Mod-U-Blast M2000-4C Manual

HORIZONTAL FILTER DUST COLLECTORS
OPERATION & MAINTENANCE MANUAL
HORIZONTAL FILTER DUST COLLECTORS
OPERATION & MAINTENANCE MANUAL
SUPERIOR PERFORMANCE
And Quality In Blast Cleaning Equipment
www.modublast.com Ph: [phone] Fax: [phone]
!WARNING
Manual #RPDC1810
Read Manual
Copyright© 2018 Mod-U-Blast®, All Rights Reserved
Failure to read, understand &
follow all safety and operation
procedures in this manual can
cause injury or death. Manuals
that are lost, incomplete, or
damaged, must be replaced
immediately.
For models M2000-4C, M3000-6C, M6000-12C, M9000-18C, M12000-24CFor models M2000-4C, M3000-6C, M6000-12C, M9000-18C, M12000-24C

Horizontal Filter Dust Collector Owner’s Manual
Copyright© 2018 Mod-U-Blast®, All Rights Reserved
Table of Contents
2
Important Notice ................................ 3
Warnings...................................... 4
Horizontal Filter Dust Collector Models .............. 5
Operational Diagram .......................... 6 & 7
Important Safety Items ........................... 8
Dust Collector Start-up and Operation................ 9
Magnehelic Gauge Operation....................... 9
Dust Disposal ................................. 10
Dust Collector Maintenance ...................... 10
Filter Removal and Installation ................ 11 & 12
Replacement Filters & Parts List .................. 13
Dust Collector Troubleshooting .................... 14
Warranty Coverage ............................. 15

Copyright© 2018 Mod-U-Blast®, All Rights Reserved
Horizontal Filter Dust Collector Owner’s Manual
3
TO DISTRIBUTORS, PURCHASERS AND END USERS OF MOD-U-BLAST PRODUCTS
The information provided described and illustrated in this material is intended for experienced, knowledgeable users of abrasive
blasting equipment and supplies(products).
The products described in this material may be combined as determined solely by the user in a variety of ways and purposes. However
no representations are made as to intended use, performance standards, engineering suitability, safe practices or compliance with
government regulations and laws that apply to these products, products of others, or a combination of various products chosen by the
user or others. It is the responsibility of the users of these products, products of third parties, and a combination of various products, to
exercise caution and familiarize themselves with all applicable laws, government regulations and safety requirements.
Nor are representations made or intended as to the useful life, maintenance cycles, efficiency or performance of the referenced prod-
ucts of any combination of products. This material must not be used for estimating purposes. Production rates, labour performance or
surface finishes are the sole responsibility of the user based on the
user’s expertise, experience and knowledge of industry variables.
It is the responsibility of the user to insure that proper and comprehensive training of operators has been performed and all environmen-
tal and safety precautions observed.
Mod-U-Blast Inc. provides a variety of excellent products to the surface preparation industry, and we are confident that all proficient
users, operators and contractors in this industry will continue to use our products in a safe and knowledgeable manner.
Before using this product, read all instructions, literature, labels, specifications and warnings sent with and affixed to the unit.
If operation of the unit is unclear after reading this manual, contact your supervisor for instructions. It is the responsibility of the
employer to read the following instructions to users of this equipment. Periodic inspection at the work site should be made by
supervisory personnel to ensure the blast machine is being properly used and maintained. A copy of this owner’s manual must be kept
with the blast machine and readily accessible to the blast machine operators at all times.
It is the responsibility of the user to insure that proper and comprehensive training of operators has been performed and all
environmental and safety precautions observed.
Important Notice

Horizontal Filter Dust Collector Owner’s Manual
Copyright© 2018 Mod-U-Blast®, All Rights Reserved
Warnings
4
WARNING: Over time, exposure to any dust could result in lung medical issues or death. Use a
reverse pulse dust collector with HEPA filters if lead or other toxic materials are removed from
items during the blasting process.
WARNING: Do not disconnect hoses while the system is under pressure, this could cause serious
injury or death.
WARNING: Use proper respirator and eye protection when servicing the dust collector
WARNING: When servicing the dust collector, disconnect and lock out the
electrical supply and disconnect the air line from the compressor.
!
WARNING
Mod-U-Blast Dust Collection
Systems are not designed for
filtration/extraction of
combustible or explosive
materials. If you are unsure of
your dust particulate, please
contact a Mod-U-Blast
representative for more
information.

