MK ZRF-P 2040 Guide

ZRF-P 2040 TIMING BELT CONVEYOR
Technical
Documentation
Each serial number is unique to that specifi c conveyor and provides mk North America with complete order details.
The conveyor serial number is located on the frame at the drive end of the conveyor. See section 2 for more details.
Your serial number is also recorded above.
Ensure the serial number tag above matches the serial number on your conveyor.

Technical Documentation
ZRF-P 2040
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 |Page 2
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 |Page 3
1 General Information 3
2 Decoding Your Serial Number 4
3 Conveyor Description 5
4 Warranty Information 7
5 Safety Requirements 8
6 Wear Items & Maintenance For Specifi c Drive & Tail Options 10
7 Conveyor Belt Maintenance - Tensioning & Tracking 16
8 Conveyor Belt Maintenance - Belt Replacement 18
9 Conveyor Maintenance - Tensioning & Greasing Of Drive Chain 20
10 Notes & Contact Information 23
10.2 Contacting mk North America, Inc. 23
1 GENERAL INFORMATION
1.1 Foreword
Congratulations on purchasing a conveyor from mk North America, Inc., a leading manufacturer of
quality low profi le conveyors. Our more than 30 years experience in material handling allows us to
offer robust solutions with long life and reliable operation. We strive to make the best products in
the industry even better and we are committed to making sure our customers get top notch support
before, during, and after each and every sale.
1.2 The importance of reading your manual
Inside this manual you will fi nd the instructions on how to set up and maintain your mk conveyor
properly, as well as maximize its performance. Please take the time to read this manual and familiarize
yourself with these set up and maintenance instructions. These instructions will help assure a long
product life that requires a minimum amount of service and keeps your conveyor working at its
maximum capacity.
1.3 If you need assistance
If you need assistance there are a variety of ways to get it. You can contact our customer service team
Monday through Friday, 8am-5pm (Eastern Time) at [phone]. You can also visit our website for
additional information and technical documentation at www.mknorthamerica.com. In addition, your
local representative can provide support in many instances.
1.4 When your shipment arrives
1) Check your shipment
a) If you have not already done so, visually inspect the shipping crate/container for any damage
caused during shipment.
b) Carefully unpack the crate/container making sure to inspect the components for damage
that may have occurred inside the packaging materials.
c) If you fi nd any damage, please contact the carrier and mk North America, Inc.
d) Lastly, check the contents against the packing slip provided by mk for any discrepancies. If
you should fi nd any, please contact mk North America, Inc.
2) Locate your ordered items
a) Each mk conveyor will ship in its own custom built container, carefully packaged in the most
economical way.
b) Review the packing slip against your Purchase Order.

Technical Documentation
ZRF-P 2040
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 |Page 4
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 |Page 5
3 CONVEYOR DESCRIPTION
3.1 Conveyor Description
Designations:
Serial #: This number is unique to this item. With this number we can access all of the original
order details.
Date: This is the date that the unit was scheduled to ship.
Type: This description refers to the type of unit that is associated with the particular serial
number. The type should NOT be substituted for the serial number when inquiring.
DWG#: This number, if applicable, refers to the specifi c drawing that was created for this unit.
Not all orders require a drawing and therefore in some cases no DWG# is assigned. If your
DWG# fi eld is blank it is not a cause for concern.
SO#: This is the shop order number in which this unit was built. This is an mk North
America, Inc. internal number. This number is also referenced on any related invoices, etc.
GUF (Gurt Foerderer) Belt Conveyor
KTF (Kettengurt Foerderer) Chain Conveyor
KFG (Knickfoerderer Gurt) Bent Belt Conveyor
KGF (Kurvengurt Foerderer) Curve Belt Conveyor
MBF (Modulband Foerderer) Modular Belt Conveyor
SBF (Scharnierband Foerderer) Hinged Belt Conveyor
SRF (Staurollen Foerderer) Accumulating Roller Conveyor
ZRF - P 2040
Profi le Series
“Profi le”
“Foerderer” = Conveyor
Style of Conveyor
2 DECODING YOUR SERIAL NUMBER
• The conveyor’s serial number is located on the frame at the drive end of the conveyor; it is affi xed to the black
drive train cover which has the gearmotor mounted to the back plate.
• If there is no black drive train cover, the serial number is affi xed to the frame.
• See image below for label example.
• YOUR SERIAL NUMBER IS ON THE FRONT COVER OF THIS MANUAL.
• We have provided an area in the back of this manual for you to add any notes about this unit.

