M25 Camera Manual
EN
Security-Vision-Systems
M25 Allround B036 to B500
M25 Allround B016
M25 Allround CSVario
More Camera For Less. Guaranteed!
The M25 series from MOBOTIX oers extremely compact, cost-eective and exceptionally powerful
6MP allround cameras with the widest range of lenses, including panorama version. Fully equipped
with IP66-certified housing and long-term internal storage on a MicroSD card.
2/128
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
M25 Camera Manual: Contents
MOBOTIX Seminars
MOBOTIX oers inexpensive seminars that include workshops and practical exer-
cises.
For more information, visit www.mobotix.com > Seminars.
Copyright Information
All rights reserved.
MOBOTIX
, the MX logo,
MxManagementCenter
and
MxPEG
are
trademarks of MOBOTIX AG registered in the European Union, the U.S.A., and other
countries.
Microsoft
,
Windows
and
Windows Server
are registered trademarks of
Microsoft Corporation.
Apple
, the Apple logo,
Macintosh
,
OSX
,
iOS
,
Bonjour
, the
Bonjour logo, the Bonjour icon,
iPod
and
iTunes
are trademarks of Apple Inc. registered
in the U.S.A. and other countries.
iPhone
,
iPad
,
iPad mini
and
iPod touch
are Apple
Inc. trademarks.
Linux
is a trademark of Linus Torvalds. All other marks and names
mentioned herein are trademarks or registered trademarks of the respective owners.
Copyright © 1999-2015 MOBOTIX AG, Langmeil, Germany. Information subject to
change without notice!
Download the latest version of this and other manuals as PDF files from
www.mobotix.com> Support > Manuals.
THE MOBOTIX INFORMATION CHANNELS
MOBOTIX Support on the MOBOTIX Website
www.mobotix.com/other/Support
The MOBOTIX Video Tutorials
www.mobotix.com/other/
Support/Tutorials
Seminars on MOBOTIX Campus
www.mobotix.com/other/
Partners/Seminars
The MOBOTIX YouTube Channel
www.youtube.com/MOBOTIXAG
3/128
Contents
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
CONTENTS
1 Product Overview 10
1.1 M25 Allround 10
1.1.1 General Product Characteristics 10
1.2 M25 with Special Lens Hemispheric B016 20
1.2.1 Advantages and New Features 26
1.2.2 Decentralized Video System 28
1.2.3 Green IP Video 30
1.3 Technical Specifications 32
1.3.1 Lens Options 32
1.3.2 Lenses, Hardware, Image Formats 34
1.3.3 Software Features 35
1.3.4 Technical Data 36
1.4 Delivered Parts and Dimensions 38
1.4.1 M25 Camera 38
1.4.2 Dimensions for Wall Installation 42
1.4.3 Dimensions for Ceiling Installation 42
1.4.4 Dimensions of Wall Mount 43
1.4.5 Drilling Template Wall and Ceiling Mount 43
1.5 Available Accessories 44
1.5.1 Lens Cover with Glass Pane 44
1.5.2 Pole Mount 44
1.5.3 MiniUSB Cable to MiniUSB (Straight/Angled) 44
1.5.4 MiniUSB Cable to MiniUSB (Angled/Angled) 45
1.5.5 MiniUSB Cable to USB-A Socket 45
1.5.6 Ethernet Patch Cable for Bayonet Catch 45
1.5.7 NPA-PoE-Set 45
1.5.8 MX-Overvoltage-Protection-Box 46
1.5.9 MX-NPA-Box 46
1.5.10 MX-GPS-Box 46
1.5.11 MX-232-IO-Box 47
1.5.12 ExtIO Expansion Module 47
1.5.13 Mx2wire+ Media Converter 47
1.5.14 Security Screw Set with Allen Bit 48
1.5.15 Other Accessories 48
1.6 MOBOTIX Software 49
1.6.1 Integrated Camera Software (Firmware) 49
1.6.2 MxManagementCenter 50
1.6.3 MOBOTIX App 51
4/128
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
M25 Camera Manual: Contents
2 Installation 52
2.1 Preparing the Installation 52
2.1.1 Mounting Options: Wall, Ceiling, Pole 52
2.1.2 Mounting with Hemispheric Lens B016 55
2.1.3 Network Connection and Power Supply, UPS 58
2.1.4 Preparing the Camera Connections, MX-Overvoltage-Protection-Box 59
2.1.5 Wiring, Fire Prevention, Lightning and Surge Protection 60
2.2 Mounting the Camera with Wall Mount 61
2.2.1 VarioFlex Wall Mount 61
