MM ECO PICK-UP 500L User guide

USE, INSTALLATION AND SAFETY MANUAL
MM ECO PICK-UP 500L and MM ECO PICK-UP 1000L

2

3
INTRODUCTION
Thank you for choosing a quality product MM. Several years of experience led us to the creation of a
multifunction machine for the ecological steam weeding and the hot water high pressure cleaning.
Every machine is carefully tested and inspected before leaving our factory to assure you the right operation.
Buying this machine you did an important investment that will reward you if you use it accurately.
Similarly to the others mechanical equipments even this product requires a proper installation as well as a
proper use and maintenance, as indicated in this manual
We suggest to carefully read all the manual before starting with the installation and the use of your
machine paying attention to the security instructions. Verify that the machine, its accessories and the
packaging are not damaged or that there aren’t missing parts. It is necessary to immediately communicate to
the courier or to MM company any complaint regarding missing parts or damages.
This symbol indicates important or dangerous operations or situations
INTENDED USE
Before starting the machine, it is necessary to know how to quickly stop it and understand the correct use of
all the commands and to know the security instructions.
Don’t allow someone to use the machine before having carefully read the instructions.
This machine has to be use only by trained people that are also aware of the security rules.
Use the machine just to remove the weed (steam weeding version) or to the high pressure washing
(high pressure washing function) or as a sprayer
The water in the tank is sucked and sent under pressure by a pump driven by a gasoline generator and sent
to a boiler or burner powered by car diesel fuel that warms the water to the desired temperature: steam at
120-140 °C for weeding mode, water at 80 °C maximum for the washing mode. The action on the two
lances operates the burner warming the water up at the chosen temperature. When the burner is off the
water goes out at the outside temperature.
Don’t use the machine with flammable liquids, corrosive acids or any other product that doesn’t refer
to the treatment, use only clean water.
These instructions are integral parts of the machine and they have to be delivered with the machine
when it is sold or rented.

4
WARNING SIGNS ON THE MANUAL AND ON THE MACHINE
Below are all the pictograms applied to the machine in order to illustrate the warnings, prohibitions and the
correct methods of use.
Legend of the symbols
1- Read the use and maintenance manual
2- Stop the machine and read the manual before performing
any intervention
3- Injury hazard. Do not approach the machine with moving
parts
4- Do not smoke
5- Do not lubricate during operation
6- Risk of injury from pressurized fluids
7- Do not get on the machine during operation or transfer
8- Do not stand on the tank
9- Do not enter the tank
10- Danger of crush injuries, do not place your hands near
moving mechanical parts
11- Work with a pressure lower than that indicated in red on
the pressure gauge
12- Always wear safety gloves
13- Always wear earing protection
14- Always wear protective suits
15- Always wear safety shoes
Beware of the unit's range of action while it is the function. Do
not direct the jet towards people, animals, electrical materials,
or any equipment that could be damaged.
Product compliant with the safety requirements envisaged by
the applicable European directives and regulations.
It is obligatory to keep all the pictograms with the warning signs in perfect conditions. If they get
damaged or deteriorated, replace them immediately

5
CHARACTERISTICS AND TECHNICAL DATA
This booklet is valid for multipurpose machines, ECO PICK-UP type for steam weeding, steam disinfection,
high pressure washing with hot water.
These multipurpose machines manufactured by M.M. srl are uniquely identifiable from the CE plate, upon
which the data, main characteristics and serial number are printed.
1
Manufacturer’s logo
2
Data of the machine (flow-rate, pressure …)
3
Serial number of the machine
4
Model and type of the machine
5
Year of manufacture
It is obligatory to keep all the plates with the warning signs in perfect conditions. If they get
damaged or deteriorated, replace them immediately.