Technical Documentation
ZRF-P 2040
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 | Page 6
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 | Page 7
The ZRF-P 2040 has many typical conveyor components. Below is a description of the basic parts and options
for the ZRF-P 2040 conveyor. The items you receive will vary based on your actual purchase order. Items may
appear different on your model based on your particular order requirements. Consult your approval drawing for
specifi c items included in your order.
3 CONVEYOR DESCRIPTION (CONT.)
3.2 Conveyor Components
4 WARRANTY INFORMATION
Warranty
mk North America, Inc. (MKNA) offers a COMPLETE ONE YEAR WARRANTY from the date of delivery, to the original purchaser of the
MKNA equipment (CUSTOMER), to be free from defects in material and workmanship; under normal use and with proper installation,
maintenance and cleaning.
Additionally MKNA offers a LIMITED 10 YEAR WARRANTY on all equipment that MKNA is the original manufacturer of, to be
free from defect and workmanship.1.
This warranty is extended by MKNA only to CUSTOMER, and is non-transferable. All warranty requests shall be made by CUSTOMER.
MKNA will replace or repair, at our factory or any other location we designate2., any defective part within the warranty period and without
charge. It is at MKNA’s sole discretion whether to repair or replace. CUSTOMER will provide MKNA with a prompt written notice of the
defect, including the serial number of the unit (when applicable) and the date of delivery.
At MKNA’s request CUSTOMER will return all defective parts for evaluation at MKNA. MKNA will provide CUSTOMER with a return goods
authorization number (RGA#). No parts will be returned without a RGA#. The RGA# must clearly be marked on all labels, packages and
packing slips.
CUSTOMER shall pay all costs for packaging, shipping, duties and/or any other related costs in the sending or receiving of parts.
CUSTOMER is responsible for all labor associated with sending or receiving of parts.
MKNA PROVIDES NO WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE; UNLESS IT IS AGREED TO BY
MKNA AND CUSTOMER IN WRITING PRIOR TO PLACEMENT OF ORDER. Such agreement requires approval of MKNA Management.
UNDER NO CIRCUMSTANCES SHALL MKNA BE HELD LIABLE FOR DAMAGES OR LIABILITY FOR LOSS OF PRODUCTION, PRODUCT,
EQUIPMENT OR PROFITS OR LIABILITY FOR DIRECT, INCIDENTAL, INDIRECT, SPECIAL OR CONSEQUENTIAL DAMAGES OR ANY
DAMAGES TO PERSONS OR PROPERTY, WHATSOEVER. CUSTOMER agrees that it is their sole remedy for liability of any kind, including
negligence with respect to the equipment and services furnished by MKNA shall be limited to the remedies provided herein. This warranty
shall not apply to any failure of the unit or its components caused by lack of maintenance and/or improper maintenance, incorrect
adjustments, misuse or unreasonable use or exposure to chemicals and/or environments which the unit is not designed for. Unauthorized
modification of the unit or the use of non-MKNA replacement parts and building components voids this warranty.
1. The limited 10 year warranty does not apply to equipment and components manufactured by others. Such equipment and components
are subject to any limitation contained in the original manufacturer’s warranty and include, but are not limited to: bearings, belts, casters,
controllers, motors and pneumatic devices.
2. No work will be performed by MKNA or an MKNA factory authorized service representative at the site of installation unless in MKNA’s
opinion it is impractical for Customer to remove and return the defective part to MKNA’s factory.
EXCEPT AS EXPRESSLY STATED HEREIN, THERE ARE NO WARRANTIES, EXPRESSED OR IMPLIED, BY OPERATION OF LAW OR
OTHERWISE, OF THE EQUIPMENT OR SERVICES FURNISHED BY MKNA OR FACTORY AUTHORIZED SERVICE REPRESENTATIVE. THERE
ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF.
mk North America, Inc. reserves the right to change, modify or discontinue products and/or specifications with or without notice.
All of mk North America, Inc. products are covered by this warranty.
Dual lane conveyor shown.
Your model will vary.
Typical Components
1) Conveyor Frame
2) Idler End
3) Gearmotor Mount/Drive Assembly - serial number plate mounted here
4) Gearmotor
5) Timing Belt
6) Controller (Not shown)
7) Side Rails
8) Support Stand
9) Stand Stringer

Technical Documentation
ZRF-P 2040
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 |Page 8
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 | Page 9
5 SAFETY REQUIREMENTS 5 SAFETY REQUIREMENTS (CONT.)
5.1 Warnings - Safety Guidelines
READ AND UNDERSTAND ALL OF THESE WARNINGS PRIOR TO OPERATING EQUIPMENT.