2.3 Mounting the Camera with Ceiling Mount 65
2.3.1 VarioFlex Ceiling Mount 65
2.4 Mounting the Camera with Pole Mount (Accessory) 69
2.4.1 Pole Mount (MX-MH-SecureFlex-ESWS) 70
2.5 Adjusting the Camera and Exchanging the Lens 74
2.5.1 Adjusting the Camera 74
2.5.2 Correcting the Image Horizon (for B016 Lens Only) 74
2.5.3 Exchanging the Lens 75
2.6 Replacing the MicroSD Card 76
2.6.1 Removing the MicroSD Card 76
2.6.2 Inserting the MicroSD Card 77
2.7 Network and Power Connection 78
2.7.1 Notes on Cable Lengths and Power Supply 78
2.7.2 Network Cabling For M25 With Patch Cables 78
2.7.3 Power Supply Using a Switch 79
2.7.4 Power Supply When Connected Directly to a Computer 80
2.7.5 Power Supply with Power-Over-Ethernet Products 80
2.7.6 Connecting a USB Cable 81
2.7.7 Connecting a Two-Wire MxBus Cable 82
2.7.8 Variable PoE 83
2.7.9 Camera Startup Sequence 84
3 Operating the Camera 86
3.1 Manual and Automatic Operation– Overview 86
3.2 First Images and the Most Important Settings 88
3.2.1 Manually Setting Up the Network Parameters in a Browser 88
3.2.2 First Images and the Most Important Settings in the Browser 91
3.2.3 First Images and Network Parameter Configuration in MxMC 93
3.2.4 Starting the Camera with Factory (Network) Settings 96
3.2.5 Starting the Camera with an Automatic IP Address (DHCP) 97
5/128
Contents
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
3.3 Virtual PTZ and Full Image Recording 98
3.3.1 Preparing the Virtual PTZ Function 98
3.3.2 Full Image Recording 100
3.3.3 Special M25 Configuration in the Browser 102
3.4 MicroSD Card Recording 109
3.4.1 Introduction 109
3.4.2 Formatting the MicroSD Card 111
3.4.3 Activating MicroSD Card Recording 112
3.4.4 Accessing Data on the MicroSD Card 113
3.4.5 Deactivating Card Recording 113
3.4.6 Using a MicroSD Card in a Dierent MOBOTIX Camera 113
3.4.7 Limitations on Warranty When Using Flash Storage Media 114
3.5 Configuration in the Browser 115
3.5.1 Overview 115
3.5.2 General Browser Settings 117
3.6 Additional Notes 119
3.6.1 Protecting the Camera Against Condensation 119
3.6.2 Password for the Admin Menu 120
3.6.3 Permanently Deactivating the Microphone 121
3.6.4 Starting the Camera with the Factory IP Address 121
3.6.5 Resetting the Camera to Factory Settings 121
3.6.6 Activating Event Control and Motion Detection 121
3.6.7 Deactivating Text and Logo Options 121
3.6.8 Deactivating the Camera Reboot 122
3.6.9 Browser 122
3.6.10 Cleaning the Camera and Lens 122
3.6.11 Legal Notes 122
3.6.12 Safety Warnings 123
3.6.13 Online Help in the Browser 124
3.6.14 Declaration of Conformity 124
3.6.15 Disposal 124
3.6.16 Disclaimer 124
Manufacturer 127
6/128
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
M25 Camera Manual: Contents
Legal Notes
Legal aspects of video and sound recording: You must comply with all data protec-
tion regulations for video and sound monitoring when using MOBOTIX products.
Depending on national laws and the installation location of the M25, the recording
of video and sound data may be subject to special documentation or it may be
prohibited. All users of MOBOTIX products are therefore required to familiarize them-
selves with all valid regulations and comply with these laws. MOBOTIX AG is not
liable for any illegal use of its products.
§
7/128
Contents
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
Safety Warnings
Installation Instructions:
•
This product must not be used in locations exposed to the dangers of explosion.
• Make sure to install this product as shown in
Chapter 2, «Installation»
of this
manual.
•
When installing this product, make sure that you are only using genuine MOBOTIX
parts and MOBOTIX connection cables.
