the CTU must be firmly secure prior to
operation. Loose or improper connections may render the terminal inoperable (not able
to power on) or result in error messages.
4.3 Common Transceiver Unit
The land mobile and fixed site MTs utilize a Common Transceiver Unit (CTU), the TU200A,
which provides interfaces for AUs, handsets and data devices, as well as managing signaling and
communications with the CGS via the satellite. The CTU demodulates and processes received
antenna signals; process, modulate, and send outgoing signals to the antenna for transmission;
and manages all handsets, data devices and other accessories.
In addition to providing the major MT interfaces, the CTU is comprised of a main board,
converter board and necessary power supplies. The main board multiplexes, scrambles, encodes,
and interleaves signals in addition to providing frame-formatting functions. Its logic and
signaling subsystem provides the central control of the MT to initialize self tests, setup/configure
!
!

MITSUBISHI ELECTRONICS AMERICA, INC.
ST200 Series Technical Support Manual 10 January 2000
the CTU, handle protocols, and manage control signals and messages with handset(s) and data
devices. A logic and signaling processor in the main board includes a CODEC for analog and
digital conversions of voice signals. The CTU converter board contains the necessary frequency
synthesizers, up and down converters, and the QPSK modulator.
The most current CTU configuration accommodates 4800 bits per second data communications,
a satellite acquisition algorithm that speeds network access, and advanced service features. The
availability of advanced service features depends on the specific offerings of each service
provider, but can include:
♦Call Line Identification (Caller ID) and Caller ID Restriction—Handset displays
the caller’s phone number or protects your phone number from such devices
♦Connected Line Identification and Connected Line Restriction —Handset displays
the phone number of the party who you called or protects your phone number
from such display
♦Call Transfer—Transfers a call in progress to a third party without any previous
connection
♦Call Forwarding and Voice Mail—Forwards incoming calls to another number
(without ringing) or to a voice mailbox when your phone is busy or unattended
♦Call Waiting—Notifies the user of an incoming call during a conversation and
allows switching between these calls
♦Conference Calling—Allows conversations with several parties simultaneously
♦Call Barring—Restricts placing one or more types of calls
♦Alternate Account Charging—Allows billing to specific accounts for particular
phone calls
♦Enhanced Fraud Protection—Requires a four digit PIN, that the service provider
assigns, to complete dialing
4.4 CTU Cradle and Junction Box
The cradle and junction box provide the appropriate interfaces for the basic handset and
accessories with the CTU. The handset cradle package (SZ130A) includes a clip mount with an
RJ-45 handset interface and the junction box (SZ350A) interface for accessories (PTT handset,
monitoring speaker, and hands free microphone).

MITSUBISHI ELECTRONICS AMERICA, INC.
ST200 Series Technical Support Manual 11 January 2000
NOTE: All connections between the basic handset and the CTU must be firmly secure. Loose
or improper connections may render the terminal inoperable (not able to power on) or
result in error messages.
4.5 Beam Steering Unit
The Beam Steering Unit, or BSU (AU1200A), is a small component that attaches to the side of a
CTU in the land mobile configuration. Its piezo-electric gyroscope and control system sense
changes in vehicle direction. The BSU feeds these measurements directly through the CTU to
the antenna for closed loop tracking. The CTU also processes this information for optimizing its
system management functions. Section 5 includes additional information on antenna pointing.
The BSU must be mounted within + 5oof vertical (relative to the ground) for proper operation.
For rapid satellite acquisition and lock, the vehicle should remain stationary or move along a
straight path for the first ten (10) seconds of MT operation.
4.6 CTU Power Components
The power cable (SZ460A) connects from a vehicle’s 12 Volt battery line directly to the CTU in
a land mobile configuration. The power cable has a +12V power line, a +12V ignition sense
line, and a ground line. The power and ignition sense lines each contain a 10A in-line fuse
which protects the CTU and the vehicle’s electrical system.
The PUP-55-13-J9 AC/DC converter provides 13.8 V at 55 Watts of continuous output power to
the fixed site ST221M. This unit is enclosed in a polycarbonate case with an IEC320 inlet
connector, which allows interchangeable power cords for international use. All models meet
VDE class B and FCC class B emissions limits, and are approved to UL, CSA, and CTUV safety
standards.
4.7 OmniQuest® Description
A brief description of each of the main components of OmniQuest®is provided below.
4.7.1 Base Unit
The OmniQuest®Base Unit (NT100A) houses all of the main electronics of the system including
the Antenna, Radio Frequency Unit (RFU), removable Transceiver Unit (TU), and power
electronics (including internal battery). Latches are included to secure the antenna and TU and a
release lever secures the battery pack when the door is open.
NOTE: The TU and the battery are the only removable sub-assemblies in the OmniQuest®. The
electronics contained in the RFU (within the NT100A unit), the antenna lid and the
TU201A subassemblies are not serviceable outside MELA’s service center.
Distributors and their agents should not attempt to access these electronics unless
authorized by MELA (does not apply to Battery Pack).

