MODI T8S User manual

1.In the off state, long press on / off key about 2S, the blue light on the
right, the headset p "power on”
2.In the boot state, at the same me, press the on / off key and volume
up key about 0.2S, the right side of the red LED light, the headset p “
power off” Or long press on / off 8s, the right side of the red LED light,
the headset p “ power off”
1.You can use the package containing the Micro USB line charging, charging
Bluetooth intercom indicator red LED flashing, charging, Bluetooth intercom
indicang red LED flash, before each use recommended to charging full the
baery.
2.Power shortage p: every 30s, the headset will automacally voice prompt
Baery low , while the right side of the red LED flashes 3 mes, to prompt the
user to charge.
3.In the starng state can be a double click on the open/shut down buon
to check the baery current baery, Baery power to the sound to listen to the
speaker.
1.Answer incoming calls, call when the phone key to answer calls.
2.Automac answering calls, when set to automacally answer the phone,
the caller is more than about 6S did not click the phone key to answer the
phone, the phone will automacally answer the phone calls.
3.Hang up the phone, when you calling, Press on the phone key to
hang up the phone.
4.Caller reject,double press phone key to reject calls.
5.Voice dialing, connecng the phone standby mode, double Press the
volume key to achieve voice dialing. (the Mobile phone itself must be
equipped with voice dialing funcon).
6.End number redial , connected mobile phone standby, double-press the
volume up key
7.Connected with the Mobile phone, the Mobile phone is not connected to
the state, you can press the phone key , Headphones from
reconnect has been connected to the Mobile phone.。
8.Connected to third party calls, when the connecon two phone, the first
mobile phone in the call, the second mobile phone calls, you can
double-Press the phone key to connect second mobile phone, to
retain the first phone calls, to be back to the first second mobile phone calls.
21
TTS
FCC ID:2AIEBTTS
Mulplex Helmet Bluetooth Headset
www.motointerphone.com
User’s Guide
4 5 6
3
7
On / off key
1.On / off
2.Paired Mobile Phone
3.Power Tips
4.Hang up the Bluetooth Intercom
Mobile Phone Key
1.Music play/pause
2.Call answering / third party call answer / end call / reject call
Bluetooth Intercom Key
1.Paired Bluetooth intercom
2.Connect Bluetooth intercom
FM Radio Key
1.Open/Exit FM Radio
Volume Up Key
1.Volume Up
2.last song
3.FM Radio Search Up
4.Last Number Redial
Volume Down Key
1.Volume Down
2.Next Song
3.FM Radio Search Down
4.Voice Dialing
1、MODI-T8S Key Funcon Descripon 2、 LED Status Indicator
3、Charging
LED Status Indicator
Blue LED Flash(once)： Bluetooth is not connected
Red LED Blue LED Alternang Flash (slow ) Bluetooth By Pairing Mode
Red LED Blue LED Alternang Flash(fast) Bluetooth is in acve pairing
search mode
Blue LED flash two mes： Bluetooth has been connected
Red LED slow flash： Charging
Red LED Long me light： Charging finish
Red LED flash three mes： Baery low warning
Vol- Vol+
Phone Key
Walkie-talkie
interface
Headset interface
Intercom Key
Intercom LEDPhpne LEDFM Power On/Off
4.ON/ OFF
5.Pairing mobile phones using
7. Walkie-talkie use method
8.FM radio
9.Front and rear seat music sharing funcon
10.Technical index
6.Bluetooth intercom
Mobile pairing
1.TTS long press on / off at about 8s, the lef red LED&blue LED
lights flashing alternately, the headset ps "pairing". Turn on the phone,
search TTS ', and then click on the phone to connect to the phone.
Aer the end of the match, the mobile phone indicator light back to the
standby mode, blue lights flash 2 mes.
Mobile Phone calls to answer or dial
Bluetooth intercom paired
1.Plug theWalkie-talkie link line into the TTS Walkie-talkie interface, when
the headset is properly connected to the headset when the headset is ready to
listen to the voice of the other Walkie-talkie, You can listen to the sound of the
other Walkie-talkie,There are other sound signals come in(such as: mobile phone,
Bluetooth intercom, music, FM radio) sound signal will mix, you can hear these
sounds at the same me.
2.Walkie-talkie Microphone transmit ：
Press the intercom connecng line of the PTT buon, you can use the headset
microphone to the speaker, release the PTT buon, if you end the intercom
speaker, in mobile phone headset / Bluetooth intercom / Music Player state, then
hold down the PTT speaker, on behalf of all the party people to hear your speech
3.Walkie-talkie volume adjustment method, when the headset is in charge to
use the walkie talkie words, because TTS headset are different and have
different volume, so suggest you in connecton with Walkie-talkie, TTS no
other voice input, the intercom itself volume to the appropriate size, in order to
adapt to the different state of the headset volume.
1.Standby mode, press FM key to turn on the radio,press again Press FM
key to turn off the radio.
2.The radio to search up：In the course of using the radio，double press
volume up key ， search up.
3.The radio to search down：In the course of using the radio，double press
volume dow key ， search down.
4.FM radio volume adjustment method,short press the volume up key
the up volume, short press the volume down key to the down volume .
1.Receive / call/play music
2. Receive / call/play music/Bluetooth intercom
3.Receive / call/play music/Bluetooth Intercom group
Dual mode Bluetooth, Bluetooth 4.0+ Bluetooth 4.1
Supports HSP Profile:, A2DP, AGHSP, HFP
Working hours: 12 hours
Standby me: 300 hours
Charging me: 3 hours
Baery: lithium containing rechargeable lithium baery 800mA
Dimensions: 83 mm *42 mm *19 mm
CE, FCC, TELEC, NCC
3.unit3 and unit4
bluetooth pairing
2.unit2 and unit3
bluetooth pairing
1.unit1 and unit2
bluetooth pairing
2S 5S 2S 5S 2S 5S
Two intercom bluetooth pairing method
5.Receive / call/play music/Bluetooth Intercom/MODI-01 adapter
9. Play / pause mobile phone music, mobile phone connecon status is short
press the phone key to achieve a mobile phone music player /pause.
10. Mobile phone volume adjustment method, a short press the volume key
to the up volume, a short press the volume key to the down
volume.
1. The first TTS into pairing state: long press the Bluetooth intercom
buton 2S, red LED and blue LED flash quickly let go, the first TTS to
into the iniave find mode。
2. The Second TTS into to passive matching state: Long press the
Bluetooth intercom buon 5S, red LED and blue LED flashing slowly let go,
the machine into the passive matching mode.Wait for a moment, the pairing is
completed in the standby mode, the blue LED on the right of the fast flashing 2
mes, voice prompts pairing success.
3. Exit the intercom paired state: short Bluetooth intercom buon to exit
the paired state ,blue LED indicator returns standby.
4. On / off the Bluetooth intercom intercom: short press Bluetooth intercom
buon ,connected Bluetooth intercom,When is Bluetooth intercom, Press
on / off buon , hang up the Bluetooth intercom.
5. On / off Bluetooth intercom group (up to 4 units can be established at the
same tme TTS intercom)：The paired intercom aer,double press the
first TTS on the Bluetooth intercom buton established intercom
Bluetooth connecon group. press on / off buon , hang up the Bluetooth
intercom group.
6. Bluetooth intercom volume adjustment method, long press the volume up
key to the up volume, long press the volume down key to the down
volume.
7. Clear the intercom paired record: Volume up key +volume down
key together press 1s, the red light flashes 3 mes, remove all intercom
matching records.
4.Receive / call/play music/Bluetooth Intercom /Walkie-talkie
Group pair method
unit1 long press bluetooth
intercom buon 2sec,
let go.
unit2 long press bluetooth
intercom buon 5sec,
let go.
Charging interface

