Modular 6 Series User manual

MOD. 60/30 FRG
MOD. 60/60 FRG
Cod. 252.153.01
0049
USER MANUAL
GAS FRYER SERIES 6

2
ENGLISH
USER’S MANUAL
3. TECHNICAL DATA TABLE - FRYERS
When installing the appliances, the gas supply pressures must be those given above in order to have maximum burner efficiency.
Pressures mbar: 1 kPa
Power: 1 kW = 860 kcal = 3.6 MJ = 3412 BTU
4. INSTRUCTIONS FOR THE QUALIFIED INSTALLER
Remove the appliance from its packaging and position it (always)
under a suction hood.
To be installed on a fire proof base with clearances of at least
200mm each side and 600mm above.
The appliance gas system and the characteristics of the room in
which the appliance is installed must comply with current laws.
This appliance must be connected from the fitting at the back with a
metal hose in compliance with AS4631 or Class B/D hoses to AS/
NZS1869. The gas inlet connection on the appliance is ½ inch and
is positioned 38mm from the side of the appliance and 40mm from
the floor/bottom of feet on appliance.
This appliance is supplied with a certified regulator. Please test
operation of the appliance after installation and inform the operator/
s on using it safely. The hose must not be subjected to loads or
twisting.
The hose must not be subjected to loads or twisting. Check it’s in
good condition and don’t hesitate to change it if it looks cracked or
slightly burnt.
APPLIANCE INSTALLATION
4.1
4.2
OVERALL DIMENSION OF APPLIANCE
For overall dimensions of appliFor overall dimensions of appliance and connecting point of gas (Part A)
see installation diagram on page 5.
4.3 MAINTENANCE AND SERVICE
Have it checked by a specialised technician at least twice a year. Clean the steel
parts with water, detergent and a wet cloth. The detergent used must not contain
any corrosive or abrasive substance as it can damage the steel surfaces.
After washing, rinse with clean water and dry with a dry cloth.
If the appliance is going to be out of use for a long period of time, rub all steel parts
briskly with a cloth soaked in Vaseline oil, leaving a protective layer. Also aerate the
premises periodically.
Any contact with ferrous materials, both continuous and occasional, must be
avoided at all costs as such materials can corrode. This means that ladles, spatulas,
spoons, etc., must be in stainless steel.
For the same reason, avoid cleaning the stainless steel parts with steel wool,
brushes or scrapers made of ordinary steel. Stainless steel wool can be used,
rubbing it in the direction of the grain.
This appliance is under warranty for one year.
We pay great attention to ensuring that each of our appliances reaches the user in
perfect operating condition.
If you do find a problem when unpacking your appliance, please report it to the shop
within 48 hours.
If the appliance cannot be adjusted to perform correctly or you require any parts,
please contact National Kitchen Equipment on 1300 767 146. No damage due to
incorrect use or failure to comply with the instructions is covered by the guarantee.
Please do not hesitate to let us have your suggestions.