Copyright© 2018 Mod-U-Blast®, All Rights Reserved
Horizontal Filter Dust Collector Owner’s Manual
Horizontal Filter Models
5
M2000-4C
M9000-18C M12000-24C M3000-6C
With Silencer
M3000-6C M6000-12C

Horizontal Filter Dust Collector Owner’s Manual
Copyright© 2018 Mod-U-Blast®, All Rights Reserved
6
Clean
Air
Outlet Compressed
Air Supply
Goyen
Valve
Hop per
Dirty
Air Inlet
Blower On
Normal Operation
Blower On
Filter C leaning
Operatio n
Goyen valves open
in sequence f rom top
to bottom knocking
dust out of the f ilters
Filters
OPERATIONAL DIAGRAM
Throughout normal operation, the dus t laden air enters the dust collector through the dirty a ir inlet plenum. The dirty air flows
downward towards the hopper and the f ilters remove the f ine dust allowing clean f iltered air to pass through the f ilters and out
past the blower f an.
Filter cleaning occ urs when a signal from the dust collector control pane l is sent to ope n the goyen v alves allowing a rush of air to
go through the f ilter bank knocking the dust out of the filters and down into the hopper.
Dirty
Air Inlet
Clean
Air
Outlet
Operational Diagram
Throughout normal operation, the dust laden air enters the dust collector through the dirty air inlet plenum. The dirty air flows
downward towards the hopper and the filters remove the fine dust allowing clean filtered air to pass through the filters and out past the
blower fan.
Filter cleaning occurs when a signal from the dust collector control panel is sent to open the goyen valves allowing a rush of air to go
through the filter bank knocking the dust out of the filters and down the hopper.

Copyright© 2018 Mod-U-Blast®, All Rights Reserved
Horizontal Filter Dust Collector Owner’s Manual
7
Clean
Air
Outlet Compressed
Air Supply
Goyen
Valve
Hop per
Dirty
Air Inlet
Blower On
Normal Operation
Blower On
Filter C leaning
Operatio n
Goyen valves open
in sequence f rom top
to bottom knocking
dust out of the f ilters
Filters
OPERATIONAL DIAGRAM
Throughout normal operation, the dus t laden air enters the dust collector through the dirty a ir inlet plenum. The dirty air flows
downward towards the hopper and the f ilters remove the f ine dust allowing clean f iltered air to pass through the f ilters and out
past the blower f an.
Filter cleaning occ urs when a signal from the dust collector control pane l is sent to ope n the goyen v alves allowing a rush of air to
go through the f ilter bank knocking the dust out of the filters and down into the hopper.
Dirty
Air Inlet
Clean
Air
Outlet
Operational Diagram

Horizontal Filter Dust Collector Owner’s Manual
Copyright© 2018 Mod-U-Blast®, All Rights Reserved
Important Safety Items
Read all instructions before using this equipment. For efficient and safe production reference the OSHA requirements.
1.1 Dust Collector Manual
This manual contains important instructions for the safe operation of this dust collector and some of its related equipment.
Before attempting to operate this dust collector and its components all personnel intending on using this equipment must read all of the
complete manuals and familiarize themselves with the operation and parts.
1.2 Safety Considerations
• Dust collectors require high pressure air to pulse the filters
• Dust collected by a reverse pulse collector must not be allowed to become concentrated in areas where workers are exposed. This
requires proper maintenance of the dust collection & Hepa components.
• When selecting a location for the dust collector take into consideration wind, seismic zone and all load conditions.
• Electrical installation, service and maintenance must be performed by a qualified electrician.
1.3 Operator’s Responsibilities Before Starting
• Inspect fittings, valves and hoses for damage and wear. Repair any air leaks before operating.
• Clean the dust collector filters as needed and empty the dust collector hopper daily.
IMPORTANT NOTE: When using this dust collector the filters need to be seasoned before pulsing. Do not turn on the auto pulse until 4-5
hours of blasting and/or one cycle of reclaiming media has occurred.
1.4 Cautions
• The compressed air supply to the pressure system needs to be oil and moisture free.
• Working air pressure of the dust collector pulse system must not exceed 80 P.S.I.
1.5 Maintenance
• Disconnect the power and air supply from the dust collector before servicing.
• Keep all components in good repair. Use Mod-U-Blast parts only and do not substitute or modify.
For Service Call:
1-800-661-3842
8

