MOD BIKES LIGHT User manual

OWNER’S MANUAL
P. 5
MOD LIGHT OWNER’S MANUAL
DESIGNED AND ENGINEERED IN AUSTIN TX

OWNER’S MANUAL
P. 5
Congratulations on your MOD BIKES purchase!
MOD BIKES is a uniquely engineered and designed line
of e-bike models which represent the next generation
of mobility. Our goal is to bring people out of their cars,
out of traffic, and into a lifestyle experience that meets
needs they didn’t know they had.
Ready to get moving?
MOD BIKES

OWNER’S MANUAL
Info Labels
Getting Started
Safety
Assembling your Bike
First Use
Display and Control Panel
Battery and Charger
Maintenance
Warranty
4
5
6
7
8
9
11
12
13
Contents
Disclaimer: This guide is intended to provide information to help you
best use your MOD BIKE. The information provided here is intended for
informational purposes only and is subject to change without notice.
Please note that this is not a legal document.

You’re just a few steps away from your first ride! Before you head off, please read this
user manual, which contains information to ensure that you have a better and safer
experience and get more life and fun out of your MOD BIKES e-bike.
To make things easy, we labeled the different kinds of information in this guide as follows:
Attention Tip Enviromental NoteWarning
P. 4

OWNER’S MANUAL
P. 5
15. Pedal
16. Crank
17. Chain
18. Deraileur
19. Freewheel
20. Reflective Sidewall
21. Taillight
22. Rack
23. Saddle
24. Seat Post
25. Main Folding Lever
26. Battery
27. Charging Port
28. Shifter
2
3
4
5
6
7
8
9
10
11
12
14
15
16
17
19
21
22
1
Parts list:
1.Display
2.Brake Lever
3.Stem
4.Cable Cover
5.Folding Stem Lever
6.Headlight
7.Headset
8.Tire
9.Rotor
10. Hub
11. Rim
12. Spoke
13. Caliper
14. Fender
18
23
24
25
28
26
20
Getting Started
Know Your MOD BIKES
27
13

OWNER’S MANUAL
P. 6
Riding any kind of
bicycle involves risks
and can result in
damages, injuries and
even death. You are
responsible for your
MOD BIKES product,
experience and safety.
Please read these
instructions and ride
carefully.
Using your MOD BIKES is done at
your own risk. MOD BIKES is not liable
for any accidents, or injuries.
• For safe riding, make sure you choose a bike that is
appropriate for your height and weight.
• Always wear a helmet, make sure it is the right size for
you, it fits snugly and that you buckle it when riding.
• Wear protective clothing and equipment for your riding
level and terrain.
• Turn on your lights when riding in the dark or in low-
visibility conditions.
• Keep in mind that you will be significantly more visible if
you wear bright clothing.
• Keep your MOD BIKES e-bike maintained and in good
working order. For more information, see page 12.
• Read the full battery and charger instructions on page
11.
• Be aware of your surroundings, pedestrians, motor
vehicles and other cyclists. Be courteous to other
riders, and be sure to comply with all traffic laws, rules
and regulations.
• Follow all city rules and regulations that apply to your
area.
• You are responsible for any changes you make to your
MOD BIKES e-bike.
• MOD BIKES are marked with speed and weight
limitations. Please note that exceeding these limits are
done at your own risk.
• Wet conditions impair traction, braking and visibility for
cyclists and other motor vehicles on the road. During wet
conditions, the risk of an accident is significantly higher.
Be aware of the risks and ride with extra care.
• Do not attempt to perform jumps, stunts or any other
tricks that are outside the parameters of this e-bike.
Regulations for electric bicycles
and scooters vary by region and are
constantly being updated. Check with
your local authorities to find out how
to use your e-bike in your area.
This guide may not include the
most recent updates. You can always
find our latest guide online at www.
mod-bikes.com.
MOD BIKES is not liable for accidents,
injuries or product malfunctions that
occur as a result of unauthorized changes/
modifications or tampering with any part of
the original product.
1
Safety