Technical Documentation
ZRF-P 2040
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 |Page 10
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 |Page 11
6 WEAR ITEMS & MAINTENANCE FOR SPECIFIC DRIVE OPTIONS6 WEAR ITEMS & MAINTENANCE FOR SPECIFIC DRIVE OPTIONS
6.1 Important Notes About Wear Items & Maintenance6.1 Important Notes About Wear Items & Maintenance 11
6.2 ZRF-P 2040 AC 12
6.3 ZRF-P 2040 AS 14
6.4 ZRF-P 2040 BA 16
6.5 ZRF-P 2040 BF 18
The following information regarding life of the wear items and service or adjustment intervals of the functional
elements are only GUIDELINES. Conveyors are application-specifi c products whose life expectancy can vary
depending on their relative loads and speeds, and which can be signifi cantly infl uenced by environmental factors.
• All moving components and screw connections should be checked every 6 months.
• All safety-relevant components should be part of a regularly scheduled weekly inspection
• The proper function of these components must be confi rmed at all times.
• Do NOT operate conveyors if safety-relevant components are damaged or missing.
• All parts which contact the product should be cleaned weekly (example: belt).
• Remove heavy grease coatings with ethyl alcohol.
• Blow off debris from belts with structured surfaces using compressed air.

Technical Documentation
ZRF-P 2040
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 |Page 12
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 |Page 13
6 WEAR ITEMS & MAINTENANCE FOR SPECIFIC DRIVE OPTIONS (CONT.)
6.2 ZRF-P 2040 AC
34
1
2
5
8
6
7
6 WEAR ITEMS & MAINTENANCE FOR SPECIFIC DRIVE OPTIONS (CONT.)
6.2 ZRF-P 2040 AC (Cont.)
Maintenance Work for ZRF-P 2040 AC
* LEGEND: Inspect, Replace, Tension, Clean, Lubricate (grease).
Position Description Action*Interval in Hours (Months) Lubrication
1 Roller Bearing I 1,000 Hours (Max. 6 Months)
2Drive/Idler Sprocket I, C 500 Hours (Max. 3 Months)
3Wear Strip I, C 500 Hours (Max. 3 Months)
RIf wear visible
4 Timing Belt I, C 500 Hours (Max. 3 Months)
RIf wear visible
5 Gearmotor I, C Service & maintenance per
manufacturer’s documentation
6 & 7 Drive Train Sprockets I, C 500 Hours (Max. 3 Months) SAE20-SAE50
8Drive Train Chain I, C, T, L 500 Hours (Max. 3 Months) SAE20-SAE50
RIf chain stretch is greater than 3%
Position Description Part Number
1Roller Bearing 6006-2RS1 K101000428
2Drive/Idler Sprocket Inquire with mk North America
3Wear Strip Inquire with mk North America
4 Belt Inquire with mk North America
5 Gearmotor Inquire with mk North America
6 Sprocket at Drive Roll Inquire with mk North America
7 Sprocket at Gearmotor Inquire with mk North America
8Chain & Connecting Link Inquire with mk North America
NOTE: Not all items shown in all views for clarity. (Cont.)

Technical Documentation
ZRF-P 2040
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 |Page 14
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 |Page 15
6 WEAR ITEMS & MAINTENANCE FOR SPECIFIC DRIVE OPTIONS (CONT.)
6.3 ZRF-P 2040 AS
43
1
8627
5
6 WEAR ITEMS & MAINTENANCE FOR SPECIFIC DRIVE OPTIONS (CONT.)
6.3 ZRF-P 2040 AS (Cont.)
Maintenance Work for ZRF-P 2040 AS
* LEGEND: Inspect, Replace, Tension, Clean, Lubricate (grease).
Position Description Action*Interval in Hours (Months) Lubrication
1 Roller Bearing I 1,000 Hours (Max. 6 Months)
2Drive/Idler Sprocket I, C 500 Hours (Max. 3 Months)
3Wear Strip I, C 500 Hours (Max. 3 Months)
RIf wear visible
4 Timing Belt I, C 500 Hours (Max. 3 Months)
RIf wear visible
5 Gearmotor I, C Service & maintenance per
manufacturer’s documentation
6 & 7 Drive Train Sprockets I, C 500 Hours (Max. 3 Months) SAE20-SAE50
8Drive Train Chain I, C, T, L 500 Hours (Max. 3 Months) SAE20-SAE50
RIf chain stretch is greater than 3%
Position Description Part Number
1Roller Bearing 6006-2RS1 K101000428
2Drive/Idler Sprocket Inquire with mk North America
3Wear Strip Inquire with mk North America
4 Belt Inquire with mk North America
5 Gearmotor Inquire with mk North America
6 Sprocket at Drive Roll Inquire with mk North America
7 Sprocket at Gearmotor Inquire with mk North America
8Chain & Connecting Link Inquire with mk North America
NOTE: Not all items shown in all views for clarity. (Cont.)

