Mobotix M16 AllroundDual Instructions for use

Mx-M16
32.845-004_EN_09/2017
Quick Install
M16 AllroundDual
Sensor Module Combinations
M16
Modular 6MP Dual Camera with Day/
Night and Thermal Sensor Modules
for Installation on Ceilings or Walls
MOBOTIX 6MP camera for exible installation in
indoor and outdoor applications, available as M16
AllroundDual with sensor modules SMA-S-6D/N/L016 to
500 with Day/Night or Night-LPF image sensors. Special
“Thermal” model with one Thermal image sensor SMA-
TP-T079/119/237 for thermal imaging and temperature
measurement (-TR) even in complete darkness, optionally
with one additional optical sensor module.
More information:
www.mobotix.com > Products > Outdoor Cameras > M16
Standard Delivery M16
1.1
1.10
1.11
1.12
1.8
1.7
1.4 1.3
1.6
1.9
1.2
1.5
M.5
M.3
M.2
M.1
M.6
M.7
M.8
M.10
M.11
M.4
1.15
1.19
1.16
1.17
M.9
1.18
1.20 1.13
1.14
Standard Delivery
Item Count Part Name
1.1 1 Camera housing with mainboard and wall mount (installed), with-
out sensor modules and front element
1.2 1 Front element with additional sensors (installed)
1.3 2 Transport plugs (installed)
1.4 1 Blind module (must be installed when using only one sensor mod-
ule)
1.5 4 Inner housing cover (installed)
1.6 4 Stainless steel Allen screw with at head M4x8 for inner housing
cover (installed)
Standard Delivery
Item Count Part Name
1.7 2 Cable lock black with bayonet catch (Ethernet patch cable, USB, one
installed, one supplied)
1.8 2 Single wire plug, blue (USB, installed)
1.9 1 MicroSD card (SDXC, SDHC pre-installed)
1.10 1 Ethernet patch cable, 50 cm/19.7 in with sealing (installed)
1.11 2 Sensor module cable 15 cm/6 in (installed in camera)
1.12 1 I/O cable with red clips to front element 15 cm/6 in (installed)
1.13 1 Hinged ferrite for Ethernet cable (installed)
1.14 1 Hinged ferrite for sensor module cable (installed)
1.15 2 Rubber plug for covering mounting screws, white
1.16 3 Stainless steel Allen screw M6x30 (installed)
1.17 3 Stainless steel washer dia. 6.4 mm (installed)
1.18 1 Stainless steel spring washer dia. 6.4 mm (wall/ceiling mount,
installed)
1.19 1 Stainless steel lock nut M6 (wall/ceiling mount, installed)
1.20 1 Rubber plug, black (installed)
Mounting Supplies
Item Count Part Name
M.1 4 Stainless steel washer dia. 6.4 mm
M.2 4 Dowels 8 mm
M.3 4 Stainless steel wood screw with hex head 6x50 mm
M.4 1 Allen wrench 2.5 mm
M.5 1 Allen wrench 5 mm
M.6 1 Lens wrench (SMA-S-6D/N/L016 lens, glass/lter insert, dome)
M.7 1 Module key (sensor module, focusing of lenses)
M.8 1 Rubber sealing for wall/ceiling mount, white
M.9 1 Ceiling mount for VarioFlex mount
M.10 4 Protection cover for screw, white
M.11 4 Security clip for sensor or blind modules, red
Opening/Closing the Camera Housing
The following tasks require opening the camera housing and removing the front element of the M16 in order to get to the interior of the camera:
Inserting the security clips , exchanging the Ethernet patch cable , connecting the USB cable , exchanging the MicroSD card (see also «Inserting/Exchang-
ing the SD Card» on page 2 ).
CAUTION: Make sure the power supply to the camera is disconnected before opening the housing!
1.Opening the Camera Housing
Place the camera face-down on a clean and dry surface. Remove the two
rubber plugs at the back of the camera housing. Using the supplied 5 mm
Allen wrench, loosen the two bolts at the back of the camera housing.
Leave the bolts and washers in the camera housing.
Using the Allen wrench, cautiously push from behind in an alternating
fashion onto the le and the right bolt 1 and push the front element
out of the front of the housing.
Tilt the front element forward as shown in the gure 2.
2.Inserting the Security Clips
To protect the modules against unwanted removal, insert the two red
security clips at the insides of the sensor modules at the proper location
(1 inserted, 2 locked). Make sure that the security clips are properly
locked in their seatings 3.
3.Closing the Camera Housing
Before inserting the front element, make sure that the sensor module cables
of both image sensors are running at the inside of the screw bore 1.