6
NOISE LEVEL OF THE MACHINE
The level of the sound pressure at the user’s position is of Lp = 82 (+ /0.5) dB (A) The
level of the acoustic power measurement is of Lw = 92 (+ /0.5) dB (A)
The sound pressure level is raised in accordance with the standards in IEC
60704-1:2021 and UNI EN ISO 3744:2010. Always wear earmuffs during the
use of the machine.
The vibrations caused the upper limbs by the handle of the lance, are of 0.98 m/s². (+ /0.5) The
repulsion force on the lance to the maximum pressure is 15.0 N. 80 bar

7
SAFETY RULES
The worker must wear long clothing, gloves, safety goggles and earmuffs. However the waterproofing
protective clothing don’t provide protection against jets of water. In case of direct contact with the water high
pressure jet, they don’t give a sufficient protection against the risk of injury
During the transport and the use the machine has to be anchored to the floor of the vehicle or of the
trailer in four points.
All the doors must always be closed during the transport of the unit.
Never attempt to move the machine by pulling a hose.
Never direct the spray toward the machine or any other electrical device. Risk of electricshock.
Never direct the jet toward oneself, toward another person or animals. In case of use by more than
one worker, absolutely avoid to direct the lance/boom toward the other operators.
Don’t use the machine in full air in case of rain.
Use the machine by day or if you use it by night do it only with a good lighting.
Don’t touch the connection plug with wet hands.
Don’t use the machine if the electric cable is damaged
Don’t use the machine when the high pressure steam hose is damaged.
Don’t stop the lever of the gun in open position. Danger of serious accident.
Check that all warning labels are placed on the machine. The machine without labels should not be
used.
It is strictly forbidden to modify the setting of the pressure regulator.

8
Don’t modify the original diameter of the nozzle. The functioning of the machine can be altered
don’t leave the machine unattended.
Each time you stop the machine, always press the lever/levers of the gun/s or turn off the valves that
operate the boom to depressurise the circuit in order to avoid possible accidents topeople.
All the conductive parts (control panel, boiler generator, cables, etc.) must be protected against
water jets.
The high pressure can cause the bounce of some parts. It is necessary always to wear protective
clothing and eye protections.
Don’t touch the chimney of the boiler. Danger of burn.
Don’t cover the chimney
Don’t cover the inlets for cooling air of the generator. Danger of overheating.
It is forbidden to work in restricted or poorly windy areas; the exhaust gases of the engine of the
tractor and of the boiler are very dangerous.
Don’t operate the pump without water
Always lower the temperature of the water under 40 °C, before stopping the machine
Don’t operate the machine if it is inclined more than 10° degrees from the ground.
Never try to turn the machine on if the machine is overturned. Contact your dealer.
Don’t leave the machine while it is operating without the supervision of qualified personnel, even
for a short time.
Caution: when the machine is operating, all the exposed metallic parts where the steam circulates
(nozzles, hose reels, weeding shield, booms, etc.) can cause burn. Always use appropriate cloche
and protective gloves
Put the MM unit in a place that is:
- protected from cold
- well-ventilated
- repaired from the rain

9
Dispose of the waste oil and exhausted products in accordance with the environmental rules. Store
them in an enclosed space and then take them to the closer storage. Don’t dumping and don’t
empty it in the ground or in the drains.
The maximum pressure of work for the weeding with water at a temperature of more than 80 °C
doesn’t have to overcome 20 BAR
Don’t enter in the working area of the machine (about 10m)
Perform all the check operations when the machine is turned off according to the maintenance table.
Don’t remove any safety device when the machine is working.
The machine has a combustion engine. Don’t operate in closed environments. The exhaust gas
contains carbon monoxide, a lethal odourless gas.
Don’t enter in the tank.
This machine is not designed for people or animals carriage.
Never completely fill the tank up to the top.
Always use appropriate protective clothes: safety goggles for the eyes, gloves for the hands
and appropriate hearing However the waterproof protective clothes give a protection
just for the water jets. In case of direct contact to the high-pressure water jet these clothing
don’t give a sufficient protection against the risk of injury. Never direct the jet toward yourself
or toward other operators.
Don’t modify the machine.
The driver of the tractor carrying or trailing the machine will have to follow the speed of
displacement of the operators or of the boom.

