Hamptons Bench Seat
1
Assembly Instructions
mocka.co.nz | mocka.com.au |
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A
Hardware Supplied
70mm screw
x4
B
50mm screw
x6
C
spring
washer
x10
F
dowel
x10
G
allen key
x1
D
flat washer
x4
E
screw pin
x6
Read the instructions carefully. Refer to the hardware and furniture parts list for
guidance. Be sure all of the pans are complete before assembling. Place all of the
wooden furniture parts on a clean and flat soft surface to prevent scratches.
Refer to the steps provided as an assembling guide.
CAUTION :
1. Do not tighten the nuts or nut bolts completely until they are all in place.
2. To avoid thread damage, avoid overtightening nuts or nut bolts.
3. Hardware is to be kept out of reach of children.

12
Hamptons Bench Seat
2
Assembly Instructions
mocka.co.nz | mocka.com.au |
Attach 1 x bench leg (2) and 1 x bench seat (1) and secure with 2 x
70mm screws (A), 2 x spring washers (C) and 2 x screw pins (E).
Tighten with an Allen Key (G).
Hammer 4 x dowels (F) into panel [1] as shown.
G
A
C
E
1
2
1
F

4
3
Assembly Instructions
mocka.co.nz | mocka.com.au |
Hamptons Bench Seat
Attach 1 x central rail (3) to assembled frame and secure with 2 x
dowels (F), 1 x spring washer (C), 1 x 50mm screw (B) and 1 x screw
pin (E). Tighten with an Allen Key (G).
G
B
C
E
3
F
3
Attach 1 x bench leg (2) and 1 x bench seat (1) and secure with 2 x
50mm screws (B), 2 x spring washers (C) and 2 x flat washers (D).
Tighten with an Allen Key (G).
G
B
C
1
2
D

6
4
Assembly Instructions
mocka.co.nz | mocka.com.au |
Hamptons Bench Seat
5
Attach 1 x bench leg (2) to assembled frame and secure with 2 x spring
washers (C), 2 x 70mm screws (A) and 2 x screw pins (E). Tighten with
an Allen Key (G).
GA
CE
Attach 1 x bench leg (2) to assembled frame and secure with 3 x spring
washers (C), 3 x 50mm screws (B) and 3 x screw pins (E). Tighten with
an Allen Key (G).
GB
CE
GBC
D

Once assembled lift furniture into place, do not drag. Ensure unit
is balanced and steady before use. You’re done, enjoy!