Place the camera on its right side (as seen by the camera) as shown and
insert the front element. When pushing the front element into the housing
(2, red arrows), take care not to crush any cables.
When inserting and closing the front element, take special care to guide
the cable of the le sensor module under the rubber hook 3!
Press the front element into the camera housing by evenly applying pres-
sure 4. Tighten the screws with washers.
Finally, apply the rubber plugs at the back of the housing that you removed
earlier.
1
2
12
3
4
2
1
3
Preparing the M16 for Installation
To facilitate the installation of the camera, you should complete the following tasks before actually installing the camera.
1. CAUTION!
• Only exchange sensor modules when powered o!
• When operating the camera with only one sensor module, always install
the supplied blind module. No operation with transport plugs!
• Thermal sensor modules are always pre-installed and cannot be removed!
2.Installing the Sensor Modules
Remove the plastic nut from the sensor module
1
. Remove the transport
plugs 2.
Push the sensor module cable plug into the connector at the back of the
module housing 3. Secure the plug using the blue bayonet catch as
shown 4.
Insert the sensor module. Make sure that the MOBOTIX lettering on the
sensor module is at the “9 o'clock” position as shown in the gure 5.
Place the back of the black module wrench onto the two holes of the sen-
sor module 6.
Using the black module wrench, turn the sensor module clockwise until
it stops 7. If desired, insert the two security clips 8. Open the camera
housing as described in «Opening/Closing the Camera Housing» .
M16 with one blind module:
Unrestricted operation
(IP66)
M16 with two transport
plugs:
No operation allowed!
M16 with one transport
plug:
No operation allowed!
1
2
34
8
7
M
O
B
O
T
I
X
6
M
O
B
O
T
I
X
5
Sensor Modules of the M16 (to Be Ordered Separately, Thermal Sensor Pre-Installed)
Protective
glass insert
Plastic nut
Sensor module
SMA-S-6D/N/L036–237
Lens cover
Sensor module
SMA-S-6D/N/L500
Top (markings)
Sensor module cable
Rear
(all except Thermal)
Dome
Plastic nut
Sensor module
SMA-S-6D/N/L016
Connections and Initial Operation of the M16
You can nd detailed information on the installation and connections of the M16 in the M15 Camera Manual (PDF, available on www.mobotix.com >
Support > Manuals).
Please note that the position of the SD card holder has changed (see gure below, at the right), the boot options of this camera have changed compared
to its predecessor (see «Boot Options of the M16» on page 2 ) and the camera only has one key ("L"). Regarding the rest of the initial operation of
the M16, please see the M15 Camera Manual in Chapter 3, «Initial Operation» .
I/O cable to front
element (red clips)
Ethernet patch cable
Sensor mod-
ules
USB
Front element
Sensor module R
Ethernet
Sensor module L
USB
Slot for microSD card
Camera housing
Sensor mod-
ules
LEDs
PIR sensor
Wall Mount
Key L
Front element
• Mx6 system platform, H.264 support
• Recording on internal microSD card (SDXC, SDHC installed)
• Audio integrated (microphone and speaker)
• Sensor for temperature and shock detector(*) integrated
• PIR detector integrated
• Convertible to ceiling installation (ceiling mount included)
• Simply mounted to poles using Pole Mount (accessory)
• Weatherproof and sturdy camera housing(IP66, IK04)
2 optical
Day/Night/LPF
1 optical
Day/Night/LPF
1 Thermal/Thermal-TR,
1 optical Day/Night/LPF
*: with rmware version 5.0.1 and higher

MOBOTIX AG
Kaiserstrasse
D-67722 Langmeil
Tel.: [phone]
Fax: [phone]
[email protected]
www.mobotix.com
Declaration of Conformity: www.mobotix.com > Support > MxMedia Library > Certicates
MOBOTIX, the MX logo, MxControlCenter, MxEasy, MxPEG and MxActivitySensor are trademarks of
MOBOTIX AG registered in the European Union, the U.S.A., and other countries • Information subject to
change without notice • MOBOTIX does not assume any liability for technical or editorial errors or omissions
contained herein • All rights reserved • © MOBOTIX AG 2017
Technical Specications M16/M16-Thermal/M16-Thermal-TR
Model Versions
Mx-M16 (any comb. of Day/Night/LPF sensor modules)
MX-M16-Thermal (optionally one add. Day/Night/LPF sensor
module)
Lens Options Mx Sensor
Module 10 to 270 mm (35 mm format), hor. angles of view 180° to 8° (6MP)
Lens Options
Thermal Image Sensor
43, 65, 135 mm (in 35 mm format),
45°, 25°, 17° horizontal angle of view
Sensitivity
Mx Sensor Module
Color sensor (6MP): 0.1 Lux at 1/60 s, 0.005 Lux at 1 s
Black&White sensor (6MP): 0.02 Lux at 1/60 s,
