HELPFUL TOOLS
For safety and ease of replacement, Moen rec-
ommends the use of these helpful tools.
INS2313B - 01/10
Silica Gel
Safety Glasses
Adjustable Wrench
Impact Drill
Spirit Level
Utility Knife
Flathead Screwdriver
Tape Measure
Marker Pen
Wall Hung Urinal
INSTALLATION INSTRUCTIONS
Record Purchased Model Number:
(Save instruction sheet for future reference)
Image is for reference only
(Style varies by model)
MOEN
400-630-8866
www.moen.cn
PLEASE CONTACT MOEN FIRST
For Installation Help, Missing or Replacement
Parts
(China) 400-630-8866
www.moen.cn

Please read this installation carefully before installation to
prepare and familiarize yourself with the required installation
tools, materials, installation steps and precautions, avoid
unnecessary losses due to improper installation.
Confirm that the bathroom wall and floor tiles have been
completed, and the sewage pipe and water supply pipe have been
reserved. If you are replacing the old urinal with a new one,
please pay attention to the status of the existing sewage pipe and
water supply pipe. If necessary, replace them in time.
Before replacing the urinal with a new one, turn off the water
supply first.
Reserve the positions of the sewage pipe and water supply
pipe, please refer to the corresponding product size, and confirm
that the pre-installed sewage pipe and water supply pipe size
meet the installation requirements.
For your personal and property safety, before using the
percussion drill to make holes, please make sure that there is
no pipeline or cable buried in the wall that’s need to be punched.
Please use it in an environment above 0℃. In an environment
below 0°℃, the product cannot store water i n t h e d r a i n t r a p ,
the expansion of water freezing may damage the product.
Please do not pour paper towels or cigarette butts into the
urinal.
Please do not use hard materials (like scouring pad) to clean
product surface, especially the product logo.
If the water in the place where you live is hard, keep the flush
hole clean to ensure that the toilet flushes normally. Use toilet
cleaner to clean at least once a week. Use a brush with a long
handle to clean the flushing hole, and extend it into the drain
pipe as much as possible to prevent mineral accumulation.
Wall drainage installation steps:
Ground drainage installation steps:
2
Checklist before Installation
Installation steps
CC
1A-2A-3-4-5-6-7A
1B-2B-3-4-5-7B
注：本说明书标注的产品示意图仅供参考，请以实物为准。 Note: The product schematics marked in this manual are for
reference only, please refer to the actual product.

Confirm that the location andspecifications of the walldrain hole
meet the urinal installation requirements.
Note: The outer diameter of the sewage pipe is50mm;It is
recommended that the pipe protrude from the wall by about
10mm, and you can adjust the it according to the actual situation.
Confirm that the locationandspecifications of the ground drain
hole meet the urinal installation requirements.
3
1A
2A
1B
2B
Schematic diagram of the installation height of wall-mounted
urinal.
The installation of sewage pipes should comply withthe national
buildingwater supply and drainage design standards, otherwise it
may affect the use of the product.
Schematic diagram of the installation height offloor drain urinal.
The installationofsewage pipes should comply withthe national
building water supply and drainage design standards, otherwise it
may affect the use of the product.
Schematic diagram of floor drainurinal
Hook up Hookup
Finished wall
Placeholder
Reserved height of sewage pipe
Schematic diagram of wall-mounted urinal
Sewage pipe
具体尺寸请以实物为准
The actual size depends
on the specific product

5
4
6
4
Pre-install the urinal in the position where it needs to be installed,
correct the horizontal position with a spirit level, and then markit
witha marker.
Installthe hanging block on the wall, and tap the expansion bolts
into the holes at both ends of the drain hole.
Warning: Before drilling, make sure that there is no pipeline or
cable buriedinthe wall that needs to be punched.
Tear off the protective paper of the wax ring, and then stick the
wax ringonthe drain port of the urinal. Align the wax ring withthe
drainpipe and press it toward the pipe to ensure a good seal.
Remove the urinal, calculate the installation position of the hook up
according to the positionwhere the expansion bolt is installed.
After marking witha marker, drill the hole and then insert it into
the expansion tube andclamp it tightly.
Warning: Before drilling, make sure that there is no pipeline or
cable buriedin the wall that needs to be punched.
This step is only applicable to walldrainage products,
please refer to step 7B for floor drainage products.
3
Schematic diagram of upper water inlet installation
Schematic diagram of rear water inlet installation
The size of the flush valve shownon the left is for
reference only, and theactual size depends on
the specific product.
The size of the flush valve shown on theleft is for
reference only, and the actual size depends on
the specific product.
Water inlet
Induction host
Drainage hole
Side view
Side view
Markerpen
Wall depth90mm
Hook up
Drainage hole
Hook up
Induction valve outlet
connection
Copper
takeover
Hose
具体尺寸请以实物为准
The actual size depends
on the specific product
具体尺寸请以实物为准
The actual size depends
on the specific product
单位：mm
Unit: mm
单位：mm
Unit: mm
130
130