10
MANIFACTURER’S LIABILITY
The company M.M. is not responsible if:
The user has not done the normal periodical maintenance operations shown in the table to the authorized
maintenance section.
The machine is equipped with accessories or components not given by MM or not original.
The operator doesn’t respect the indications and the instruction of the manual.
The user modified the machine.
The protections have not been mounted or have been removed.
PRELIMINARY CHECKS
A) WATER SUPPLY
Using a eater tank of 500 o 1000 litres. If you apply your own tank make sure to have a supply pipe of at least
20 mm of inner diameter, without restrictions and that is no longer than 1,8m.
B) VENTILATION
It is forbidden to use the machine in closed environments.
C) VEIHICLE
If the unit is placed on a motor or trailed vehicle it has to be anchored to the floor in 4 points.
REPOSITIONING OF THE MACHINE FOR THE STORAGE OR THE MAINTENANCE
The machine can be moved only by qualified personnel able to use forklifts or cranes.
Dimensions of the machine
Unladen weight
Full load weight
500L
mm 1020x1700x1160
Kg. 450
Kg. 1055 ca.
1000L
mm 1020x2100x1600
Kg. 470
Kg. 1625 ca.
CAUTION: IT IS ABSOLUTELY FORBIDDEN TO MOVE THE MACHINE WHEN THE TANK IS
FULL (loading, unloading and storage).
THE TANK SHOULD BE COMPLETELY DRAINED.
There are two ways to move the machine once the tank is completely empty:
•using a forklift
•using a crane

11
SAFETY RULES:
•Make sure that the lifting means are proper to support the weight
•Make sure that there is sufficient space to move the machine in height.
•Make sure that there is sufficient space to turn and/or to operate the trailer on which the machine is
placed.
•Before lifting the machine, make sure that the transport will be safe
•When using a crane, it is recommended to use proper belts, in good conditions and make sure that
they are well-fixed to the lifting-hooks of the machine. Check the distribution of the weight of the
machine considering that the metal box containing the boiler, the pump and the fuel tank is heavier
than the empty tank.
•Make sure that the floor of the route is unvarying in order to have a safetytransport
•Check that the machine could be easily moved and that is not anchored with wires, cables, hoses or
fixed mountings.
•Never lift the machine more than 50 cm from the ground during the transport; lift at the required
placement height only near the final destination.
PLACEMENT ON THE GROUND
Before placing the machine on the ground make sure that:
- The frame is in a flat position or at most inclined of 10 degrees from the ground
- There is enough space to allow the passage of people, means of transport or to do any other activity
- no heating sources or free fires are in the near
- it is in a stable position and easy to reach for the maintenance operations.

12
PLACEMENT ON MOTORIZED VEHICLE OR ON TRAILERS
For the placement on trailers make reference to the point above where characteristics and dimensions are
indicated.
Make sure that the weight at full load is compatible with the characteristics of the means of transport used.
The fixing of this unit on the means of transport has to be done by qualified person who knows the specific
features of the mean of transport.
However, it is forbidden to use temporary fixing systems (belts etc.) but it is necessary always to provide
a proper fixing system (bolting etc.)
Always put anti-vibration systems between the frame of the machine and the floor of the vehicle.
For the placement of the machine on the vehicles, it is necessary do the following preliminary checks:
- dimensions of the opening through which the group will pass.
- stability of the vehicle before and after the placement of the unit.
- check the distribution of the weight (after the placement of the unit on the vehicle).
- mooring for the overthrow of the group.
- Any fuel or lubricants dispersion from the motor pump
The use inside wood chips tracks is forbidden.
During the transport of the machine (with empty tank) it is necessary to consider that the mass is not
uniform, the maximum weight is focused on the metallic box the contains the unit, the pump and the boiler,
etc. This can cause an imbalance in the mean of transport.
During the transport the machine has to be anchored at the floor in 4 points.
The driver has to adapt the speed to that of the operators on the way.
IT IS STRICTLY PROHIBITED THE USE FOR PEOPLE UNDER THE AGE OF 18