3
4.4
LAWS, TECHNICAL REGULATIONS AND GENERAL
RULES
Standard AS/NZS 5601.1
Accident prevention laws.
Always install a cut-off cock between each appliance and the gas
pipe.
Check that aeration in the room is sufficient when the appliance is
working, considering that the necessary quantity of air for
combustion is 2 m³/h of air for each kW of installed power.
4.5DISCHARGE OF FUMES FOR TYPE “A” APPLIANCES
N.B.: the manufacturer declines all responsibility for direct or
indirect damage caused by incorrect installation, bad
maintenance, tampering, improper use and failure to comply with
the accident prevention norms regarding the prevention of
fire and safety for gas systems.
5.1 CONVERSION FOR USE WITH A DIFFERENT TYPE OF
GAS - FRYER (ADJUSTMENTS)
The appliance is tested and set for working with gas according to the
characteristics table affixed in proximity to the appliance’s gas inlet.
In order for it to function with a different type of gas, proceed as follows:
The conversion must be carried out by qualified personnel
The nozzles for LPG are supplied with the appliance in a nylon
bag
Changing the burner nozzle (Fig. 1):
open the compartment doors (20), change the nozzles (30)
according to the type of gas (see the TECHNICAL DATA table).
Changing the pilot burner nozzle:
remove the panel (20), unscrew the pilot burner nut and change
the nozzle (19) according to the type of gas (see the
TECHNICAL DATA table).
Adjusting the burners, checking supply pressures and working
order:
once the nozzles have been changed, check that the gas
pressure, both in the valve output and input, is as given in the
TECHNICAL DATA table. To do this, remove the screws on the
valve’s (1) pressure tap (11), insert a rubber pipe connected to a
gauge and check pressure. If the inlet supply pressure is
different to that specified, find the cause and correct it.
Adjusting the pilot burner:
this burner needs no adjusting. If you find it does need adjusting,
act on the PILOT screw of the safety valve (1), see fig. 2
Regulating the minimum flame –burner:
The valve has a on/off function so needs no adjusting.
5.2 CHANGING SPARE PARTS
Thermostatic cock (6):
remove the control panel (1), unscrew the entrance (9) and exit
(10) joint connections. Unscrew the small pilot pipe fitting (11)
and the thermocouple (12). Unscrew the screws (13) fixing the
valve to the support. Unscrew the thermostat bulb (31) from the
bowl (14).
Replace the valve and put everything back in place. Check that
the thermostat bulb of the valve (31) in inserted in the special
protection tube.
Safety thermostat (8
drain the oil from the bowl, unscrew the nut (16), extract the
thermostat bulb (8) and change the thermostat. Put everything
back in place. Check that the safety thermostat bulb is inserted
in the protection tube.
Thermocouple (12):
unscrew the thermocouple (12) from the valve (6) and from the
pilot (17) and then change it.
Ignition plug (18):
Unscrew the plug securing nut (19) on the pilot and change the
plug.
Piezoelectric lighter (20)
remove the ignition plug connection cable, unscrew the nut
attaching the piezoelectric lighter to the control panel and
replace it.
Changing the pilot (27):
Unscrew the two burner securing screws on the bowl, unscrew
the nut (28) securing the nozzle holder (29). Change the burner
and then put everything back in place.
N.B.: After any replacement or repair, check that the parts work
properly and adjust them as needed. Check for leaks from the
gas pipe fittings with a soapy water solution –never use a bare
flame.
6. USER INSTRUCTIONS
6.1 LIGHTING THE FRYER BURNERS
Lighting the pilot flame:
Make certain that the thermostatic safety valve knob is in the CLOSED
position ( symbol). Press the push button right down and holding
it pressed, press the piezoelectric lighter push button at the same time.
The pilot flame lights automatically.
Check the flame is lit through the holes (21) on the appliance panel.
Keep the valve push button (24) pressed for 10-15 seconds in order to
heat the thermocouple and then let it go.
Repeat this operation if the burner goes out.
Lighting the burners and adjusting the temperature:
Once the pilot flame is lit, turn the thermostatic safety valve (6) knob
(22) into the position minimum 1 to maximum 8 (the other numbers
represent the intermediate temperatures). The burners light
automatically and once the temperature is reached you set with the
knob, the thermostatic valve turns the burners off, lighting them again
when the temperature drops.
6.2 APPROXIMATE TEMPERATURE OF THE VALVE KNOB
Pos. 1 = 100°C Pos. 2 = 110°C Pos. 3 = 125°C
Pos. 4 = 135°C Pos. 5 = 145°C Pos. 6 = 160°C
Pos. 7 = 170°C Pos. 8 = 180°C
Tolerance ± 10%
6.3 TURNING THE FRYER BURNERS OFF
Turn the knob round to the position. The burners will go out, leaving
only the pilot flame alight.
6.4 TURNING THE FRYER OFF COMPLETELY
Press the push button right down (23) and then let it go. This stops
gas reaching the burners and the pilot burner. This button will stay
down automatically for 1 minute after which it returns to its initial
The appliances must be installed on premises that are suitable for the
discharge of the combustion products and be in compliance with
AS/NZS 5601.1. Our appliances are considered type “A” gas
appliances (see the Technical Data Tables) and are not for connecting
to a natural discharge duct for combustion products.
These appliances must discharge through specific extractors, or similar
devices, connected to a properly working flue or discharged directly
outside.
In the absence of these, it is admissible to have an air aspirator
connected to a safe flue pipe or directly to the outdoors.
If this is not possible, an air suction device can be used connected
directly to the outside, with a capacity that must be no less than that
required, see Table 1, plus the quantity of fresh air that is necessary for
the well-being of the workers.
4.6CHECKING FOR GAS LEAKS
Once installed, check there are no gas leaks on pipe joints using a
soapy water solution. You will know if there are leaks by the foamy
bubbles that form. Never use bare flames to check for leaks.
When the appliance is ready to use, check that there are no gas leaks,
by checking on the gauge, if used (for a period of 30 minutes), that
there is no passage or consumption of gas.
MAINTENANCE
There is very little maintenance thanks to the correct way the
appliances have been made. However, we do advise having the
systems checked by qualified personnel at least twice a year.
4.7TEST APPLIANCE AFTER INSTALLATION
As per user instructions in section 6, test appliance to ensure it is working
correctly.