7A 7B
Apply silica gel to the place where the wax ring is connected to the
drain port of the urinal, and then install theurinal on the scraper.
Apply mildew-proof silicone to the edge where urinal touches the
wall.
Install the S-bend drain pipe first. Apply silica gel to the place
where thewax ringis connected to the drain port of the urinal, and
then install the urinalonthe scraper. Apply mildew-proof silicone
to the edge where urinal touches the wall.
5
(Need to be purchased
separately)
S-bend drainpipe

©2022 Moen Incorporated
摩恩产品是在高质量标准及生产工艺下制造的，摩恩承诺
为消费者购买的洁具产品提供有期限免费保修及终身维修
服务。
材质为陶瓷的部件免费保修期为5年，非陶瓷材质部件，
如水箱内的水件、冲洗阀、坐便器盖板等免费保修期为3
年。均自消费者购买日（以摩恩产品分销商开具的发票或
收据上载明日期为准）起计。
免费保修范围为产品及产品配件（落水以及溢水等）由于
材质及工艺原因而造成的故障或损坏。免费保修期内，我
们将无偿为您提供修理服务及更换发生故障的产品或产品
配件。摩恩的售后服务责任仅限于对故障产品的修理，而
不延及您因产品故障而发生的其他损失，法律另有规定的
除外。
您需了解：产品外观碰伤、刻划痕迹，以及滥用及不正当
保养所导致的故障或损坏，均不属于免费保修范围。即使
在免费保修期内，属下列（1）-（5）情况之一的，需酌
情收取修理费用：
1. 不能出示相符的保修卡和有效购买凭证情况的，
2. 未按使用说明书告知的使用方法和注意事项造成的故
障，
3. 自行拆卸、维修、改装所造成的故障和损坏，
4. 由于不可抗力等外部原因引起的故障和损坏，
5. 由于运输、搬卸、挤压等造成的损坏。
对于保修期外或不在保修范围内的产品，如需维修，摩恩
将酌情收取上门费、人工费及材料费。
本保修条款仅对原始消费者和酒店行业的购买者有效，并
不适用于本产品在工业，商业，贸易和非酒店行业的使
用。
如对本保修条款内容有任何疑问，请拨打400 630 8866
咨询热线，或向当地分销商咨询。
产品售后保修条款 MOEN LIMITED WARRANTYMOEN LIMITED WARRANTY
We offer limited warranty and lifetime maintenance
for Moen products, which are all manufactured with
high standards of workmanship.
The period of warranty shall start from the date of
purchase of the product (according to the invoice or
receipt issued by Moen distributors) and shall cover
a period of the following: the warranty period for
ceramic parts is 5 years, non-ceramic parts, such as
water fittings, flush valve, toilet seat, etc. is 3 years.
This warranty is your coverage against material
and workmanship malfunction or defects in Moen
products or components (Pipe kit etc.). During the
warranty period, we offer free maintenance and
changing of malfunctioned products or product
components. Moen’s after sales service liability is
limited to the maintenance of faulty items and does
not cover your other losses caused by product
malfunction, except for otherwise stipulated by law.
Cosmetic damages (scratches, dents, etc.) and
malfunction or defects caused by abuse or improper
maintenance is not covered by this warranty.
Although the warranty period remains valid, in case
of the following conditions (1) - (5), the maintenance
cost (material cost and labor cost) shall still be
charged as the case may be:
1. Corresponding warranty card and valid invoice
cannot be presented;
2. Faults were caused by the incompliance with
the instructions and precautions provided in the
user’s manual;
3. Damages and faults were caused by self-actuated
dismantling, repair and refit;
4. Faults and damages were caused by external
factors such as force majeure;
5. Damages were caused by transportation,
unloading and extrusion, etc.
This warranty is valid for the original consumers
only (including hotel use), and excludes industrial
and commercial use of the product (except for hotel
use). This card is only responsible for product
maintenance rather than any other liabilities.
In the event that the product requires maintenance
but exceeds the warranty period, or that the product
is not covered by this warranty, labor cost and
material cost shall be charged as the case may be.
Please call 400-630-8866 or contact local dealer for
any question.
壁挂式小便器
Wall Hung Urinal
合格证
产品名称
检验员
生产日期
摩恩（上海）厨卫有限公司
MOEN (SHANG HAI)KITCHEN&BATH PRODUCTS CO.,LTD
No. 399 Fute North RD, China (Shanghai) Pilot Free Trade Zone,
Shanghai 200131 P.R. China
中国（上海）自由贸易试验区富特北路399号
邮编：200131
Compliance Certification
Inspector
Product Name
Date of Production