Copyright© 2018 Mod-U-Blast®, All Rights Reserved
Horizontal Filter Dust Collector Owner’s Manual
Dust Collector Start-Up and Operation
For Service Call:
1-800-661-3842
9
Initial Start-Up Check
Magnehelic Gauge Operation: Model 2015
Operation Checklist
1. Check for proper fan rotation as noted on the fan or the housing.
2. All access doors should be sealed secure.
3. Check that the dust hopper is properly sealed.
4. Remove any loose items in or near the inlet or outlet of the dust collector.
5. Set the air pressure on the regulator to 80 psi. (Do not turn on the auto pulse box - see below)
6. Turn dust collector fan motor ON.
1. Monitor the physical condition of the dust collector and repair or replace any damaged components.
2. Check the compressed air components for leaks.
3. Monitor pressure drop across filters. Changes in pressure drop may indicate a change in operating conditions. (See Magnehelic
Gauge below)
4. Check the exhaust
5. Check the dust disposal.
The Magnehelic gauge measures differential pressure between the clean air and dirty air plenums of the dust collector and provides
timely information of filter change requirements.
When the Magnehelic reading is between 5-6 on the gauge the filters need pulsing.
To check the condition of the filters using the Magnehelic reading, pulse the filters with the blower fan off for 4 hours and then start the
dust collector blower fan. If the reading continually stays between 5-6 on the Magnehelic gauge it is time to change the filters. (see filter
removal and installation)
NOTE: AFTER THE FILTERS ARE SEASONED THE AUTO PULSE CAN BE TURNED ON AND STAY ON. THE FILTERS CLEAN BETTER
WHEN PULSED WHILE THE BLOWER FAN IS OFF.
See the Magnehelic Gauge printout with this manual for maintenance instructions and trouble shooting.
NOTE: DO NOT TURN THE FILTER AUTO PULSE ON UNTIL AFTER 4-5 HOURS OF RUNNING THE DUST COLLECTOR TO RECLAIM
MEDIA AND/OR REMOVE DUST FROM THE BLASTROOM WHILE BLASTING . THIS IS TO SEASON THE FILTERS & TO PREVENT ANY
PERFORATIONS IN THE FILTER MATERIAL.

Horizontal Filter Dust Collector Owner’s Manual
Copyright© 2018 Mod-U-Blast®, All Rights Reserved
Dust Collector Maintenance
10
Dust Disposal
Maintenance Schedule For Blastroom Pneumatic System
Daily Maintenance
Six Month Maintenance
1. Empty the dust container (s) as required to minimize the amount of dust in the hopper.
2. Whatever type of dust container is used under the hopper to collect the dust, care should be given to make sure it does not over fill -
empty the container when it is about 2/3 full or less.
3. Reinstall the dust container.
NOTE: If the 6” butterfly valve is left open during operation of the dust collector it must be sealed to the waste container.
NOTE: The auto pulse control panel uses a Zelio timer internally. Should the pulse time between filter banks need to be adjusted for any
reason please contact the Mod-U-Blast service departments for directions.
When servicing the dust collector disconnect and lock out the electrical supply and disconnect
the air supply from the compressor.
• Report and / or fix any operational problems
• Correct any safety issues
• Pulse dust filters (after seasoning)
• Empty dust collector hopper
• Check dust collector filters - if the magnehelic gauge on the DC reads 5- 6 inches even after
pulsing then the filters need replacing (see filter removal and installation)
• Check for leaks in dust hoses

Copyright© 2018 Mod-U-Blast®, All Rights Reserved
Horizontal Filter Dust Collector Owner’s Manual
11
Filter Removal and Installation
Be sure to use proper safety and protective equipment when removing the dust contaminants
and dirty filters.
Turn off electrical power source and lock out before performing service or maintenance.
Turn off compressed air supply and bleed the dust collector storage tank before performing
service or maintenance.
Start by removing the top row of filters first and replace. This will limit the amount of dust during
replacement.
Do not operate the dust collector with missing or damaged filters.
Remove the knob by turning counter clockwise
While removing the knob hold the lter lid in place until fully unscrewed and remove
the lid.