MITSUBISHI ELECTRONICS AMERICA, INC.
ST200 Series Technical Support Manual 12 January 2000
4.7.1.1 Antenna
The integrated lid Antenna receives signals transmitted from the satellite and transmits signals
provided from the RFU. The OmniQuest®Antenna is comprised of a two element planar array
patch antenna integrated into the lid and connected to the OmniQuest®Base Unit. The antenna
provides a gain of approximately 10.8 dBic and emits 20 Watts of RF energy nominally in the L
Band frequency range (~1.6 GHz).
WARNING: Stay 2 feet (24”) / 61 cm away from the antenna while transmitting
The OmniQuest®antenna must be manually pointed at the satellite which is aided by using the
Quick Reference Card and compass provided in the standard carrying case. Because the
beamwidth of the antenna is fairly wide (~30o), approximate pointing of the antenna is easy.
Once the approximate location of the satellite has been established, the pointing angle can be fine
tuned by using the Received Signal Strength Indicator (RSSI) displayed on the Handset (i.e.,
approximate or initial pointing of the satellite needs only to be accurate enough so that a signal
can received on the RSSI). See section 5.11 for operational considerations concerning the RSSI
and OmniQuest®setup.
NOTE: If an approved external antenna is used, the cable must be securely attached to the
RFU prior to operation. Likewise, if switching from an external antenna back to the
OmniQuest®self-contained antenna, the antenna cable must also be securely attached.
Loose or improper connections may render the terminal inoperable (not able to power
on or low received signal) or result in error messages.
4.7.1.2 RF Unit
The RFU is contained within the Base Unit and provides an interface between the OmniQuest®
antenna and the removable TU. The RFU contains a High Power Amplifier (HPA), Low Noise
Amplifier (LNA), diplexer, and control electronics that provide the proper amplification,
filtering, and control of the RF signals generated from the TU and received from the satellite
through the antenna.
4.7.1.3 Transceiver Unit
The removable TU201A Transceiver Unit is located inside the Base Unit, providing the
necessary interfaces for user devices and the RFU, as well as managing all signaling and
communications with the CGS via the satellite. It demodulates and processes the signals
received by the antenna through the RFU; processes, modulates, and sends signals to the RFU
for transmission, and manages all interfaces with user interface equipment, other connected
accessories, and network interfaces with the CGS.
NOTE: All required interfaces for the OmniQuest®Transceiver Unit are available on the TU
connector panel. Distributors should not attempt to access the electronics inside the
Base Unit without prior authorization from MELA.
!

MITSUBISHI ELECTRONICS AMERICA, INC.
ST200 Series Technical Support Manual 13 January 2000
NOTE: The connection of the TU to either the Base Unit or the TMU must be firmly secure.
To ensure proper connections after inserting the TU into the Base Unit, adjust latches
(located on BOTH sides of the Base Unit) to the “L” or locked position.
4.7.2 Battery Pack
The SZ511A Battery Pack provides DC voltage for operating the OmniQuest®MT. The Battery
Pack is comprised of NiMH Battery cells (similar to some cellular telephones) and provides for
the storage of energy to provide DC power (see specifications for ratings). The Battery Pack can
be charged through use of the AC Adapter/Charger from an external 115 VAC / 60 Hz power
source while installed in the OmniQuest®Base Unit or when removed as discussed below.
NOTE: There are several handling, storage, and charging considerations for increasing the
performance and lifetime of NiMH Battery Packs. Please refer to the ST251 Operating
Instructions for details.
NOTE: The standard Battery Pack is rated to provide for > 1 hour of talk time at 77oF / 25oC.
Because the MT is voice activated, the typical conversation time obtained from a fully
charged Battery Pack could be > 2 hours.
NOTE: There are several operational considerations concerning battery run time, which should
be well understood by the users. Please refer to the ST251 Operating Instructions or
section 5.11 for details.
NOTE: This Battery Pack has been designed specifically for use and operation with the
OmniQuest®ST251 MT. Do not attempt to use other batteries with this unit.
4.7.3 OmniQuest®AC Adapter/Charger
The SZ503A AC Adapter/Charger provides two methods for charging the Battery Pack as well
as providing DC power output for operations. The DC output cable of the AC Adapter/Charger
can be used for trickle charging a battery pack installed in the OmniQuest®MT and/or for
powering the MT during operation when connected to the DC Input Connector of the MT.
Alternately, the Battery pack can be removed from the MT and attached directly to the unit for
charging. Rapid charging of the battery takes approximately 2 hours. When the MT is powered
on and in transmit mode, rapid charging changes to trickle charging and may take up to 24 hours
if the MT is continuously transmitting (e.g., in data mode).
NOTE: When the battery pack is fully charged, the indicator light on the SZ503A will change
from red to green (for either the “spare” battery pack or the “main” battery pack inside
the base unit). Prompt removal of the battery is required to avoid overcharging, and
potential damage to the SZ511A battery pack.
The DC output cable of the SZ503A is approximately 1 foot (32 cm) in length and is hard wired
directly to the AC Adapter/Charger. The plug at the end of the DC output cable is a special 4-pin
connector which mates to the DC Input connector of the Base Unit. The AC input cable for the
AC Adapter/Charger is approximately 6 feet (1.8 m) in length. The cylindrical objects attached

