MobiShow MS-200 User manual

User sManual
(ModelName:MS-200)
Version:1.0
Date:December5,2008

MobiShowQuickInstallationGuide AwindInc.
--
2
1)PackageContents
lMobiShowBox
lPowerAdapter(DC+5V,2.5A)
lCD-ROMwith Smartphone&PCutilitiesandUser sManualinside.
lQuickInstallation Guide
lWarrantyCard
lCarryBag
2)PhysicalDetails
lFrontPanel
lRearPanel

MobiShowQuickInstallationGuide AwindInc.
--
3
3)HardwareInstallation
1) ConnectpoweradapterDCplugto MobiShowDC
jack.
2) ConnectProjectorsVGAcableto MobiShowVGAconnectoron therear
panel.
3) Turnon projector.
4) TurnonMobiShowbox
♦Aftersystemready,the “POWER”LEDand “WLAN”LEDwillbeyellow
color.The “LAN”LEDwill beoff.
♦When LANconnection isestablished,then “LAN”LEDwillbeyellow
colorand blinkingwhiledatatransmission.
5) When MobiShowisready,thefollowingscreenisshown.
AC
plug
DC
i
n

MobiShowQuickInstallationGuide AwindInc.
--
4
4)SoftwareInstallation
4.1 DownloadfromMobiShow box
1) TurnonWiFion yourphone.
2) Connectyourphoneto MobiShowwireless network.TheSSIDisdisplayedon
screen (defaultSSIDis MobiShow).
3) Open thebrowseron yourphoneand entertheIPaddress of theMobiShowbox.
♦ThedefaultIPaddress is 192.168.100.10.
♦Or,referto theIPaddress which shownon theprojectorscreen.
4) Thefollowingweb pagewill beshownon yourbrowser.

MobiShowQuickInstallationGuide AwindInc.
--
5
5) Select “Download”to enterthesoftwaredownload page.
6) Clickthe “Download”button todownload thesoftwareinstaller(inCABformat)
to yourphone.
7) Open Exploreron yourphoneandfind theCABfile.
8) Doubleclickon theCABfileto startinstallation.
9) Followon-screeninstructionsto finishinstallation.
4.2 Install fromCD
1) ConnectyourWindowsMobilephoneto PC. Makesureitisconnectedin
ActiveSync.
2) InsertMobiShowSetup CDto PC.
3) TheAutoRunprogram willautomaticallybringup theSetup page.If thesystem
asksyou whatto do on CDinsertion,pleaseselect “Launch MobiShow Setup CD”.
4) On theSetup page,select “Install toPhone”.
5) Followtheon-screeninstructionstoinstall softwareto PC.
6) When prompted,checkthescreenof yourphoneto finish installation on your
phone.

MobiShowQuickInstallationGuide AwindInc.
--
6
7)UsingMobiShowwitha Smartphone
1) Open “Programs”on yourphoneand find “MobiShow”application.
2) Select “MobiShow”icon to launch theclientsoftware.
3) MobiShowclientwillsearchforMobiShowboxautomatically.When aboxis
found,itwillautomaticallylogin and thefollowingmain menu isshownon your
phone.
lIf morethan oneMobiShowisfound,thefollowinglistisdisplayed foryou to
selecttheoneto use.

MobiShowQuickInstallationGuide AwindInc.
--
7
4) Selectwhichfeatureto use.To projectthescreenof yourphone,clickon the
“Screen”icon.To do aPC-less presentation with Presentation-to-Go (PtG),select
the “PtG”icon.ToplayavideoorMP3fromyourphone,selectthe “Media”icon.
lScreenProjection:
MobiShowwill projectanythingdisplayedon yourscreen.You maylaunch
anotherapplication(such PowerPointViewer)oropen anyfile(such asWord
documentorJPGimage)and itwillbeprojected to theprojector.
Note:Donot exitMobiShowapplication whileopening otherapplication tokeep
screenprojected.
Clickthe “Stop”icon to stop projection.
Clickthe “Pause”icon to pauseprojection.Click “Pause”again to resume
projection.
Clickthe “Zoom”iconto zoomtheprojected screen to extend thelongestsideof
yourscreen to fillthescreen.
Clickthe “Play”icon to startprojectionagainifitis stopped.
Clickthe “OK”button or “Back”to return to main menu.

