Moen Brushed Chrome 4945BC Setup guide

DISCONTINUED SKUS
4944A Lav w/metal waste Antique Brass
4944P Lav w/metal waste Polished Brass
4944W Lav w/metal waste Glacier
4944 Lav w/metal waste Chrome
4949 Lav w/metal waste Chrome/Polished Brass
■ Order by Part Number
There is more than 1 version of this model.
Page down to identify the version you have.
Cartridge Nut
13401
Handle Adapter Kit
90274
Spout Assembly Kit
100649 Chrome
100649BC Brushed Chrome
100667 Chrome (use with 8924)
Replacement Cartridge
1224
Escutcheon
100650 Chrome
100650BC Brushed Chrome
4944pt: Rev. 4/11
Lever Handle Kit
100621 COLD Chrome
100624 HOT Chrome
100621BC COLD Brushed Chrome
100624BC HOT Brushed Chrome
Hardware Package
12715
Valve body kit
100676
Hydrolock™and
supply hose kit
114299
Hardware Kit
113173
Lift Rod Kit
12694 Chrome
12694BC Brushed Chrome
99511 Polished Brass
Flo-Control Aerator (1.5 gpm)
101010 Chrome
101010BC Brushed Chrome
Flo-Control Aerator (2.2 gpm)
3919 Chrome
3919SLP Brushed Chrome
Handle Cap
115034 Chrome
115034BC Brushed Chrome
CHATEAU®
Two-Handle Widespread Lavatory Faucet
MODEL TYPE FINISH
4945 Lav w/metal waste Chrome
4945BC Lav w/metal waste Brushed Chrome
8922 Lav w/metal waste Chrome
8924 Lav w/grid waste Chrome
Replaced by
Illustrated Parts
TO ORDER PARTS CALL: 1-800-BUY-MOEN
www.moen.com
Handle Screw (2)
11845
Cartridge Nut
prior to 1/6/05

Flo-Control Aerator (1.5 gpm)
101010 Chrome
Flo-Control Aerator (2.2 gpm)
3919 Chrome
■ Order by Part Number
Hardware Package
11926
Escutcheon
14349 Chrome
Handle Adapter Kit
90274
Handle Screw
90507 Chrome
Supply Hose Kit
14373
Wing Handle Insert Kit
14904 Chrome
Cartridge Nut
13401
Wing Handle Hub Kit
(Hot & Cold)
90506 Chrome
Spout Assembly Kit
96472 Chrome
(with lift rod hole)
96495 Chrome
(used with 8924, no lift rod hole)
Replacement Cartridge
1224
CHATEAU®
Two-Handle Widespread Lavatory Faucet
MODEL TYPE FINISH
8922 Lav w/metal waste Chrome
8924 Lav w/grid waste Chrome
4944pt: Rev. 11/08
Replaced by
Valve body (includes
cartridge & cartridge nut)
1371 - HOT
1373 - COLD
Illustrated Parts
TO ORDER PARTS CALL: 1-800-BUY-MOEN
www.moen.com
Cartridge Nut
prior to 1/6/05