MITSUBISHI ELECTRONICS AMERICA, INC.
ST200 Series Technical Support Manual 14 January 2000
to the cords are special inductive filters and are required to maintain compliance with FCC
requirements for conducted emissions. No attempt should be made by distributors or users to
fabricate replacement or alternate cables, to modify the length of these cables, or to remove or
change the filters on the cables.
NOTE: The AC Adapter/Charger has been designed specifically for the OmniQuest® ST251.
Only this unit should be used to provide power to the MT for operation or to charge the
Battery Pack from an AC power source.
4.7.4 Standard Carrying Case
The Standard Carrying Case provides space to accommodate all of the standard components of
the OmniQuest®, and AC Adapter/Charger. Also provided with the Standard Carrying Case is a
magnetic compass and a Quick Reference Card to assist in setup. The Standard Carrying Case is
constructed of 600 denier nylon with reinforced seams.
NOTE: The Standard Carrying Case only provides light protection to the OmniQuest®
components from moisture and impact. The user is responsible for ensuring that the
OmniQuest®components are protected to a level consistent with the users specific
operating and transportation environment.
4.7.5 OmniQuest®Cigarette Lighter Adapter (CLA)
The SZ601A Cigarette Lighter Adapter (CLA) provides a method to supply 9.6V DC input to the
MT from a standard 12V vehicle cigarette lighter socket. The CLA cables are similar in length
to the AC Adapter/Charger cables. The CLA is functionally equivalent to the AC
Adapter/Charger and can both power the OmniQuest®unit and charge a battery while installed in
the OmniQuest®unit or when installed on top of the charger.
NOTE: The SZ601A CLA has been designed to meet the specific voltage requirements of the
OmniQuestTM ST251. Only the SZ601A should be used to provide power to the MT for
operation or to charge the SZ511A Battery Pack from a standard cigarette lighter
socket. Use of other CLA adapters may void the ST251 limited warranty.
4.7.6 OmniQuest®Junction Box
Only OmniQuest®specific Junction Boxes (SZ351A, SZ352A) are designed to work with the
ST251 terminal. Both Junction Boxes provide the capability of using the PTT Microphone and
allow the use of hands-free accessories (i.e. external speaker, microphone). The SZ352A
Junction Box includes a longer cable and is therefore more suitable for permanent vehicle
installations or if the customer desires a longer cable. The Junction Box connects to the “J-Box”
port of the OmniQuest®TU. For hands-free operation, the user connects the hands-free
microphone and speaker to the junction box.
NOTE: Although the handset contains an external speaker which will provide hands-
free/dispatch audio, the external speaker is a desirable and highly recommended option
if the handset speaker is not loud enough or a remote location of the speaker is desired.

