Modern Forms Aviator Flush User manual

Aviator Flush
Installation Instructions
works with the
Google Assistant

FH-W1811
Aviator Flush Instructions2
Please read and
save these instructions
before installation
DO NOT RETURN TO STORE

FH-W1811 Aviator Flush Instructions 3
For all questions about your ceiling fan please read all included
instructions, installation procedures, troubleshooting guidelines
and warranty information before starting installation
For missing parts or general inquiries call our trained technical sta at:
1-866-810-6615 option 0
MON-FRI 8AM-8PM EST
Email: [e-mail]
Or live chat at modernforms.com
For fast service have the following information below when you call:
1. Model Name and Number
2. Part Number and Part Description
3. Date Of Purchase and Purchase Location
1-866-810-6615 option 1
MON-FRI 8AM-8PM EST
Email: [e-mail]
General Inquiries
Fan Support

FH-W1811
Aviator Flush Instructions4
For operation, maintenance, and troubleshooting information,
visit http://modernforms.com/fan-support/
To reduce the risk of electric shock, ensure electricity has been turned o at the circuit breaker
before beginning. All wiring must be in accordance with the National Electrical Code “ANSI/NFPA
70” and local electrical codes. Electrical installation should be performed by a licensed electrician.
The fan must be mounted with a minimum of 7 ft. (2.1m) clearance from the trailing edge of
the fan blades to the oor and a minimum of 1.5 ft (0.5m) from the edge of the fan blades to the
surrounding walls. Never place objects in the path of the fan blades. To avoid personal injury or
damage to the fan and other items, please be cautious when working around or cleaning the fan.
To avoid electrical shock or damage to the motor or nish, do not use water or chemicals
when cleaning the fan or fan blades. A dry cloth or lightly dampened cloth will be suitable
for most cleaning.
After making electrical connections, spliced conductors should be turned upward and pushed
carefully up into the outlet box. The wires should be spread apart with the grounded conductor and
the equipment-grounding conductor on one side of the outlet box, and the ungrounded conductor
on the other side of the outlet box.
All set screws must be checked and re-tightened
where necessary before installation.
Safety Rules

FH-W1811 Aviator Flush Instructions 5
WARNING:Do not install or use your fan if any part(s) is/are damaged or missing. This product
is designed for use only with the supplied parts and/or accessories designated for use with this
product by Modern Forms. Substitution of parts or accessories not designated for use with this
product by Modern Forms could result in personal injury or property damage and will void the
warranty. Contact an authorized dealer or the manufacturer if any parts are damaged or missing.
WARNING:To reduce the risk of electric shock, this fan must
be installed and operated with the supplied wall control, or controlled from the Modern Forms app
or Wi-Fi Touch Panel Wall Control (not included).
WARNING:Do not use power tools to assemble or install your fan. Using power tools can result in
improper assembly which can lead to noise or fan damage,personal injury or property damage.
WARNING:To reduce the risk of personal injury, do not bend the blade arms when installing the
brackets, balancing the blades or cleaning the fan.
WARNING: Do not insert foreign objects between rotating fan blades.
WARNING:Do not operate fan unless fan blades are in place. Noise and fan damage can occur
WARNING:This appliance is not intended for use by young children without supervision.
WARNING: To reduce the risk of re, electric shock, personal injury or damage to the fan or other
items, the outlet box and support structure must be securely mounted and capable of reliably
supporting a minimum of 35 Ibs (15.9 kg). Use only UL/cUL listed outlet boxes marked “FOR FAN
SUPPORT.” Use only the screws and washers provided with the outlet box.
CAUTION:Before assembling your fan, refer to the “Making the Electrical Connections“
section. If you feel you do not have enough wiring knowledge or experience, have your fan
installed by a licensed electrician.
NOTE:Before servicing or cleaning the fan, switch power o at the circuit breaker.

