ML CFR5WW Instruction Manual

INSTALLATION & MAINTENANCE MANUAL
CFR5WW / CFR5CW / CFR5DL

These instructions should be read carefully and retained after installation by the end user for
future reference and maintenance.
These instructions should be used to aid installation of the following products:
CFR5WW / CFR5CW / CFR5DL
GENERAL INSTRUCTIONS
• This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671)
and current Building Regulations. If in any doubt, consult a qualified electrician
• Please isolate mains prior to installation or maintenance
• Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating of the
circuit cable, fuse or circuit breaker
• Please note the IP (Ingress Protection) rating of this luminaire when deciding the location for installation
• Allow 50mm above and around the fitting for air dissipation (do not cover the fitting with insulation)
• This product is for indoor use only
• This product is Class II double insulated
• This product is IP65 rated (IP20 from above)
SAFETY
INSTALLATION
Note - If this luminaire is being used in conjunction with an external PIR or sensor, please confirm with the
manufacturer of the sensors that they are compatible with LED luminaires
• Provide power to the required point of installation
• Cut a suitable hole in the mounting surface as per the cut-out details (see Fig. 1) ensuring not to infringe
with any joists, gas/water pipes or electrical cables

INSTRUCTIONS CFR5xx
These instructions should be read carefully and retained after installation by the end user for future reference
and maintenance.
These instructions should be used to aid installation of the following products:
CFR5WW / CFR5CW
SAFETY
•This product must be installed in accordance with the latest edition of the IEE Wiring Regulations
(BS7671) and current Building Regulations. If in any doubt, consult a qualified electrician
•Please isolate mains prior to installation or maintenance
•Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating of
the circuit cable, fuse or circuit breaker
•Please note the IP (Ingress Protection) rating of this luminaire when deciding the location for
installation
•Allow 50mm above and around the fitting for air dissipation (do not cover the fitting with insulation)
•This product is Class II double insulated
•This product is IP65 rated
INSTALLATION
Note -If this luminaire is being used in conjunction with an external PIR or sensor, please confirm with the
manufacturer of the sensors that they are compatible with LED luminaires
•Provide power to the required point of installation
•Cut a suitable hole in the mounting surface as per the cut-out details (see Fig. 1) ensuring not to
infringe with any joists, gas/water pipes or electrical cables
Fig. 1
•Connect the luminaire to the mains supply ensuring that correct polarity is observed (see Fig. 2): L -
Live (brown), E - Earth (green/yellow), N - Neutral (blue). The earth terminal is non-functional and only
provided for convenience. Two cables can be inserted into the push-fit terminal block in order to
achieve loop in / loop-out wiring
Fig. 2
Fig. 1
• Connect the luminaire to the mains supply ensuring that correct polarity is observed (see Fig. 2): L - Live
(brown), E - Earth (green/yellow), N - Neutral (blue). The earth terminal is non-functional and only provided
for convenience. Two cables can be inserted into the push-fit terminal block in order to achieve loop-in /
loop-out wiring
INSTRUCTIONS CFR5xx
These instructions should be read carefully and retained after installation by the end user for future reference
and maintenance.
These instructions should be used to aid installation of the following products:
CFR5WW / CFR5CW
SAFETY
•This product must be installed in accordance with the latest edition of the IEE Wiring Regulations
(BS7671) and current Building Regulations. If in any doubt, consult a qualified electrician
•Please isolate mains prior to installation or maintenance
•Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating of
the circuit cable, fuse or circuit breaker
•Please note the IP (Ingress Protection) rating of this luminaire when deciding the location for
installation
•Allow 50mm above and around the fitting for air dissipation (do not cover the fitting with insulation)
•This product is Class II double insulated
•This product is IP65 rated
INSTALLATION
Note -If this luminaire is being used in conjunction with an external PIR or sensor, please confirm with the
manufacturer of the sensors that they are compatible with LED luminaires
•Provide power to the required point of installation
•Cut a suitable hole in the mounting surface as per the cut-out details (see Fig. 1) ensuring not to
infringe with any joists, gas/water pipes or electrical cables
Fig. 1
•Connect the luminaire to the mains supply ensuring that correct polarity is observed (see Fig. 2): L -
Live (brown), E - Earth (green/yellow), N - Neutral (blue). The earth terminal is non-functional and only
provided for convenience. Two cables can be inserted into the push-fit terminal block in order to
achieve loop in / loop-out wiring
Fig. 2
Fig. 2
• Secure the mains cable under the cable clamp and refit the terminal cover
• Lift both spring clips on the sides of the fitting and push into the ceiling
• Switch on and check for correct operation

This luminaire must be disconnected from the circuit if subjected to any high voltage or insulation resistance
testing. Irreparable damage will occur if this instruction is not followed.
WARNING
GENERAL
This product contains a light source of energy efficiency class C (CFR5CW, CFR5DL) / D (CFR5WW) to
Regulation (EU) No. 2019/2015 and (UK) 2021 No. 1095.
This product contains a non-replaceable LED light source and a non-replaceable control gear
Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may damage the
product.
This product is dimmable with most trailing-edge dimmers, please check compatibility before installation.
This product should be dismantled for disposal when it reaches the end of its life. Please see website for
dismantling instructions.
This product should be recycled in the correct manner when it reaches the end of its life. Check local authorities
for where facilities exist.
Press to disable the daylight sensor, the luminaire will switch on
when motion is detected regardless of the ambient light level
Fig. 4
WARNING
This product must be disconnected from the circuit if subjected to any high voltage or insulation resistance
testing. Irreparable damage will occur if this instruction is not followed.
GENERAL
This product contains a light source of energy efficiency class D to Regulation (EU) No. 2019/2015 and (UK)
2021 No. 1095.
This product contains a non-replaceable LED light source and non-replaceable control gear.
Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may damage the
product.
Please be aware that these products may require an MCB upgrade to a Type-C due to high inrush currents.
The maximum constant ambient temperature at the point of installation should not exceed 500C.
This product is dimmable via a 0-10V dimmer, please check compatibility before installation.
This product is DALI compatible. Relevant DALI software and control gear is required for use of this
functionality.
This product should be dismantled for disposal when it reaches the end of its life. Please see website for
dismantling instructions.
This product should be recycled in the correct manner when it reaches the end of its life. Check local authorities
for where facilities exist.
WARRANTY
This product has a warranty of 5 years from date of purchase. Failure to install this product in accordance with
the current edition of the IEE Wiring Regulations (BS7671), improper use, or removal of the batch code will
invalidate the warranty. If this product should fail within its warranty period, it should be returned to the place of
purchase for a free of charge replacement. ML Accessories does not accept responsibility for any installation
costs associated with the replacement product. Your statutory rights are not affected. ML Accessories reserve
the right to alter product specification without prior notice.
230V 50Hz, IP65, Class I, Dim 0-10V, indoor only, Ta 50°C
AKJAN21_V1

WARRANTY
This product has a warranty of 3 years from date of purchase. Failure to install this product in accordance with
the current edition of the IEE Wiring Regulations (BS7671), improper use, or removal of the batch code will
invalidate the warranty. If this product should fail within its warranty period, it should be returned to the place
of purchase for a free of charge replacement. ML Accessories does not accept responsibility for any installation
costs associated with the replacement product. Your statutory rights are not affected. ML Accessories reserve
the right to alter product specification without prior notice.

AV_APR22_V4