MobiShowQuickInstallationGuide AwindInc.
--
8
lWirelessPtG:
When you selectPtGfunction,MobiShowclientwill automaticallyopenExplorer
foryou to selectaPtGfile.Selectthefiletoopenforyourpresentation.When
thefileisopen,thePtGslideswillbeprojected,and thefollowingscreenis
displayed on yourphoneforyou to controlyourPtGpresentation.
Click “Prev”or “Next”to go to thepreviousornextitemin theslide.
Click “PgUp”or “PgDn”to go to previousornextslide.
Click “Stop”to stop projectingthefile.Theicon will become “Play”if thefileis
notplayed.Click “Play”again to playthefileifitisstopped.
Click “Home”to go to thefirstslide.
Click “Jump”and MobiShowclientwill showeveryslideon thephone.You can
selectanypageto go to.
Click “Open”to selectanotherPtGfile.

MobiShowQuickInstallationGuide AwindInc.
--
9
lMediaSender:
When you selectMediaSenderfunction,MobiShowclientwillautomatically
open Explorerforyou to selectamediafile.Selectafile(videosin mpegorwmv9
format,orMP3 musicfiles)to play.When thefileis open,themediawillbe
projected,and thefollowingscreenisdisplayedon thephoneforyou to control
yourmediaplayback.
Click “FR”or “FF”to seekbackwardorforward.
Click “Vol-“or “Vol+”to adjustvolumeforplayback.
Click “Stop”to stop playingthefile.Theiconwillbecome “Play”if thefileisnot
played.Click “Play”again to playthefileif itisstopped.
Click “Mute”to mutetheaudio.Click “Mute”again to bringaudioback.
Click “Open”to selectanothermediafile.
5) When you arein themain menu,clickthe “OK”button or “Back”again to close
theapplication.

MobiShowQuickInstallationGuide AwindInc.
--
10
8)UsingMobiShowwitha PC
BesidesSmartphones,you mayalso useMobiShowwith onePC. TouseMobiShow
with yourPC,followthestepsto installMobiShowclientto yourPCand use
MobiShow.
1) InserttheMobiShowSetup CDto yourPC.
2) TheAutoRunprogram willautomaticallybringup theSetup page.If thesystem
asksyou whatto do on CDinsertion,pleaseselect “Launch MobiShow Setup CD”.
3) On theSetup page,select “Install PCUtilities”.
4) Followtheon-screeninstructionstoinstall softwareto PC.
5) Afterinstallation,thefollowingshortcutswill beplaced ontheDesktop.
MobiShowPCProjectorMobiShowPtGConverter
6) Makesureyourpersonal firewallallowsMobiShowsoftwareto pass through.
7) Wheninstallationiscompleted,thisprogram willlaunch automaticallyand search
forMobiShowboxes. When aMobiShowboxisfound,thesoftwarewill
automaticallyloginifno otherPCisusingit.

MobiShowQuickInstallationGuide AwindInc.
--
11
8) Thefollowingcontrolpanelisdisplayed on yourDesktop ifitlogin successfully.
Clickthe “Play”button to startprojection.Clickthe “Pause”icon to
pauseprojection.Theiconwillbecome “Play”if projectionispaused.Click
“Play”again to resumeprojection.
Click “Stop”to stop projection.
9) Youmayswitch to “Video”paneto stream videosfromyourPC.
Clickthe “Play”button to startplaying. Click “Pause”to pausethe
streaming. Theicon willbecome “Play”if thefileispaused.Click “Play”
again to resumestreaming.
Click “Stop”to stop playingthefile.
Click “Open”to selectanothermediafile.
Click “Mute”to mutetheaudio.Click “Mute”again to bringaudioback.
Usethevolumesliderto adjustvolumeforplayback.

MobiShowQuickInstallationGuide AwindInc.
--
12
9)UsingPtGConverter
Open “MobiShow PtGConverter”in “MobiShow\MobiShow PtGConverter”folder
from “Programs”in theStartmenu.Thefollowingcontrolpanelisdisplayedon your
Desktop when itislaunched.
Clickthe “Convert”button to selectaPowerPointPPT fileand startconversion.
PtGConverterwill openthePowerPointfileandconvertitto PtGformat.You can see
theconversion process on yourDesktop.
Clickthe “Preview”button to expand orcollapsethepreviewpane.Click “
Play”to playbackselectedPtGfile,orclick “Open”to selectaPtGfile.

MobiShowQuickInstallationGuide AwindInc.
--
13
10)WebManagement
nHomePage
♦MakesureyourPCconnectto MobiShowboxsuccessfully.
♦Open yourbrowser,andentertheIPaddress of yourMobiShowon thebrowser.
♦TheIPaddress isdisplayed on thebottomof theprojectorscreen.
♦ThedefaultIPis192.168.100.10
nLoginWebAdmin
♦Click[Admin] andthen enterpassword to login web page.
♦Thepassword defaultvalueis “admin”.