OWNER’S MANUAL
P. 7
Please follow these
instructions
for unboxing and
assembling your
MOD BIKES e-bike.
You may also visit
www.mod-bikes.com
for a detailed video. We
highly recommend that
you seek out the help of a
skilled mechanic with this
assembly.
These instructions are meant to
serve as a guide only. The images
used throughout the guide are for
demonstration purposes only. Your
actual bike may look different from
the one shown here.
Congratulations on
your MOD BIKES
purchase.
It’s time to get it out
of the box and onto
the road!
1. Take all the contents out of the box.
2. Remove all the packaging.
3. Unfold the bicycle.
4. Assemble and tighten both wheels.
5. Fill both tires with air (35 psi).
6. Lean the bike on the kickstand.
7. Tighten all three stem screws.
8. Assemble the seat post.
9. Install pedals.
All MOD BIKES packaging
material is recyclable. Please
dispose of all packaging in a green
and environmentally friendly way!
Your MOD BIKES box contains
everything you need to assemble your
bike. You don’t need any other tools.
Don’t feel like assembling your
bike on your own? Please visit your
nearest bike shop for assistance.
2
Assembly

9. Shift gears using your shifter with your
right hand: 1 is for slow speed and high
torque, while 7 is for high speed with
better efficiency. Ensure you only shift
gears when pedaling to avoid snapping
your chain.
10.Brake using the right lever (for the
rear wheel) and left lever (for the front
wheel). In most cases, we recommend
using both brakes together gently, but
in some cases, one set of brakes will
suffice. Make sure to learn how your
brake system works and how to use it
properly.
OWNER’S MANUAL
P. 8
• Make sure you read this
user guide carefully.
• Always wear safety gear,
including a helmet.
• If you need to make an
abrupt stop, pull off the
road to a safe spot away
from other vehicles,
pedestrians and any
other obstacles.
• Before riding, make
sure your battery is fully
charged.
Did you know that on average, 50%
of car trips can be replaced with an
electric bike? By choosing a bike over a
car, you’re reducing pollution and doing
your part to ensure that we can all live
on a greener and healthier planet.
Ready to ride?
Here are a few
things to keep in
mind before you get
moving.
Let’s get moving!
1. Charge your battery using the MOD
BIKES charger provided. The charger
light is red when charging and
turns green when it’s fully charged.
2. Connect the battery by sliding the
battery into place and locking the
battery or door using your MOD BIKES
key.
3. Go over the safety checklist on page 6
before every ride.
4. Adjust the seat and handlebars. If
you’re new to electric bikes, for your
first few rides, adjust your seat so that
you can reach the ground with your
feet when your legs are straight. After
riding for a while and getting used to
the feeling, you can raise your seat to
a more comfortable height.
5. Turn the display on by holding the “i"
button on the control panel.
6. Turn the lights on by holding the “+”
button on the control panel.
7. Adjust your driving mode by pressing the
“+” and “–“ buttons: 0 means no pedal
assist, 1 is slow pedal assist, 2 is higher
pedal assist and so on. This MOD BIKES
model allows you to use the throttle
for maximum-speed without having to
pedal.
8. Ride using pedal assist, the throttle or
both. You may also pedal normally to
use your e-bike as a regular bicycle.
No matter how you choose to ride, ride
safely.
Riding at full throttle requires
experience and appropriate safety
equipment.
Get to know the MOD BIKES
display and its unique features!
Check out page 9.
Do not raise your seat post above
the maximum-height mark. This can
put pressure on and compromise the
frame.
3
First Use