• Make sure that you are installing this product on a solid surface that provides
for a sturdy installation of the fixing elements used.
Electrical installation: Electrical systems and equipment may only be installed,
modified and maintained by a qualified electrician or under the direction and super-
vision of a qualified electrician in accordance with the applicable electrical guidelines.
Make sure to properly set up all electrical connections.
Electrical surges: MOBOTIX cameras are protected against the eects of small elec-
trical surges by numerous measures. These measures, however, cannot prevent the
camera from being damaged when stronger electrical surges occur. Special care
should be taken when installing the camera outside of buildings to ensure proper
protection against lightning, since this also protects the building and the whole
network infrastructure.
Max. power consumption of attached extension modules: The power consump-
tion of all attached
MxBus modules
must
not exceed 2.5W
. When attaching mod-
ules to the MxBus connector
and
the USB connector, the
power consumption of all
attached modules must not exceed 3W
,
if the camera is powered by PoE class3
.
If
PoE class2
is used,
the power consumption of all attached modules must not
exceed 1W!
Never touch the lens: Due to the high performance of the M25, the area of the
image sensor can get quite hot, especially when the ambient temperature is also
high. This does not aect the proper functioning of the camera in any way. For this
reason, the product must not be installed within the reach of persons without the
lens cover.
Power o before opening the camera: Make sure the power supply is disconnected
before opening the camera (i.e., for installing or replacing sensor modules and SD
cards).
Network security: MOBOTIX products include all of the necessary configuration
options for operation in Ethernet networks in compliance with data protection laws.
The operator is responsible for the data protection concept across the entire system.
The basic settings required to prevent misuse can be configured in the software and
are password-protected. This prevents unauthorized parties from accessing these
settings.
8/128
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
M25 Camera Manual
FOREWORD
Dear MOBOTIX customer,
Congratulations on your decision to purchase a professional and modern
HiRes network camera “Made in Germany”! The robust and versatile M25 is
a cost-ecient and professional mono camera solution with interchangeable
lenses for indoor and outdoor applications (IP66). You can select from a wide
range of lenses, from Hemispheric to Super Wide-Angle to Tele lenses (now
up to 320mm) and CSVario lens. Add to that the proven advantages that are
inherent to the MOBOTIX concept, such as the integrated event, alarm and telephone
features and the modern long-term storage directly in the camera with all of its benefits.
The weatherproof MxBus and MiniUSB interfaces of the camera allow attaching
MOBOTIX interface boxes and standard devices, such as 3G/UMTS modems, external
storage devices, etc. The integrated SD card flash storage is easily exchanged for larger
storage requirements, providing for secure long-term storage.
The introduction of the newest image sensor technology with increased light sensitivity
in combination with the new HD Premium lenses (f/1.8) provides brilliant images with
image sizes of up to 3072x2048 pixels, thus delivering color images of higher quality
under lowlight conditions. The LPF (“Long-Pass Filter”) night variants have been designed
for special purposes, such as number plate recognition, for example.
You can download the MxManagementCenter video management software for
MOBOTIX cameras from the MOBOTIX website: www.mobotix.com> Support >
Software Downloads. For the iPad, iPhone and iPod touch iOS devices, MOBOTIX oers
the MOBOTIX App, a free-of-charge mobile solution that is easily found when searching
for “MOBOTIX AG” in the App Store.
If you have any questions, our support and international sales sta are available at
from Monday to Friday, 8am to 6pm (German time).
We would like to thank you for your trust and wish you all the best with your new MOBOTIX
camera M25 Allround!
10/128 M25 Camera Manual: Product Overview
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
1 PRODUCT OVERVIEW
1.1 M25 Allround
1.1.1 General Product Characteristics
Model Variants
The M25 is available with dierent feature sets. By default, the M25 is equipped with either
a color or a Black&White image sensor (Day/Night) and an B041 Super Wide-Angle
lens (horizontal angle of view of 90°). If desired, the camera can be fitted with one of
seven other lenses with horizontal angles of view of 8°, 15°, 31°, 45°, 60°, 103° and
180° or it is available as a special version with CS Vario lens. Every M25 comes with a pre-
installed and formatted MicroSD card and a VarioFlex mount for fast and easy installation.
Due to its extreme distortion, the M25 with the B016 Fisheye lens is especially challenging
where the adjustment of hardware and software is concerned. For this reason, the lenses
B036 to B500 B016 CSVario
11/128
M25 Allround
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
of the B016 variant are not interchangeable. The fine-tuning of the lens at the factory is an
extremely laborious and precise process and the setting should not be changed any more.