13
DESCRIPTION OF THE MACHINE
The machine meets the essential health and safety requirements according to the directive 2006/42/CE and
subsequent changes.
This is a multifunctional machine, fitted with hand lance and/or boom for the steam low pressure weeding
and the high-pressure warm water washing. It could be used even to water flowerbeds or flower boxes with
cold water. The machine is also fitted to be connected totractors.
It is composed of a self-supported powder painted frame, a stainless steel or a polyethylene tank with an
external level scale, a diesel boiler for warming water and a 230 V gasoline soundproof generator to power
the different components.
The emptying of the tank is made thanks to a cap located at the bottom of the tank
The high-pressure volumetric pump with 3 ceramic pistons is fed by the hydraulic motor powered by the
generator
The pump sucks the water from the tank and sends it at high or low pressure (according to the modes of
operation desired) to the boiler that warms the water up until the burner is on.
A two valves system allows working with two lances or booms.
The regulation system is at constant pressure. The pressure check is made through a pressure gauge
mounted at the level of the regulation group placed on the control panel
Always place the machine in a stable and safety position to avoid the overturning.
TANK (pos. 1)
The tank is in polyethylene or in stainless steel with a smooth bottom to minimize the quantity of residual
water on the bottom of the tank
The filling of the tank takes place through the cap of the tank or through a 1” floating placed on the rear of
the tank.
DESCALING KIT (pos. 3)
The machine is equipped with an automatic metering pump of descaling agent.
Make sure that there is always enough PREKALK product in the tank.
The machine is supplied with a bin of descaling product with sealed cap and with a cap with suction hose.
This last one replaces the sealed cap from the first use.
SUCTION FILTER (pos. 2)
The filter prevents the pump to suck impurities. It is supplied with a yellow or red cap and allows to be
cleaned with the full tank thanks to a valve that also allows to suck water from an external source
The minimum diameter of the suction pipe (not fitted) is of 20 mm.
PRESSURE REGULATOR (pos. 18)
The pressure regulator allows the pressure regulation shown on the pressure gauge (pos. 13).
The machine is delivered with the pressure regulator calibrated between the two working points:
80 BAR (maximum working pressure for washing)
20 BAR working pressure for weeding)
It is forbidden to change this setting. Each change of this setting voids the warranty.

14
VALVES (Pos. 4)
Two stainless steel ball valves allow to open or close the water/steam supply to the lances or to the booms.
THERMOSTAT / THERMOMETER (Pos. 5)
The thermostat / thermometer indicates the working temperature shown in red on the display.
The thermostat / thermometer allows to adjust the desired working temperature in green indicated on the
display
The machine is fitted with the thermostat create to operate at a temperature between 40 ° C e 140 ° C
(these two limit values can’t be changed).
BOILER (Pos. 6)
The machine can be equipped with one or two vertical steel boilers air cooled and a double spiral steel coil
without welding
High efficiency diesel burner with 230V electric motor.
DIESEL FUEL TANK FOR THE BURNER (Pos. 7)
Polyethylene tank, capacity 45 litres (about 8 working hours for a boiler) placed inside the machine
Use only car diesel fuel
The warranty on the boiler is void when using with a diesel fuel which is not that of cars
DIESEL FUEL FILTER (Pos. 8)
The diesel fuel placed between the boiler and the fuel tank with transparent cover allows to filter the fuel.
ELECTRICAL PANEL OF THE BURNER (Pos. 9)
The electrical panel placed inside the machine includes:
▪ General switch ON / OFF
▪ Power switch of the machine
▪ The ON/OFF switch of the burner
▪ Thermostat / thermometer to adjust and check the temperature
▪ Stopping cycle switch
▪ The alarm to indicate that the pump is functioning
▪ The alarm to indicate that the burner is ON
▪ The alarm to indicate that the temperature of the burner is reached
▪ Alarm for diesel fuel reserve
▪ Alarm to indicate the water reservation
▪ Flashing light alarm for insufficient water supply when the steam outlets are opened.
PUMP pos. 10)
See the use and maintenance manual of the pump
GENERATOR (pos. 11)
See the manual of use and maintenance of the generator
The fuel for the generator is unleaded gasoline
CONTROL PANEL OF THE GENERATOR (Pos. 12)
–Opening, closing handle, opening for the fuel valve and air opening to the starting. (pos. 15).
–Multifunctional luminous display (pos. 17) that indicates: tension, frequency and working hours
–Alarm to indicate the lack of oil

