Mobotix Mx-VB2A-5-IR-VA Original operating instructions

NOTE!
This guide is only valid for installing and connecting the 5MP Vandal Bullet Analytics Camera. For
more information on the camera, please refer to the other documents (see Further Reading, p. 8).
Important Installation Notes
nThis camera must be installed by qualified personnel and the installation should conform to
all local codes.
nTo prevent damage when adjusting the camera's field of view, loosen the corresponding
screws. Once done. tighten the screws again.
nTo ensure that the unit is not affected by vibration, twisting, etc., properly tighten all mount-
ing screws.
nThis product must not be used in locations exposed to the dangers of explosion.
nDo not look directly into the infra-red LEDs that may be active on the product.
nDo not use this product in a dusty environment.
nProtect this product from moisture or water entering the housing.
nInstall this product as outlined in this document. A faulty installation can damage the
product!
nDo not replace batteries of the camera. Risk of explosion may occur if the battery is replaced
by an incorrect type.
nThis equipment is not suitable for use in locations where children are likely to be present.
nExternal power supplies must comply with the Limited Power Source (LPS) requirements and
share the same power specifications with the camera.
nWhen using a ClassI adapter, the power cord shall be connected to a socket-outlet with
proper ground connection.
nTo comply with the requirements of EN50130-4 regarding the power supply of alarm systems
for 24/7 operation, it is highly recommended to use an uninterruptible power supply (UPS) for
V1.07_7/26/2022, Order Code: Mx-VB2A-5-IR-VA
Quick Installation
MOBOTIX 5MP Vandal Bullet Analytics Camera
Mx-VB2A-5-IR-VA
©2022MOBOTIX AG

Quick Installation 5MP Vandal Bullet Analytics Camera
backing up the power supply of this product.
nThis equipment is to be connected only to PoE networks without routing to other networks.
NOTE! Observe the MOBOTIX MOVE Installation Hints document to ensure optimum performance
of the camera features.
CAUTION! To prevent damage when adjusting the camera's field of view, loosen all corresponding
screws. Once finished, tighten these screws again.
NOTE! To ensure that the unit is not affected by vibration, twisting, etc. after adjusting the camera,
properly tighten all mounting screws.
All-in-One Cable
No Cable Pin Definition Remarks
1RJ-45 – For network and PoE connections
2Audio I/O Green Audio Out / Mic Out
(Line Out)
Two-way
audio trans-
mission
Pink Audio In / Mic In
(Line In)

3BNC – For analog video output
2 / 9

No Cable Pin Definition Remarks
4Alarm I/O
(5-pin Ter-
minal
Block)
1 Alarm In 2+ Alarm con-
nection
Do NOT con-
nect external
power supply
to the alarm
I/O connector
of the IP cam-
era!
2 Alarm In -
3 Alarm In 1+
4 Alarm Out -
5 Alarm Out +
5Power
(DC 12V /
AC 24V)
(2-pin Ter-
minal
Block)
1 DC 12V − AC 24V 1 Power con-
nection
2 DC 12V + AC 24V 2
Desiccants Removal
Before installation, remove the desiccants on the vent at the bottom of the camera body. The loc-
ation of the desiccants is shown below.
Quick Installation 5MP Vandal Bullet Analytics Camera
3 / 9

Quick Installation 5MP Vandal Bullet Analytics Camera
microSD Card Slot/Default Button
The positions of microSD card slot and default button are shown as below.
microSD Card Slot
Insert the microSD card into the card slot to store videos and snapshots. Do not remove the microSD
card when the camera is powered on.
NOTE! It is not recommended to record with the microSD card for 24/7 continuously, as it may not
be able to support long term continuous data read/write. Contact the manufacturer of the
microSD card for information regarding the reliability and the life expectancy.
Default Button
Press the default button with a proper tool for at least 20 seconds to restore the system.
Connecting Power
Using Power over Ethernet (PoE)
Use a PoE switch (Class0) and connect the Ethernet cable to the RJ-45 port of the camera.
Using AC24V or DC12V
To power up the camera, connect either the DC12V or the AC24V power adapter to the power con-
nector of the camera and the power outlet.
4 / 9

Diagram and Pin Definition for AC24V Power Connection
Pin Definition
1AC24V L
2GND
3AC24V N
Ethernet Cable Connection
Connect one end of the Ethernet cable to the RJ-45 connector of the camera and plug the other end
of the cable into the network switch or PC.
NOTE!
nThe length of the Ethernet cable should not exceed 100m/300ft.
nCheck the status of the link indicator and the activity indicator LEDs of the switch. If the
LEDs are unlit, please check the LAN connection.
nIn some cases, an Ethernet crossover cable may be needed when connecting the camera dir-
ectly to the PC.
Ethernet Connector LEDs
nGreen Link LED indicates good network connection.
nOrange Activity LED flashes for network activity indication.
NOTE! The ITE is to be connected only to PoE networks without routing to the outside plant or
equivalent description.
Accessing the Camera
The 5MP Vandal Bullet Analytics Camera supports all current browsers without requiring any addi-
tional plug-ins or add-ons (e.g. for H.264/H.265/MJPEG support).
Camera Login
The default IP address of the camera is: 10.x.x.x. By default, the camera starts as DHCP client and
automatically tries to get an IP address from a DHCP server.
1. Enter the camera’s IP address in the URL bar of the web browser and hit “Enter”.
2. Enter the default username (admin) and password (meinsm).
NOTE! User names and passwords are case sensitive.
Quick Installation 5MP Vandal Bullet Analytics Camera
5 / 9

Quick Installation 5MP Vandal Bullet Analytics Camera
3. You will be prompted to set a new admin user password.
NOTE! The password can have between 6 and 16 characters (at least one digit, no special char-
acters allowed).
4. After setting a new password, you will be prompted to log in again. Remember to use the new
password.
Browser-Based Viewer
The main page of the IP camera user interface is shown as the figure below. The function buttons
vary depending on the camera model.
6 / 9

Camera Maintenance
It is recommended that you perform the following maintenance tasks at regular intervals to keep
the 5MP Vandal Bullet Analytics Camera in good working condition:
nClean the front glass using plain water and a soft cloth.
CAUTION! Do not use any detergents or alcohol to prevent damaging the coating!
nCheck the mounting and make sure that all screws are properly tightened to prevent the cam-
era from falling down.
nWhen opening the camera, add a silca gel dry pack to prevent condensation accumulating at
the front glass.
Quick Installation 5MP Vandal Bullet Analytics Camera
7 / 9

Quick Installation 5MP Vandal Bullet Analytics Camera
Further Reading
Manuals and Quick Installation documents
Technical Specifications
MOBOTIX MOVE Installation Hints
8 / 9