Installation method
MOUNTING (Permanent Mount)
1, Locate and clean a position on the left side of helmet close to lower edge of the
helmet,
2,Pell off the 3M double sided tape protective film and place the mount with logo on
bottom and place mount to the position in step 1
3,Apply pressure to the metal bracket to the metal bracket to ensure that the bracket
is, firmly secured. Note: It takes 24hours for adhesive to set.
MOUNTING (Temporary Mount)
1, Position and fasten the clip bracket onto helmet.
2, Remove the metal handles after clip bracket has been installed.
3, Use additional anti-slip rubber patch provided if required.
INSTALL CONTROL UNIT
1, from the top, slide Ejeas_TTS unit onto the bracket. You should hear a click sound

when fully inserted,
2, Fully insert the speaker 3.5mm jack connector.
3, Remove 3.5mm Jack spear connector.
4, Slide Ejeas _ TTS upward to release from.
Earphone mounting method
1, Headphone speakers are on the left and right ears of the helmet.
2, The microphone is mounted near the mouth of the helmet.

NOTE:This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.

Thisdevicecomplieswithpart15oftheFCCrules.Operationissubjecttothefollowingtwo
conditions:
(1)thisdevicemaynotcauseharmfulinterference,and
(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycause
undesiredoperation.

Changesormodificationstothisunitnotexpresslyapprovedbythepartyresponsiblefor
compliancecouldvoidtheuser'sauthoritytooperatetheequipment.
Note:The test separation distance used for the SAR assessment is 10mm.
The device cannot be installed on a helmet that does not meet the minimum separation distance specified.