0.001 Lux at 1/1 s
Sensitivity
Thermal Image Sensor
NETD typ. 50 mK, IR range 7.5 to 13.5 μm
Range of temperature measuring: –40 to 550 °C/–40 to 1,022 °F
Precision Sensor Module Thermal-TR: ±10 K of the thermal radia-
tion received at the sensor
Image Sensor
Mx Sensor Module 1/1.8” CMOS, 6MP, progressive scan
Image Sensor
Thermal Image Sensor Uncooled microbolometer, 336x252 pixels
Max. Image Size
Mx Sensor Module
Color: 3072x2048 (6MP), 6144x2048 (12MP)
Black&White: 3072x2048 (6MP), 6144x2048 (12MP)
Max. Image Size
Thermal Image Sensor
Can be scaled up to 3072x2048 (6MP), automatically scaled to size
of Mx sensor module
Image Formats
(Independent of Type,
Per-Sensor Setting)
3072x2048 (6MP), 2592x1944 (5MP), 2048x1536 (QXGA), 1920x1080
(Full-HD), 1280x960 (MEGA), 1280x720 (HD), 1024x768, 800x600,
768x576 (D1-PAL), 704x576 (TV-PAL), 640x480, 384x288, 320x240,
160x120, custom formats
Max. Frame Rate
Mx sensor module
• MxPEG* (max): 42@HD (1280x720), 34@Full-HD, 24@QXGA,
15@5MP, 12@6MP, 6@2x6MP
• M-JPEG* (max): 26@HD (1280x720), 13@Full-HD, 9@QXGA,
5@5MP, 4@6MP, 2@2x6MP
• H.264 (max): 25@Full-HD, 20@QXGA
*Single core use only
Max. Frame Rate
Thermal Image Sensor
9 fps (when displaying an Mx sensor module and a thermal sensor
module, the overall frame rate of the camera is reduced to 9 fps)
Image Compression MxPEG, M-JPEG, JPEG, H.264
Internal DVR MicroSD card (SDXC, SDHC pre-installed)
External
Video Ring Buer
Directly on NAS or PC/Server, no additional recording soware
required
Soware (Included) MxManagementCenter video management soware
Image Processing
Backlight compensation, automatic white balance, image distor-
tion correction, panorama correction, video sensors (video motion
detection/MxActivitySensor), optional o-color/black & white
display of thermal image sensor
Virtual PTZ Digital pan/tilt/zoom, continuous up to 8X
Alarm/Events
Video Motion detection, MxActivitySensor, external signals, tem-
perature sensor, PIR, microphone, shock detector (with rmware
version 5.0.1 and higher), notication via e-mail, FTP, IP telephony
(VoIP, SIP), visual/sound alarms, pre- and post-alarm images
Microphone and
Speaker Integrated microphone and speaker
Audio Functions Lip-synchronous audio, two-way communication, audio recording
Interfaces Ethernet 100Base-T, MiniUSB;
inputs/outputs and RS232 via accessories
Video Telephony VoIP/SIP, two-way communication, remote controlling using key
codes, event notication
Security User/group management, HTTPS/SSL, IP address lter, IEEE 802.1x,
intrusion detection, digital image signature
Certications
EN55032:2012, EN55022:2010; EN55024:2010; EN50121-4:2015,
EN61000-6-1:2007; EN 61000-6-2:2005, EN61000-6-3:2007+A1:2011,
EN61000-6-4:2007+A1:2011, AS/ NZS CISPR22:2009+A1:2010, CFR47
FCC part15B
Power Supply Year-round Power-over-Ethernet (IEEE 802.3af);
PoE class variable (M16-Thermal(-TR): class 3 required)
Power Consumption
M16: Typ. < 4.5 W with one sensor module, < 5 W with two sensor
modules
M16-Thermal/M16-Thermal-TR Typ. < 5 W with thermal image
sensor, < 5.5 W with 1 additional sensor module
Operating Conditions IP66, –30 to 60 °C/–22 to 140 °F,
air humidity up to 90–100% (according to EN 50155 Chap. 12.2.5)
Protection Against
Mechanical Impact
(According to IEC 62262/EN 50102)
M16 with hemispheric sensor modules: IK07
M16 with other sensor modules: IK04
Dimensions
M16, M16-Thermal(-TR)
W x H x D with wall mount: 158 x 244 x 239 mm;
W x H x D with ceiling mount: 158 x 210 x 207 mm
Weights M16 without
Sensor Modules
Weight with wall mount: approx. 1,160 g
Weight with ceiling mount: approx. 1,110 g
Weights
M16-Thermal(-TR)
without Add. Sensor
Module
Weight with wall mount: approx. 1,320 g
Weight with ceiling mount: approx. 1,270 g
Dimensions/Weights
Sensor Modules
SMA-S-6D/N/L016: Ø x D: 43 x 45 mm (installation dim.), weight 85 g
SMA-S-6D/N/L041/079: Ø x D: 43 x 57 mm (installation dim.), weight
111 g
SMA-S-6D/N/L061/119/237: Ø x D: 43 x 60 mm (installation dim.),
weight 122 g
SMA-S-6D/N/L500: Ø x D: 43 x 60 mm (installation dim.), weight
160 g
Standard Delivery
Housing (high-resistance composite, PBT), white, shock-resistant
dome for SMA-S-6D/N/L016 sensor module, coated glass pane
for all other Mx sensor modules, protective Germanium cover
for thermal image sensor (only M16-Thermal/M16-Thermal-TR),
accessories for installation on wall and ceiling, Allen wrench, 50 cm
patch cable, soware, MicroSD card (pre-installed)
Important Notes
Safety Warnings
Notes on Installing:
• This product must not be used in locations exposed to
the dangers of explosion.