MobiShowQuickInstallationGuide AwindInc.
--
14
nSystemStatus
*** Click [SystemStatus], showscurrentsystemstatus.
Model Name:Productmodelname
Versions:
♦Firmwareversion no.:Productfirmwareversion number.
♦Softwareversionno.:Windowsclientutilityversion number.
NetworkStatus:
♦IPaddress IPaddress of MobiShowdevice.
♦SubnetMask subnetmask
♦DefaultGateway defaultgateway
♦Wireless MACaddress wireless MACaddress
♦WireMACaddress wireMACaddress
Connection Status:
♦Projectingstatus:whichis “Waitingforprojecting”or “Projecting”
♦TotalUsers:Itshowshowmanyuserslogininto MobiShowbox.

MobiShowQuickInstallationGuide AwindInc.
--
15
nNetworkSetup
Therearemanykindsofoperatingconfigurationsasbelow.
<Auto-Configuration NetworkSetup>
Thedefaultsettingof theMobiShowboxisDHCPclient.When theMobiShowboxis
connected toaLAN thatalreadyhasaDHCPserverpresent,theMobiShowboxtakes
an IPaddress assigned to itbytheserver.When theMobiShowboxisconnected to a
LAN thatdoesnothaveaDHCPserver, theMobiShowboxbecomestheDHCPserver
in thenetwork.
<IPSetup>
Youcan select “obtain IPaddress automatically”or “UsethefollowingIPaddress”
♦IPAddress:Thedefaultvalueis192.168.100.10.
♦SubnetMask:Thedefaultvalueis255.255.255.0
♦DefaultGateway:Thedefaultvalueis192.168.100.10

MobiShowQuickInstallationGuide AwindInc.
--
16
<DHCPServerSetup>
Youcan select “Auto”or “Disable”.When “Auto”isselected,itwillautomatically
disableDHCPonMobiShowisanotherDHCPserverisdetected,otherwiseitwill
enableitsDHCPservice.
♦StartIP:ThestartIPaddress of DHCPServer.
♦End IP:Theend IPaddress of DHCPServer.
<Wireless Setup>
♦Wireless LAN:youcan select “Enable”or “Disable”
♦Region:defaultvalueis “Worldwide”.
♦SSID:SSIDstring,max. Length is32 bytes.
♦SSIDBroadcast:you can select “Enable”or “Disable”
♦Channel:to setfixed channelorAuto.The “Auto”meansafterpoweron iShow,
itwillscan allof wireless channeland selectclearonechannelautomatically.
♦WEP:you canDisableWEPkeyorselectoneof 64bitor128bitinASCII orHEX
string.
♦Key:If WEPisenabled,youhaveto setkeyvalueaccordingto WEPmodeyou
selected.
<Apply>: press button to selectthismode
<Cancel>: press buttonto abortaction.
<Back>: Backto Operatingmodemain menu
nProjectionSetup
*** Click [Projection Setup] button

MobiShowQuickInstallationGuide AwindInc.
--
17
<Resolution>:XGA(1024X768)orSVGA(800X600).
<ScreenRefreshRate>:ThisisVGAoutputrefreshrate,provides60 Hzand 75Hzto
suitfordifferentkindsofprojectors.
<Apply> Confirmation and Savemodifications
<Cancel>: Cancelallthemodifications
nChangePasswords
*** Click [ChangePassword] button,tochangepassword value.
<EnterNew Password>: enternewpassword you wantto changeforeach category.
<ConfirmNew Password>:doubleconfirmnewpassword.
<Apply>: Confirmationand Savemodifications.
nResettoDefault

MobiShowQuickInstallationGuide AwindInc.
--
18
*** Click [Reset toDefault] button torestorefactorydefaultsettings.
<Apply>: Confirmationand action.
nFirmwareUpgrade
*** Click [FirmwareUpgrade] buttonto upgradefirmware.
♦Firstly,you haveto getlatestfirmwareimagefilefromyourvendor.
♦Click <Browse> to specifyfilenameyou wantto upgrade.
♦Click <Upgrade> to start.
When upgradeinprocess,theLEDturnstored.Theupgradeprocess takesabout7
minutesto complete.Itwill rebootoncefirmwareupgradeisfinished.Ifforsome
reason itdoesnotrebootafter15 minutes, pleasemanuallyturnoff thedeviceand
turn on again.
Warning: Don tpoweroff MobiShowwhilefirmwareupgradein progress,
otherwisewillcauseyourBoxdoesn tworkand haveto return deviceto yourvendor
forfixing.

MobiShowQuickInstallationGuide AwindInc.
--
19
nRebootSystem
*** Click [Reboot System] button,torestartsystem
<Reboot>: rebootsystemautomatically.