15
HOSEREEL –OPTIONAL (Pos. 21)
Specific techniques: automatic spring or manual hosereels for 20m of insulated pipe for the washing and
steam weeding.
Pay attention to your hand during the rolling up of the pipe and to the danger of burns.
For any other information consult the instruction manual of the hose reel delivered with the machine.
PIPES
The machine is fitted with rubber pipes for the professional high pressure washing with double steel braid of
inner diameter 5/16” (DN8) with working pressure of 120 BAR and 200 °C of temperature.
Always use pipes with the same features in case of replacement.
The high-pressure pipes have to be connected by qualified
personnel
They have to be installed and fixed in order to reduce as possible the dangers.
Never paint the pipes.
After each use it is necessary always to depressurize them by operating the lance/lances.
Make sure that the pipes are free and pay attention to sharp edges. Avoid to fold or submit them to strong
pulls up.
The high-pressure pipes are subject to normal wear and limited duration; for this reason, they must
be regularly replaced according to the use even if damages are not immediatelyvisible.
The reference value in the rule DIN is of 6 years, over a possible storage period of 4 years (if the
pipe is not connected).
Use only high-pressure pipes resistant to the original working pressure and temperature
Replace immediately the high-pressure pipes if you find even one of the following
problems:
- damage of the outer layer until the internal insert caused by cuts or cracks.
- weakening of the outer layer (cracks formation) caused by storage/ improper use.
- over the storage period and the useful duration.
- leakages by the pipes or the connections.

16
LANCE (pos. 14)
The two lances fitted with the machine is proper to the weeding or the washing according to the accessories
that the worker uses. Watering lances can be supplied on demand.
The lances are equipped with swivel quick-couplings. The ring-nut has the only function to
prevent the detachment of the accessories from the lance. So, it is necessary to correctly close it for
the hydraulic seal.
The lance is connected to the pump through an high pressure isolated steam pipe 400bar 150°C working
values.
The trigger of the lance allows the opening and the closure of the water flow to the accessories (nozzles,
steam shields, etc.)
in the “weeding mode” the working pressure is of 20 bar max.
ACCESSORI –OPTIONAL ON DEMAND
- 2 weeding nozzles with weeding shield.
- 2 replacement weeding nozzles.
- 1 nozzle for washing with one lance
- 2 washing nozzles for 2 lances that work simultaneously
- 1 rotating brush for the panel’s cleaning.
WARNINGS:
Always do the preliminary checks (the level of the oil in the pump, the sealing of clamps, bolts and
screws, and the pipes condition) before operating the machine. It is possible to avoid accidents or damages
to the device or to people.
Keep children and animals away from the working area (10m) in order to avoid danger of burn
caused by hot parts of the machine, water or steam jets or from injuries caused by any debris
Before operating the unit, it is necessary to know how to quickly stop it, to know the functioning of all
the controls and to be aware of all the safety rules.
Never let someone using the gears without knowing how to use the machine.