Complete HiRes Video Solutions by MOBOTIX
As opposed to conventional solutions, MOBOTIX cameras with their decentralized approach
oer so much more – state-of-the-art, network-based video security technology that increases
operating eciency and yields a high degree of every-day usefulness.
Extraordinary Picture Quality
Image quality is the one key criterion of a security camera. Due to their internal video analysis
and data storage capabilities, the decentralized MOBOTIX systems are independent of the
available network bandwidth. As a result, the system provides for eciently storing and
managing the video streams of a virtually unlimited number of cameras with the highest
resolution at a reasonable cost.
6 Megapixel Image Sensors (6MP)
MOBOTIX cameras possess high-resolution image sensors with 6megapixel resolution and
excellent light sensitivity, which translates into more details when zooming and more clear-
cut advantages for every user. By using the 6MP technology in their color and black&white
image sensors, MOBOTIX cameras deliver convincing image quality and details even in
bad weather and under lowlight conditions. Another important plus: thanks to its internal
pre-processing of the image data, the camera can generate video streams with up to
30 frames per second.
6MP Image Format: 3 Times More Detail Than Full HD
The 6MP sensor has a resolution of 3072x2048 pixels on both day and night sensors. This
means that the full image information is available in the live image and in the recordings.
Low Light Conditions– No Problem
The maximum resolution of the color and black&white image sensors is 6megapixels.
The higher light sensitivity of the new color image sensors now allow using MOBOTIX color
cameras around the clock even when the illumination is low.
MxLEO: Exposure Optimization and Reduced Image Noise
MxLEO– the MOBOTIX Lowlight Exposure Optimization– is an innovative technology that
provides an entirely new experience in digital image optimization in all cameras running
firmware 4.1.9 and higher. On the one hand, the improved light sensitivity of the MOBOTIX
6MP sensors drastically reduces exposure times. MxLEO, the exposure and image optimi-
zation program especially developed for these conditions, on the other hand, generates
perceptibly better and more detailed images especially under low-light conditions below
25Lux. Such conditions are typical at a parking lot at night that is illuminated by regular
lights (approx. 10 to 25Lux). Or in a building after hours, in which the emergency lights
are burning (approx. 5Lux). This significantly reduces motion blur that is typical of longer
12/128 M25 Camera Manual: Product Overview
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
exposure times with little light and thus provides much more image detail (faces, license
plates, etc.) for proper identification.
Hemispheric Technology
Thanks to the fisheye technology with integrated distortion correction, MOBOTIX Hemispheric
cameras with their B016 lenses provide the perfect overview. Meaningful 180-degree
panorama images from wall-to-wall and from the floor to the ceiling don’t leave any
corners of the room unmonitored. In contrast to other systems, the correction of the dis-
torted hemispheric image happens directly in the camera and not on the computer, thus
drastically reducing the size of the image before it is transferred and stored. This approach
reduces the network load and allows showing dozens of hemispheric cameras on a
computer or a smartphone.
Robust and Maintenance-Free
Thanks to its low power consumption of about 4.5 Watts
and the total absence of mechanically moving parts, the
M25 models feature a wide operating temperature range of
–30 to +50 °C/–22 to +122 °F. Since MOBOTIX cameras neither
fog up nor require heating, power can be supplied via the
network cabling using standard PoE products according to PoE
standard IEEE 802.3af. M25 models are absolutely dustproof
and resistant against water jets (IP66). In combination with the
supplied M25 wall and ceiling mount, you can use the camera in outdoor applications and
installation over flush-mounted sockets so that the cabling remains perfectly concealed.
A Master of Adaptability
The M25 models are accompanied by an extensive range of easily replaceable and
interchangeable lenses and a robust lens protector made of scratchproof special-purpose
plastic or glass. Application-optimized options for installation on walls, ceilings and poles, for
supplying power, or expanding the functions of the camera are also available. Furthermore,
MOBOTIX customers can take advantage of the professional video management software
MxManagementCenter free of charge and with an unlimited user and camera license.
If required, an M25 can even be upgraded to function as a powerful intercom system by
adding the MOBOTIX ExtIO module.
