Modulex SX-LF082 User manual

SX-LF082
Weight2.4kg
Thefixtureisforindooruseonlyingeneralconditions.
Cannotbeusedfollowingconditions(Causesoffalling,electrocutionandfire)
●Ambienttemperatureunder0℃andover35℃
●Highhumidity
●Outside
●Onthefloor
●Insulatedinsideofceiling
20cm〜
10cm〜
●Vibratedorshockedareas
●Areasgetdirectsunlight
●Inclined,unevensurface
●
Ceilingwhichcanʼtholdthefixtureweight
●Onthewall
●
Placesaffectedbywindorair-conditionermachine
●Nearfire
●
Dustyareas,corrosivegasoutbreaksareas
Before
installation
Warning
Caution
Pleasecontactifyouarenotabletojudgewhetherinstallation
environmentissuitabletotheplacesornot.
Insulator
InsulatorInsulator
Toinstallthefixturesafely《Readcarefullyandfollowallthe instructionsintheguide》
Warning: Failuretoinstallthefixtureproperlycouldresultinpersonalinjury.
Failuretoinstallthefixtureproperlycouldresultinpropertydamage.
:Prohibited
:Strictobservance
Caution:
Warning
Pleasefollowthefixturesʼindicationorspecificationforthedistanceofirradiatedarea.
(Causesofchangeinshape,changeincolorofirradiatedobjects)
Atlighting
fixture
installation
Caution
Makesuretheconstructionwillnotaffectanyfirepreventionsystemssuchassprinklerbyheatfromthefixture.
(Causesforimproperoperation)
Pleasefollowthefixturesʼinstructionorthisguidetoinstallthefixtureandlamp.(Causesoffalling・electrification・fire)
Makesuretoinstallallthepartsoffixturesbesidesinstallationandmountingpartswillnottouchwithany
objectsbothinsideandoutsideofceilingsuchaslightingtrack,etc.(Causesoffalling・electrification・fire)
Donotdismountorremodelfixtures.(Causeofelectrification・fire・falling・brokenfixtures)
GRIDTRIMLESS
holedimension
formounting
217×332
Conformityceilingthickness 12.5～25mm
Fixture
(soldseparately)
Bracket
Box
Ballast(soldseparately)
Channelbar
(ConstructsSeparately)
Ceilingboard
(ConstructsSeparately)
Frame
InstallationGuideMounting
(85mmfrommountingframe.)
Screwstandard
punchingmetal
Toavoidhittingthepunchingmetal,
pleasecutthechannelbars.
InstallationGuide Mounting

SX-LF082
1
3
4
2
c
1
5
6
7
5
6
7
2
a
b
c
a
b
c
3
4
ToinstallModuleXsafety
Ceilingfinish
Buttermuslinisstuck
Paint
Finishtheseamwithputty
ToCeilingConstructorsPleasepayattention.
Whenconstructing,makesure
theputtyissecurelyfinished
andtherewillbenocrack
Makesuretherewillbenoceiling
paintontheopeningofthebox
Buttermuslin
paint
Box
Finishputty
Undercoatputty
Ceilingboard
Board Board
Board Board
InstallationDetails InstallationDiagram Caution Caution InstallationDiagram
InstallationDetails
Forceilingconstruction,itbecomes
contractor'swork,butbecareful
onthecautionsoftheconstruction
Makesuretohavetheceiling
surfaceandtheopeningto
becomeflush
Ballast
(soldseparately)
Fixture
punchingmetal
Surfacefinish
Mounting
InstallationGuide
InstallationBox
Opentheinstallationholeand
putintheBox.
Applyascrewtothepunchingmetal
ontheceilingandsecurethebox.
Adjustthepositionofthepunching
metalbythethicknessofthe
ceilingboard.
putinthePowersupply.
Installtothefixture.
Screw
LongbowHouse,14-20ChiswellStreet,London,EC1Y4TW,U.K
Tel:[phone]
HavellsSylvaniaEuropeLtd.
（Contact） （Manufacturer）
ModuleXInc.
#21AraiBldg,1-20-6Ebisu-MinamiShibuya-ku,Tokyo
Tel:[phone]
