MJ 150037 User manual

USER MANUAL
Holmstrupgårdvej 250, 8210 Århus V MJ-FIVE POINT BELT
Side 1af 7
It is important to read this manual before installation and use of MJ-Five Point belt as well
as the advice given on the safety and use followed to ensure the optimal utilization of the
MJ-Five Point belt.
MJ-Five Point belt is designed for use in the positioning of PWD that causes uncontrolled
movements, or for active persons who run the risk of leaving the seat in a vehicle, -the
standard safety belt which may cause a risk of falling or ejection during transport.
•The MJ-Five Point belt is designed and tested in accordance with DS/EN ISO
10525:2007 Personnel lifting for disabled persons – Requirements for test methods.
•The test is performed as a static test, the specified person weight for use, with a
safety factor of 2, is set at 220 kg.
MJ-Five Point belt is used in connection with a seat with backrest which is attached to the
vehicle.
MJ-Five Point belt designed for use by children and adult.
MJ-Five Point belt is NOT a safety belt, but a positioning belt to ensure the person proper
location on the seat.
MJ-Five Point belt be used for any purpose other than described, the CE marking and
warranty are only valid to the manufacturer's written approval.
Table of Contents
1. CE Declaration of Conformity.
2. The use
3. Use with harness pillow, harness with backrest and safety seat.
4. Maintenance.
5. Warranty.

USER MANUAL
Holmstrupgårdvej 250, 8210 Århus V MJ-FIVE POINT BELT
Side 2af 7
1. CE Declaration of Conformity
CE Declaration of Conformity
MJ Autosadelmager
Holmstrupvej 250
8210 Århus V
Hereby declares that MJ-Five Point belt. is manufactured in accordance with the
Regulation (EU) 2016/425 of the Parliament and the Council of 9 March 2016 on
personal protective equipment.
MJ-Five Point belt is designed for positioning of PWD that causes uncontrolled
movements, or for active persons who run the risk of leaving the seat in a vehicle, -the
standard safety belt which may cause a risk of falling or ejection during transport.
Furthermore, the product is subject to the following standards and circulars:
ISO 13688:2013. Protective Clothing – General requirements.
EN 13210:2004. Childcare articles. Children´s safety harnesses, reins and similar type
articles. Safety requirements and test methods.
EN 365 General requirements for the use, maintenance, periodic inspection, repair,
marking and packaging.
Danish Working Environment Authority, Bek. No 210 of 14/03/2018, about Personal
protection and safety.
.
DK8210 Århus V, date 20.07.2020.
Morten Jespersen

USER MANUAL
Holmstrupgårdvej 250, 8210 Århus V MJ-FIVE POINT BELT
Side 3af 7
2. The use:
Place the triangular assembly
plate high on the back of the
seat backrest, close the lock and
set the belt.
Open seat belt click locks and
put the belt around the seat
Billeddelen med relations-id rId15 blev ikke fundet i filen.
Lock the horizontal belt at the
back
Place the person in the seat and
adjust the shoulder-, hip- and
crotch belts loosely around the
person.

USER MANUAL
Holmstrupgårdvej 250, 8210 Århus V MJ-FIVE POINT BELT
Side 4af 7
Ensure that relief cushions fit
right where the belts have
contact with the body
Assembly of three-point seatbelt
buckles.
Close the lock and fine-tune the
the belt.
1. Set the crotch belt so that the
clip seal is located on the lower
part of the abdomen above
pelvic bones. The setting is
made on the back of the seat
backrest.
2. Adjust the shoulder belts; this
is going on the front.
3. Adjust the hip belt, which is at
the back of the seat backrest.
4. Make sure the belt is not too
tight, there may be an adult flat
hand between the belt and the
person.
Place the person in the MJ-Five
point belt.

USER MANUAL
Holmstrupgårdvej 250, 8210 Århus V MJ-FIVE POINT BELT
Side 5af 7
Safety:
When the person is placed and fixed by MJ-Five point belt put on the vehicle's seat belt
around the person, in accordance with regulations for the transport of children and
adolescents.
Never leave children or unattended, when they are fixed with MJ-Five point belt.
3.Use with harness pillow, harness pillow with backrest and safety seat.
The seat cushion is placed on
the vehicle seat
The MJ-Five point belt harness
is placed around the vehicle seat
and under the vehicle seat belt,
as shown in section 2.
The seat cushion with backrest
is placed on the vehicle seat
The MJ-Five point belt harness
is placed around the vehicle
seat, under the vehicle's seat
belt, as shown in section 2.

USER MANUAL
Holmstrupgårdvej 250, 8210 Århus V MJ-FIVE POINT BELT
Side 6af 7
4.Maintenance.
MJ-Five point belt is made of polyamide and the breast pad is made of synthetic leather
MJ-Five point belt can be washed at 40˚C, do not uses tumble dryer for drying after wash.
Daily maintenance before use, inspect MJ-Five point belt for damage and wear, also check
the locks functions.
MJ-Five point belt must be send for repair, if there are any damage or wear.
Disposal.
When MJ-Five point belt sh.ould no longer be used, this can be sent for destruction of
recyclable ferrous waste and combustible material.
5.Warranty.
The manufacturer's warranty covers manufacturing, materials and function of the
equipment supplied. The warranty is applicable when the equipment is operated in
accordance with instructions for use and for the purpose for which the equipment is
delivered.
The warranty covers repair of defects in the equipment supplied, and not possible effects
caused by these.
All repairs and replacement of components during the warranty period shall not be made
without prior consent and approval of the manufacturer.
The warranty period is under current law or as agreed in the order confirmation.
OnConsult, 20.07.2020
Translation of the original user manual.
The MJ-Five Point harness is not
ideal for use in the car seat; If
the MJ-Five-point harness is
used, the locks and straps must
be free of each other. The child
seat is placed and fixed as
described in its instruction
manual, this can be
accomplished by the use of the
vehicle's safety belt or Isofix
fitting.
The MJ-Five-point belt harness
is placed under the car seat's
approved seat belt and fastened
around the car seat and
backrest.