17
SAFETY NORMS-GENERATOR
never start the generator near petrol or fuel gas stations because of the potential danger of explosion
Don’t fill the fuel tank while the motor is operating. Don’t smoke or use free fire near the fuel tank.
Refuel (gasoline or diesel fuel o diesel), in well ventilated areas and with the machine off. Pay
attention not to invert the two types of fuel. Pay attention not to overthrow the fuel during the filling. If you
overthrow it, clean and let it dry before starting the motor.
Never place flammable materials near the generator.
Pay attention not to put fuel, matches, gun powder, oily textiles, straw, refuses or other flammable
materials near the generator.
Don’t operate the generator inside a room, a tunnel, a gallery or any other not ventilated place
because the engine could warm up and emit carbon monoxide from the exhaust gases and seriously
endanger people’s life. Avoid to inhale exhaust fumes.
Don’t smoke while managing the battery. The generator’s battery emit flammable hydrogen gas that
can explode if exposed to an open flame. Keep the generator well aired and keep away from open flame or
sparks while managing the generator’s battery.
The battery of the generator contains sulphuric(electrolyte) acid that burns skin and eyes. Always
wear gloves and protective visor. If the electrolyte meets the skin immediately wash with clean water. If the
electrolyte meets eyes, wash with clean water for at least 15 minutes and immediately consult a doctor.
The electrolyte is poisonous. If ingest drink lot of water or milk, than magnesium milk or vegetal oil
and immediately consult a doctor.
The engine remains extremely hot for a period after the functioning. Keep any combustible material
from the generator.
Pay attention not to touch any part of the engine when it is hot, especially near the exhaust gas
because of the serious burns it can cause.
For all the other information of use and safety consult the manual given with the machine.
Don’t connect any electric device on the generator when you use the lances (weeding, washing and
irrigation)

18
CONTROL, PROTECTION AND SAFETY DEVICES
A) FLOW METER
It starts and stops the burner during the opening and closing of the lance or the boom in order to avoid the
overheating and to have a more constant temperature
The flashing light (10) indicates an insufficient flow of water in the circuit when the steam
outputs are open
B) WATER SUPPLY FILTER
Preserve the system from impurities like sand or rust.
C) FUEL FILTER
(On the suction filter). Preserve the fuel pump from fuel tank impurities.
(In the pump). Preserve the fuel pump from the impurities that could come from the first filter.
D) FLOATING DIESEL FUEL
The diesel fuel float is placed in the diesel fuel tank. The electric floating placed in the diesel fuel
tank turns off the burner before the tank is empty. This allows not to damage the diesel fuelpump.
E) WATER FLOAT
The electric float placed inside the water tank stops the machine when inside the tank remains the 10%
of water
So, the operator has the time to start again the machine (stopping cycle switch) to cool the water circuit
(about 7 min). When this cycle is finished the machine completely stops. It will be necessary to fill
again the tank to start working again.
Do a new starting procedure.
F) THERMOSTAT / THERMOMETER
The thermostat allows to adjust the temperature between 40°C and 140°C Max.
It isn’t possible to overcome these temperatures.
G) SAFETY VALVE
Placed at the bottom outlet of the boiler protect the system against an excessive pressure caused
by an improper use of the pressure regulator. It protects the system against the overheating
caused by an improper use of the thermostat. However, the maximum temperature is of 140 °C
H) FUSES
Inside the control panel. Protect the electric controls from the short circuits.
I) OIL ALARM
On the panel of the generator. Turn off the engine il the level of the oil is too low.
When some parts of the machine are replaced always use original spare parts produced by the
manufacturer of the machine.

