modway MOD-6334 User manual

Before you start, here is some helpful advice:
Thank you for purchasing the MODWAY BED !
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the bed, we recommend that it is assembled by two adults, on a carpeted
or padded area, in the room that it is intended for. Approx assembly time: 20 minutes.
4.Please do not throw away any of the packaging or the instruction until you have checked all the components
and hardware and the furniture is fully assembled.
3.Please do not use any tools other than those provided or recommended in these instructions.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten
the components from time to time, so please save the tools that have been provided.
6.Please keep all small pieces out of reach of children.
Customer Service 908-368-1025 ; www.modway.com
Page 1/4
Hardware
A
B
C
D
E
F
G
H
I
J
K
L
x1
x1
x2
x4
x4
x6
x4
x14
x10
x8
x4
x8
JCBC Bolt M6 x 50mm
JCBC Bolt M6 x 40mm
JCBC Bolt M6 x 35mm
JCBC Bolt M6 x 15mm
Side Rail Connect
Allen Key M5
Allen Key M4
Spring Washer
Flat Washer
CBS Screw M4 x 32mm
JCCA Bolt M6 x 50mm
JCBB M8 x 16mm
COMPONENT
L
R
1- Headboard
2- Footboard
3- Side Rail Right
4- Side Rail Left
5- Support Leg
6- Footboard Leg
7- Side Rail Leg
8- Slat(6pcs)
9- Slat Support
10- Headboard Left Leg
11- Headboard Right Leg 3
11
10
1
2
6
6
4
78
5
9
9
58
3
7
MOD-6334

Customer Service 908-368-1025 ; www.modway.com
Page 2/4
Hardware & Tool required
Hardware & Tool required
Ax1 Fx6 Hx6 Ix6
1
10
11
A
I
F
H
STEP 1 :
1- Unzip the cover at the back-facing of the Headboard(1) and unpack the hardware & headboard parts
as shown.
2- Secure the Right Leg (11) & Left Leg (10) using JCBC Bolt 40mm (F), Spring Washer (H),
Flat Washer (I), tighten with Allen Key (A).
Ax1 Kx4
K
A
6
2
STEP 2 :
Attach the Footboard Leg (6) (2pcs) to Footboard (2) use JCCA Bolt 50mm (K) and Allen Key (A) to fix.
MOD-6334

Customer Service 908-368-1025 ; www.modway.com
Page 3/4
Hardware & Tool required
Hardware & Tool required
Ax1 Gx4
STEP 3 :
Attach the Slat (8) to Slat Support (9) and Support Leg (5). Use JCBC Bolt 50mm (G) and Allen Key (A)
to fix.
Ax1 Cx2
STEP 4 :
Attach and tighten the Side Rail Right (3) (2pcs) and Side Rail Left (4) (2pcs) to Side Rail Leg (7) (2pcs).
On the Side Rail use Side Rail Connect (C), Spring Washer (H), JCBC Bolt 15mm (D) and Allen Key (A) to fix.
On the Side Rail Leg use JCBC Bolt 35mm (D), Spring Washer (H), Flat Washer (I) and Allen Key (A) to fix.
5
8
A
G2 x Slats
9
8
5
9
4
4
3
3
A
E
H
IC
D
7
H
Dx4 Ex4 Hx8 Ix4
MOD-6334

Customer Service 908-368-1025 ; www.modway.com
Page 4/4
Hardware & Tool required
Hardware & Tool required
Bx1 Lx8
STEP 5 :
Attach both Side Rail (3&4) to the bracket of Headboard (1) and Footboard (2).
Use JCBB Bolt 16mm (L) and Allen Key (B) to fix.
Jx8
STEP 6 :
Attach and tighten the Slats (8) to Side Rail.
Adjusting the leg adjuster to the floor.
Use CBS Screw 32mm (J) and screwdriver to fix.
1
2
4
4
L
B
3
3
Adjuster
Screw
8
J
8
8
