User’s Manual
Magnetic Stirrer
www.biolynx.ca
Available in Canada from ...
Toll Free: 1-888-593-5969 • Phone: [phone]
Website: biolynx.ca • Email: [e-mail]
P.O Box 1150, 300 Laurier Blvd., Brockville, ON K6V 5W1

Table of Contents
1
Introduction
Thank you for choosing BioLynx's product. This product can be used in medical,
biotechnology, chemistry, and other research fields. It was designed to be ergonomic and
highly waterproof.
Before you use the unit, please read this entire manual carefully to understand how to
operate and maintain the instrument.
Keep this manual on-hand so it can be used by all operators of the unit. Be sure all
operators of the unit are given appropriate training before putting the unit in service.
Cautions for Usage
1. Be sure you follow any city, county, or other ordinances in your area regarding the
use of this unit.
2. Use only approved accessories. Do not modify system components. Any alterations or
modifications to your instrument may be dangerous and will void your warranty.
3. Do not modify the power cord provided with the unit. If the plug does not fit an
outlet, have a proper outlet installed by a qualified electrician.
4. Please only use the enclosed power supply adaptor with the unit.
5. Place the unit on a level and sturdy surface to avoid vibration and noise.
6. Be mindful of liquid level to avoid splashing while stirring.
7. Place container on the center of working plate.
8. Keep the unit stable when in operation.
9. Clean the stir bar after use.
10. DO NOT clean the unit with any corrosive or flammable liquids.
Introduction ......................................................................................1
Cautions for Usage ..............................................................................1
Receiving and Inspection .....................................................................2
Features .......................................................................................2
Specification .................................................................................2
Structure .................................................................................3
Panel ...........................................................................................3
Operation Instructions ..........................................................................3
Maintenance ...................................................................................4
Troubleshooting ....................................................................................4
Packing list ...........................................................................................4
Warranty Card .......................................................................................5
www.biolynx.ca
www.biolynx.ca

2 3
Your satisfaction and safety require a complete understanding of this unit,
including its proper function and operational characteristics. Be sure operators
are given adequate training before attempting to put the instrument in operation.
1.1 Inspection: Upon delivery please inspect the package for visible exterior damage,
note and describe on the freight bill any damage found and enter your claim on the form
supplied by the carrier.
1.2 Inspect for concealed loss or damage on the unit itself. If any, the carrier will
arrange for official inspection to substantiate your claim. Save the shipping crate until
you are sure the unit has been delivered in good condition.
1.3 Return Shipment: If for any reason you must return the unit, please contact your
distributor’s customer service department.
1.4 Accessories: Make sure that all of the equipment indicated on the packing slip is
included with the unit. Carefully check all packaging materials before discarding.
Receiving and Inspection
○ Ergonomic design
○ Motorless drive mechanism for quiet maintenance-free operation
Features
Specifications
Speed
Capacity
Working Platform
Load
Ambient
Weight
Power Supply
Power
Dimensions(L×W×H)
IP rating(DIN EN 60529)
15-1500rpm
500ml Water
110×110mm
Max. 2.0kg
5-40°C, ≤ 80%RH
0.3kg
AC1 00-240V, 50/60Hz
6W
175mm×125mm×20.5mm
IP 45
Model
MS-01FUA
MS-01FUW
Structure Power Adapter
Platform
Control Panel
Panel
Operation Instructions
1. Connect the unit to the power supply, and turn it on.
2. Put the stirrer bar into a container first.
3. Put the container on the center of the working plate of magnetic stirrer.
4. Set the speed: The initial speed is 15rpm, and spin speed value can be changed 15rpm by
at a time by pressing the“ ”or“ ” keys. Speed will be memorized after power off.
5. Set clockwise/counterclockwise spin: Press“ ”.Under this mode, the stirring direction
of stirrer bar will be reversed every 30 seconds. The stirrer bar will stop for 5 seconds at every
reversal. The Reversal LED will light up.
Note:
1. If any abnormal stirring starts, please slow down the speed until the spinning returns back to
normal.
2. Start the unit from lower speed and gradually increase the speed for best operation.
MS-01FUSA
Plug
US, CA
E-EN-AU
SA
Certifications CE Marked
www.biolynx.ca
www.biolynx.ca
On/Off
Button
Reversal LED
Reverse
Button
Slower
Button
Faster
Button

4 5
Save this card carefully please. When you need service, contact the service company with card & invoice.
WARRANTY CARD
Warranty Card
User Name
Address
Postal Code
Product Name
Serial number
Telephone
E-mail
Model
Purchase Date
1.Warranty period is 24 Months from purchase date.
Warranty:
Warranty is not valid under the following circumstances:
1. Warranty term is expired.
2. Damage due to improper use, maintenance or handling.
3. Unmatched serial numbers, or modification of serial numbers.
Customer service: 1-888-593-5969
Maintenance records
Name of service
Address
Maintenance sheet number
Name of service
Address
Maintenance sheet number
Name of service
Address
Maintenance sheet number
Maintenance date
Telephone
Maintenance staff signature
Maintenance date
Telephone
Maintenance staff signature
Maintenance date
Telephone
Maintenance staff signature
First
Second
Third
The following should be completed by maintenance staff.
For safe use, please follow directions below:
• Unplug the power cord before cleaning.
• Clean the unit with a soft cloth and non-corrosive liquid (PH<8).
• Do not spray the unit.
• Make sure the unit is completely dry before use.
• Make sure there aren't any hazardous materials in the unit prior to maintenance.
Maintenance
Packing List
Description Quantity Remark
User’s Manual
1
1
√
√
Troubleshooting
Please find solution from the table below before calling for service.
Description
Not working
No stirring or
improper stirring
Cause
Power off
Local power failure
Placed on an uneven surface
Improper choice on viscosity gear
Liquid overflown
Solution
Power on
Call service provider
Place the unit on level surface
Choose a proper viscosity gear
Decrease liquid
Magnetic Stirrer
Accessories
Stir Bar (ø7mm×20mm)
Stir Bar Retriever
(ø7mm×320mm)
Adapter 1√
Adapter Converter 1For SA
1√
