modway EEI-2267 User manual

Customer Service 609-256-9000︱www.modway.com Page 1 of 2
EEI-2267 / EEI-3917 SOFA
Hardware:
Component:
A Bolt M6x20mm x4
B
C Allen Wrench M4 x1
1 Top Rail x1
Thank you for purchasing the MODWAY LOVESEAT！
Before you start, here is some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the sofa, we recommend that it is assembled by two adults, on a carpeted or
padded area, in the room that it is intended for. Approx assembly time: 30 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or the instruction until you have checked all the components and
hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe
environmentally friendly way.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that has been provided.
6.Please keep all fitting out of reach of children.
2
1
Bolt M6x25mm x6
3
4
2 Left Leg x1 3 Right Leg
4 Seat Frame x1 5 Seat Cushion x2 6 Back Cushion
5
5
6
6
EEI-2267 EEI-3917

Customer Service 609-256-9000︱www.modway.com Page 2 of 2
EEI-2267 / EEI-3917 SOFA
STEP 1:
Remove the plastic covers which pre-install in the end of the Seat Frame (4) by using Allen Wrench (C).
Please put the Left Leg (2) on a carpeted or padded area.
Insert Top Rail (1) and Seat Frame (4) into Left Leg (2) as shown.
Insert 3 pieces of Bolts (B) from the pre-drilled holes on the bottom of the Top Rail (1) and Seat Frame (4) into each side
on the bottom of Left Leg (2).
Insert 2 pieces of Bolts (A) from the pre-drilled holes on the side rail of the Seat Frame (4) into each end of Left Leg (2) as shown.
Do not fully tighten Bolts (A&B) at this step.
Repeat the same steps for Right Leg (3).
After checking the leveling for all connections,
please use Allen Wrench (C) to tighten all Bolts (A&B) clockwise until secure.
Ax4 Bx6 Cx1
STEP 2:
Assembly is completed. The Sofa is ready to enjoy now!
Carefully position the sofa to your desired location.
Put the Seat Cushions (5) and Back Cushions (6) to assembled sofa frame as shown.
1
C
A
2
4 2
B
2
The bottom of seat frame and legs
The bottom of seat frame and legs
The bottom of top rail and legs
3
4
2
1
4
B
C
C
EEI-2267 EEI-3917
please use Allen Wrench (C) to tighten all Bolts (B)
please use Allen Wrench (C) to tighten all Bolts (A)