Technical Documentation
ZRF-P 2040
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 | Page 16
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 | Page 17
6 WEAR ITEMS & MAINTENANCE FOR SPECIFIC DRIVE OPTIONS (CONT.)
6.4 ZRF-P 2040 BA
4
3
1
2
6 WEAR ITEMS & MAINTENANCE FOR SPECIFIC DRIVE OPTIONS (CONT.)
6.4 ZRF-P 2040 BA (Cont.)
Maintenance Work for ZRF-P 2040 BA
* LEGEND: Inspect, Replace, Tension, Clean, Lubricate (grease).
Position Description Action*Interval in Hours (Months) Lubrication
1 Roller Bearing I 1,000 Hours (Max. 6 Months)
2Drive/Idler Sprocket I, C 500 Hours (Max. 3 Months)
3Wear Strip I, C 500 Hours (Max. 3 Months)
RIf wear visible
4 Timing Belt I, C 500 Hours (Max. 3 Months)
RIf wear visible
Position Description Part Number
1Roller Bearing 6006-2RS1 K101000428
2Drive/Idler Sprocket Inquire with mk North America
3Wear Strip Inquire with mk North America
4 Belt Inquire with mk North America
NOTE: Not all items shown in all views for clarity. (Cont.)

Technical Documentation
ZRF-P 2040
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 |Page 18
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 | Page 19
6 WEAR ITEMS & MAINTENANCE FOR SPECIFIC DRIVE OPTIONS (CONT.)
6.5 ZRF-P 2040 BF
4
3
1
2
5
5
6 WEAR ITEMS & MAINTENANCE FOR SPECIFIC DRIVE OPTIONS (CONT.)
6.5 ZRF-P 2040 BF (Cont.)
Maintenance Work for ZRF-P 2040 BF
* LEGEND: Inspect, Replace, Tension, Clean, Lubricate (grease).
Position Description Action*Interval in Hours (Months) Lubrication
1 Roller Bearing I 1,000 Hours (Max. 6 Months)
2Drive/Idler Sprocket I, C 500 Hours (Max. 3 Months)
3Wear Strip I, C 500 Hours (Max. 3 Months)
RIf wear visible
4 Timing Belt I, C 500 Hours (Max. 3 Months)
RIf wear visible
5 Gearmotor I, C Service & maintenance per
manufacturer’s documentation
Position Description Part Number
1Roller Bearing 6006-2RS1 K101000428
2Drive/Idler Sprocket Inquire with mk North America
3Wear Strip Inquire with mk North America
4 Belt Inquire with mk North America
5 Gearmotor Inquire with mk North America
NOTE: Not all items shown in all views for clarity. (Cont.)

Technical Documentation
ZRF-P 2040
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 |Page 20
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 |Page 21
7 CONVEYOR BELT MAINTENANCE - TENSIONING & TRACKING
7.1 Standard Idler 17
General Remarks:
• Belts may need to be tracked due to shifting during shipping.
• Prior to delivery of the mk conveyor, the belt was tensioned and tracked at the factory.
• Belt tracking should only be done at the idler end.
• Avoid over tensioning the belt, increase slack in belt if necessary.
All work to be performed by qualifi ed personnel only.
Conveyor power must be disconnected before replacing the belt.
7 CONVEYOR BELT MAINTENANCE - TENSIONING & TRACKING (CONT.)
7.1 Standard Idler
All work to be performed by qualifi ed personnel only.
Conveyor power must be disconnected before replacing the belt.
Belt Tensioning
Caution!
Belt tensioning is only to be done at the idler end (opposite the
motor end).
General Instructions:
• The belt was tensioned and adjusted at the factory before
delivery of the mk product.
Loosen screws (2) and (4) to pull the entire assembly (1)
out (arrow direction) in order to pretension the timing belt.
Tighten screw (4) and then fi nally adjust the timing belt with
screw (3), see below.
Tighten bolt (2).
Belt Tracking
Caution!
Tracking (or realignment) of the belt must only be done while
the belt is moving (pinch points).
Adjust bolt (2) and screw (3) in the direction of the arrow, for
the fi ne adjustment to the timing belt until the belt is running
centrally on the pulley. Tighten the bolt (2).