FH-W1811
Aviator Flush Instructions6
Get Smart...
Integrates
seamlessly with:
Premium smart
features:
Accessories:
DC
MOTOR
devices you already own
complements high quality materials
personalize your experience
Quiet, reliable, and up to 70%
more ecient than AC fans
Wi-Fi and Bluetooth enabled
for exible control
Wi-Fi Touch Panel Wall Control
Full app control | Sold separately
F-TS-BK Black F-TS-WT White
works with the
Google Assistant
Bluetooth Wall Control
Dims light to 1% | ON/OFF
6 fan speeds
F-RCBT-WT White
Bluetooth Remote Control
Dims light to 1% | ON/OFF
6 fan speeds
F-RCBT-WT White | Sold separately
Wet location-listed to the strictest
UL/cUL safety regulations. Finished
and rated for interior and exterior use

FH-W1811 Aviator Flush Instructions 7
1. Mounting Options 10
2. Installing the Mounting Bracket 12
3. Attaching The Fan Blades 12
4. Attaching Decorative Lower Cap 12
5. Making the Electrical Connections 14
6. Installing the Wall Control 16
7. Finishing the Installation 18
8. Installing the LED Luminaire Module 20
9. Controlling the Fan 22
10. Factory Reset 24
11. Breeze Mode 24
12. Application 24
13. Accessories 26
Contents
Tools Required

FH-W1811
Aviator Flush Instructions8
** denotes nish code of fan *** denotes blade sweep of fan
Package Contents
6. Bottom Cap (Aluminum)
7. Control Receiver W/
Hardware
RPL-F1811-54-REC
8. Wall Control W/Hardware
F-WCBT-WT
• 3/16” x .375” Flat head
screws (5 pcs) -Blade
Collector Ring
• ø 4x9mm Flat head screws
(10 pcs) - Blade Screws
• 1/4” x 16mm Pan head
Philips screws with washer
(7 pcs)
• ø 5x14x1mm Flat washers (2
pcs) - Hanger Plate
• #8-32x38mm Pan Head
Philips Screw (2 pcs) -
Hanger Plate
• ø 5.2x8.4x1mm Spring
washers (2 pcs) - OPTIONAL
for direct wood mount -
Hanger Plate
Hardware Bag
RPL-AVIATORFH-PART
1. Blade Set of 3
RPL-F1811-54-BD-**
2. Blade Collector Ring
3. Hanger Plate
RPL-F1811-HANGER-**
4. Hanger Gasket
5. Motor Assembly
Before discarding packaging materials be certain all parts have been removed.
Place the parts from the hardware bag into a small container to keep them from being lost.
• ø 4.4x9.4x1mm Star washers
(2 pcs) OPTIONAL for direct
wood mount - Hanger Plate
• #10x38mm Pan head Philips
wood screws (2 pcs) -
OPTIONAL for direct wood
mount -Hanger Plate
• ø 5.2x8.4x1mm Spring
washer (1 pc) - Safety Cable
• ø 6.5x19x2mm Flat washer (1
pc) - Safety Cable
• #10x76mm Pan head Philips
wood screw (1 pc) - Safety
Cable

FH-W1811 Aviator Flush Instructions 9
IMPORTANT: Please make note
of the MAC ID on the
receiver and keep it in a
safe place.
1
MACID
8
4
2
7
5
6
3
Hanging Weight: 13 lbs

FH-W1811
Aviator Flush Instructions10
1. Mounting Options
CAUTION: To prevent electrical shock, ensure electricity has been
turned o at the circuit breaker before beginning.
To prevent electrical shock, ensure electricity has been turned o at
the circuit breaker before beginning.
If there isn’t an existing UL/cUL listed outlet box, please refer to the
following instructions. Secure the outlet box directly to the building
structure. Use appropriate fasteners and building materials. The
outlet box and support structure must be able to fully support the
moving weight of the fan (at least 35 lbs/15.9 kg). Do not use plastic
outlet boxes. Use only UL/cUL listed outlet boxes marked
“FOR FAN SUPPORT.”
Secure the outlet box directly to the building structure.
Use appropriate fasteners and building materials. The outlet box
and its support must be able to fully support the moving weight
of the fan (at least 35 lbs). Do not use plastic outlet boxes.
Figures 1-4 are examples of dierent ways to mount the
outlet box.
NOTE: To hang your fan where there is an existing xture but no
ceiling joist, you may need an installation hanger bar.
NOTE: Downrod fans can be suspended up to a maximum
recommended length of 72” using additional downrods
(sold separately) and the included 80” lead wire.
NOTE: The sloped ceiling kit (sold separately) is required for sloped
ceiling applications, and will accommodate slopes up to 45° (Fig.3).
NOTE: You may need a longer downrod to maintain proper blade
clearance when installing on a steep, sloped ceiling (Fig. 3).

