Modulex SX-LN131 User manual

Conformityceilingthickness 12.5〜25mm
Afterwireconnection
Heightadjustmentispossible
(ConstructsSeparately)
3/8”bolt
Box
wiringhole
Weight9.4kg
SX-LN131
NEODOWNLIGHT
Thefixtureisforindooruseonlyingeneralconditions.
Cannotbeusedfollowingconditions(Causesoffalling,electrocutionandfire)
●Ambienttemperatureunder0℃andover35℃
●Highhumidity
●Outside
●Onthefloor
●Insulatedinsideofceiling
20cm〜
10cm〜
●Vibratedorshockedareas
●Areasgetdirectsunlight
●Inclined,unevensurface
●
Ceilingwhichcanʼtholdthefixtureweight
●Onthewall
●
Placesaffectedbywindorair-conditionermachine
●Nearfire
●
Dustyareas,corrosivegasoutbreaksareas
Before
installation
Warning
Caution
Pleasecontactifyouarenotabletojudgewhetherinstallation
environmentissuitabletotheplacesornot.
Insulator
InsulatorInsulator
Toinstallthefixturesafely《Readcarefullyandfollowallthe instructionsintheguide》
Warning: Failuretoinstallthefixtureproperlycouldresultinpersonalinjury.
Failuretoinstallthefixtureproperlycouldresultinpropertydamage.
:Prohibited
:Strictobservance
Caution:
Warning
Pleasefollowthefixturesʼindicationorspecificationforthedistanceofirradiatedarea.
(Causesofchangeinshape,changeincolorofirradiatedobjects)
Atlighting
fixture
installation
Caution
Makesuretheconstructionwillnotaffectanyfirepreventionsystemssuchassprinklerbyheatfromthefixture.
(Causesforimproperoperation)
Pleasefollowthefixturesʼinstructionorthisguidetoinstallthefixtureandlamp.(Causesoffalling・electrification・fire)
Makesuretoinstallallthepartsoffixturesbesidesinstallationandmountingpartswillnottouchwithany
objectsbothinsideandoutsideofceilingsuchaslightingtrack,etc.(Causesoffalling・electrification・fire)
Donotdismountorremodelfixtures.(Causeofelectrification・fire・falling・brokenfixtures)
FixtureInstallingRail
Fixture(soldseparately)
Ballast(soldseparately)
Covermaintenance
Adjustablebracket
Surfacefinish
Channelbar
ballastshallbeplacedoutside
theboxfromtheaccesshole
Thefixturecordshallbeputoutfromthethrough
holeinthecenteroftheboxandputoutthroughaccesshole.
ballastshallbeplacedoutsidetheboxandclose
themaintenancecover
(ConstructsSeparately)
(ConstructsSeparately)
InstallationGuideMounting
InstallationGuide Mounting

2
1
2
3
4
a
a
ｂ
ｃ
ｂ
ｃ
1
2
3
Finishtheseam paint
5
1
3
3
InstallationDetails InstallationDiagram Caution Caution InstallationDiagram
InstallationDetails
Buttermuslinisstuck
thesideoftheboxtoinstall
Attachmenttoaceiling
Placethechannelandthebar
Slidetheadjustablebracketto
onthebox
Becarefulofthepositionof
theadjustablebracket
thethicknessoftheceilingboard
falloff.
Adjustitaccordingto
asperthedrawing
(BrackethasstickerAindicated)
Incaseitsinstalledincorrectly,
itmayeffecttheconstruction
totheceilingorthefixturemight
9.5mm×2,therewillbe3mmgap
Withboardthicknessof9.5mmand
betweenthebox.
Pleasemakeadjustments
withthematerial.
Slidethebrackettotheprecisearea
andsecurewithanchorbolt.
Slidethefixturetotherailwithin
theboxandinstall.
(PleaserefertotheFixtureInstallGuide)
Connectthewirestothefixture.
(PleaserefertotheFixtureInstallGuide)
Ceilingfinish
Whenconstructing,makesure
theputtyissecurelyfinished
andtherewillbenocrack
Makesuretherewillbenoceiling
paintontheopeningofthebox
Buttermuslinisstuck.
Finishtheseamwithputty.
paint.
2
4
3
5
3
Mbar
Cchannel
55ｍｍ
1
4-φ14
Mbar
19 38
9.5mm
+
9.5mm
12.5mm
9.5mm
9.5mm
+
12.5mm
ToCeilingConstructorsPleasepayattention.
Ceilingboard
Box
withputty
Undercoatputty
Buttermuslin
paint
Surfacefinish putty
OM-
OM-
OM-
OM-
OM-
OM-
Fillinthe3mmgap
withmaterial
Ceilingboard
Adjustable bracket
Anchorboltfixation
areaandtheceiling
surfacetotheflush
surface
NEODOWNLIGHT
Cchannel
ToinstallModuleXsafety
Mounting
InstallationGuide
LongbowHouse,14-20ChiswellStreet,London,EC1Y4TW,U.K
Tel:[phone]
HavellsSylvaniaEuropeLtd.
（Contact） （Manufacturer）
ModuleXInc.
#21AraiBldg,1-20-6Ebisu-MinamiShibuya-ku,Tokyo
Tel:[phone]
SX-LN131
