Mobile Edge MEABH1 User manual

1. Introduction
Thank you for your purchase. The M100 PowerSmart Bluetooth Headset is an advanced wireless headset for
Handsfree operations. The M100 can be connected to any Bluetooth device that supports a Headset or
Handsfree profile. Three comfortable earpiece si es are included for an individuali ed secure fit.
The M100 PowerSmart Bluetooth Headset is convenient to wear and very lightweight. With its easy twist and
fold design and modern architecture, you can drive or walk the streets with Handsfree confidence.
This instruction manual will get you started!
1.1. Product Features
Bluetooth V2.0, 1.2, 1.1 compliant
Supports Headset & Hands ree pro iles
High per ormance built-in speaker
Noise suppression and echo cancellation
Red and blue LED indicators or Bluetooth operations, battery and charging
Up to 6 hours o talk time and 150 hours o standby time
Ultra Power Saving Mode up to 60 days
Smart Connection™ Allows you to answer calls by simply olding the Headset
Auto key lock prevents accidental calls when in the upright un olded position
Three (3) Ear Bud sizes or com ortable individualized it
Charge with either o the included AC charger or USB adapter

1.2. Product Specifications
•Weight – less than 10 grams
•Standards – Bluetooth Speci ication 2.0 compliant
•Range – 10 meters
•Support Pro ile – HSP, HFP
•Charger – USB Adapter, AC Adapter
•Charge Time – 2 hours
•Dimensions – 60 mm x 19 mm x 14.8 mm
1.3. Package Contents
M100 PowerSmart Bluetooth Headset
USB Adapter - AC/DC Charger Adapter
Ear Buds (3 sizes)
Lanyard (strap & clip)
User’s Manual
2. Operating Procedures
B
uttons
MFB
(Multi-Function Button)
VOL UP (+)
VOL DOWN (-)

2.1. Charging the Battery
Before using the headset, charge the battery for at east 2 hours .
Charge with either the AC Charger or connect the USB Adapter to your computer.
While charging, headset LED will turn red. When ully charged, LED will turn blue.
2.2. Switching the B uetooth Headset ON/OFF
To power the headset on, click and hold MFB until Headset LED lights up blue and then periodically
blinks blue.
To switch power o , click and hold MFB until Headset LED lights up red and shuts down.
2.3. Handsfree Operations
Function Action / Tone Indicator
Pairing Mode Powered OFF, click and hold MFB continuously or about 8 seconds until LED is
continuously displayed. From a Bluetooth phone, search or device and establish the
connection. I prompted or pin key, enter ‘0000.’ The LED will lash 10 times once
connected.
Answer Call Answer call by olding headset. I headset is already olded, press the MFB on your
headset to answer call.
Make Call Most phones automatically connect to headset once phone number is dialed. I your
phone does not support this unction, press the MFB or one second to trans er the
call.
Redial Press the MFB or one second.
Note: When MFB is pressed, some phones display the last number dialed or received.
Press MFB again to redial. Most phones allow direct redialing by clicking MFB just
once.
Voice Dial Make sure your phone supports voice dialing and that it is activated. Ensure voice tags
have been recorded. To voice dial, press MFB in idle Hands ree mode. Follow the
instructions message rom your phone to complete voice dialing.
Volume Control Click (+) or (-) to adjust volume during Hands ree mode. The tone will increase or
decrease sound while being adjusted.
End Call Press MFB. I the other party ends the call irst, the headset automatically returns to
Hands ree standby mode.
Reject Call Press and hold MFB until mobile phone stops ringing.
Ultra Power Save Mode Setting: Press and hold the MFB and volume (-) button simultaneously until the LED
light blinks.
Releasing: Press and hold the MFB and volume (+) button simultaneously until the
LED light blinks.
Mute While talking, press the volume (+ or -) button or one second. To reengage or un-
mute, press the volume (+ or -) button or one second.
Call Waiting/On Hold To place a call on hold and answer another call, press the MFB or one second and
answer the second call. Press the MFB or one second to switch back and orth
between calls. Press the MFB or less than a second to end a call.

Adjusting Transmitted
Sound Level
Factory settings are set in the middle o ive level settings. Adjust volume when
headset is olded, press and hold the volume (+) button or eight (8) seconds to
increase one level. To increase the volume more repeat the same step. To lower the
volume, press and hold the volume (-) button or eight (8) seconds to decrease one
level.
•De ault setting – Purple LED blinks two times.
•One level up rom actory setting – Blue LED blinks one time.
•Two levels up – Blue Led blinks two times.
•One level down rom actory setting – Red LED blinks one time.
•Two levels down – Red LED blinks two times.
Setting LED Blinking
Mode
LED Blinking on: In type old, press and hold volume up (+) and volume down (-)
button simultaneously until the blue LED blinks. In this mode, blue LED blinks
periodically.
LED blinking o : In type old, press and hold volume up (+) and volume down (-)
button simultaneously until the red LED blinks. In this mode, red LED blinking stops.
3. Troub eshooting
•I hear electronic static noises – For best sound quality always wear the headset on the
same side as your mobile phone.
•I can not hear anything – In crease the volume o the headset, ensure the headset is paired
with the mobile phone.
•I have problems pairing even though my phone indicates it is connected – You may have
deleted your headset pairing connection on your phone. Follow the pairing instructions in
your phone’s user manual.
•Will the M100 work with other Bluetooth devices? – The Mobile Edge M100 is designed to
work with Bluetooth mobile phones. It will work with other Bluetooth devices that are
compliant with Bluetooth version 1.1, 1.2 and support a headset/Hands ree pro ile.
4. Genera Information
•Avoid storage o extreme temperatures, as this will a ect the battery li e o the M100.
•Do not expose the M100 to rain or other liquids.

•Keep away rom children and animals.
•Please do not disassemble.
•Please only use the certi ied charger that came within the original packaging.
5. Warranty
Mobile Edge is pleased to provide the original purchaser o this accessory product a warranty
or de ects in material or workmanship under normal use and service or one year rom the date
o purchase. I you need to make a warranty claim, please provide the original receipt, on-line
registration, or other acceptable documentation. This limited warranty does not cover any
damage due to accident, misuse, abuse or negligence. Please contact Mobile Edge Customer
Service at in [e-mail] or 714-399-1400 or warranty service.