19
STARTING PROCEDURE OF THE MACHINE
The machine is provided with the level of the oil in the pump ready to use; however, it is necessary always
to check it at the first operation.
1. Fill the tank with clean water till the level desired through the upper cap of the tank or through
the floater placed in the upper part behind the tank. (pos.1).
2. Fill the generator with gasoline (UNLEADED PETROL) till the desired level opening the door in
the upper part of the machine (Pos. A) between the two hose reels (GASOLINE TANK). Pay
attention not to invert the two fuels, that of the generator and that of the boiler.
3. Open the upper door and the side one with the key supplied. (pos. B).
4. Put car diesel fuel in the fuel tank (pos. 7) till the level.
5. Close the side door (pos. D).
6. Always leave the upper door open (pos. C) when working (pos.E).
7. Before starting the engine Make sure the pump is powered by water.
STARTING THE GENERATOR
1. Open the petrol tap (Pos.15) on the generator by turning it anticlockwise
2. Pull the air knob (Pos.17) (STARTER) for cold starting
3. Turn on the start key (Pos.16)
NOTE: Do not use the starter if the engine is hot
4. When the engine starts to warm up, push the starter (Pos.17)
5. Wait few seconds to let the motor reach a right temperature.
USE OF THE MACHINE
The machine works only when the generator is operating and at a tension of 230 V
When the generator stops (lack of fuel or a block for power surge) it is necessary to check the level
of the fuel, doing the checks shows in the table at chapter “maintenance” and repeat the starting
procedure of the machine. If the problem remains, contact the dealer.
Wear long wears, gloves, glasses, and earmuffs.
NOTE: When the generator is ON, check that the alarm indicates at least 230V. When the generator is on,
check the alarm indicates at least 230V.
1) Set the general switch on/off on the electric panel of the machine "1". A timed device allows you to
start the machine after 20 seconds. Before this period the machine won’t operate.
2) Push the button START to operate the high-pressure pump.
3) Open the supply valves (pos. 4) of the hose reels used. Always close the valve of the hose reel that is
not used.
Remove the rust from the warming coil, let the water flow from the lance removing any accessory
applied. Install again the accessory required once the unblocking is completed.
4) Star the burner through its switch (pos. 1). For the use with cold water (washing or irrigation) the
burner has to stay off.
Use only car diesel fuel. Don’t use gasoline or any other product containing fuel oil, solvents or water.
Pay attention not to invert the two fuels (gasoline for the generator, diesel for the burner).

20
Follow one of the two procedures shows below to do the weeding or the washing:
WEEDING MODE PROCEDURE
To obtain the best weeding results you have to work with one or two weeding shields at the same
time (one for each lance) or with a 40 cm boom on only one lance. The use with a weeding shield on
a lance and the boom on the other lance doesn’t allow to reach the maximum temperature of work.
1. Connect the accessory desired (weeding shield or 4 nozzles boom) to the lance with the quick connector
Always check the nozzles are clean and not clogged.
Caution: hot parts. Danger of burn.
2. Adjust the pressure gauge to 20 bar with the pressure regulator’s knob.
Caution: it is dangerous to work at a pressure of more than 20 bar if the temperature of the
boiler exceeds 80 °C. Risk of damaging of the boiler.
3. To adjust the working temperature desired push and release the button on the thermostat
(pos. 5)
The red display shows "Set 1"
use the key to increase the temperature (always 140°C MAX).
use the key to reduce the temperature (always 40° C MIN).
After 10 seconds the new value will be stored in the green display
The red display will show the current value.
The temperature suggested for a good weeding result is 120-140° C.
4. To increase the water temperature till 140° C let it circulate by pushing the lever gun:
- of the 2 lances if they works at the same time
- of one lance if only one person works.
5. Check the temperature in the red display of the thermostat (Pos. 5).
When the water temperature shown on the thermostat (pos. 5) exceeds 120° C you can start the
weeding treatment.
TO REDUCE THE CONSUMPTION OF FUELS YOU CAN WORK AT A TEMPERATURE OF120°C AND
THE GENERATOR IN ECONOMIC MODE AUTO P-SAVE
Avoid to pass on the grass you don’t want to remove with water warmer than 70° C.
NOTE:
The burner automatically stops warming when the lever of the gun is released or when the temperature
reaches about 140°C (temperature alarm on) and it starts again operating when the lever is push again or
when the temperature drops below 130°C
