MOA WC70 User manual

Winecooler WC70
Instruction Manual
English / Nederlands / Deutsch / Français
www.moacolors.com

Wine Cooler - English manual 2
EN
BEFORE USE
Before use, please read this manual carefully.
Only connect the appliance to an earthed wall socket.
This appliance is for household use only. When using electrical
appliances, basic safety precautions should always be followed to
avoid res, electric shocks, burns, or other injuries and damage. Read
these operating and safety instructions carefully.
IMPORTANT SAFEGUARDS (1/2)
1. This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety.
2. Children should be supervised to ensure that they do not play with
the appliance.
3. This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall not be made
by children without supervision.
4. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent, or similarly qualied persons in order to
avoid a hazard.
5. To avoid a hazard due to instability of the appliance, it must be xed
in accordance with the instructions.
6. When positioning the appliance, ensure the supply cord is not
trapped or damaged.
7. Do not locate multiple portable socket-outlets or portable power
8. Keep ventilation openings, in the appliance enclosure or in the built-
in structure, clear of obstruction.

Wine Cooler - English manual 3
EN
IMPORTANT SAFEGUARDS (2/2)
9. Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
10. Do not damage the refrigerant circuit.
11. Do not use electrical appliances inside the drink storage
compartments of the appliance, unless they are of the type
recommended by the manufacturer.
12. Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
13. This appliance is intended to be used in household and similar
applications such as
-staff kitchen areas in shops, ofces and other working environments;
-farmhouses and by clients in hotels, motels, and other residential type
environments;
-bed and breakfast type environments;
-catering and similar non-retail applications.
14. Children aged 3 to 8 years are allowed to load and unload
refrigerating appliances.
15. To avoid contamination of drink, please respect the following
instructions:
-Opening the door for long periods can cause a signicant increase in
the temperature in the compartments of the appliance.
-Clean regularly surfaces that can come in contact with drink and
accessible drainage systems.
-Clean water tanks if they have not been used for 48 h; flush the water
system connected to a water supply if water has not been drawn for 5
days.
-If the refrigerating appliance is left empty for long periods, switch
off, defrost, clean, dry, and leave the door open to prevent mold from
developing within the appliance.
Note: This appliance contains flammable refrigerant R600a and
foaming agent cyclopentane.
Please avoid contact re when you transport and use it.
Please ask a professional for servicing when the machine broke down.
Please send it to your local appointed disposal station when you
discard it.

Wine Cooler - English manual 4
EN
INSTALLATION INSTRUCTIONS
- This appliance is designed to be freestanding only, and should not be
recessed or built-in.
- Place your appliance on a floor that is strong enough to support the
appliance when it is fully loaded. To level your appliance, adjust the
leveling legs at the bottom of the appliance.
- Allow 10 cm of space between the top, the back, and sides of
the appliance, which allows the proper air circulation to cool the
compressor and condenser.
- Locate the appliance away from direct sunlight and sources of heat
(stove, heater, radiator, etc.). Direct sunlight may a฀ect the acrylic
coating and heat sources may increase electrical consumption. Extreme
cold ambient temperatures may also cause the unit not to perform
properly.
- Avoid locating the appliance in moist areas.
- Plug the unit into an exclusive, properly installed-grounded wall
outlet. Do not under any circumstances cut or remove the third (ground)
prong from the power cord. Any questions concerning power and/
or grounding should be directed toward a certied electrician or an
authorized Products service center.
- After plugging the appliance into a wall outlet, allow the appliance
to cool down for 2-3 hours before placing any items in the compartment
OPERATING YOUR UNIT
Setting the Temperature Control
Your wine cooler is equipped with a control panel lock feature. The lock
will automatically activate 20 seconds after the last button is pressed.

Wine Cooler - English manual 5
EN
CONTROL PANEL
Temperature & light
1. Quik press the button once for the interior light to turn ON or OFF.
The light will be turned off automatically if it remains ON for 10
minutes.
2. You can select the temperature display setting from Fahrenheit to
Celsius degree by pushing this button for two seconds.
Lock
Press and hold the button for 2 seconds to unlock the control panel. You
will hear a “BEEP” sound to alert you that the control is now active.
Temperature up & down
After unlocking you can set the temperature as you desire by pressing
the arrow pointing up (increase) or the arrow pointing down (decrease)
to adjust the temperature in 1 increment.
Note:
When you use the cooler for the rst time or restart the cooler after
having been shut off for a long time, there could be a few degrees
variance between the temperature you select and the one indicated on
the LED readout. This is normal. Once the cooler runs for a few hours
the display will stabilize.
Storage Capacity
You may place up to 24 standard-sized 75cl bottles in this wine cooler.
As bottles differ widely in size and the actual number of bottles may
vary.

Wine Cooler - English manual 6
EN
Others
1. It is intended to be used exclusively for the storage of wine.
2. This refrigerating appliance is not suitable for freezing foods.
3. The wine cooler is recommended to be designed at 12°C.
4. The shelves placed in factory mode is the most efcient use of energy
for the refrigerating appliances.
5. The following combination of shelves is recommended for energy to
be used as efciently as possible by the refrigeration unit.
COOLING
1. When the surrounding temperature is 25°C and the wine cooler has
no bottle loaded, it will take around 30 minutes to increase the wine
cooler’s temperature from 5°C to 12°C. Under the same circumstance,
it will take around one hour to decrease the wine cooler’s temperature
from 12°C to 5°C. The less the temperature span is, the less time it will
take
2. The wine cooler is recommended to be designed at 12°C. The
energy consumption is 0.389kWh/24h. If the set temperature is higher
than 12°C, the energy consumption will be lower. If the set temperature
is lower than 12°C, the energy consumption will be higher.
3. When the compressor works for 8 hours, the compressor will stop
and defrost for 45 minutes

Wine Cooler - English manual 7
EN
ELECTRIC DIAGRAM
TROUBLESHOOTING
Failure: No cooling
Possible reason: No power
Action: Check the electricity supply, or change a new plug
Failure: Poor cooling performance
Possible reason: High ambient temperature
Action: The room temperature is hotter than normal
Failure: Poor cooling performance
Possible reason: Poor instruction
Action: The door is opened too often
Failure: Poor cooling performance
Possible reason: Poor ventilation
Action: Install cooler according to our ventilation instruction
Failure: Noisy
Possible reason: Dust
Action: Clean the dust from the fan
Failure: Frost or ice inside
Possible reason: No defrost
Action: Stop working for at least one hour, then restart it
Failure: Frost or ice inside
Possible reason: Low ambient temperature
Action: Adjust the air-conditioner to be around 25degree

Wine Cooler - English manual 8
EN
DISPOSAL
Do not dispose of the device in normal domestic waste.
Dispose of the device over a registered waste disposal rm or through
your communal waste disposal facility.
Observe the currently valid regulations. In case of doubt, consult your
waste disposal facility.
WARRANTY
Dear Valued Customer,
Thank you very much for purchasing a MOA product.
We wish you to inform you that this product is covered by a warranty
which complies with all legal provisions concerning existing warranty
and consumer rights in the country where the product was purchased.
Should you nd any defect or malfunction of your MOA product,
please contact the appropriate Customer Care Center.
Sincerely yours,
The MOA Team
