INSTALLATION MANUAL
Congratulations on choosing MODE COM computer case.
You have received the highest quality product which will
satisfy any of your expectations. Should You have any
comments about using our product, please don’t hesitate to
contact us.
Note, the device you have purchased is not a final product
intended to and ready to work as a household or office
appliance. The system builder company will assemble
appropriate devices and components inside a case and
configure the computer before sale. Depending on given
configuration of components installed in a case, appropriate
user manual will be attached.
1.Disassembly of case cover
Remove securing screws then slide the right cover ca.
2,5 cm backwards and raise upwards. Disassemble left cover
in the same way.
MODE COM
3
INSTALLATION MANUAL
2. Installing the fan (option)
Fix the fan in its place using the screws provided. After
installing the Motherboard, connect fan electrical wires to
a socket on the Motherboard, according to its installation
manual.
3. Assembling / Disassembling front panel
Disassemble both sides covers then remove front panel by
pressing & pushing towards (outside of the case) panel
mounting pins.
4. Installing internal devices: FDD, HDD, CD ROM,
FDD 5,25", DVD, CD-RW, DVD-RW
Caution : When installing devices follow their manufacturer’s
instruction attached.
Installing 3,5 ” HDD and FDD drives
A. Insert drive into its place in 2,5 “ or 3,5’’ bay and
position it in the right place.
B. Secure it with the screws provided.
Installing 5,25” CD ROM, DVD or FDD drives
Caution : To remove 5,25’’ blinds, removing front
panel is needed first.
A. Insert drive into its place in 5,25’’ bay and
position it in the right place.
B. Secure it with the screws provided.
MODE COM
4
6. Installing illumination of the front panel
Connect power supply socket to a free (4pin) plug in the
power supply of the case.
Caution : The illumination of the front panel ensues providing
the installation of the motherboard, connection to
the circuit and switching on with Power button has
been performed.
INSTALLATION MANUAL
5. Installing the Motherboard
Caution : When installing, follow the attached manufacturer’s
instructions
A. Lay the case on its side, providing an access to the
Motherboard compartment.
B. Secure the Motherboard using the screws provided and
connect all cables, according to Motherboard’s
installation manual. Special plastic posts are intended to
secure the Motherboard to the standardized openings
and they are the only components to secure it. Special
kind of plastic absorbs vibrations of Motherboard caused
by devices mounted inside, and minimizes transmission
of external shocks (e.g. during transport). It also provides
electrostatic isolation.
MODE COM
5
7. Connecting USB & audio outlets
Caution : When installing USB & Audio outlets follow the
motherboard and Sound Card manufacturer’s
instructions.
Connect USB wires to appropriate pins on the
Motherboard, according to USB wires layout attached to USB
harness and the Motherboard installation manual. Guide USB
wires outside the case through the rear slot blind. Connect
Audio wires to Mic and Phones outlets in the Sound Card.
USB 1.1 wires layout :
red or orange (Supply, VCC5V)
white or yellow (USBD-)
green or blue (USBD+)
blue or brown (Ground)
USB 2.0 wires layout :
red & orange (Supply, USB V+)
white & yellow (USBD-)
green & blue (USBD+)
black & brown (GND, uziemienie)
INSTALLATION MANUAL
MODE COM
INSTALLATION MANUAL
6
MODE COM
7
8. Assembly / disassembly of Power Supply
Insert Power Supply into its bay and secure it with the
screws provided.
9. Assembly of side covers
Assembly side covers using their inner side rulers, then
slide them forward. Secure side covers with screws.
10. Working conditions
• Working temperature: from 10° C until 50° C,
• Storage temperature: from –40° C until 60° C,
• During assembling components inside case, power
should be disconnected by pulling out the electrical plug
from the power socket.
• The device should be protected against shocks and
mechanical damages.
• The Power Supply mounted in the case is a 1st class
device intended to work in power networks with
internal grounding installation (the socket must be
equipped with grounding bolt),
• Laminates used in devices mounted inside a case must
be conformed to the requirements of flammability class
V1 or higher.
! WARNING !
The device should be located close to easy accessible electrical outlet.
The device is fully disconnected from mains only by removing the
plug from electrical socket. The voltage selection switch located at
the rear side of Power Supply must be set according to the voltageof
electrical network (in Europe: 230V).
INSTALLATION MANUAL
