modway MOD-6192 User manual

A
B
JCBB SCREW M8 x 16MM
M5 ALLEN KEY
C
D
E
JCBC SCREW M6 x 50MM
SPRING WASHER 1/4''
ADJUSTABLE GLIDE C167
Hardware for Headboard
Hardware for Bed Frame and Legs
Component :
1- HEADBOARD
2- HEADBOARD SUPPORT
3- SIDERAIL (L & R)
4- FOOTBOARD
Customer Service 908-368-1025 www.modway.com Page 1/3
x8
x1
x3
x11
x3
Thank you for purchasing the MODWAY BED !
Before you start,here is some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the bed, we recommed that it is assembled by two adults,on a carpeted or
padded area, in the room that it is intended for.Approx assembly time:30 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or the instruction until you have checked all the components
and hardware and the furniture is fully assembled.Please ensure that the packaging is disposed of in a safe
environmentally friendly way.
5.Assemble all components loosely until advised to tighten.Depending on use, it may be necessary to tighten
the components from time to time,so please save the tools that has been provided.
6.Please keep all fitting out of reach of children.
MOD-6192
5- SLAT
6- SLAT WITH HOLE
7- CENTER SLAT
8- CENTER SLAT SUPPORT
1
5
F
G
M4 ALLEN KEY (BALL SHAPE )LONG
PAN HEAD SCREW M4 x 25MM
x1
x28
HJCBC SCREW M6 x 40MM x4
IFLAT WASHER 1/4" x8
2
6
8
7
4
3
JPROTECTION PAD x4

Place
Place
STEP 1 :
STEP 2 :
Hardware & Tool required
Page 2/3
Customer Service 908-368-1025 www.modway.com
4x
B
A
STEP 1.1
Hardware & Tool required
A x 8 B x 1
Place SIDERAIL (L & R)(3) and FOOTBOARD(4) on a carpeted or padded area as shown.Attach FOOTBOARD(4) into
SIDERAIL (L & R)(3)by inserting JCBB SCREW M8 x 16MM(A).Tighten with M5 ALLEN KEY(B).
4x
A
B
STEP 1.2
A x 3 B x 3 B x 3 F
2
F
H
G
5
3
3x
3x
4
Flip the assembled CENTER SLAT(7) over. Place the SLAT WITH HOLE(6) on the CENTER SLAT (7) and place the
CENTER SLAT SUPPORT(8) attach them by inserting JCBC SCREW M6 x 50MM(C),and Spring Washer1
4''.
Tighten with M4 Allen Key(Ball Shape)Long(D).Then, attach ADJUSTABLE GLIDE C167(E) into CENTER SLAT SUPPORT(8).
MOD-6192
2x
2x
J
J
J x 4

Place
Place
Hardware & Tool required
STEP 3 :
Page 3/3
Customer Service 908-368-1025 www.modway.com
G
5
28x
G x 28
Screw the slat(5) by inserting PAN HEAD SCREW M4 x 25MM (G) or padded area as shown. Tighten with SCREW DRIVER.
Assembly is complete,the bed is ready to be enjoyed now!
Remark: Do not sit or lie down on the
platform without the mattress