• Make sure that you install this product as outlined in
Chapter 2, «Installation» of the corresponding manual.
A faulty installation can damage the camera!
• When installing this product, make sure that you are only
using genuine MOBOTIX parts and MOBOTIX connection
cables.
• Only install this product on suitable, solid materials that
provide for a sturdy installation of the xing elements
used.
Electrical installation: Electrical systems and equipment may
only be installed, modied and maintained by a qualied
electrician or under the direction and supervision of a qualied
electrician in accordance with the applicable electrical guide-
lines. Make sure to properly set up all electrical connections.
Electrical surges: MOBOTIX cameras are protected against
the eects of small electrical surges by numerous measures.
These measures, however, cannot prevent the camera from
being damaged when stronger electrical surges occur. Special
care should be taken when installing the camera outside of
buildings to ensure proper protection against lightning, since
this also protects the building and the whole network infra-
structure.
Never touch the lenses: Due to the high performance of the
M16, the area of the image sensor canget quite hot, especially
when the ambient temperature is also high. This does not
aect the proper functioning of the camera in any way. For
this reason, the product must not be installed within the reach
of persons without domes or protective lens covers.
Power o before opening the camera: Make sure the power
supply to the camera is disconnected before opening the cam-
era housing (e.g., when inserting or exchanging lenses, lens
units and SD cards).
Network security: MOBOTIX products include all of the nec-
essary conguration options for operation in Ethernet net-
works in compliance with data protection laws. The operator
is responsible for the data protection concept across the entire
system. The basic settings required to prevent misuse can be
congured in the soware and are password-protected. This
prevents unauthorized parties from accessing these settings.
Attention – Special Export Laws Apply!
Cameras with thermal image sensors (“thermal cameras”) are
subject to the special export regulations of the U.S.A. and the
ITAR (International Traic in Arms Regulation):
• According to the currently applicable export regulations
of the U.S.A. and the ITAR, cameras with thermal image
sensors or parts thereof must not be exported to coun-
tries embargoed by the U.S.A. or the ITAR. At present,
this applies to the following countries: Syria, Iran, Cuba,
North Korea and Sudan. The same export ban applies to
all persons and institutions listed in “The Denied Persons
List” (see www.bis.doc.gov > Policy Guidance > Lists
of Parties of Concern).
• Under no circumstances must the camera itself or its thermal
image sensors be used in the design, the development
or in the production of nuclear, biological or chemical
weapons or in the weapons themselves.
Legal Notes
Legal aspects of video and sound recording: You must comply
with all data protection regulations for video and sound mon-
itoring when using MOBOTIX products. Depending on national
laws and the installation location of the M16, the recording of
video and sound data may be subject to special documentation
or it may be prohibited. All users of MOBOTIX products are
therefore required to familiarize themselves with all applicable
regulations and to comply with these laws. MOBOTIX AG is not
liable for any illegal use of its products.
Disposal
Electrical and electronic products contain many valuable
materials. For this reason, we recommend that you dispose
of MOBOTIX products at the end of their service life in accor-
dance with all legal requirements and regulations (or deposit
these products at a municipal collection center). MOBOTIX
products must not be disposed of in household waste! If the
product contains a battery, please dispose of the battery sep-
arately (the corresponding product manuals contain specic
directions if the product contains a battery).