OWNER’S MANUAL
P. 9
General operation:
• To switch your MOD BIKES on or off, hold down
the “i” button for 2 seconds.
• To switch the lights on or off, hold down the “+”
button for 2 seconds.
• Change the pedal assistance level from 0 to 5
using the “+” and “–” buttons.
• Use the “i” button to move between the
odometer and the trip info.
• To access the settings menu, hold down the “+”
and “–” buttons together for 2 seconds. Then
use “+” and “–” to scroll back and forth and “i”
to select and save. To exit the settings menu and
save, hold the “i” button for 2 seconds. To exit
without saving, hold down the “–” button for 2
seconds.
To conserve battery power, your
bike’s display will automatically turn
off after 10 minutes of inactivity.
To ensure proper functioning,
keep your bike’s display and control
panel dry at all times.
Got an error message? Please
visit your nearest MOD BIKES shop
for assistance.
Your MOD BIKES has a smart LCD display with
unique features for better riding.
*USB charging port is located under the display lip.
The display has the following:
• Battery indicator
• Assistance level indicator
• Bike light indicator (on/off)
• Motor power indicator
• Speedometer
• Odometer and trip info
• Error Code indicator
• USB Charging Port
4
Display and Control panel

OWNER’S MANUAL
P. 10
To extend you range and battery
life, we recommend setting your
current between 12A- 14A.
For your safety and convenience,
we recommend you do not alter or
change any setting designtated as
“Manufacturer default.”
*Please scroll down on your MOD display to access options 10 and 11.
4
Display and Control panel
The display includes the following settings:
1. Clear Trip: Allows the user to reset the trip
computer. To clear the trip, select YES on
this menu.
2. Set Unit: Sets Imperial or Metric units.
Set Metric for kilometers and Imperial for
miles.
3. Wheel Diameter: Inputs programmed
wheel diameter for accurate speed results.
(Manufacturer default; Do not change)
4. Speed Limit: Adjusts the speed
limiter. When enabled, the limiter will
automatically keep the bike from exceeding
the programmed speed.
5. Set Voltage: Defines the battery indicator
levels (Manufacturer default; Do not
adjust)
6. Set Power: Choose the number of pedal
assist levels (from 3 to 9) and adjust each
level’s amount of assist by percentages
(from 0% to 100%)
7. Set Current: Adjust for increased or reduced
acceleration response. The higher, the number,
the faster the motor accelerates. (Do not
exceed 18A)
8. Assistant Number: Programs the pedal assist
sensor for accurate response (Manufacturer
default; Do not adjust)
9. Speed Sensor: Programs the speed sensors for
accurate results (Manufacturer default; Do not
adjust)
10.Set Backlight: Adjusts the brightness of the
screen.
11.Set Password: When enabled, locks the bike
and deactivates the MOD electric system.
Unlocks when the user’s correct pin is entered.
To set the PIN, enter the default PIN of 1212 by
pressing the “+” button to increase the number
in the highlighted field and the “i” button to
move to the next field. When on the fourth field,
press the “i” button to confirm. Can be disabled
or changed from the menu once default PIN is
entered.

OWNER’S MANUAL
P. 11
Please follow these instructions for using your battery and charger:
• To charge your battery, connect your 36V or 48V charger to your
battery charging port. Then connect the charger plug to your home
power outlet.
• During charging, the charger indicator will show a red light. Once the
charging is complete, the light will turn green.
• When the light indicates that charging is complete, unplug the
charger from the battery and the outlet.
• MOD BIKES batteries do not have the memory effect, they can be
briefly charged at anytime regardless of their charging state without
having a negative impact.
• If you plan on storing your bike without using it for 30 days or longer,
we recommend leaving the battery charged to 50%. Storing the
battery either empty or full can cause irreparable damage.
Single charge range is affected by many different
factors. There is no way to determine the exact range
for your MOD BIKES e-bike, but there are several
ways to get better range and performance out of your
bike:
• Adjust the system preferences to your needs.
• Pedal and use pedal assist.
• Don’t overload your bike.
• Starting requires a lot of battery power—use the
pedals to give that extra push when starting, then
ride at a steady safe speed.
• Keep your tires inflated to 35 psi.
• Charge your battery until full before each ride.
• Take care of your bike and keep it well maintained.
Always charge your bike’s battery
with the original MOD BIKES charger
and the right voltage (36V or 48V).
Using a different charger can cause a
fire.
All MOD BIKES use
batteries containing
high-quality lithium
ion cells and a
smart battery
management
system, for
long-lasting,
rechargeable
energy.
Your MOD BIKES battery and
charger may get hot when charging.
Do not leave unattended.
Your bike wants to be ridden!
Storing it for long periods of time
without using it can cause a decline
in the battery’s performance.
5
Battery and Charger