FH-W1811 Aviator Flush Instructions 11
1
3
3
2
4
4
Outlet Box
Joist
Support
Brace
Outlet Box
Provides
Strong Support
Mounting
Bracket
Recessed
Outlet Box
SLOPED CEILING
MAX 30° ANGLE
Outlet Box
Mounting
Screw
UL/cUL
Mounting
Mounting
Screws
120V Wire

FH-W1811
Aviator Flush Instructions12
1. Disconnect power to the fan location at the breaker. A licensed
electrician must install the fan.
2. There are four screws on top of the motor assembly. Remove two
that are on the opposite of each other and save for section 10.
Loosen remaining two.
3. Pass the 120-volt supply wires through the center hole in the
ceiling mounting bracket as shown in Figure 2.
4. Secure the hanger plate and hanger gasket to the ceiling outlet
box with the screws and washers provided (Fig. 2).
REMEMBER to turn o power at the breaker.
Follow the steps below to hang your fan properly:
3. Attaching The Fan Blades
4. Attaching Decorative Lower Cap
1. Place blade on motor as shown in Fig. 3 and secure with the
blade attachment screws and washers.
2. Repeat this procedure with the remaining blades (Fig. 3).
3. Secure the bottom of the blades together using the provided
blade collector ring and hardware (Fig. 3A).
1. Tightly twist the decorative lower cap onto the
motor assembly (Fig. 4).
2. Installing the Mounting Bracket

FH-W1811 Aviator Flush Instructions 13
2
3A
3
4

FH-W1811
Aviator Flush Instructions14
5. Making the Electrical Connections
WARNING: Installation of this fan requires that a three-conductor
cable (including ground wire) which should run between ceiling and
wall outlet box.
WARNING: Check to see that all connections are tight, including
ground, and that no bare wire is visible at the wire nuts,
except for the ground wire.
Insert the receiver into the mounting bracket with the at side of the
receiver facing the ceiling (Fig. 5).
Motor to Receiver & Receiver to housing supply wires (Fig. 5A).
1. Connect the hanger ball/downrod assembly ground wire,
mounting bracket ground wire and receiver ground wire to
the ground wire in outlet box
WARNING: Failure to connect ground wires could result in
poor fan control functionality.
2. Connect the red wire from the fan to the red wire marked
“TO MOTOR” from the receiver.
3. Connect the grey wire from the fan to the grey wire marked
“TO MOTOR” from the receiver.
4. Connect the yellow wire from the fan to the yellow wire marked
“TO MOTOR” from the receiver.
5. Connect the white wire from the fan to the white wire marked
“FOR LIGHT” from the receiver.
6. Connect the blue wire from the fan to the blue wire marked
“FOR LIGHT” from the receiver.
7. Connect the black (hot) wire from the ceiling to the black wire
marked “AC in L” from the receiver.
8. Connect the white (neutral) wire from the ceiling to the white
wire marked “AC in N” from the receiver.

