OneOdio GAMER10 Assembly instructions
GAMER10
User Manual Guide
Specifications
Speaker:
Frequency Response:
Impedance:
Magnet Type:
Sensitivity:
Max Input Power:
Plug Type:
Cable 1: 2m Cable with Volume Control
Cable 2: Dual 3.5mm "Y" Extension Cable
3.5mm stereo jack
300 mW
110dB ± 3dB
NdFeB magnet
32 Ohms
50mm neodymium driver
20Hz-20KHz
Thank you for choosing Studio. Please follow all sides of this user guide to ensure
proper use.
1
Model Name: Gamer10
Features
3.5mm 3.5mm
3.5mm
3.5mm
High-resolution and deep-reaching sound
The 50mm large neodymium driver and innovative technology deliver high definition sound in
new perfection. It reproduces all your music dynamics and controlled bass that audiophiles
need, and brings Gamers perfect immersive sound experience.
Boom Mic
The extended microphone provides you with more convenient voice calls and good sound
quality. It can be used not only as a music headset, but also as a telephone headset and gaming
headset. It is a multifunctional model
2
Functions
Premium Comfort Ear Pads and Excellent Noise-canceling Performance
The over-ear pads are covered with premium soft PU leather for extended comfort and
enhanced noise isolation.
Volume +
Volume –
Mic on /off
Remote control Jack Lock System
There is a movable bead in the 3.5mm socket of the headphones,
and a small groove on the end of the cable with a Mic. When the
cable is plugged into the 3.5mm jack, the bead will be snapped to
the groove, thus the connection can be more stable. You don’t
need to worry about the cable falling off easily.
Play / Pause
Movable bead
Samll groove
3
90° Rotating Ear Cups
The ear cups pivot for a personalized fit and rotate 90 degrees to lay flat. The lay-flat design
makes it easier to transport and more comfortable when resting on the neck. Besides, it is more
convenient for single-ear monitoring as the ear cups can be rotated both left and right.
Foldable and Portable
OneOdio Studio is a flexible headphone that can be adjusted to fit any head size. It can be flat
folded and put into the designed pouch.
left-hand
rotation only
right-hand
rotation only
single-ear monitoring
4
Q: Why can't I hear any sound after connecting it with Apple computers/laptops?
A: Go to System Settings, select Sound, Output, and then choose USB PnP Audio Device.
Q: Why can't I use the Microphone?
A: 1.You need disable the computer's onboard mic by accessing your sound devices in the
hardware section of the control panel. And choose the mic of the headphone.
2. Check whether the mute switch of the cable is on or off.
FAQ
5
Please sign up for OneOdio warranty service at www.oneodio.com. OneOdio warrants that this product, for 2
years from the date of retail purchase by the original end-use purchaser, when delivered to you in new
condition, in original package, from an OneOdio authorized reseller and used in normal conditions, is free from
any defects in manufacturing and workmanship. We will, at our sole option, repair or replace (using new or
refurbished replacement parts) any defective parts within a reasonable period and free of charge.
This warranty does not cover defects resulting from improper or unreasonable use or maintenance; failure
to follow operating instructions; accidents; excess moistures; insects; lightning; unauthorized alteration or
modification of original condition; damage caused by inadequate packing or shipping procedures; loss of,
damage to or corruption of stored data; damage caused by use with non-OneOdio products; the product
that requires modification or adaptation to enable it to operate in any country other than the country for
which it was designed, manufactured, approved and/or authorized, or repair of products damaged by their
modifications; and products purchase from unauthorized dealers.
In the event damage has occurred to products, you must follow these instructions:
Within two months, contact info@oneodio.com with order number in e-commerce website after you
discover a product defect (or should have discovered it, if such product defect was obvious);
In order to get professional solutions from OneOdio, please give a detailed explanation of how the
damage occurred.
Return the products. OneOdio will, at our sole option, repair or replace (using new or refurbished
replacement parts) any defective parts within a reasonable period of time and free of charge.
6
Email us at info@oneodio.com with faulty products.
Pls attach the video and the description of the product. We could solve the problem with more details
timely. Those who email with videos and detailed descriptions will be awarded with 1 gift products.
If you can't connect the headphones to your cell phones or other devices, please ask us for complete FAQ
guidance of Bluetooth Headphones, you can find the solutions finally!
Depending on your head/ear size/shape, it may be a little tight (feels like“on ear") for someone to wear
which is designed to avoid sound leakage. In case of that and to get both audio and wearing comfort,
please take off the headphone every 2 hours to get your ears relaxed and protect them from the muggy
environment in use.
This limited warranty gives you specific legal rights, and you also may have other rights that vary from state to
state or country to country. Some places do not allow limitations on implied warranties or the exclusion or
limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you.
Thank you for choosing OneOdio. We hope you enjoy our product. Do you like the purchase experience in our
store? We d appreciate it if you can share your fair product review and feedback. If you are not completely
satisfied, please reply to [email protected] Or you can contact us via Telephone: +852 6940 3848 (Mon to Fri
9:00 am - 6:30 pm, UTC+8 HKT) INDIA: +91 84319 76061（Mon to Sat IST 9:30 am-6:00 pm) so that we may
address your concerns before you leave a product review.