OWNER’S MANUAL
P. 12
Battery and charger safety warnings:
• Your MOD BIKES battery and charger may get hot when charging. Do not leave unattended.
• If the charger indicator light flashes, do not use it. Contact your local MOD BIKES dealer for
assistance.
• Keep your battery well protected. Store it away from humidity, liquids and flammables, and at a
temperature between 50 and 85°F.
• Your battery may get hot during use. Let it cool before charging.
• Keep your battery away from water, as it can cause irreparable damage.
• Do not open the battery pack.
• If the battery is damaged because of any kind of accident, stop using it immediately, as there may
be a risk of liquid leakage. If any liquid leaks onto your skin, rinse the affected area with water and
seek medical help immediately.
• When your battery has reached the end of its service-life, recycle or dispose of it properly.
Contact your local waste disposal or environmental agency for advice on disposing lithium ion
batteries.
Always charge your bike’s battery
with the original MOD BIKES charger
and the right voltage (36V or 48V).
Using a different charger can cause a
fire.
MOD BIKES
models have
different battery
configurations,
with each battery
storing a different
amount of energy
and supplying a
different range.
Your MOD BIKES battery and
charger may get hot when charging.
Do not leave unattended.
Your bike wants to be ridden!
Storing it for long periods of time
without using it can cause a decline
in the battery’s performance.
5
Battery and Charger

OWNER’S MANUAL
P. 13
1. Before every ride:
• Do a quick visual
inspection.
• Check brakes.
• Check lights.
Avoid riding your MOD
BIKES e-bike in heavy rain
or near salt water, as it can
cause corrosion and rust.
The warranty does not cover
damage caused by water.
MOD BIKES are built
to be your long-lasting
partner in mobility.
The key to keeping
your e-bike working
properly and safely is
proper maintenance,
which involves three
stages:
2. Once a month:
• Do a general visual
inspection
• Check tire pressure
(should be 35 psi).
• Check stem and fork
screws.
• Tighten wheels, stem
and fork screws, if
necessary.
3. Every 4 months or 1000 miles
(whichever comes first):
• Take your bike to mandatory
professional service by an authorized
seller or a professional bike shop.
DO NOT grease any of the
followings: brakes, tires, battery or
electric components.
To clean your MOD BIKES e-bike,
wipe it down with a damp towel. MOD BIKES is not liable for accidents, injuries or product
malfunctions resulting from lack of
maintenance or neglect.
6
Maintenance

OWNER’S MANUAL
P. 14
The MOD BIKES 18-month
limited warranty covers your
e-bike’s:
• Main frame, fork and
suspension.
• Electric system, including the
motor, controller, display and
battery.
• This warranty is limited to
the repair or replacement of
the parts listed above. The
warranty applies exclusively
to the original owner and is
not transferable without an
official ownership transfer
by MOD BIKES. The warranty
only covers bicycles and
components purchased
through an authorized
MOD BIKES dealer, and is
contingent upon mandatory
Warranty
Info
Print
service and maintenance
(see page 12).
The warranty
does not cover:
• Water damage, corrosion or rust.
• Damage/failure due to accidents.
• Damage/failure caused by
tampering or use of unauthorized
parts or accessories.
• Misuse.
• Neglect.
• Modifications of components.
• Normal wear and tear.
MOD BIKES limited warranty claims will
be approved only upon presentation of the
original sale receipt and signed warranty
statement.
Bike:
Model:
Frame no:
Battery no:
Customer:
Name:
ID:
Phone:
Date:
Store name:
Year:
Color:
Capacity:
Please fill and sign the form and keep it for your records:
7
Warranty

OWNER’S MANUAL
P. 5
MOD-BIKES.COM
YOU ARE ALL SET AND READY
To Ride