Disclaimer
MOBOTIX AG does not assume any responsibility for damages,
which are the result of improper use or failure to comply to the
manuals or the applicable rules and regulations. Our General
Terms and Conditions apply. You can download the current
version of the General Terms and Conditions from our web-
site at www.mobotix.com by clicking on the COS link at the
bottom of every page.
§
§
§
Boot Options of the M16
By default, the camera starts as DHCP client and automatically tries to get
an IP address from a DHCP server. To start the camera in a mode dierent
from the default mode, you can activate the boot menu of the camera.
1.Preparing the Camera
• Disconnect the camera's power supply.
• Make sure that you have suitable item such as a paper clip at hand,
but never use sharp or pointed objects!
• Reconnect the power supply of the camera.
2.Activating the Boot Menu
The red LED lights up 5 to 10 seconds aer establish-
ing the power supply and will stay on for 10 seconds.
Briey press the key by inserting the paper clip into
the hole indicated by the red circle in the gure. The
camera enters the boot menu, ready for selecting one
of the boot options.
The LED now ashes once and repeats the ash signal aer pausing for
one second (the number of ashes indicates the current boot option). To
go to the next boot option, briey press the key again (< 1 sec). Aer the
last boot option, the camera returns to the rst option (LED ashes once).
LED
ashes
Boot
Option Meaning Audio Conrmation*
1 x Not used Not available on this camera model. —
2 x Factory
Defaults
Starts the camera with factory defaults
(factory default IP address, users and
passwords will not be reset).
Boing
3 x Automatic IP
Address
Starts the camera as DHCP client and
tries to obtain an IP address from a DHCP
server. If a DHCP server cannot be found or
no IP address can be obtained, the camera
starts with its factory default address.
Boing Boing
4 x Recovery
System
Starts the camera with the recovery sys-
tem, e.g., in order to recover from a failed
update of the camera soware.
Alarm Sound
*Only on cameras with audio option and installed speaker.
3.Selecting a Boot Option
Press the paper clip longer (> 2 sec) into the hole. The camera conrms the
selection by ashing rapidly three times. You can now remove the paper
clip. Aer 20 sec, the camera will conrm the selection by playing a sound
according to the table above.
If nothing is selected, the camera will resume its normal boot process
aer a certain time.
Installing the M16
1.Drill the holes for the dowels (if required)
Use the drilling template for this step (see below).
Mark the holes for dowels or screws (blue cir-
cles in gure). If required, drill the holes for
the dowels, push them in and cut the hole for
the cables. Guide the Ethernet cable and any
other cables that are to be connected through
the cut-out.
2.Install the camera
Press the wall/ceiling mount and the wall sealing
against the mounting position and align the
holes with the holes for the dowels/screws.
Insert the screws with washers and tighten
them using a torque of 0.4 Nm. Finally, press
the white covers onto the screw heads.
Inserting/Exchanging the SD Card
All camera models can use the integrated microSD card (SDHC) to record video data. In order to exchange the microSD
card, please proceed as outlined in the following instruction. For information on reliable SD cards, please see the MOBOTIX
website www.mobotix.com > Support > MxMedia Library > Planning in the document MicroSD Card Whitelist for
MOBOTIX Cameras .
When replacing the SD card, make sure that recording has been deactivated in the browser ( Admin Menu > Storage >
Storage on External File Server / Flash Device ; activate recording again in the same dialog aer exchanging the card).
1.Remove the SD Card
Open the camera (see «Opening/Closing the Camera
Housing» on page 1 ), remove all connectors in the
cover of the inner housing, then remove the cover. Using
your ngernail, carefully slide the metal cover of the slot
in the direction of the arrow and ip the cover open.
You can now li the card out of the slot.
2.Insert the SD Card
Place the MicroSD card into the slot and lock the cover
by carefully sliding it in the direction of the arrow. Make
sure that the cover is locked properly. Apply the cover
of the inner housing and reconnect the cabling. Finally,
install the front element of the camera (see «Opening/
Closing the Camera Housing» on page 1 ).
Dimensions/Drilling Template
244 mm/9.61 in
199 mm/7.83 in
158 mm/6.22 in
106 mm/4.17 in
239 mm/9.41 in
106 mm/4.17 in
244 mm/9.61 in
199 mm/7.83 in
210 mm/8.27 in
199 mm/7.83 in
158 mm/6.22 in
106 mm/4.17 in
207 mm/8.15 in
244 mm/9.61 in
199 mm/7.83 in
80 mm/3.15 in
80 mm/3.15 in
75 mm/2.95 in
15 mm/
0.59 in
Interface Box
Wall/ceiling mount M16