Technical Documentation
ZRF-P 2040
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 |Page 22
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 |Page 23
8 CONVEYOR BELT MAINTENANCE - BELT REPLACEMENT
8.1 Standard Idler 19
General Remarks:
• Prior to replacing the belt, the tail assembly must be completely loosened and retracted – instructions for
this to follow.
• Any auxiliary parts that interfere must be removed.
• One side of the conveyor must be free and clear of all interferences. THIS IS BEST DONE ON THE SIDE
WITHOUT THE MOTOR MOUNT.
• Reassemble in reverse order.
• Replacement belts must be tracked and tensioned prior to use. (see Section 7)
All work to be performed by qualifi ed personnel only.
Conveyor power must be disconnected before replacing the belt.
8 CONVEYOR BELT MAINTENANCE - BELT REPLACEMENT (CONT.)
8.1 Standard Idler
Loosen all bolts and push the entire head (1) inwards (in
the direction of the arrow), in order to create slack in the
timing belt.
Additional Instructions:
• The belt can now be replaced once all auxiliary obstructions are removed.
• Slide the existing belt off the free side of the conveyor frame.
• To replace belt, slip it over the side of the conveyor.
• Reassemble conveyor in the reverse order and the track and tension belt prior to use. (see Section 7)
All work to be performed by qualifi ed personnel only.
Conveyor power must be disconnected before replacing the belt.

Technical Documentation
ZRF-P 2040
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 |Page 24
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 |Page 25
Remove both cap nuts (1) and remove chain guard.
Loosen the motor mounting screws (1). Move the motor (2) in
the arrow direction to tension the drive chain (3).
Do not over-tension the drive chain!
Proper chain tension should allow 2-10 mm of play on one side.
Drive Chain Lubrication
The drive chain (1) must be lubricated with grease in
accordance with the maintenance instructions (See Section 6).
Apply the lubricant with a brush to the chain edges, in order for
the lubricant to penetrate the links completely.
9 CONVEYOR MAINTENANCE - TENSIONING & GREASING OF DRIVE CHAIN
9.1 ZRF-P 2040 AC 21
9.2 ZRF-P 2040 AS 22
Do NOT lubricate timing belt and pulley drive trains.
9 CONVEYOR MAINTENANCE - TENSIONING & GREASING OF DRIVE CHAIN (CONT.)
9.1 Tensioning & Greasing of the Drive Chain - ZRF-P 2040 AC
Note: Reassemble in reverse order; ensuring all screws are tight and all guards are in place before
operating.
1
3
1
1
2
2-10 mm
All work to be performed by qualifi ed personnel only.
Conveyor power must be disconnected before performing maintenance.

Technical Documentation
ZRF-P 2040
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 | Page 26
mk North America, Inc. |105 Highland Park Drive | Bloomfi eld, CT 06002 | [phone] |www.mknorthamerica.com
©2022 | Page 27
9 CONVEYOR MAINTENANCE - TENSIONING & GREASING OF DRIVE CHAIN (CONT.)
9.2 Tensioning & Greasing of the Drive Chain - ZRF-P 2040 AS
10 NOTES & CONTACT INFORMATION
10.1 Record Your Notes
Email: [e-mail]
Phone: [phone]
Fax: [phone]
Remove both upper and lower screws and remove chain
guard.
Loosen both console mounting screws (1). Move the
motor (2), including the motor console, in the arrow
direction to tension the drive chain (3).
Do not over-tension the drive chain!
Proper chain tension should allow 2-10 mm of play on one
side (see 4.9, Drive Chain Lubrication).
Greasing the Drive Train
The drive chain (1) must be lubricated with grease in
accordance with the maintenance instructions (See
Section 6).
Apply the lubricant with a brush to the chain edges in order
for the lubricant to penetrate the links completely.
2-10 mm

Technical Documentation
ZRF-P 2040
Timing Belt Conveyor
REV. 2022.15.045
All rights reserved, information subject to change without notice. © 2022 mk North America, Inc.
mk North America, Inc.
an mk Technology Group Company
105 Highland Park Drive
Bloomfield, CT 06002, USA
Phone: [phone]
Fax: [phone]
www.mknorthamerica.com
[email protected]