High-Resolution Sees More and Costs Less
One M25 equipped with a hemispheric or standard wide angle lens is usually all that
is required to monitor either an entire room or the four lanes of a gas station. The high
degree of image detail not only reduces the number of required cameras, but also mini-
mizes system costs by reducing the wiring complexity, emergency power requirements
and number of recording devices required. All M25 cameras feature direct recording to
VarioFlex wall mount
with concealed cabling
perfectly covers ush-
mounted sockets
MOBOTIX ExtIO
(Function Extension)
13/128
M25 Allround
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
integrated MicroSD cards or external USB drives and can therefore be used in standalone
operation without creating additional network load.
Universal Application from Vacation Homes to Airports
MOBOTIX M25 cameras are suitable for use in large-scale facilities, such as airports, given
their unlimited scalability and high performance. However, they are equally suitable for
use in small commercial or private buildings thanks to their integrated event, storage,
alarm and telephony functions. In addition, MOBOTIX recommends the M25 with hemi-
spheric B016 lens as a superb and inspiring webcam.
The Right Lens for Every Application
No MOBOTIX camera has ever had so many lens options! For the M25, MOBOTIX oers
seven lenses ranging from the 8° tele to the 180° Fisheye lens.
One Camera For Four Gas Station Lanes –
Long-Term Recording Without Additional Devices
HiRes Video
MOBOTIX original
image of 180° pan-
orama (B016 lens)
MOBOTIX original image
of 90° Super Wide-Angle
14/128 M25 Camera Manual: Product Overview
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
In combination with the hemispheric B016 lens (180° horizontal angle of view), the M25
becomes a Hemispheric camera.
The M25-CSVario is an M25 model that is shipped with a CS mount and a compact
B045–100 1/2” Vario lens. To protect the lens against the weather, this version comes with
a longer lens cover and threads for an external filter. This cover will work for lenses, which
have a maximum diameter of 36mm and which are not longer than 43mm. Because
of the image sensor’s size of 1/2.5”, you can only use CS and C mount lenses (C mount
lenses with adapter ring) for 1/2.5” sensors or larger. In comparison with MOBOTIX fixed
lenses, Vario lenses are less robust and less reliable in the long run. For this reason, Vario
lenses are typically used in applications where recording conditions change frequently,
e.g., for surveillance of dierent construction sites.
MOBOTIX Standard Lenses Are Easily Exchanged
Note that you can change all lenses of the M25 yourself on site whenever necessary
(except the hemispheric B016 lens). The ordered lens is factory-aligned and quality-tested
in the camera, which makes on-site camera focusing unnecessary in most cases. Each
M25 is available for delivery with a lens of your choosing or no lens at all.
MOBOTIX original
image of 180° pan-
orama (B016 lens)
The software of an M25
equipped with an B036 or
B041 lens allows correct-
ing the distorted image
MOBOTIX original
image (B237 tele)
15/128
M25 Allround
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
The image area captured by the camera varies depending on the selected lens (see
Section 1.3, «Technical Specifications»
). With a Super Wide Angle lens (e.g., B041 with 90°),
for example, almost an entire room can be recorded from one corner. An B237 Tele lens
enables an M25 with a high-resolution 6 megapixel sensor to clearly record a license
plate number, for example, from a distance of approximately 75meters.
Or even the serial number of a bill from a distance of 2m/6ft.
MOBOTIX original
image (B237 tele)
16/128 M25 Camera Manual: Product Overview
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
Virtual PTZ (vPTZ) – Without Motor
The M25 can also zoom in on details. This vPTZ function (virtual Pan, Tilt, Zoom)
is a standard feature in the integrated M25 camera software. The image
from the hemispheric camera can be enlarged using, for example, the
mouse wheel, a joystick or a software-controlled PTZ panel and you can
“move” the view to any section of the image. This provides the features of
a mechanical PTZ camera without the disadvantages of maintenance and
wear.
Depending on the platform used to operate the camera (Internet browser,
MxManagementCenter), the vPTZ function may work in a dierent manner. When using
MxManagementCenter specific software tools and an optional joystick make virtually
zooming, panning and tilting much more comfortable. Even if you are using only an Internet
Explorer (with activated ActiveX plug-in), you can use an optionally attached joystick.