FH-W1811 Aviator Flush Instructions 15
Follow the steps below to connect the fan to your household wiring. Use the plastic wire nuts with your fan.
Secure the plastic wire nuts with electrical tape. Make sure there are no loose strands or connections.
5
5A
1
2
1. Mounting Bracket
2. Receiver
White (neutral)
Outlet box
Black (hot)
Black (“AC IN L”)
Red (to motor)
Gray (to motor)
Yellow (to motor)
Yellow (motor)
Gray (motor)
Red (motor)
Receiver
Green (Ground)
To hanger ball
Green (Ground)
To hanger bracket
Green (Ground)
White (for light)
White (for light)
Blue (for light)
Blue (for light)
White (“AC IN N”)
Green (Ground)

FH-W1811
Aviator Flush Instructions16
6. Installing the Wall Control
NOTE: Wall Control not included. A bluetooth wall control accessory
can be purchased separately.
1. Connect the green wire marked “GROUND” from the wall
control to the copper wire from the wall outlet box that
feeds back to the circuit breaker – important for proper
fan function (Fig. 7).
2. Connect the black wire marked “LINE IN” from the wall control to
the black LINE VOLTAGE wire from the wall outlet box that feeds
back to the circuit breaker (Fig. 7).
3. Connect the red wire from the wall control to the black wire from
the wall outlet box that feeds up to the fan (Fig. 7).
4. Connect the white wire from the wall control to the white
(neutral) wire from the wall outlet box (Fig. 7).
5. Carefully tuck the wire connections inside the outlet box. Secure
the wall control with the two (2) wall control screws provided.
(Fig. 7A)
6. Attach the wall mounting plate over the wall switch and secure
with the two (2) wall mounting plate screws provided (Fig. 4A).
7. Fasten the wall plate to the wall mounting plate (Fig. 4A).
6
21
White
Black (to fan)
Copper
Ground
White
(Neutral)
Black (from Breaker)
White
Red
Black
Green (Ground)

FH-W1811 Aviator Flush Instructions 17
Maximum of 2 fans can operate on a circuit through the wall transmitter. Maximum of 12 fans can operate
on a circuit through an on/o switch or breaker when utilizing the app for the fan control (without the wall
control in the circuit).
6A
Multi-location wiring
1 2 3
54
1. Wall Outlet
2. Wall Control
3. Wall Mounting
4. Mounting
5. Wallplate
Wall Controller 1 Wall Controller 2 Wall Controller 3
if Applicable
Green
Green to Fan
Black to Fan
White to Fan
Green White Black Red
Black Black White Red Red White Green Green
HOT IN
Individually pair each of the wall controls with the fan
receiver using the pairing instruction. See page 27

FH-W1811
Aviator Flush Instructions18
7. Finishing the Installation
1. Secure all wire connections with supplied wire ties to assist in fan
installation.
2. Tuck connections neatly into ceiling outlet box.
3. Remove the motor assembly from the hook on the mounting
bracket. Position the motor up to the hanger plate and attach using
two screws through the two key slots in the top of the motor housing
(Fig. 7).
Note: Make sure the receiver sits at
and does not interfere with the hook.
4. Align the remaining two circular holes on motor housing with the
two holes on the hanger plate. Secure by tightening the two screws.
WARNING: Make sure tab at bottom of hanger bracket is properly
seated in groove of hanger ball before attaching canopy to bracket.
Failure to properly seat tab in groove could cause damage to electrical
wiring.

FH-W1811 Aviator Flush Instructions 19
7

FH-W1811
Aviator Flush Instructions20
8. Installing the LED Luminaire Module
WARNING: Before starting installation, disconnect the power
by turning o the circuit breaker or removing the fuse at fuse box.
NOTE: If you do not plan to install the luminaire module with your
fan at this time, skip this step.
1. Remove the three screws from the LED wire storage cap, keep the
cap for future use when not using the luminaire (Fig. 8).
1. Install the LED mounting plate using 3 screws removed from step
1 (Fig. 8A).
1. Raise and hold the LED luminaire module close to the adapter
plate and proceed to secure the wire connections. Connect the
white wire connector from the luminaire module to the white
wire of the fan. Follow the same procedure with the black wire
connectors (Fig. 8B).
1. Seat the LED luminaire onto LED mounting plate using 3 screws
provided with LED luminaire (Fig 8C).
1. Install glass shade by turning it clockwise until it locks securely
(Fig. 8D).