4
position. Only now can the fryer be turned on again, repeating the steps
from the beginning.
6.5 SAFETY THERMOSTAT
Besides the thermostatic safety valve (1), the appliance also features a
safety thermostat (8) situated inside the control panel and will work if
the thermostatic valve fails to turn the burners out when the oil reaches
maximum temperature.
If the safety thermostat intervene, find the reason immediately and
change the part that is not working if necessary. Press the red push
button on the safety thermostat to light the burners again.
6.6 OIL LOAD
Check that the bowl drainage tap is closed. Fill up with oil or fat until
you reach the minimum (lower) or maximum (higher) notch printed on
the back of the bowl.
6.7 EMPTYING THE BOWL
Once the oil has cooled the user must make sure that there is a specific
tank for collecting the drained water. Mount the drain pipe with
bayonet joint, conforming to the drawing. Operate the lever to drain
the water as shown in the drawing.
7. MAINTENANCE, CLEANING AND CARE
Have it checked by a specialised technician at least twice a year.
Clean the steel parts with water, detergent and a wet cloth. The
detergent used must not contain any corrosive or abrasive substance
as it can damage the steel surfaces.
After washing, rinse with clean water and dry with a dry cloth.
If the appliance is going to be out of use for a long period of time, rub all
steel parts briskly with a cloth soaked in Vaseline oil, leaving a
protective layer. Also aerate the premises periodically.
Any contact with ferrous materials, both continuous and occasional,
must be avoided at all costs as such materials can corrode. This means
that ladles, spatulas, spoons, etc., must be in stainless steel.
For the same reason, avoid cleaning the stainless steel parts with steel
wool, brushes or scrapers made of ordinary steel. Stainless steel wool
can be used, rubbing it in the direction of the grain.
8.0 WARRANTY AND AFTER SALES SERVICE
This appliance is under warranty for one year.
We pay great attention to ensuring that each of our appliances reaches the user in
perfect operating condition.
If you do find a problem when unpacking your appliance, please report it to the shop
within 48 hours.
If the appliance cannot be adjusted to perform correctly or you require any parts,
please contact National Kitchen Equipment on 1300 767 146. No damage due to
incorrect use or failure to comply with the instructions is covered by the guarantee.
Please do not hesitate to let us have your suggestions.
9.0 WARNINGS
Do not store flammable materials in or near the appliance. DO NOT SPRAY
ARESOLS IN THE VICINITY OF THIS APLIANCE WHILE IT IS ON OPERATION.

5
INSTALLATION DIAGRAM

6
10. EXPLODED FUNCTIONAL PARTS TABLES MOD. 60/30 FRG E 60/60
14
32
31
29
Mod. 60/30 FRG
Mod. 60/60 FRG
28
FIG. 1
FIG. 2
30
27
9
4
5
13
6
24
23
22
21
1
26
25
8
20
18
19
3
2
17
12
10
12
11
PIL
MIN
6