MITSUBISHI ELECTRONICS AMERICA, INC.
ST200 Series Technical Support Manual 15 January 2000
In most cases, the customer will prefer the external speaker for dispatch and hands-free
operation. To activate hands-free mode, the handset must be connected to the TU and securely
latched into the handset cradle. The handset cradle contains a magnet that deactivates the
handset speaker and activates the external speaker when connected to the Junction Box.
4.7.7 OmniQuest®Fixed Dish Antenna
OmniQuest®is capable of being operated with an external Fixed Dish Antenna (OQFAU50)
connected to the RFU through the external antenna port (located on the back of the OmniQuest®
base unit). The Fixed Dish Antenna is 18” in diameter and comes with mounting hardware and
50 feet of cable (LMR240). A 100’ cable may also be used and is commercially available. The
cable type needed is LMR400 and requires SMA straight connectors. The OQFAU50 is fully
weatherproof and “marinized” for use in harsh or salt water environments. For temporary fixed-
site applications, use of a tripod is desirable, however, the OQFAU50’s mounting bracket will
also accommodate a 2” diameter mounting pole.
4.8 Basic Handset
The standard handset (SZ100A) operates as a control panel for dialing and storing phone
numbers and accessing built-in functions. The handset has a two line, seven character liquid
crystal display (LCD) and a 23 button keypad (illuminated). The keypad control panel has a
standard 12 button alpha-numeric telephone keypad (most with multiple functions), 3 speed
External antenna
(OQFAU) shown with
100’ cable (Type
LMR400) and
optional tripod.
Weight of antenna
and mounting
hardware is
less than 5 lbs.
See Appendix C for
detailed installation
instructions.
18”

MITSUBISHI ELECTRONICS AMERICA, INC.
ST200 Series Technical Support Manual 16 January 2000
dialing keys, and eight other unique keys including a power button and two volume control
buttons on the side of the handset. Users can input up to 28 characters or numbers for placing a
call or memory storage in one of 99 locations (two screens required to see the entire location).
The interface between the standard handset and the cradle is a special 8-wire interface using RJ-
45 connections. The interface consists of three audio lines, two serial data lines, a power-on
signal line, +12V DC power, and ground. The serial data lines transmit keypad strokes and
receive and display commands from the handset and CTU.
The curl cord stretches to a maximum length a 5 feet (1.5m). Do not attempt to fabricate a
replacement or alternate cable, or modify the length of the curl cord provided. Although
standard RJ-45 extension cables exist, Mitsubishi Electronics does not endorse these extension
cables or guarantee MT product performance and reliability with these cables.
The connection of the Handset curl cord at the cradle must be firmly secure. Loose or improper
connections may render the terminal inoperable (not able to power on) or result in error
messages.
4.9 Push-to-Talk Handset
The Push-To-Talk handset, or PTT microphone, is an optional accessory providing access to the
wide-area dispatch service known as net radio. The PTT handset lets users select up to 15
different networks, or talkgroups. The MSAT service provider configures these channels, which
operate in a half-duplex manner like a standard two-way radio. The PTT handset also allows
users to automatically scan through configured talk groups and select active networks. The PTT
handset plugs into the junction box with the optional external speaker (needed for received
audio).
The interface between the PTT handset and the junction box is a special 8-wire interface using
RJ-45 connections. The interface comprises one audio line, two serial data lines, a PTT signal

MITSUBISHI ELECTRONICS AMERICA, INC.
ST200 Series Technical Support Manual 17 January 2000
line, a power-on signal line, +12V DC power, and ground. The serial data lines transmit keypad
strokes and display commands to/from the transceiver.
The PTT handset must be securely connected to the junction box prior to power-on of the MT.
Net radio operation also requires an external monitoring speaker.
4.10 Other Accessories
Other accessories such as Mitsubishi hands free microphones and external speakers are available
through equipment distributors. Customers should contact these distributors directly concerning
cost and availability.
5.0 Product Operation
Mitsubishi satellite telephones are user friendly, operating like a cellular phone (i.e., no dial tone)
and requiring minimal user interaction. These MTs have many built-in features including special
function keys, user programmability options, and security features. This section includes a brief
design overview as useful background for understanding MT operations.
5.1 Design Overview
The Mitsubishi MTs operate under a blanket license from the FCC for MSAT Service under Part
25 (Satellite Communications) of its rules. This license, on file with the FCC (File No. 2823-
DSE-P/L-93), does not require special MT identification tags for compliance. The fixed site
MT, ST221M, also complies with Part 15 of the FCC Rules as a Class B unintentional source of
radiation subject to the conditions thereunder. The land mobile MT has no requirement for Part
15 compliance.
The MSAT network operates in the L-Band of the frequency spectrum, roughly covering 1.5-1.6
GHz. Because L-Band signals are subject to fading, Mitsubishi MT design includes additional
margin to assure performance and reliability. The terminals’ digital modulation and signal