Horizontal Filter Dust Collector Owner’s Manual
Copyright© 2018 Mod-U-Blast®, All Rights Reserved
12
Filter Removal and Installation cont’d
Removing the lid exposes the lters
Grab the lter as shown and pull out to remove. Most of the dust
collectors will have 2 lters except the M2000 and the M3000 which are
singles.
NOTE: Dirty lters may be heavier than they appear. Safe measures
should be taken when removing
When replacing the lters note that the end with the foam rubber seal
ALWAYS goes in rst whether it’s a single or double lter conguration.
Filter Installation
Reverse the above procedures when installing new lters

Copyright© 2018 Mod-U-Blast®, All Rights Reserved
Horizontal Filter Dust Collector Owner’s Manual
ABR Blastroom Owner’s Manual
13
Horizontal Filter Requirements
HEPA Filters (if required)
Dust Collector Parts
Replacement Auto Pulse Control Box Complete
For Supplies and Parts Call - 1-800-661-3842
DUST COLLECTOR NO. OF FILTERS STOCK NUMBER FILTER TYPE
STOCK NUMBER DESCRIPTION
STOCK NUMBER DESCRIPTION
DC MODEL STOCK NUMBER
M2000-4C 4 19123 Cartridge
M3000-6C 6 19136 Cartridge
M6000-12C 12 19123 Cartridge
M9000-18C 18 19123 Cartridge
M12000-24C 24 19123 Cartridge
11516HF Filter, Hepa, Large
11516PF Pre-Filter, Hepa, 24” x 24” x 1”
50350 Regulator
16424 Magnehelic Gauge
SP-RCAC25DD Goyen Valve
16440 Electric Coil for Goyen Valve
SP-RCAC25 Goyen Valve Repair Kit
M2000 16997
M3000 16995
M6000 16998
M9000 16996
M12000 16994

Horizontal Filter Dust Collector Owner’s Manual
Copyright© 2018 Mod-U-Blast®, All Rights Reserved
PROBLEM POSSIBLE CAUSE REMEDY
Fan blower and
motor don’t start
Not wired correctly Check and correct the motor wiring.
Electrical supply circuit down Check power supply circuit. Check for fuse or circuit breaker fault
Fan blower and
motor start - do not
stay running
Incorrect motor controller installed Check for proper motor controller and replace if required
Electrical circuit overload Check that the power supply circuit has sufficient power to run the dust
collector
Clean air outlet
discharging dust
Filters not installed properly See filter installation
Filter damage, gasket damage or
holes in filters
Replace filters if necessary - See filter installation
Access cover (s) loose Tighten door (s)
Insufficient Airflow Blower fan rotation backwards Proper fan rotation is clockwise when looking down at the motor top -
Electrician will have to change wiring in the motor controller or the control
panel
Access doors open or not closed tight Check all access doors for tightness. Check the hopper discharge opening
is closed unless sealed to a waste container.
Exhaust area restricted Check all exhaust areas for obstructions. Adjust where available. Adjust
any damper flow controls if available
Filters need replacing Remove and replace filters. See filter removal and installation
Lack of compressed air for filter
pulsing
Check the dust collector regulator is set to 80 psi and for any air leaks and
repair
Pulse valves not working Check to see if the auto pulse box is plugged into a 110 volt receptacle and
that the switch is turned to the ON position.
14

Copyright© 2018 Mod-U-Blast®, All Rights Reserved
Horizontal Filter Dust Collector Owner’s Manual
Mod-U-Blast equipment is covered by a one (1) year warranty against defects in material and workmanship starting from the purchase
date. This covers the equipment as well as all major components.
This warranty does not apply to abnormal use of the equipment or parts. Parts considered consumables are not covered by warranty.
Claims will be honored only if the warranty card is returned within a period of two (2) months from the factory shipping date.
The card can be returned to your Mod-U-Blast salesperson or mailed to the address below.
In the event of failure of this equipment
please contact a Mod-U-Blast service centre
or call [phone].
403 - 69 Avenue NW
Edmonton, Alberta
Canada
T6P 0C2
PH: [phone] FAX: [phone]
Warranty Coverage
15