Quick and easy naviga-
tion with a USB joystick
vPTZ
vPTZ
17/128
M25 Allround
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
Simultaneous Corrected Live Image and Full Image Recording
All conventional, motorized PTZ cameras only store the image that is currently viewed as
the live image (live image recording). This has one serious disadvantage as the recording
can only show what has happened in the “visible” portion of the image; the rest is lost and
cannot be examined later on. For this reason, MOBOTIX has added the new full image
recording feature to the M25. This will not store the currently viewed image that reflects
the pan/tilt position and the zoom setting chosen by the user, but the full sensor image,
without vPTZ settings or image correction. When examining the recorded images, the
vPTZ features again come into play, as they allow zooming the visible image and using
the pan/tilt features to examine every corner of the recorded full image.
Example: The persons highlighted by the red circles in the center image would not have
been recorded by a regular PTZ camera; the full image recording of the M25 in this example
allows determining the exact time at which these persons had entered the image area
recorded by the camera. A browser (Internet Explorer with MxPEG ActiveX plug-in) or
MxManagementCenter can be used to examine the recorded sequences.
Integrated vPTZ func-
tions allow the com-
plete stored full image
to be analyzed at a
later point in time (in
MxManagementCenter)
Live Image Stored Full Image Analysis in Full Image
Live Image Stored Full Image Analysis in Full Image
18/128 M25 Camera Manual: Product Overview
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
Internal DVR
The M25 features direct recording to the integrated MicroSD card,
which makes the camera fully independent of any external storage
media, even for longer periods of time. The camera internally stores
high-resolution video, without requiring an external recording device
or PC and therefore without overloading the network whatsoever. Old
recordings can be overwritten automatically or automatically deleted
after a specified period of time. When using a 16GB SD card, for
example, the camera can store more than a quarter million event
images in VGA format (640x480). For security reasons, the camera
can even encrypt the stored data.
Power failures are not an issue, since the video and image sequences remain safely
stored on the SD card. Access to stored video sequences is possible at any time from
the camera user interface in the browser or MxManagementCenter. If you would like to
archive sequences, you can export the required data to a PC or USB stick for evidence
purposes, for example.
MxActivitySensor Video Motion Analysis: Secure Detection, Avoiding False Alarms
Regardless if there are large objects in the foreground or small objects in the background–
MxActivitySensor will only trigger video recording and alarm messaging if something
important is happening. Interference such as trees shaking in the wind, moving shadows
and clouds and snow falling will no longer lead to false alarms. Since all of this is filtered
automatically, all that remains is to set the direction of movement of objects that should
trigger alarms.
MicroSD card already
integrated in the camera.
20/128 M25 Camera Manual: Product Overview
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
1.2 M25 with Special Lens Hemispheric B016
Equipped with the 180° B016 lens, an entire room can be ideally monitored using only one
M25, which replaces the time-consuming and expensive installation of several standard
cameras. The overview image provided by a single M25, which may be personalized in a
number of ways according to specific user requirements, not only reduces the number of
required cameras, but also minimizes the system costs by reducing the wiring complexity,
emergency power requirements and number of recording devices required.
B016 Lens: High-Resolution 180° Panorama
When several cameras are monitoring a single room, it is dicult to understand the room
layout due to the dierent viewing directions of each individual camera. This makes it hard
to comprehend the overall setting. The new panorama function of the M25 with the B016
lens delivers a widescreen, corrected image of a high-resolution 180° allround view. High
image quality is achieved through the use of a six-megapixel color sensor and the new
hemispheric lens of the M25.
With approximately 0.6 megapixels (1280x480 pixels), an M25 panorama image only
requires a fraction of the original data volume or bandwidth of a 6MP full image (3072x2048
pixels).
6MP full image (3072x2048 pixels)
Panorama image with 0.6 megapixels (1280x480 pixels)
Corrected image after
panorama correction
Economical bandwidth
usage due to smaller,
camera-corrected
images (no loss of
image information)
Table of contents
Other Mobotix Digital Camera manuals
Mobotix
Mobotix M16 AllroundDual Instructions for use
Mobotix
Mobotix Q26 User manual
Mobotix
Mobotix S26 Flex Instructions for use
Mobotix
Mobotix p26 Instructions for use
Mobotix
Mobotix Mx-VB2A-5-IR-VA Original operating instructions
Mobotix
Mobotix S26 Flex Instructions for use
Mobotix
Mobotix i26 Hemispheric User manual
Mobotix
Mobotix M26 Allround Series User manual
Mobotix
Mobotix Q25 User manual
Mobotix
Mobotix BeyondHumanVision V16 Vandalism Original operating instructions
