Mixxim MIXXTAPE User manual

USER MANUAL

•To prevent possible hearing damage,
do not listen to high volume levels for
long periods
•Fully understand user manual before
use
•Ensure your player is at low volume
levels and power off when not in use
•To help avoid accidental damage keep
player in jewel case when possible
•To reset the player, press and hold the
Power button in the ON (up) position
for approximately 10 seconds
!
STOP!
IMPORTANT INFORMATION
Please read this manual
before using your MIXXTAPE

Before First Use
Be sure to read this manual before you
use your MIXXTAPE for the first time.
The battery might be low when you use
your MIXXTAPE for the first time. Charge
the battery before using.
Memory Card Important Information
•Do not insert or remove the memory
card while the device is powered on.
•Be careful when inserting or removing
the memory card. The memory card
slot is spring loaded. To insert, gently
push the memory card in until it snaps
into place. To remove, push the
memory card in until it pops out.
•Supports microSD SDHC/SDXC Type
10 cards up to 128GB.

Introduction
MIXXTAPE is a digital and analog audio
player, supporting lossy and lossless
music formats including FLAC, MP3,
WMA, OGG, APE, WAV, AAC-LC,
ACELP, and Audible. MIXXTAPE will also
play in most tape decks.
Key Features
•Built-in LCD Display
•Touch Control Panel
•Bluetooth 4.0
•Headphone Out
•Plays As A Cassette Tape
•Supports up to 128GB microSD Card
•Internal 200mAh Rechargeable Battery
•MicroUSB Port

Buttons & Ports Introduced
Control Panel
Display
Power
Lock
Magnetic Head
Memory Card Slot
Data/Charging USB Port
Headphone Out

Power/Lock button
When the unit is powered off, slide the
button up, hold for three seconds and
release it. The MIXXTAPE will power on
(after a brief pause). To turn off, slide the
button up and wait for the three second
countdown to finish. When the unit is on,
slide the button down to lock all buttons.
Data/Charging USB Port
•Charging
Connect using the included USB cable
to an 5V/500mAh charger adapter.
•Loading Audio
1. Make sure a memory card is inserted
2. Connect the player to a computer
using the provided USB cable
3. The unit will show up as if it were a
connected thumb drive, external hard
drive, or memory card.
4. Drag and drop the desired audio files
or folders into the drive location on
the connected computer
5. After the files are loaded onto the
unit, right-click on the drive and eject
it from the computer, then disconnect
the data cable

REW/PREV: Play mode: press
briefly to skip to the previous
song, hold down to rewind the
current song
Menus: press briefly to choose the
previous item
Volume: press briefly to decrease
FWD/NEXT: Play mode: press
briefly to select the next song,
hold down to fast-forward the
current song
Menus: press briefly to choose the
next item
Volume: press briefly to increase
PLAY/SELECT: Play mode: press
briefly to play/pause
Menus: press briefly to confirm
actions or to enter the submenu of
the selected item
MENU: Press briefly to access
menus
VOL/BACK: Press briefly to move
to the previous screen. Press and
hold for three seconds to change
volume. Use REW & FWD buttons
to increase/decrease
vol

Volume
When the unit is playing an audio file,
press and hold the VOL key for three
seconds. The volume level will appear. To
decrease, press the < key (REW). To
increase, press the > key (FWD).
To increase the volume above 20, quickly
press the Menu key when prompted and
then continue to press the > key (FWD).
NOTICE - To prevent possible hearing
damage, do not listen to high volume
levels for long periods
Tape Deck
Select a song and press Play. Insert the
MIXXTAPE into the tape deck. Press Play
on the tape deck.

Main Menu
Music
Press Play to resume playing the most
recently played audio file.
If an audio file is playing when the
MIXXTAPE is powered off, the unit will
store the last position played. The next
time MIXXTAPE is powered on, press
Play on the Music screen to Resume.
Bluetooth
1. Put MIXXTAPE and the Bluetooth
wireless headphones/speaker in
range of each other
2. Turn on Bluetooth in the MIXXTAPE
(under the Bluetooth menu)
3. Put the headphones/speaker in
pairing mode
Bluetooth
Music

4. Search for the headphones/speaker
by selecting Scan Devices
Bluetooth Connection Tips for Vehicles
•The vehicle audio system must
support A2DP Bluetooth
•Some vehicles will require a code
before pairing, use "0000"
Explorer
Browse and select audio files loaded on
the memory card
Settings
•Repeat Mode
Once - single play, it will stop after
playing one audio file
Explorer
Settings
